MAINTENANCE

Maintenance

6:2

Changing the needle plate

Switch off the main switch

Removal

• Raise the presser foot. Position the needle plate changer (light bulb

changer) as shown and press the needle plate up on the right, then

on the left. It can now be easily removed.

Replacing

• Place the needle plate against the rear edge of the cut-out then press

down at the front until you hear it snap in place. Before you start

sewing, check that the needle plate is lying ﬂat.

Note: Lower the feed dogs to make removing the needle plate easier.

Cleaning

Switch off the main switch

• Remove the needle plate and lower the feed dogs. Clean the feed

dogs and hook area with the brush.

• Clean the sewing machine after every 10 - 15 hours of operation.

Cleaning the window

Wipe the window with a soft, lint-free dry cloth. DO NOT use abrasive

cleansers or solvents!

Maintenance

6:3

Changing the light bulb

Switch off the main switch

• Disconnect the lead cord and the foot control plug from the

machine.

• Remove the accessory tray. The light bulb is located inside the

sewing machine near the needle threader.

Bulb removal

Push the light bulb changer up as far as it will go. Now turn the bulb

half a rotation counter clock-wise and remove the bulb.

Insertion of the bulb

Important: Use a light bulb as indicated on the left side of the machine,

12 V max 5 W.

Insert the bulb in the light bulb changer. Guide the bulb into the

diagonal holder and turn it until the pins of the bulb engage. Push

the bulb upward into the holder as far as it will go and turn it half a

rotation in a clock-wise direction. Remove the light bulb changer from

the bulb. The bulb will be held ﬁrmly so you can remove it safely.

Bulbs can be purchased from your Pfaff dealer.

Maintenance

6:4

What to do if...?

In this chapter you are suggested solutions if you have a problem with your creative 2170. For further information please

contact your Pfaff dealer who will be pleased to help you.

Sewing

Problem/Cause Remedy

The machine skips stitches

Did you insert the needle properly? Push the needle fully upwards with its ﬂat side facing the

back.

Did you insert a wrong needle? Use needle system 130/705 H.

Is the needle bent or blunt? Insert a new needle.

Did you thread the machine properly? Check how the machine is threaded.

Is the needle too small for the thread? Change the needle.

Needle thread breaks

Did you insert the needle properly? Push the needle fully upwards with its ﬂat side facing the

back.

Did you insert a wrong needle ? Use needle system 130/705 H.

Is the needle bent or blunt? Insert a new needle.

Did you thread the machine properly? Check how the machine is threaded.

Is the needle too small for the thread? Change the needle.

Are you using poor thread with slubs or thread which has

become dry after overlong storage? Change the thread.

Bobbin thread breaks

Did you insert the bobbin properly? Check the bobbin thread.

The seam is sewn unevenly

Is the thread tension misadjusted? Check needle thread tension.

Are you using too thick or slubbed thread? Change the thread.

Is the bobbin thread evenly wound? Check bobbin winding.

The machine does not feed or feeds irregularly

Did you thread the machine properly? Check how the machine is threaded.

Has sewing lint collected between the feed dog teeth rows? Remove the needle plate and clean the feed dog with a brush.

The machine binds

Is the feed dog lowered? Engage the feed dog.

Incorrect or no display

Are there thread remnants in the hook ways? Remove the thread remnants.

Is the contrast control for the display

misadjusted? Set the contrast for the display.

Maintenance

6:5

Embroidery

Problem/Cause Remedy

The embroidery design is distorted

Did you hoop the fabric strongly enough? The fabric must be tightly hooped, in such a way that no

creases form.

Is the inner embroidery hoop completely attached to the

outer embroidery hoop? Hoop the fabric in such a way that the inner hoop always

exactly matches the outer hoop.

The embroidery design has contracted

Did you stabilize your fabric sufﬁciently? Place a sheet of Adhesive backed paper/stabilizer and/or

Water-soluble stabilizer onto the fabric.

Needle thread breaks

Did you use the right needle? Insert a needle with a larger eye

(System 130N).

Is the needle bent or blunt? Insert a new needle.

Is the thread too thick for the needle? Use the right needle size.

Did you insert the needle properly? Push the needle fully upwards with its ﬂat side facing the

back.

Did you thread the machine properly? Check how the machine is threaded.

Are you using poor thread with slubs or thread which has

become dry after overlong storage? Change the thread.

Non-original Parts and Accessories

The warranty does not cover any defect or damage caused by use of non-original accessories or

parts.

Index

6:6

Index

Accessories

embroidery accessories 5:10

standard accessories 1:16

Accessory tray 2:4

Alphabets 1:13, 4:26–4:27, 5:27–5:30

Animal stitches 1:12

Antique Embroidery stitches 1:12

Antique hand embroidery stitches 4:23

Appliqué embroidery 5:47

Arcing 5:6, 5:31–5:32

Automatic stitch building 5:5, 5:33

Balance 3:6

Basting in the embroidery hoop 5:4, 5:17

Basting program 3:14

Blindhem stitch 3:22

elastic blind stitch 3:22

Bobbin and bobbin case

inserting 2:12

Bobbin thread 2:15

Bobbin thread monitor 2:12, 3:2

Bobbin winding

from the second spool pin 2:9

from the spool pin 2:8

from the third spool pin 2:9

setting the speed 2:11

through the needle 2:10

while embroidering 2:10

Bridging stitch 3:23

Built in designs 5:49–5:70

Buttonhole 3:15–3:18

attaching the foot 3:15

automatic buttonhole 3:16

Eyelet buttonhole with gimp thread 3:17–3:18

how to balance a buttonhole 3:16

how to sew 3:16

manual buttonhole 3:16

programmed buttonhole 3:16

sensormatic buttonhole guide 3:15

tips 3:18

with gimp thread 3:17

Buttons

sewing on buttons 3:19

Carrying case 2:4

Cleaning 6:2

Color changing 5:7, 5:18

Context menu 3:8–3:9

in embroidery 5:8

Contrast of the screen 2:3

Correct top tension 2:13

Creative Assistant 2:17, 3:10

creative Data Manager 2:18–2:19, 5:36–5:40

creative memory card

prepare for saving 5:41

Crosshem stitch 3:23

Cross Stitch 4:23

Cross stitches 1:11

Current state 5:8

Cutwork embroidery 5:47

Darning 3:20

automatic darning 3:20

Index

6:7

balancing the darning stitch 3:20

programmable Darning 3:20

with the elastic stitch 3:20

Data Manager 5:2, 5:9, 5:36–5:40

Decorative sewing 4:1–4:28

general notes 4:2

Decorative stitches 1:11, 1:12, 1:13

altering a decorative stitch 3:12

selecting 4:2

Delete 5:6

Demo 3:28

playing 3:28

programming 3:28

Designs

built in designs 5:49–5:70

transferring designs 5:41

Electrical connection 2:2

Electronic knee lift 2:16

Embroider 5:21

Embroidering several colors 5:26

Embroidery 5:1–5:70

accessories 5:10

Appliqué embroidery 5:47

attaching the embroidery foot 5:10

attach the hoop 5:13

basting in the hoop 5:17

cutwork embroidery 5:47

embroidery combinations 5:31

embroider single designs from a card 5:16

get started to embroider 5:14

hoop 5:13

inserting a card 5:10

move the design within the hoop 5:20

multi-color embroidery 5:19

one color embroidery 5:20

positioning of designs in the hoop 5:22–5:23

remove the hoop 5:13

selecting a design 5:16–5:17

speed 5:9

window 5:2

Embroidery template

how to use 5:42–5:43

Embroidery unit

connecting 5:12

remove 5:13

Embroider monograms and letters 5:27–5:30

End to end Mirroring 3:3

Enlarged representation 5:6, 5:22

Esc 3:10

Eyelets 3:19

Feed dogs 2:7

lowering 5:11

File formats 5:40

Foot control, connecting 2:2

Four directions sewing 3:3, 3:25–3:26

Free-Motion Sewing 3:6, 4:24

Free-Motion Stippling 4:19

Free arm 2:4

Function Buttons 3:2

Gathering with straight stitch 4:25

General notes 2:17

Grid on 5:8

Index

6:8

Hemstitching 4:22

Hem stitches 1:11

Hoop 5:13

attach the hoop 5:13

remove the hoop 5:13

selection 5:7

Hooping the fabric 5:15

Hoop adapter 5:40

IDT (Integrated Dual Feed)

disengaging 2:6, 5:11

engaging 2:6

Immediate tie-off 3:4

Information 3:7, 5:9

Introduction 1:7–1:18

Jumping over stitches 5:26

Knee lift 2:16

removing 5:11

Last stitch 3:7

Leaves and Flowers 1:12

Lid 2:4

Light bulb

changing 6:3

Machine Assistant 2:17

Machine overview 1:14

Maintenance 6:1–6:5

Main Menu 3:7

Main switch 2:3

MAXI stitches 1:13, 4:24

Messages

options for messages 3:28

options for messanges 5:8

Mini Main menu 5:3

Mirroring 3:13

Mirror end to end 5:6

Mirror side to side 5:7

Monogram 4:28, 5:70

Monograms and letters

embroider monograms and letters 5:27–5:30

More options 5:6

Move Hoop 5:8

Move icon 5:5

Move the design within the hoop 5:20

Multi-color embroidery 5:19

Needle

changing 2:7

threading 2:14

Needles 5:45

Needle plate

changing 6:2

Needle positions 3:13

Needle threader 2:14

Needle Up/Down Button 3:2

Nostalgia /Heirloom 4:22

Index

6:9

OK 3:10

One color embroidery 5:20

Operating Instructions 2:2

Overlock stitches 3:21

closed overlock stitch 3:21

closed with edge thread 3:21

open overlock stitch 3:21

Parts of the creative 2170 1:14

Parts of the embroidery hoop 1:15

Parts of the embroidery unit 1:15

Patchwork 4:16

Patchwork program 3:6, 4:16

create a new 4:17

Pattern start 3:2

Personal menu 3:27

Piecing the quilt top 4:18

Pintucks

twin needle Pintucks 4:23

Precise Positioning a design 5:6, 5:23–5:25

Preparations 2:1–2:24

Presser foot

changing 2:5

snap off 2:5

snap on 2:5

Presser foot lift 2:16

Quilting 4:16

Quilt Appliqués 4:19

Quilt stitches 1:11

Reverse Sewing Button 3:2

Rolled hem 3:24

Satin stitches 1:11

Save parameter 3:12

Scalloped edgings 1:11

Select a stitch 3:11

Select stitches 5:4

Sensormatic buttonhole guide 3:15

Sewing 3:1–3:28

Sewing mode functions 3:3–3:6

Sewing sequence 4:4–4:10

adjust an existing sewing sequence 4:7

arrange stitches 4:6

close without saving 4:9

create 4:5

delete 4:9

inserting a stitch 4:7

inserting a stitch at the start 4:7

open from creative memory card 4:10

open from memory 4:10

save 4:8

select and open saved 4:9

Sew Slow Button 3:2

Shell edging 4:25

Side to side mirroring 3:3

Single Stitch 3:4

Speed

embroidery speed 5:9

Stabilizers 5:44–5:45

Stitch-in-the-Ditch 4:18

Index

6:10

Stitch building

automatic 5:5, 5:33–5:34

Stitch Chart 1:8

Stitch Creator 4:11–4:15

Stitch information 5:4

Stitch length 3:11

Stitch settings

alter the stitch settings 4:3

Stitch width 3:11

Straight stitch 3:14

Table of Content 1:4–1:6

Tapering 3:5, 4:20–4:21

asymmetric taper 4:21

symmetric taper 4:20

Technical Data 6:11

Threading

needle 2:14

twin needle 2:15

Threads 5:46

Thread cutter 2:3

Thread snips 5:9

Thread Snips Button 3:2

Thread tension 2:13, 3:11

Three-step Zigzag stitch 3:14

Tie-off 3:12

Tie-off program 3:5, 3:12

Toolbar 3:7

Twin needle 3:6, 3:24

sewing 3:24

sewing Maxi stitches 3:24

Twin needle, threading 2:15

Twin needle Pintucks 4:23

Undo pattern re-sort 5:7

Update your machine 2:20–2:23

Utility stitch

altering a utility stitch 3:11

Utility stitches 1:8-1:11

Welcome Screen 3:7

Wing Needle 4:22

Word sequence

editing 4:27

saving 4:27

Zippers

sewing in zippers 3:23

Zoom

move the zoomed area 5:35

zoom in 5:4, 5:35

zoom out 5:4

Otros manuales para creative 2170

Tabla de contenidos

Otros manuales de Máquina de coser de Pfaff

Pfaff

Pfaff 1053 Manual de usuario

Pfaff

Pfaff 939 Manual de usuario

Pfaff

Pfaff 130-6 Manual de usuario

Pfaff

Pfaff performance 2056 Manual de usuario

Pfaff

Pfaff CREATIVE VISION - V13598 UPDATE CREATIVE VSION SEWING AND EMBROIDERY... Manual técnico

Pfaff

Pfaff 937 Manual de usuario

Pfaff

Pfaff 1216 Manual de usuario

Pfaff

Pfaff 3822-1/22 Manual de usuario

Pfaff

Pfaff 418 Series Manual de usuario

Pfaff

Pfaff hobby 1142 Manual de usuario

Pfaff

Pfaff GrandQuilter Manual de usuario

Pfaff

Pfaff creative 4874 Manual de usuario

Pfaff

Pfaff 294 Manual de usuario

Pfaff

Pfaff 910 Series Manual de usuario

Pfaff

Pfaff select 1540 Manual de usuario

Pfaff

Pfaff creative 1371 Manual de usuario

Pfaff

Pfaff 1571 Manual de usuario

Pfaff

Pfaff 471 Manual de usuario

Pfaff

Pfaff Espression line Manual de usuario

Pfaff

Pfaff Sewing Machine Manual de usuario

Pfaff

Pfaff 3574-2/02 Manual de usuario

Pfaff

Pfaff 918 Manual de usuario

Pfaff

Pfaff Tipmatic 1014 Manual de usuario

Pfaff

Pfaff hobbylock 2.0 Manual de usuario

Manuales populares de Máquina de coser de otras marcas

Riccar

Riccar RL634DE Manual de usuario

Singer

Singer 2517 Manual de usuario

Janome

Janome Quilt Maker Pro 18 VERSA Manual de usuario

Siruba

Siruba C007JP Manual de usuario

Husqvarna Viking

Husqvarna Viking Designer SE Manual de usuario

Singer

Singer 148-5 Manual de usuario

IKEA

IKEA SY Manual de usuario

Singer

Singer 15-91 Manual de usuario

Brother

Brother BB370 Manual de usuario

Pegasus

Pegasus WT100 Series Manual de usuario

Reliable

Reliable 7100DB Manual de usuario

Singer

Singer 6038 Manual de usuario

Singer

Singer 413K Manual de usuario

Kenmore

Kenmore 16677 - Serger Sewing Machine Manual de usuario

HIGHLEAD

HIGHLEAD GC2008-M Manual de usuario

Singer

Singer 400W4 Manual de usuario

Singer

Singer Quantum XL-100 Manual de usuario

Singer

Singer 85-10 Manual de usuario

Pfaff creative 2170 Guía

Manuales populares de Máquina de coser de otras marcas
