INSTRUCTION MANUAL

AT3 GENERATION 2

All-Terrain Stroller

PG8350

To see our full line of products, visit us online at: www.petgearinc.com

CUSTOMER SERVICE HELP DESK

[email protected]

Toll-Free 877-752-9123 - Eastern Standard Time 8am-3pm, Monday through Friday

For The ON-THE-GO Pet™

For Pets

Only

Interior Dimensions:

30.5L x 14W x 24H

• Do not carry additional bags, goods, or accessories in or on stroller except as recommended

in the manufacturer’s instructions.

• Recommended use of an approved safety restraint correctly fitted and adjusted.

• Do not leave pet unsupervised in stroller.

• Before making adjustments to stroller ensure that pet’s body is clear of any moving parts.

• This stroller is designed for one pet only.

• Do not hang bags from handles as this may cause the product to become unstable.

• Do not use on escalator or stairs; fold stroller and carry.

• Put on brake whenever you park the stroller.

• Ensure stroller is completely erected and check that all locks are engaged before placing

pet in stroller.

• Do not overload as stroller may become unstable; maximum weight of pet using this stroller

not to exceed 60 lbs.

• Any goods carried in the basket not to exceed 6 lbs.

WARNING!

FOR PETS ONLY.

Not intended to be used as a restraining device for aggressive or dangerous animals that dig,

chew or paw aggressively. Do not leave your pet unattended. PET GEAR is not liable for any damage

caused by aggressive, destructive, immature or untrained animals.

Do not use near an open or exposed

flame. Failure to follow these warnings and the instructions could result in serious injury or death.

PARTS LIST

(1) Front Wheel

AT3 GENERATION 2 All-Terrain Pet Stroller PG8350

(1) Axle

Check that you have all the parts shown BEFORE assembling your product.

If any parts are missing, call Customer Service. No tools required.

Stroller

(2) Rear Wheels

AT3 GENERATION 2 All-Terrain Pet Stroller PG8350

INSTRUCTIONS FOR USE

Step Here

Back View of Stroller

Spread the canopy apart to the open position.

Ensure the canopy is closed before

folding the stroller.

Apply brake lever (A) by pushing down with toe.

Ensure brakes are applied when parking stroller.

Release by lifting brake lever with toe.

WARNING: Never leave your stroller parked without

applying brakes.

Canopy

UNFOLDING THE STROLLER

Step 1. Release folding lock (B).

Step 2. Spread handle (C) and seat apart until

the frame clicks and locks on both sides.

Step 3. Ensure that the stroller is locked in on

both sides before using.

ASSEMBLY INSTRUCTIONS

4AT3 GENERATION 2 All-Terrain Pet Stroller PG8350

Step 1. Push back wheels on to axle, as

shown in Figure A, until they clock into place.

To remove wheel, push the lock/release button

(Figure C) and pull wheel off.

Step 2. Pull on wheel to make sure the wheel

is engaged. Repeat on other side. When

finished it should look like Figure B.

Figure C

Lock/Release Button

Back

Wheels

Inside Outside

Shown with both back wheels in place.

Figure A

FOLDING STROLLER

Folding

Mechanism

Before folding the stroller close the canopy and unzip

stroller. Slide second frame lock release (H) to the right,

while squeezing the main frame lock release (G) rotate

the folding mechanism almost 180 degrees forward

untill stroller releases and handle is lowered to the rear

wheels. When closed, push folding lock (B) onto catch.

Step 1. Before folding the stroller, close the canopy

and unzip stroller.

Step 2. Slide second frame lock release (H) to the

right, while squeezing the main frame lock release

(G) rotate the folding mechanism almost 180

degrees forward until stroller releases and handle is

lowered to the rear wheels.

Step 3. When closed, push folding lock (B) onto

catch.

Figure B

AT3 GENERATION 2 All-Terrain Pet Stroller PG8350

Step 4. Slide wheel up, until velco pins pop

out of holes.

Velco Pin

Tubing Tubing

Step 3. To attach front wheel, slide plastic wheel

support up and into tubing.

Step 5. To use stroller in locked position for

jogging, push pin in.

Step 6. To use stroller in swivel position, pull pin

down, and to the right.

ASSEMBLY INSTRUCTIONS

Swivel

Position

Locked Position

6AT3 GENERATION 2 All-Terrain Pet Stroller PG8350

For Pets

Up To

60 lbs

•Always store product in a clean, dry place.

• Not recommended for use on the beach.

• Do not put heavy items on top of the stroller.

•Clean frame by wiping with a lightly oiled cloth.

• Do not use detergent or abrasives. Spot clean fabric with dry cleaning fluid or mild soap and warm water.

•To ensure easy maneuverability and to minimize wear and tear, (especially wheels, axles, and swivels),

keep all moving parts clean and lubricated with WD40® or light machine oil.

• NOTE: Do not lubricate brake components or swivel locks.

• Regularly check stroller for loose parts. These should be tightened or replaced.

LOOKING AFTER YOUR STROLLER

•To clean and lubricate front and rear wheels, push out locking lever under wheel housing

to release rear wheel.

•To ensure ease of maneuverability and to minimize wear and tear, keep all moving parts

clean and lubricated with WD40® or light machine oil.

•Push wheel sets back on until they click and lock in position; pull on wheel housings to

ensure they are secure.

•Push stroller back and forth and rotate swivels around to work in lubricant.

•Clean the rear wheel assembly and the rest of the frame with warm, soapy water; clean

off with warm water and dry thoroughly.

•NOTE: Do not lubricate brake components or swivel locks.

WHEEL MAINTENANCE

PO Box 99

West Rutland, VT 05777

877-752-9123

www.petgearinc.com

REPLACEMENT PARTS

Please have your model number ready before calling. Use only PET GEAR replacement parts.
