pellenc POWER PACK M Manual de usuario
PELLENC POWER TOOL BATTERY
POWER PACK M, L
Operating instructions 56_159267-A
03/2022
ENG
Translation of the original op-
erating instructions manual
READ THE USER GUIDE CAREFULLY BEFORE USE
.
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
TABLE OF CONTENTS
1. INTRODUCTION ..................................................................................................................... 5
2. SAFETY ................................................................................................................................... 6
2.1. SAFETY MEASURES ASSOCIATED WITH THE USE OF THE TOOL ......................................... 6
2.2. SAFETY MEASURES ASSOCIATED WITH BATTERY USE ......................................................... 6
2.3. SAFETY MEASURES WHEN USING THE "PELLENC" CHARGER ............................................. 7
2.4. SAFETY SIGNAGE .......................................................................................................................... 8
3. DESCRIPTION AND TECHNICAL CHARACTERISTICS ...................................................... 9
3.1. TECHNICAL CHARACTERISTICS - BATTERY ............................................................................. 9
3.2. TECHNICAL FEATURES - CHARGER CB5022HV ........................................................................ 9
3.3. DESCRIPTION .................................................................................................................................. 9
4. COMMISSIONING ................................................................................................................. 10
4.1. SWITCHING THE BATTERY ON AND OFF ................................................................................. 10
4.2. BATTERY DISPLAY ...................................................................................................................... 10
4.3. CHARGING THE BATTERY .......................................................................................................... 10
4.4. FITTING THE BATTERY ON THE HARNESS AND CONNECTING THE TOOL ......................... 12
5. MAINTENANCE .................................................................................................................... 16
5.1. MISCELLANEOUS MAINTENANCE BATTERY ........................................................................... 16
5.2. MISCELLANEOUS MAINTENANCE CHARGER .......................................................................... 16
6. INCIDENTS AND TROUBLESHOOTING ............................................................................. 16
6.1. SUMMARY OF CHARGE INDICATOR AND BEEP MESSAGES ................................................ 16
6.2. TROUBLESHOOTING .................................................................................................................... 18
7. STORAGE AND TRANSPORT ............................................................................................ 20
7.1. BATTERY STORAGE CONDITIONS ............................................................................................ 20
8. ACCESSORIES AND CONSUMABLES .............................................................................. 20
8.1. ACCESSORIES INCLUDED .......................................................................................................... 20
9. WARRANTIES ...................................................................................................................... 20
9.1. GENERAL WARRANTIES ............................................................................................................. 20
9.1.1. STATUTORY WARRANTY ............................................................................................................... 20
9.1.2. COMMERCIAL WARRANTYPELLENC .............................................................................................. 21
9.1.3. PAID AFTER-SALES SERVICE ........................................................................................................ 22
10. COMPLIANCE STATEMENTS ........................................................................................... 23
10.1. "EU" DECLARATION OF CONFORMITY: POWER PACK M & L ............................................. 23
3
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
4
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
1. INTRODUCTION
Dear Customer,
Thank you for purchasing your PELLENC Power Tool battery Power Pack M, L. Properly used and maintained, this
equipment will give you years of satisfaction.
Warning
Your machine contains numerous recoverable or recyclable materials. Return it to
your dealer or, failing this, to an approved servicing centre to be treated.
Comply with the regulations in force in your country as concerns environmental protection associated with your
activity.
Warning
It is imperative that you read through the ENTIRE user’s manual guide before using or servicing
the tool. Always comply with the instructions and illustrations provided in the user’s manual.
Throughout the user’s manual guide you will find advisory notes and information entitled: NOTE, IMPORTANT,
ATTENTION and WARNING.
Points marked “NOTE” indicate additional information.
Points marked "IMPORTANT" warn the user of a potential risk for the equipment.
Points marked “ATTENTION” warn the user of a potentially hazardous situations which if not avoided may result
in minor injuries.
Points marked “WARNING” warn the user of a potentially hazardous situation which if not avoided may result in
serious injury or death.
The warning indicates that damage resulting from failure to comply with the procedures and instructions is not
covered by the warranty and the owner will be liable for any repair costs.
Safety indications are also given on the tool; they remind you of the safety precautions to be taken. Identify and
read these indications before using the tool. Immediately replace any indications that may become partially illegible
or deteriorated.
Refer to Section 2.4, “Safety signage” for the location diagram of the safety stickers affixed to the tool.
No part of this manual may be reproduced without the written permission of the company PELLENC. The illustrations
provided in this manual are for information purposes only and are in no way contractual. The PELLENC company
reserves the right to make any modification or improvement to its products as deemed necessary without inform-
ing customers already in possession of a similar model. This manual forms an integral part of the tool and must
accompany the tool if it changes hands.
5
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
2. SAFETY
Warning
Never carry out maintenance work on damaged battery packs. Service of battery packs should
only be performed by the manufacturer or authorized service providers.
2.1. SAFETY MEASURES ASSOCIATED WITH THE USE OF THE TOOL
Note
Please refer to the instructions of the tool concerned.
Warning
Read all safety warnings and all instructions. Retain all the safety measures and instructions for
later reference.
This device is not intended for use by individuals (including children) with reduced physical, sensory or mental
capabilities, nor by anyone lacking in experience or knowledge, except if they are supervised or have received prior
instructions from a person responsible for their safety.
2.2. SAFETY MEASURES ASSOCIATED WITH BATTERY USE
1. If not using the battery unit, store it away from other metal objects such as paper clips, coins, keys, nails, screws
or other such small metal items that might form a connection between the two terminals. Creating a short-circuit
between the battery terminals can lead to burns or cause a fire.
2. Keep the battery out of the reach of children and place it on a non-combustible support.
3. Do not interfere with its cooling cycle.
4. Do not use or leave the battery near a heat source (> 60°C).
5. Do not leave the battery in direct, strong sunlight.
6. Do not expose the battery to microwaves or high pressure.
7. Do not immerse the battery in water.
8. The batteries must be charged in a dry, ventilated room at a temperature between 10°C and 25°C maximum,
away from any moisture.
9. If the battery is not used for 10 days, the battery will automatically discharge until it reaches its storage charge
rate, then goes to standby. It will heat up during this phase.
10. Over time, the capacity of your battery decreases. When it reaches half of its original battery-life operating
autonomy, it should be replaced.
11. The battery may lose 1 to 4 % of its capacity when exposed to a temperature higher than or equal to 55 °C
for one week.
12. The charging location must be equipped with a class D fire extinguisher (for metal fires) in good working order.
13. The standards in effect must be complied with when shipping a complete tool or a battery.
• Complete tool with battery: product classified UN3481 class 9.
• Battery alone: product that is classified as class 9, UN3480.
14. Use of a battery other than that provided by Pellenc SA is dangerous (risk of serious injury). If a different battery
is used, Pellenc SA cannot be held responsible for any consequences.
15. The battery must be protected from any impact and must be positioned and secured appropriately during trans-
portation.
16. In the case of suspicious smoke, place the battery outside the charging area or transportation vehicle as far
away as possible from any inflammable material.
17. Never store a battery when its capacity is below 50 %. Recharge the battery before storage if the value is
below 50%.
6
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
18. In inappropriate conditions, a liquid can flow batteries; avoid contact with it. In the event of accidental contact,
rinse with water. In the event of contact with eyes, seek professional medical help. The liquid leaking from the
batteries can cause irritations or burns.
19. Pellenc power tools must only be used with the battery units designed for the purpose. Use of other battery
units can present a risk of injury and fire.
20. Recharge only with the charger specified by the manufacturer. A charger adapted to one type of battery unit
may present a fire risk if used with a different battery unit.
21. Do not use the battery for any purpose other than that initially envisaged (exclusively for use with Pellenc tools).
22. At the end of its life, the battery must be returned to the authorized distributor from whom it was purchased to
be recycled in accordance with waste regulations.
23. Fragile case, contains an electronic board and lithium.
2.3. SAFETY MEASURES WHEN USING THE "PELLENC" CHARGER
1. When in operation, the charger’s temperature can reach 60°C. No flammable material must be within 1.5 metres
of the charger and battery.
2. Place the charger out of the reach of children and on a non-combustible support.
3. Do not interfere with its cooling cycle.
4. The charger is intended only for recharging the battery. Do not charge non-rechargeable batteries.
5. The charging location must be equipped with a class D fire extinguisher (for metal fires) in good working order.
6. If the output cord is cut or damaged, bring the entire charger back to the authorised distributor where the tool
was purchased.
7. Only recharge using the "PELLENC" charger indicated by the manufacturer. A charger adapted to one type of
battery unit may present a fire risk if used with a different battery unit.
8. This charger is designed to charge Pellenc tool lithium batteries.
9. Do not use it for any other purposes.
10. Children must be supervised to ensure they do not play with the charger.
11. Check that the cable cannot be bent and that it does not touch hot surfaces or sharp edges.
12. Ensure good ventilation during the charging.
13. Never cover the charger. This charger must not be used outdoors.
14. Make sure the power connector is not exposed to water.
15. Never attempt to charge a damaged battery.
16. The grid connection must comply with national electrical regulations.
17. Check the wiring of the charger before use. Never use the charger if the wiring is damaged.
18. When the battery is charging, place the charger on a non-flammable support, more than 1.5 m away from any
flammable object.
7
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
2.4. SAFETY SIGNAGE
Power Pack M Power Pack L (depending on configuration)
Do not expose to rain.
Read the user guide.
This equipment must be used at a tem-
perature of between -5° and +35°C.
Marking symbol for identifying the
chemical characteristic of the battery
during recycling.
Lithium-ion battery.
At the end of its life, the battery must
be returned to the authorized distributor
from whom it was purchased to be re-
cycled in accordance with waste regula-
tions.
Tool compliant with Moroccan stan-
dards.
Tool compliant with EC standards.
8
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
3. DESCRIPTION AND TECHNICAL CHARACTERISTICS
3.1. TECHNICAL CHARACTERISTICS - BATTERY
Battery Power Pack M Power Pack L (depending on configuration)
Rated battery voltage 43.2V 44.4V 43.2V
Type of battery 12 x 3 cells per pack 12 x 6 cells per pack 12 times 5 elements
included in 1 pack
Battery capacity 10.35Ah 17.4Ah 16.5Ah
Battery energy 447Wh 773Wh 745Wh
Battery life Depending on the tool
Battery weight 2.93 kg 4.89 kg 4.52 kg
Operating frequency band 13.56 Mhz, Receiver
3.2. TECHNICAL FEATURES - CHARGER CB5022HV
Commercial reference of the charger 57256
Voltage 100-240V ~ 50/60W 130W class II
Charging voltage 50.2 V dc
Charging current 2.2A DC max.
Battery: Power Pack M Power Pack L
70% 3hrs. 20mins 5hrs. 30mins
CB5022HV charger (2.2 A) 100% 5hrs. 30mins 8hrs. 30mins
3.3. DESCRIPTION
Battery
1. Gauge display
2. Charge connector cap
3. Charging connector
4. Tool power supply connector
5. On/Off button
9
PELLENC POWER TOOL BATTERY POWER PACK M, L
56_159267-A
Charger
6. Charging connector
7. Indicator light
8. Power cord
4. COMMISSIONING
4.1. SWITCHING THE BATTERY ON AND OFF
• Set the switch (5) to the off position "0"
• Set the switch (5) to the on position "I".
4.2. BATTERY DISPLAY
The battery has a gauge display showing the remaining capacity it holds. The capacity
is expressed as a percentage.
•If the gauge display shows , the battery is fully charged.
•If the gauge display indicates a value greater than after one day of work, it is not necessary to recharge the
battery for a second day of work.
•If the gauge display shows or a value close to it, you must recharge immediately.
4.3. CHARGING THE BATTERY
Note
When the battery is discharged, the tool stops automatically; the gauge display (1) indicates and the buzzer
beeps intermittently (see Section 6.1, “Summary of charge indicator and beep messages” ).
1. Check that the battery switch (5) is off (position '0').
Note
Before using the battery for the first time at the start of a new season, it must be fully charged (99% steady).
10
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Manuales populares de Paquete de baterías de otras marcas
IOGear
IOGear GBP24V Series Manual de usuario
Inventus Power
Inventus Power PROTRXion S-12V100-TRX-HD Manual de usuario
Clas Ohlson
Clas Ohlson PW-290A Manual de usuario
EINHELL
EINHELL MULTI-Ah Power X-Change Plus Manual de usuario
Samsung
Samsung EB-U3300 Manual de usuario
ECTIVE
ECTIVE LC Series Manual de usuario
