PBI DCH-4000P Manual de usuario

Professional Digital Decoder

User’s Manual

DCH-4000P

http://www.pbi-china.com

DCH-4000P User Manual

- 1 -

CONTENT

CONTENT .....................................................................................................................................- 1 -

1. Warning......................................................................................................................................- 2 -

2. Introduction...............................................................................................................................- 3 -

2.1. Features:...............................................................................................................................- 3 -

2.2. Options:................................................................................................................................- 3 -

3. Appearance Introduction .........................................................................................................- 4 -

3.1. Front Panel List.................................................................................................................... - 4 -

3.2. Rear Panel List.....................................................................................................................- 4 -

3.3. Usage of Control Buttons.....................................................................................................- 5 -

4. Operation on Front Panel.........................................................................................................- 6 -

4.1. Inputs Menu..........................................................................................................................- 6 -

4.3. System Menu.......................................................................................................................- 10 -

5. Frequently Asked Question....................................................................................................- 12 -

6. Appendix..................................................................................................................................- 12 -

6.1. Specification .......................................................................................................................- 12 -

6.2. Option List...............................................................................................................................14

7. Technology Support.....................................................................................................................15

8. DVB-S2 Input Menu....................................................................................................................15

DCH-4000P User Manual

- 2 -

1. Warning

* Please refer to the explanation below before operating to avoid user hurt or device

breakdown. Please do NOT power on before safety installation procedure checking.

Product specification and appearance are based on the actual product purchased;

any changes will not be notified accordingly.

Danger! Electricity!

Please use the outlet with the grounded

pin. If not use the machine for a long

period, please pull out the power plug

from the outlet to avoid the damage by

the lightening or electric wave. Make

proper layout of circuitry to protect the

machine from the destruction by hoof or

extrusion and impact by something laid

on it.

Depart From Dampness!

Do not use the machine in the area with

high humidity or put it in the water or

wet place.

No pressing heavily!

Please do NOT put too much pressure

on the machine.

No touching!

Please do NOT touch the machine during

thunderstorm.

No Dismantle!

1. Please do NOT dismantle the

machine by yourself.

2. Please do NOT change the

parts by yourself. If the machine

cannot work, please call the

agent and professional repairer.

！

！！

！

Urgent instance!

Please pull out the plug in any

following cases：

1. Wire or plug is damaged.

2. Filtered by the liquid, or fall into

water.

3. Poured by rain or water.

4. Drop from a high place or the

chassis is broken.

DCH-4000P User Manual

- 3 -

2. Introduction

DCH-4000P is a professional IRD with a variety of input (including DVB over ASI, IP, QPSK,

QAM, COFDM and DS3) and output (CVBS, SDI, ASI, DS3 and IP) combinations. An

appropriate IP port equipped as an option supports DVB over IP applications. LAN control and

monitoring are achieved with TCP/IP, SNMP and HDMS*.

(*Headend Devices Management System, a PBI's proprietary software)

2.1. Features:

Fully complies with MPEG-2, MP@ML and DVB-S/-T/-C standards

IP input or output with UDP/RTP (optional)

Multicast and Unicast on IP

Supports PAL, NTSC or SECAM

Supports various Conditional Access systems

SDI video output with digital audio embedded

Two sets of independent ASI outputs

Automatic PMT update

Compatible with Multiple De-encrypt CI modules

DS3 I/O for TS (optional)

Switchable audio sound track

Teletext VBI, EBU subtitle and DVB subtitle

Upgradeable through LAN

Easy-to-use LCD menu

2.2. Options:

DVB-S, DVB-T or DVB-C tuner input

High Speed 100M Base-T IP output

High Speed 100M Base-T IP input

DS3 I/O card

DCH-4000P User Manual

- 4 -

3. Appearance Introduction

3.1. Front Panel List

Figure 3.1 Front Panel of DCH-4000P

(1) PBI logo

(2) Power LED

(3) Tuner lock LED

(4) Alarm LED

(5) LCD ( 20×2 characters )

(6) Control Panel

(7) Common Interface (×2 slots)

3.2. Rear Panel List

Figure 3.2 Rear Panel of DCH-4000P

DCH-4000P User Manual

- 5 -

(1) TS/IP Input/Output interface

(2) XRL L interface

(3) XRL R interface

(4) RGB/YUV interface (G/Y)

(5) RGB/YUV interface (B/U)

(6) RGB/YUV interface (R/Y)

(7) CVBS1 interface

(8) L-Audio-R interface

(9) CVBS2 interface

(10) ASI IN interface

(11) ASI/SDI Output interface

(12) ASI Output interface

(13) RS-232 interface

(14) Ethernet interface

(15) Tuner Out interface

(16) Tuner In interface

(17) Power socket

(18) ON/OFF switcher

3.3. Usage of Control Buttons

Figure 3.3 Control Unit

ENTER Call the menu and confirm the performance

EXIT Go back to the previous menu or cancel the operation

& Zapping or switch the options of the menu and modify the values of options

& Move cursor Left /Right

DCH-4000P User Manual

- 6 -

4. Operation on Front Panel

After power on and connecting necessary cables, the LCD will display below information:

There are three submenus in Main Menu, including Inputs, Outputs and System.

4.1. Inputs Menu

Under Inputs Menu, the user could monitor configure the parameters of the Tuner and IP input

settings.

There are three submenus in Inputs menu, including Status, QPSK and Ethernet. Press

ENTER button to enter edit mode. Press & buttons to move cursor and use & button to

modify the value. Press ENTER button to confirm the operation and EXIT button to cancel.

Note: The IP could be configured by user.

Main Menu

System

Main Menu

Inputs Main Menu

Outputs

DCP-4000P

IP:10.10.70.111

Press ENTER button. Use & to choose menus,

Enter button to enter the menu and EXIT button to back

to the previous menu.

Main Menu

Inputs

Status

Inputs

QPSK

ASI unlock

Tuner 0.00000M

IP IN: No Link

IP in unlock

Show the status of inputs and could

not be configured by user.

DCH-4000P User Manual

- 7 -

Inputs

Ethernet

LNB Frequency

5150MHz

Satellite Frequency

4043MHz

Symbol Rate

17778KBand

Press ENTER button to enter the edit

mode. Use to key in the

value. Press ENTER to confirm and

EXIT to cancel

LNB Voltage

Off

LNB 22KHz

Off

Press ENTER button to enter the edit

mode. Use to modify the

value. Press ENTER to confirm and

EXIT to cancel.

Source IPAddr

0.0.0.0

Source Network

255.255.255.0

Press ENTER button to enter the edit

mode. Use to modify the

value. Press ENTER to confirm and

EXIT to cancel

Multicast IPAddr

0.0.0.0 Use to modify the value.

Source Mac Address

00:0e:26:ff:aa:41 Show the source Mac address. This

option cannot be configured by user.

Source Gateway

1.0.0.0 Use to modify the source

gateway.

Multicast UDP Port

3000

Use to modify the value

of the UDP Port.

Protocol

UDP User can configure the protocol to be

UDP or RTP

Output Smoothing

Auto User can choose Auto, Disable and

Fixed Rate.

DCH-4000P User Manual

- 8 -

4.2. Outputs Menu

Under Outputs Menu, the user could configure the settings of output programs, such as the

source signal for CI (CI Source), video standard, aspect ratio, DVB/EBU Subtitle, Audio mode and

language, the source for ASI/SDI output, SDI output with or without audio embedded etc.

There are five submenus in Outputs menu, including Status, CI, Decoder, ASI and ASI

2/SDI. Press ENTER button to enter edit mode. Use & button to move cursor and use

& button to edit the value. Press ENTER button to confirm the operation and EXIT button to

cancel.

Status

Ethernet

Status

Decoder OK

PMT: 1024 PN: 101

A/V: 80/160

Video: OK

Audio: OK

Show the information of outputs.

Status

CI Slot1

No Module

CI Slot2

No Module

Show the information of CI. If there

is no CAM card in CI Slot, it will

show No Module on the LCD. If

there is, it will show the information

of CAM card.

Outputs

Status

Outputs

CI Source

TUNER

Setup

Use to change the CI source.

There are TUNER, ASI Input and

IP to choose.

Main Menu

Outputs

DCH-4000P User Manual

- 9 -

Outputs

Decoder

Program

Decoder

Video

Video Standard

Auto

EUB Subtitle lang

eng

Screen

4:3 Full

DVB Subtitle lang

eng

Subtitle Priority

DVB first

There are Auto, SECAM, NTSC

and PAL to choose.

There are 4:3 Full, 16:9 Full and

4:3 Letter box to choose.

Use to change the letters

to spell the language.

e.g.: To choose English subtitle,

please spell eng.

Change the subtitle priority. There are

DVB First and EUB first to choose.

Decoder

Audio

Audio Level

Audio Mode

Stereo

Audio lang

eng

Use to modify the audio

level.

There are Stereo, Left, Right and

Mono to choose in Audio mode.

Use to change the letters

to spell the language.

Outputs

ASI

ASI Package Length

Bypass

ASI Source

TUNER

Use to change the ASI Source.

There are Tuner, ASI Input, CI

De-encrypted and IP to choose.

User could select Bypass or 188
