Patton electronics 536S Manual de usuario

USER

MANUAL

MODEL 536S

802.5 Token Ring (STP)

Surge Protector

SALES OFFICE

(301) 975-1000

TECHNICAL SUPPORT

(301) 975-1007

http://www.patton.com

Part# 07M536S

Doc# 074171U,

Rev. B

Revised 1/22/08

CERTIFIED

An ISO-9001

Certified Company

Dear Valued Customer,

Thank you for purchasing Patton Electronics products! We do

appreciate your business. I trust that you find this user manual helpful.

We manufacture one of the widest selections of data communications

products in the world including CSU/DSU's, network termination units,

powered and self-powered short range modems, fiber optic modems, interface

converters, baluns, electronic data switches, data-line surge protectors,

multiplexers, transceivers, hubs, print servers and much more. We produce

these products at our Gaithersburg, MD, USA, facility, and can custom

manufacture products for your unique needs.

We would like to hear from you. Please contact us in any of the

following ways to tell us how you like this product and how we can meet your

product needs today and in the future.

Web: http:www.patton.com

Sales E-mail: [email protected]

Support E-mail: [email protected]

Phone - Sales (301) 975-1000

Phone - Support (301) 975-1007

Fax: (301) 869-9293

Mail: Patton Electonics Company

7622 Rickenbacker Drive

Gaithersburg, MD 20879 USA

We are committed to a quality product at a quality price. Patton

Electronics is ISO 9001 certified. We meet and exceed the highest standards in

the industry (CE, UL, etc.).

Please contact us and let us know how we may provide you with the

answers to your needs.

Thank you.

Burton A.Patton

Vice President

P.S. Please tell us where you purchased this product.

_________________________________________________________

1.0 WARRANTY INFORMATION

Patton Electronics warrants all Model 536S components to be free

from defects, and will—at our option—repair or replace the product

should it fail within one year from the first date of shipment.

This warranty is limited to defects in workmanship or materials, and

does not cover customer damage, abuse or unauthorized modification.

If this product fails or does not perform as warranted, your sole recourse

shall be repair or replacement as described above. Under no condition

shall Patton Electronics be liable for any damages incurred by the use

of this product. These damages include, but are not limited to, the

following: lost profits, lost savings and incidental or consequential

damages arising from the use of or inability to use this product. Patton

Electronics specifically disclaims all other warranties, expressed or

implied, and the installation or use of this product shall be deemed an

acceptance of these terms by the user.

1.1 SERVICE

All warranty and non-warranty repairs must be returned freight

prepaid and insured to Patton Electronics. All returns must have a

Return Materials Authorization number on the outside of the shipping

container. This number may be obtained from Patton Electronics

Technical Service at: (301) 975-1007; http://www.patton.com; or,

[email protected].

Note: Packages received without an RMA number will not be

accepted.

Patton Electronics' technical staff is also available to answer any

questions that might arise concerning the installation or use of your

Model 1092. Technical Service hours: 8AM to 5PM EST, Monday

through Friday.

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product.

This product has been thoroughly inspected and tested and is warranted

for One Year parts and labor. If any questions or problems arise during

installation or use of this product, please do not hesitate to contact

Patton Electronics Customer Service at (301) 975-1007.

APPENDIX A

536S SPECIFICATIONS

Protocol/Application: IEEE 802.5 Token Ring, shielded or

unshielded twisted pair

Circuit: Bipolar, Solid State, 4-wire bi-directional

protection on RJ-45 connectors

Maximum Signal Rate: 16 Mbps

RJ-45 Pins Protected: 3, 4, 5 & 6

Response Time: Clamps to 7.5V in 0.5μ Sec

Capacitance: 18 pF

Surge Current: 400A (8x20 S.C. Waveform)

Energy Handling: 1.5 KW for 1 msec

Grounding: External connection provides separate unit-

ground to chassis-ground contact

Size: 3.05” x 1.68” x 0.81” (7.74cm x 4.26cm x

2.06cm)

3.0 INSTALLATION

Patton's Model 536S units are easy to install and should give you

years of trouble-free service. Here are a few simple instructions to help

you get things hooked up right:

1. Unplug (disconnect) the existing connection between the network

cable and the equipment’s I/O port.

2. Install the Model 536S between the incoming network cable and the

protected equipment using the 6” (15.24cm) modular patch cable

(supplied). Place the surge protector as close as possible to the

device being protected.

3. Connect the braided ground strap directly to a chassis ground

connection on the protected device. If you are unsure where to

locate a chassis ground connection on your equipment, consult the

equipment's user manual or contact the manufacturer—the ground

connection is critical for proper operation of the Model 536S.

Output to protected

equipment

input from

network

Connection to

frame ground

2.1 FEATURES

• Uses a multi-stage hybrid circuit for the best possible protection

• Handles surge energy up to 1.5 kW

• Conforms to the IEEE 802.5 specification

• Works in 4 Mbps / 16 Mbps Token Ring environments

• Diverts surges directly to chassis ground through braided metal

ground strap

• STP wire shield connected directly to chassis ground

• Easy to install

• Made in the U.S.A.

2.2 DESCRIPTION

The potential threats to your Token Ring network are vast:

lightning, AC power induction, electrostatic discharge, ground potential

differences, EMI/RFI interference and more. The Patton Model 536S

has been designed to greatly reduce these risks. Just attach one unit

to each of your 802.5 Token Ring devices and rest easy.

1.2 CE NOTICE

The CE symbol on your Patton Electronics equipment indicates

that it is in compliance with the Electromagnetic Compatibility (EMC)

directive and the Low Voltage Directive (LVD) of the Union European

(EU). A Certificate of Compliance is available by contacting Technical

Support.

The Model 536S connects directly between your shielded or

unshielded twisted pair (UTP) network cables and respective I/O ports.

By shunting all threatening voltages to the chassis ground, the Model

536S insures the integrity of the data in your LAN and protects

connected equipment from damage. Using a solid state design and

sophisticated multistage hybrid circuits, these units can operate at

speeds of 4 or 16 Mbps. Grounding is accomplished via an external

ground strap that provides a separate unit-ground to chassis-ground

connection. In addition, the wire shield is connected directly to chassis

ground (when shielded modular plugs are used).

Warning: This product will not provide complete protection should your

equipment or building be subject to a direct lightning hit.
