Parkside PPS 40 B2 Manual de usuario

IAN 327358_1904 NIIE

PLASMA CUTTER PLASMASCHNEIDER

Operation and Safety Notes

Translation of the original instructions Bedienungs- und Sicherheitshinweise

Originalbetriebsanleitung

GB ATIE CHNI

PLASMA CUTTER PPS 40 B2

327358_Plasmaschneider_PPS_40_B2_cover_LB6_IE_NI.indd 3 06.09.2019 13:05:26

GB IE NI

Before reading, unfold the page containing the illustrations and familiarise yourself with all

functions of the device.

DE AT CH

Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich

anschließend mit allen Funktionen des Gerätes vertraut.

GB/IE/NI Operation and Safety Notes Page 5

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 27

327358_Plasmaschneider_PPS_40_B2_cover_LB6_IE_NI.indd 4 06.09.2019 13:05:26

1 2

14 9

35678 4

8b 8c

B C

8b 8c

327358_Plasmaschneider_PPS_40_B2_cover_LB6_IE_NI.indd 5 06.09.2019 13:05:28

8e8d

F G 16

21 21

K L

23a 23c23b

327358_Plasmaschneider_PPS_40_B2_cover_LB6_IE_NI.indd 8 06.09.2019 13:05:33

5GB/IE/NI

Table of contents

Table of pictograms used ............................................................................... Page 6

Introduction........................................................................................................... Page 7

Intended use ............................................................................................................... Page 7

Package contents......................................................................................................... Page 8

Parts description.......................................................................................................... Page 8

Technical specifications ................................................................................................ Page 9

Safety instructions.............................................................................................. Page 9

General plasma explanations...................................................................... Page 16

Before use.............................................................................................................. Page 16

Installation environment................................................................................................ Page 16

Connecting compressed air........................................................................................... Page 17

Connecting the cutting torch.......................................................................................... Page 17

Connecting the ground cable ........................................................................................ Page 17

Fitting the removable roller guide (optional) .................................................................... Page 17

Using the device.................................................................................................. Page 18

Operation................................................................................................................... Page 18

Types of plasma cutting ................................................................................................ Page 18

Troubleshooting................................................................................................... Page 19

Maintenance and care ..................................................................................... Page 21

Maintaining the burner................................................................................................. Page 21

Maintenance............................................................................................................... Page 22

Storage ...................................................................................................................... Page 22

Information about recycling and disposal............................................. Page 23

EU Declaration of Conformity....................................................................... Page 23

Warranty and service information ............................................................ Page 24

Warranty conditions .................................................................................................... Page 24

Warranty period and statutory claims for defects............................................................. Page 24

Extent of warranty ....................................................................................................... Page 24

Processing of warranty claims ....................................................................................... Page 25

327358_Plasmaschneider_PPS_40_B2_content_LB6_IE_NI.indb 5 06.09.2019 12:41:01

6GB/IE/NI

Table of pictograms used

• Table of pictograms used

Caution!

Read the operating

instructions!

Caution!

Risk of electric shock!

Warning:

Potential hazards! Important note!

Do not dispose of

any electrical devices

in domestic waste!

Dispose of packaging

properly. Do not dispose of

the appliance in household

waste!

Made from recycling

material. Never use the device in the

open or when it’s raining!

Electric shock from the

welding electrode can be

fatal!

Inhalation of welding fumes

can endanger your health!

Welding sparks can cause

an explosion or fire!

Arc beams can damage

your eyes and injure your

skin!

Electromagnetic fields

can disrupt the function of

cardiac pacemakers! AC–mains connection.

H Insulation class. Terminal for the external

(grounding) equipment

conductor.

Cutting with the

plasma cutter. Gouging tool.

Cutting metal plates. Cutting expanded metal.

Indicator lamp –

thermal sensor. Connection –

Ground terminalplug

Indicator lamp –

mains connection.

Connection –

plasma burner -plug

Plasma burner power plug

327358_Plasmaschneider_PPS_40_B2_content_LB6_IE_NI.indb 6 06.09.2019 12:41:02

7GB/IE/NI

Plasma cutter PPS 40 B2

• Introduction

Congratulations! You have

purchased one of our high-quality

products. Please familiarise yourself

with the product before setup or first use.

Please also read the safety instructions

carefully. This product must be set up or used

only by people who have been trained to

do so.

Keep out of the reach of children!

PLEASE NOTE!

fThe use of the term ‘product’ or

‘device’ in the following text refers to the

plasma cutter named in these operating

instructions.

• Intended use

The device is intended for compressed-air

plasma cutting of all electrically conductive

metals. Observing the safety instructions

and assembly instructions and operating

information in the instructions for use is also

a component of the intended use.

It is imperative to adhere to the applicable

accident prevention regulations. The device

must not be used:

in insufficiently ventilated rooms,

in moist or wet environments,

in explosive environments,

to defrost pipes,

in close proximity to people with cardiac

pacemakers and

in close proximity to easily flammable

materials.

... / Introduction

IP21S Protection class I1 eff

Effective value of the

greatest mains current.

Standardised operating

voltage. X % Duty cycle.

I1 max

Greatest rated value of the

mains current. I2

Rated value of the cutting

current

1 ~ 50 Hz

Power input;

Number of phases and

alternating current symbol

and rated value of the

frequency.

Static frequency

converter-transformer-

commutator

Open circuit voltage

rated value U1

Rated value of the

mains voltage

327358_Plasmaschneider_PPS_40_B2_content_LB6_IE_NI.indb 7 06.09.2019 12:41:02

8GB/IE/NI

Use the product only as described and only

for the specific applications as stated. Keep

these instructions in a safe place. Ensure you

hand over all documentation when passing

the product on to anyone else. Any use that

differs to the intended use as stated above is

prohibited and potentially dangerous.

Damage or injury caused by misuse or

disregarding the above warning is not

covered by the warranty or any liability on

the part of the manufacturer. The device

is not intended for commercial use.

Commercial use will void the guarantee.

RESIDUAL RISK

Even if you operate the device as intended,

there will be residual risks.

Following hazards may occur in conjunction

with the construction and design of this

plasma cutter:

Eye injuries due to glare,

Touching hot parts of the device or

workpiece (burn injury),

In case of improper protection risk of

accident and fire through sparks and

slag particles,

Harmful emissions from smoke and gases

if there is a lack of air or if closed rooms

are insufficiently extracted.

Reduce the residual risk by carefully using

the device as intended and observing all

instruction.

• Package contents

1 plasma cutter

1 ground cable with terminal

1 cutting cable incl. cutting torch

1 compressed air hose with Quick-Connect

2 hose clamps

3 electrodes (1 pre-assembled)

1 set of operating instructions

3 burner sleeves (1 pre-assembled)

1 Removable roller guide

• Parts description

PLEASE NOTE!

fAfter unpacking the product, please

check that all of the package contents

are present and that the device is in

perfect condition. Do not use the device

if it is defective.

1Plasma cutter

2Handle

3Mains plug

4Ground terminal

5Ground terminal plug

6Plasma burner power plug

7Plasma burner plug

8Plasma burner

8a Plasma burner button

8b Nozzle clamping sleeve

8c Burner sleeve

8d Electrode

8e Diffuser

9Overheat protection indicator lamp

10 Plasma burner power socket

11 Ground terminal connection socket

12 Plasma burner connection socket

13 Current controller

14 Mains indicator lamp

15 Quick connector compressed air hose

16 Compressed air hose

Introduction

327358_Plasmaschneider_PPS_40_B2_content_LB6_IE_NI.indb 8 06.09.2019 12:41:02

9GB/IE/NI

17 On/off -switch

I switched on

O switched off

18 Condensation water tank

19 Manometer

20 Compressed air connection

21 Rotary knob to regulate the pressure

22 Hose clamp

23 Removable roller guide

23a Locking screws

23b Fixing screws

23c Guide rollers

• Technical specifications

Output: 15–40 A

Input: 230 V~ 50 Hz

Weight: approx. 5.0 kg

Dimensions 341 × 116 x 237 mm

Insulation class: H

Duty Cycle*: 35 % at 40 A (25 °C)

20 % at 40 A (40 °C)

“Real” cutting

capacity: 0.1 mm–12 mm

(depending on the material)

Copper:1–4 mm

Stainless steel: 1–8 mm

Aluminium:1–8 mm

Iron: 1–10 mm

Steel: 1–12 mm

Working pressure:4–4.5 bar

(4 bar preset)

Changes to technical and visual aspects of

the product may be made as part of future

developments without notice. Accordingly,

no warranty is offered for the physical

dimensions, information and specifications

in these operating instructions. The operating

instructions cannot therefore be used as the

basis for asserting a legal claim.

*Duty Cycle = is the percentage of the

operating time, in which the machine can be

used continuously under normal temperature

conditions. In relation to a 10-minute time

period this means, for example, that with a

duty cycle of 20%, that it can be used for

2 minutes and then there should be a break

of 8 minutes. If you exceed the duty cycle

values then this will trigger the overheating

protection which will bring the device to a

stop until it has cooled down to the normal

working temperature. Exceeding the duty

cycle values continuously can damage the

device.

• Safety instructions

WARNING!

fPlease read through the

operating instructions care-

fully before use. Familiarise

yourself with the device, its

proper use and the safety

notes based on these operat-

ing instructions. These form

part of the product and must

be available at all times.

Introduction / Safety instructions

327358_Plasmaschneider_PPS_40_B2_content_LB6_IE_NI.indb 9 06.09.2019 12:41:02

10 GB/IE/NI

WARNING!

fRISK OF SERIOUS

INJURY OR DEATH

FOR INFANTS AND

CHILDREN! Never leave

children unsupervised near

packaging material. There is

a risk of suffocation.

This device may be used by

children aged 16 years and

older, and by persons with

reduced physical, sensory or

mental capacities, or a lack of

experience and knowledge,

if they are supervised or have

been instructed in how to use

the device safely and under-

stand the dangers that may

arise when using it. Do not

allow children to play with the

device. Cleaning and day-to-

day maintenance must not be

performed by children without

supervision.

Repairs or/and maintenance

work must only be carried out

by qualified electricians.

Only use the cutting cable

provided in the scope of

delivery.

During operation, the device

should not be positioned

directly on the wall, covered

or jammed between other

devices so that sufficient air

can be absorbed through the

ventilation slats. Makes sure

that the device is correctly

connected to the supply

voltage. Avoid any form of ten-

sile stress of the power cable.

Disconnect the plug from the

socket prior to setting up the

device in another location.

If the device is not in opera-

tion, always switch it off by

pressing the ON/OFF switch.

Place the electrode holder on

an insulated surface and only

remove it from the holder after

allowing it to cool down for

15 minutes.

Hot metal and sparks are

blown off from the cutting arch.

The flying sparks, hot metal

as well as hot objects and hot

device equipment can cause

fires or burns. Check the working

environment and make sure the

workplace is suitable prior to

using the device.

Remove all flammable material

within 10 m of the plasma

cutter. If this is not possible,

cover the objects meticulously

using suitable covers.

Do not make cuts in places

where flying sparks could

Safety instructions

327358_Plasmaschneider_PPS_40_B2_content_LB6_IE_NI.indb 10 06.09.2019 12:41:02

Otros manuales para PPS 40 B2

Tabla de contenidos

Idiomas:

Otros manuales de Sistema de soldadura de Parkside

Parkside

Parkside PESG 120 A1 Manual de usuario

Parkside

Parkside PFDS 33 A1 Manual de usuario

Parkside

Parkside PPSK 40 A1 Manual de usuario

Parkside

Parkside PFDS 120 A2 Manual de usuario

Parkside

Parkside PISG 80 A3 Manual de usuario

Parkside

Parkside PPSK 40 A1 Manual de usuario

Parkside

Parkside PFDS 33 B2 Especificaciones técnicas

Parkside

Parkside PISG 120 B3 Manual de usuario

Parkside

Parkside PFDS 120 A2 Especificaciones técnicas

Parkside

Parkside PMSG 200 A1 Manual de usuario

Parkside

Parkside PESG 120 A1 Especificaciones técnicas

Parkside

Parkside PESG 120 B4 Manual de usuario

Parkside

Parkside PISG 80 A2 Manual de usuario

Parkside

Parkside PESG 120 A1 Manual de usuario

Parkside

Parkside P-ES 120 Manual de usuario

Parkside

Parkside PISG 80 A2 Manual de usuario

Parkside

Parkside PESG 120 A1 Manual de usuario

Parkside

Parkside PESG 120 A1 Manual de usuario

Parkside

Parkside PESG 120 A1 Manual de usuario

Parkside

Parkside PPS 40 A1 Manual de usuario

Parkside

Parkside PFDS 33 B3 Manual de usuario

Parkside

Parkside PESG 120 A1 Especificaciones técnicas

Parkside

Parkside PPS 40 A1 Manual de usuario

Parkside

Parkside PSGS 120 A1 Manual de usuario

Manuales populares de Sistema de soldadura de otras marcas

Berner

Berner PLASMACUT 54 Manual de usuario

Pro Spot

Pro Spot PR-155 Manual de usuario

Forney

Forney 210 Manual de usuario

Thermal Arc

Thermal Arc 400S Manual de usuario

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manual de usuario

GYS

GYS PROTIG 201 AC/DC Manual de usuario

TAFA

TAFA 30*8B35 Manual de usuario

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manual de usuario

ESAB

ESAB Buddy Arc 145 Manual de usuario

CIGWELD

CIGWELD 636804 Guía rápida

Red-D-Arc

Red-D-Arc DC-400 Manual de usuario

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manual de usuario

Elettro

Elettro HI-MIG 3000 SYNERGIC Manual de usuario

WIA

WIA Weldmatic 270 CP132-2 Manual de usuario

Sonics

Sonics H520T Manual de usuario

Miller

Miller Big Blue 400D Manual de usuario

NewArc

NewArc RT2000 Guía de inicio rápido

Hypertherm

Hypertherm powermax1000 Manual de usuario
