Parkside PMFWZ 1 A1 Especificaciones técnicas
MULTI-PURPOSE TOOL
ACCESSORIES PMFWZ 1 A1
MULTI-PURPOSE TOOL ACCESSORIES
Assembly, operating and safety instructions
PRIBOR ZA VIŠENAMENSKI ALAT
Uputstva o sastavljanju, upotrebi i bezbednosti
ΕΞΑΡΤΉΜΑΤΑ ΠΟΛΥΕΡΓΑΛΕΊΟΥ
Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας
MULTIFUNKTIONSWERKZEUG-ZUBEHÖR
Montage-, Bedienungs- und Sicherheitshinweise
IAN 385615_2107
GB/CY Assembly, operating and safety instructions Page 3
RS Uputstva o sastavljanju, upotrebi i bezbednosti Strana 16
GR/CY Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας Σελίδα 30
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 43
3GB/CY
Introduction ................................... Page 4
Intended use .................................. Page 4
Scope of delivery ............................. Page 5
Safety instructions............................ Page 5
Personal safety ................................... Page 5
Safety instructions for all types of use ................. Page 6
Kickback and related safety instructions ............... Page 8
Use.............................................. Page 9
Before use ...................................... Page 9
Sawing / Cutting ................................. Page 9
Sanding ........................................ Page 9
Instructions for mounting ........................... Page 10
Meaning of symbols.......................... Page 11
Cleaning and care ............................ Page 14
Storing ......................................... Page 14
Disposal........................................ Page 15
Service ......................................... Page 15
4 GB/CY
MULTI-PURPOSE TOOL ACCESSORIES
Introduction
We congratulate you on the purchase of your new product. You have
chosen a high quality product. Familiarise yourself with the product
before using it for the first time. In addition, please carefully refer to the
operating instructions and the safety advice below. Only use the product
as instructed and only for the indicated field of application. Keep these
instructions in a safe place. If you pass the product on to anyone else,
please ensure that you also pass on all the documentation with it.
Intended use
This product is not intended for commercial use.
This product is intended for sawing, cutting and grinding. The following
materials are preferable for processing: wood, plastic, drywall elements,
light and non-ferrous metals, fasteners (e.g. nails, screws) and wall tiles.
It is particularly suitable for near-edge and flush work. Any other usage
is considered improper and carries a significant risk of accidents. The
manufacturer accepts no responsibility for damage(s) resulting from
improper usage.
5GB/CY
Scope of delivery
HG08989A: 1x Z85 C3 HSS Segment Saw Blade
1x Z32 C3 HCS Plunge-cut Saw Blade
20x Z80 A2 20 hook & loop sanding papers
1x Z52 A1 Stainless Steel Scraper
HG08989B: 1x Z52 A1 Stainless Steel Scraper
1x Z64 B2 Diamond Disc
1x Z79 B2 Triangular RIFF Sanding Plate
10x Z80 A2 10 pieces of Hook & Loop
Sanding Paper
Safety instructions
Personal safety
Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
6 GB/CY
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes and
gloves away from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
Safety instructions for all types of use
Only use equipment expressly intended for use with this tool set and
recommended by the manufacturer.
The exterior diameter and thickness of the attachment must correspond
to the size requirements of your power tool. Incorrectly measured
attachments cannot be sufficiently shielded or controlled.
All attachments must fit exactly on your power tool’s reception spindle.
Attachments that do not fit exactly on your power tool’s reception
spindle cause a loss of control.
Do not use any damaged attachments. Before use, always check your
attachments for damages. Check grinding disks for tears or high wear.
7GB/CY
If you drop a power tool or attachment, check it for damages or use
undamaged attachments. You and all people in your vicinity should
keep on a different level as the oscillating attachment as soon as you
have mounted it.
Make sure that anyone who enters your workspace is wearing
appropriate personal protective clothing. Broken pieces of the object
you are working on or broken pieces from your tool attachments may
fly around and cause injury even outside your direct working vicinity.
Keep the power cable away from all oscillating tool attachments. If
you lose control of the device, the power cable may be severed or
caught, causing the oscillating attachment to come into contact with
your hand or arm.
Allow all tool attachments to come to a complete stop before setting
down your power tool. Oscillating attachments may come into contact
with the surface. This may cause you to lose control of the power tool,
leading to injury of yourself or others.
Turn off the power tool when carrying it about. Your clothing may
otherwise become tangled up in the oscillating attachment, causing
personal injury.
Do not use the power tool near flammable materials. Sparks may
ignite such materials.
8 GB/CY
Kickback and related safety instructions
Kickback is a sudden reaction arising when an oscillating power tool
attachment.
Kickback is the result of improper use of the power tool. Heed the
following safety precautions to prevent kickback:
Always maintain a firm grip on the power tool and use any available
additional handle to better control kickback.
Keep your hands away from oscillating tool attachments
at all times. The attachment may come into contact with your hand
in case of kickback.
Keep your body out of the area that the power tool
would enter in case of kickback. Exercise extreme
caution when working on corners, sharp edges, etc.
Prevent your tool attachments from jumping back from
the workpiece and jamming. The oscillating tool attachment
tends to jam when working on corners, sharp edges or when it jumps
back from the workpiece. This leads to loss of control or kickback.
9GB/CY
Use
Before use
Always check the tools for damages before use.
Do not use any damaged tools.
Rust build-up or other signs of chemical or mechanical alteration to the
fitting equipment may cause premature failure of the tool.
Before use, please study the manual of the power tools.
Sawing / Cutting
Use only undamaged saw blades that are in perfect working order.
Bent, blunt or otherwise damaged saw blades may break.
When sawing lightweight construction materials, follow the statutory
regulations and all recommendations from the material manufacturers.
Only soft materials such as wood, plasterboard or similar should be
processed using the plunge saw process.
Sanding
To prolong the service life of the sanding sheets, ensure that you apply
even pressure.
Ensure that your workplace is adequately ventilated.
Sanding sheets are attached to the sanding pad by means of the hook
and loop fastening.
Before fitting a new sanding sheet, remove any dust and dirt from the
sanding pad.
10 GB/CY
Instructions for mounting
Follow the instructions included with the machine to mount grinding/
buffing tools and brushes.
Make sure to use the tools only with devices that have an appropriate
tool attachment.
After mounting, always do a small test run.
