Parkside PDT 40 F4 Manual de usuario

AIR STAPLER

Operation and Safety Notes

Translation of the original instructions

SŰRÍTETT LEVEGŐS TŰZŐGÉP

Kezelési és biztonsági hivatkozások

Az eredeti használati utasítás fordítása

ŽEBLJALNIK NA STISNJEN ZRAK

Navodila za upravljanje in varnostna opozorila

Prevod originalnega navodila za uporabo

PNEUMATICKÁ SPONKOVAČKA

Návod k obsluze a bezpečnostní pokyny

Originální návod k obsluze

PNEUMATICKÝ SPONKOVAČ

Návod na obsluhu a bezpečnostné upozornenia

Originálny návod na obsluhu

DRUCKLUFT-TACKER

Bedienungs- und Sicherheitshinweise

Originalbetriebsanleitung

DE AT CH

AIR STAPLER PDT 40 F4

IAN 383221_2110 SK

Before reading, unfold the page containing the illustrations and familiarise yourself with all

functions of the device.

Olvasás előtt hajtsa ki az ábrát tartalmazó oldalt, és ezután ismerje meg a készülék

mindegyik funkcióját.

Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.

Než začnete číst tento návod k obsluze, rozložte stránku s obrázky a seznamte se se všemi

funkcemi zařízení.

Prv než začnete čítať tento návod, rozložte si stranu s obrázkami a potom sa oboznámte so

všetkými funkciami zariadenia.

DE AT CH

Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich

anschließend mit allen Funktionen des Gerätes vertraut.

GB Operation and Safety Notes Page 5

HU Kezelési és biztonsági hivatkozások Oldal 27

SI Navodila za upravljanje in varnostna opozorila Stran 51

CZ Návod k obsluze a bezpečnostní pokyny Strana 73

SK Návod na obsluhu a bezpečnostné upozornenia Strana 94

DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 116

124

B14 15

5GB

List of pictograms used.............................................................................. Page 6

Introduction..................................................................................................... Page 7

Intended use ......................................................................................................... Page 7

Package contents................................................................................................... Page 7

Equipment ............................................................................................................ Page 7

Technical speciﬁcations .......................................................................................... Page 8

Special instructions...................................................................................... Page 9

Regulations........................................................................................................... Page 9

Comment.............................................................................................................. Page 10

Safety instructions for the fastening device .................................... Page 10

Operating hazards ................................................................................................ Page 12

Additional safety instructions for devices powered by compressed air .......................... Page 15

Supplementary safety instructions for air staplers ....................................................... Page 16

Supplementary safety instructions for protective goggles............................................. Page 17

Explanation of the markings on the protective goggles:............................................... Page 17

Trigger device ....................................................................................................... Page 18

Trigger system ....................................................................................................... Page 18

Additional instructions for fastening devices powered by compressed air...................... Page 19

Original accessories/additional devices................................................................... Page 20

Before using the device............................................................................. Page 20

Using the device............................................................................................ Page 20

Connecting the compressed air supply ..................................................................... Page 20

Filling the magazine............................................................................................... Page 21

Operation......................................................................................................... Page 21

Handling the device............................................................................................... Page 21

Removing jammed staples....................................................................................... Page 22

Maintenance ................................................................................................... Page 22

Maintenance by the user ........................................................................................ Page 23

Cleaning............................................................................................................ Page 23

Information about recycling and disposal....................................... Page 23

EU Declaration of Conformity ................................................................. Page 23

Warranty and service information ...................................................... Page 25

Warranty conditions............................................................................................... Page 25

Warranty period and statutory claims for defects....................................................... Page 25

Extent of warranty.................................................................................................. Page 25

Processing of warranty claims ................................................................................. Page 26

6GB

List of pictograms used

Caution!

Read the operating

instructions! Wear ear protectors!

Attention!

Possible risks! Wear eye protection!

Warning – ﬁre hazard! Do not use the device on

scaffolding or ladders!

Trigger safety catch Never use oxygen or other

combustible gases as a

source of energy!

Dispose of packaging

properly. Do not dispose of

the appliance in household

waste!

Important note!

Made from recycled

material

Do not use the device for

applications such as closing

cardboard boxes or crates

and ﬁtting transport safety

systems to trailers and

goods vehicles.

Warning: the device

should only be used in

safe workplaces.

Be careful when you

swap from one location

to another.

7GB

AIR STAPLER PDT 40 F4

zIntroduction

Congratulations on the purchase of your new

device. By doing this you have chosen one

of our high-quality products. The operating

instructions form part of this product. They

contain important information on safety,

usage and disposal. Please familiarise your-

self with all operating and safety instructions

before using the product. Use the product

only as described and only for the speciﬁc

applications as stated. Ensure you hand over

all documentation when passing the product

on to anyone else.

zIntended use

The air stapler is designed for installation

and repair work. You must wear the appro-

priate eye protection every time you use it.

Caution! This device may

be used only as speciﬁed

herein.

Keep these instructions in a safe place.

Ensure you hand over all documentation

when passing the product on to anyone else.

Any use that differs to the intended use as

stated above is prohibited and potentially

dangerous. Damage or injury caused by

misuse or disregarding the above warning

is not covered by the warranty or any

liability on the part of the manufacturer. This

product is not suitable for commercial use.

It is only suitable for domestic use or similar

applications. Commercial use will void the

guarantee.

Only trained persons may

start up this product.

Keep out of the reach of

children!

NOTE:

The use of the term ‘product’ or ‘device’ in

the following text refers to the air stapler

named in these operating instructions.

zPackage contents

1 Air stapler PDT 40 F4

1 Carry case

1Oil container with

compressed air special oil

1Threaded barbed ﬁtting,

6.35 mm (¼")

(pre-assembled)

1Pack of nails, 1000 pcs.

(15 mm, 25 mm, 40 mm,

50 mm, pack of 250)

Pack of staples, 1000 pcs.

(16 mm, 40 mm,

pack of 250 and 25 mm,

pack of 500)

1 Protective goggles

1 Operating instructions

zEquipment

Exhaust air outlet (can be rotated)

Trigger

Handle

Threaded barbed ﬁtting 6.35 mm (¼")

Cover cap

Magazine lever

Magazine

Fill level display

8GB

Knurled screw

Trigger safety catch

Mouth

Face plate

Quick clamp lever for face plate

Oil container with compressed air

special oil

Protective goggles

Nails

Staples

zTechnical speciﬁcations

Dimensions

(W x H x D) 240x239x57mm

Weight

(without fasteners) 1197 g

Type of trigger Compressed air

Maximum permitted

pressure

(Working pressure) max. 8 bar

Recommended

pressure range 4–7 bar

Air consumption

depending on the

fastening operation approx. 0.09 l

Recommended

lubricant Compressed air

special oil

Loading capacity 100 pcs.

Nail lengths

15 mm, 20 mm,

25 mm, 30 mm,

32 mm, 35 mm,

38 mm, 40 mm,

45 mm, 50 mm

Staple length 10–40 mm

Staple width 5.7 mm

Recommended hose

diameter (internal) 9 mm

Compressed air

quality

clean,

oil-atomised and

condensate-free

Noise and vibration

information

Measured value determined

in accordance with EN

12549:1999, EN ISO 4871.

Typical A-weighted sound

pressure level of the device is:

92.7 dB(A)

Uncertainty K = 2.5 dB

LWA: 105.7 dB(A)

(at the work station): 98.8 dB(A)

LpC: 115.3 dB(C)

These values are device-related

characteristic values and do not

reﬂect the noise emission at the

place of use. The noise emission

at the place of use depends,

for example, on the working

environment, the workpiece, the

workpiece support, the number of

fastening operations. Depending

on the work station conditions

and the shape of the workpiece,

it may be necessary to implement

customised noise reduction

measures, such as, for example,

placing the workpieces on

sound-absorbing mats, preventing

vibration of the workpieces by

clamping or covering, adjusting

to the lowest pressure necessary

for carrying out the procedure. In

speciﬁc cases, you must wearing

personal ear protectors.

9GB

Vibration total value

Vibration emission value

ah= 2.481 m/s2

Uncertainty K = 1.5 m/s2

in accordance with

ISO 8662-11:1999

Mechanical impacts

(Vibrations)

For the fastening device, the

vibration characteristic value is

determined in accordance with

ISO 8662-11:1999 – Handheld

motor-driven machines – Meas-

uring mechanical vibrations on

the handle – Fastening devices

(see Technical speciﬁcations).

The value is a device-related

characteristic value and does

not represent the effect of the

hand-arm system when using

the device. The impact on the

hand-arm system when using the

device depends, for example,

on the gripping force, contact

pressure, direction of operation,

the air pressure which has been

set, the workpiece, the workpiece

support.

zSpecial instructions

zRegulations

The DIN EN ISO 11148-13:2018

standard “Handheld non-

electrically operated machines–

Safety requirements – Part 13:

Fastening devices” applies to

fastening devices. This standard

states that

you must only work with

those fasteners as listed in

the corresponding operating

instructions for the fastening

devices (see Technical speciﬁ-

cations). The fastening device

and the fasteners indicated in

the operating instructions are

regarded as a safety system;

Quick couplings are used for

connection to the compressed

air supply and the non-clos-

able nipple must be ﬁtted to

the device so that when it

is disconnected, there is no

compressed air in the device.

Oxygen or combustible gases

must not be used as a source

of energy for fastening devices

Fastening devices must only

be connected to lines, where

the maximum permitted pres-

sure of the device cannot be

exceeded by more than 10%;

with higher pressures, a pres-

sure regulating valve (pressure

reducer) with downstream

pressure relief valve must be

10 GB

ﬁtted in the compressed air

line;

only spare parts designated

by the manufacturer or his

representative may be used for

servicing fastening devices;

Servicing work may only

be carried out by an agent

appointed by the manufacturer

or by other experts taking the

information contained within

the operating instructions into

account;

zComment

An expert is someone who, due

to his/her professional training

and experience has sufﬁcient

knowledge in the area of fasten-

ing devices and is familiar with

the relevant national occupational

health and safety regulations,

accident prevention regulations,

directives and generally accepted

rules of technology (e.g. CEN or

CENELEC standards) to the extent

that he/she can assess the opera-

tional safety of fastening devices.

Brackets to ﬁx fastening

devices onto a support, e.g.

workbench, the bracket must

be designed by the manufac-

turer such that the fastening

devices can be securely ﬁxed

for the intended purpose,

e.g. so that they cannot be

damaged, rotated, moved.

Special areas of application for

the fastening device may require

compliance with additional regu-

lations and rules (e.g. working in

hazardous areas (Ex)).

zSafety instructions for the

fastening device

Read all safety

instructions and

other instructions.

Read and under-

stand all the safety

instructions, before you

connect, disconnect, load,

use or maintain the device,

replace accessories or work

near the device. Failure to

do so can result in serious

bodily injury.

Please keep all safety

instructions and other

instructions in a safe place!

Keep your ﬁngers away from

the trigger when you are not

using this device and switch

from a working position to

another position.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Herramientas eléctricas de Parkside

Parkside

Parkside 353260 2007 Manual de usuario

Parkside

Parkside PSTK 800 A1 Manual del propietario

Parkside

Parkside PABSW 10.8 B2 Manual de usuario

Parkside

Parkside PFBS 12 C5 Manual de usuario

Parkside

Parkside PFMR 1400 A1 Manual de usuario

Parkside

Parkside PSTK 800 A1 Manual del propietario

Parkside

Parkside PAMFW 12 C3 Manual de usuario

Parkside

Parkside 378355 2110 Manual de usuario

Parkside

Parkside PSG 50 B2 Manual de usuario

Parkside

Parkside POF 1200 C2 Manual de usuario

Parkside

Parkside PSG 50 A1 Manual de usuario

Parkside

Parkside 322437 1901 Manual de usuario

Parkside

Parkside PSTK 730 A1 Manual de usuario

Parkside

Parkside PKGA 20-Li C2 Manual de usuario

Parkside

Parkside PLHLG 2000 A1 Manual de usuario

Parkside

Parkside PBSG 55 A1 Manual de usuario

Parkside

Parkside 96760 Manual del propietario

Parkside

Parkside PPHSS 670 Manual de usuario

Parkside

Parkside PLPRS 1.5 B3 Manual de usuario

Parkside

Parkside KH 3027 MULTI-FUNCTION TOOL Manual de usuario

Parkside

Parkside WWS-GLK9-Y02 Manual de usuario

Parkside

Parkside PASSK 20-Li A1 Manual de usuario

Parkside

Parkside PDBS 6.2 A1 Manual de usuario

Parkside

Parkside PHLG 2000 B1 Manual de usuario

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
