Parkside 302787 Manual de usuario

BATTERY PAP 20 A3

IAN 302787

AKKU

Bedienungsanleitung

BATTERY

Operating instructions

GB Operating instructions Page 1

DE/AT / CH Bedienungsanleitung Seite 21

Before reading, unfold the page containing the illustra-

tions and familiarise yourself with all functions of the

device.

Klappen Sie vor dem Lesen die Seite mit den Abbildun-

gen aus und machen Sie sich anschließend mit allen

Funktionen des Gerätes vertraut.

All Parkside tools of the X20V Team series are com-

patible with the PAP 20 A1 / PAP 20 A2 / PAP 20 A3

battery pack.

20V max.

18V

PAP 20 A3 GB │ 1 ■

Contents

Introduction........................2

Intended use............................. 2

Features ................................ 3

Package contents ......................... 3

Technical data ........................... 3

General Power Tool Safety Warnings ..5

Extended safety guidelines.................. 7

Charging the battery pack (see ﬁg. A) ..8

Checking the battery charge level ............ 9

Maintenance and storage ...........10

Kompernass Handels GmbH warranty 11

Service ................................14

Importer ............................... 14

Disposal..........................15

Notes concerning the EC

Declaration of Conformity ...........17

Ordering a replacement battery......18

Online ordering ......................... 18

Telephone ordering ......................20

IB_302787_PAP20A3_LB6.indb 1 06.03.18 08:24

PAP 20 A3■ 2 │ GB

Introduction

Congratulations on the purchase of your new appli-

ance. You have chosen a high-quality product. The

operating instructions are part of this product. They

contain important information about safety, usage and

disposal. Before using the product, please familiarise

yourself with all operating and safety instructions.

Use the product only as described and for the range

of applications speciﬁed. Please also pass these

operating instructions on to any future owner.

Intended use

This rechargeable battery is suitable for:

This rechargeable battery is not intended for com-

mercial use. Any other usage of or modiﬁcation to

the appliance is deemed to be improper and carries

a signiﬁcant risk of accidents. The manufacturer

accepts no responsibility for damage(s) attributable

to misuse.

IB_302787_PAP20A3_LB6.indb 2 06.03.18 08:24

PAP 20 A3 GB │ 3 ■

Features

Battery pack

Battery charge level button

Battery display LED

High-speed charger (not supplied)

Red charge control LED

Green charge control LED

Package contents

1 battery

1 set of operating instructions

Technical data

Battery: PAP 20 A3

Type: LITHIUM ION

Rated voltage: 20 V (DC)

Capacity: 4.0 Ah

Cells: 10

IB_302787_PAP20A3_LB6.indb 3 06.03.18 08:24

PAP 20 A3■ 4 │ GB

To charge the battery pack, use only the

following high-speed battery charger:

X20V Team Serie

(not supplied)

PLG 20 A2:

INPUT:

Rated voltage: 230–240 V ∼, 50 Hz

(AC)

Rated power

consumption: 85 W

Fuse (internal): 3.15 A

T3.15A

OUTPUT:

Rated voltage: 21.5 V (DC)

Rated current: 3.5 A

Charging time: approx. 80 min

Protection class: II/ (double insulation)

IB_302787_PAP20A3_LB6.indb 4 06.03.18 08:24

PAP 20 A3 GB │ 5 ■

General Power Tool

Safety Warnings

WARNING!

■Read all safety warnings and all instructions.

Failure to follow the warnings and instructions

may result in electric shock, ﬁre and/or serious

injury. Save all warnings and instructions for

future reference.

a) Charge a rechargeable battery unit using only

the charger recommended by the manufacturer.

Chargers are often designed for a particular type

of rechargeable battery unit. There is the danger

of ﬁre if other types of rechargeable battery units

are used.

b) Only the rechargeable battery units supplied

are to be used with an electrical power tool.

The use of other rechargeable battery units may

lead to the danger of injury or ﬁre.

IB_302787_PAP20A3_LB6.indb 5 06.03.18 08:24

PAP 20 A3■ 6 │ GB

c) When they are not being used, store recharge-

able battery units away from paperclips, coins,

keys, nails, screws or other small metal objects

that could cause the contacts to be bridged.

Short-circuiting the contacts of a rechargeable

battery unit may result in heat damage or ﬁre.

d) Fluids may leak out of rechargeable battery

units if they are misused. If this happens, avoid

contact with the ﬂuid. If contact occurs, ﬂush

the aﬀected area with water. Seek additional

medical help if any of the ﬂuid gets into your

eyes. Escaping battery ﬂuid may cause skin

irritation or burns.

CAUTION! RISK OF EXPLOSION!

Never charge non-rechargeable

batteries!

Protect the rechargeable battery from

heat, for example from continuous

exposure to sunlight, ﬁre, water and

moisture.

There is a risk of explosion.

IB_302787_PAP20A3_LB6.indb 6 06.03.18 08:24
