Parblo coast 16 Manual de usuario
coast 16
15.6”GRAPHIC DRAWING MONITOR
USER MANUAL
Windows XP/7/8/8.1/10 or above; Mac OSX 10.8.5.or above
1
www.parblo.com
1
www.parblo.com
Contents
1. Product Overview
2. Driver Installation
a. Windows
b. Mac
3. Driver Configuration
a. Windows
b. Mac
4. Specification
5. FAQ
1
2
3
4
5
6
7
8
9
1
www.parblo.com
Product Overview
15.6”
1920 X 1080 IPS
Shift
Ctrl
Alt
Canvas/Brush +/-
Power Switch/Status Led
Esc
Menu
Mini HDMI
Fixed Stand 30°
USB Type-C
Space
Shift
Ctrl
Alt
Space
15
1
1
www.parblo.com
Side Button: it is equal to the right-key of a mouse by de-
fault and it can be customized as the Left Key, Right Key,
Middle Key, Double Click Key, Scroll Up, Scroll Down, Key-
board, Application and Disable function.
Pen Tip: It can be as the same function as left key of the
mouse. When the tip gets too short or develops a sharp
edge, you can replace it with one of the replacement tips
inside the pen box. (Please replace the pen tips according to
the FAQ9.)
WINDOWS
STEP1: Please uninstall and completely remove any driver of
other graphics tablet/monitor on your computer.
STEP2: Please temporarily disable any anti-virus and firewall
software. Make sure you are installing the driver as the Ad-
ministrator.
STEP3: Connect Coast16to your computer. (USB cable: to
provide power for Coast16; HDMI cable: to provide the
“display” function to Coast16.)
STEP4: Insert the disk into your CD drive, open it and install
the driver by following the computer instruction. (Note: or
you candownload the up-to-date driver from http://parb-
lo.com/support by finding out “PARBLO COAST16”.)
Kindly Remind
If your computer has installed the driver forParblo Coast16
and you will see the following message:
1
www.parblo.com
Driver Installation
2
1
www.parblo.com
Please choose “Remove” to remove the former old driver
in your computer. Then, install the driver again.
STEP5: Restart your computer after finishing the installa-
tion.
STEP6: Once it is installed successfully, the digital pen
should be in a control of the cursor. Pls open“tablet set-
ting” in the “start tray” of your computer/laptop and test
the pressure.
1
www.parblo.com
Mac
STEP1: Connect Coast16to your computer. (USB cable: to
provide power for Coast13; HDMI cable: to provide the
“display” function to Coast16.)
Note: 1. If your computer/laptop is Mac Book Air or IMac,
please use the Mini DisplayPort to HDMI adapter to con-
nectCoast16 to your laptop.
2. If your laptop is the Mac Book Pro, please use the USB 3.1
type C to HDMI adapter to connectCoast16 to your laptop.
STEP2: Insert the disk into your CD driver,open it and install
the driver by following the screen instruction. (Note: Or you
candownload the up-to-date driver from http://parblo.com/-
support by finding out “PARBLO COAST16”.)
STEP3: Log out and restart your computer/laptop by follow-
ing the computer instruction.
STEP4:Once it is installed successfully, there is an icon at
the top right of your computer screen.And the digital pen
should be in a control of the cursor.
1
www.parblo.com
You may configure the Parblo Coast16 by modifying the
functions of the pen tip and the shortcut keys, please follow
the WIN and MAC installation steps to configure your
Parblo.
Windows
1. ap [Start] >and then find [Tablet Setting] (you can directly
search for it in the Search Bar), double-tap it and open it. You
will see [Pen Setting], [Mapping], [Key Setting] and [About]
button.
2. Pen Setting:
You can test the pen pressure and configure the shortcut key
of the digital pen. You can set the shortcut key as the func-
tion of“Left Key”,“Right Key”,＂Middle Key”,＂Double
Click Key”,“Scroll Up”,“Scroll Down”,“Keyboard”,
“Application” and “Disable”.
3. Mapping:
Monitors: Please choose the monitor that you want the digi-
tal pen to take control of it.
a. Please make it clear that which one is“monitor1”and
“monitor2”between Coast16 and your computer.
b. For example,your computer= Monitor 1 &Coast16=Moni-
tor2,
1
www.parblo.com
Driver Configuration
3
1
www.parblo.com
1
f you want the pen to control your computer only, so please
choose the “Monitor 1”; if you want the digital pen to con-
trol Parblo only, please choose “Monitor2”.
⊙ Calibrate:Please click the “Calibrate” and you will see 4
red-cross on the Coast16‘s screen, please use the digital
pen to click the center of the cross over right above it in
turns.
4. Key Setting:
You can configure those express keys (8+1) of the Coast16.
5. About:
Introduce the basic information about this version of driver.
MAC:
1. Please find the tablet icon at the top right of your
computerscreen. Click it and enter to the “Quick Setup”,
and you will see the below panel:
1
www.parblo.com
1
www.parblo.com
2. Normal Setting:
You can test the pen pressure and configure the shortcut
keys of the digital pen. You can set the shortcut keys as the
function of “Disable”, “Left Key”, “Right Key”,＂Middle
Key”,＂Double Click”, “Launch Application”, “Key Bind-
ings”, “Switch Screen”.
3. Region Setting:
⊙ Monitors: Please choose the monitor that you want the
digital pen to take control of it.
a. Please make it clear that which one is “monitor1” and
“monitor2” between Coast16 and your computer.
b. For example, your computer= Monitor 1 &Coast16=Moni-
tor2,
If you want the pen to control your computer only, please
choose the “Monitor 1”; if you want the digital pen to con-
trol Parblo only, please choose “Monitor2”.
⊙ Calibrate: Please click the “Calibrate” and you will see 4
red-cross on the Coast16’s screen, please use the digital
pen to click the center of the cross over right above it in
turns.
4. Key Setting
You can configure the 8 express keys on the Coast16 as the
function of“Disable”,“Left Key”,“Right Key”,“Middle
Key”,“Double Click”,“Launch Application”,“Shift”,
“Ctrl” and“Alt”.
5. About
Introduce the basic information about this version of driver.
