Panasonic RR-US395PC Manual de usuario

Power output: 300mW (max.)

Frequency response: 240Hz - 5,100Hz (HQ mode)

230Hz - 3,400Hz (FQ/SP mode)

S/N: 36dB(HQ mode)

Jack:

Output jack; Earphone, 3.5mm(1/8in.), 0.5mW

16Ω

Input jack; Mic, 3.5mm(1/8in.), 0.56mV plug in

power

Speaker: 28mm(1-3/32in.) 8Ω

Power requirement: DC 3V

2 AAA size (LR03, AM-4) batteries

Dimensions (W×H×D):

Max dimensions; [RR-US395]

35.0×100.2×24.0mm

(1-3/8×3-15/16×15/16in.)

[RR-QR180/QR170]

35.0×99.6×24.0mm

(1-3/8×3-29/32×15/16in.)

Cabinet dimensions; 32.8×99.3×22.5mm

(1-9/32×3-29/32×7/8in.)

Mass:

with batteries; [RR-US395]

About 62g (2.2oz.)

[RR-QR180/QR170]

About 61g (2.16oz.)

rights reserved. Unauthorized copying and

distribution is a violation of law.

RR-US395PC

RR-QR180P

RR-QR180PC

RR-QR170P

Colour

S............Silver Type (RR-US395/RR-QR180)

W...........White Type (RR-QR170)

without batteries; [RR-US395]

About 39g (1.4oz.)

[RR-QR180/QR170]

About 38g (1.35oz.)

Operational temperature range: 0°C-40°C (32°F-104°F)

Battery life:

[When used at 25°C(77°F) on a flat, stable surface]

Panasonic alkaline batteries;

Playback;

[RR-US395]

bout 9 hours 30 minutes

(HQ mode)

About 11 hours 30 minutes

(FQ/SP mode)

Recording;

[RR-US395]

bout 14 hours 30 minutes

(HQ mode)

About 19 hours 30 minutes

(FQ/SP mode)

Playback;

[RR-QR180/QR170]

bout 10 hours

(HQ mode)

About 12 hours

(FQ/SP mode)

Recording;

[RR-QR180/QR170]

bout 15 hours

(HQ mode)

About 20 hours

(FQ/SP mode)

*The battery life may be less depending on the operating conditions.

Note:

Specifications are subject to change without notice.

Mass and dimensions are approximate.

IC Recorder

Specification

ORDER No.AD0604004CE

1 Accessories 3

2 Control Guide 3

3 Replacement Parts List 3

4 Schematic Diagram 4

4.1. Schmatic Diagram Notes 4

4.2. Schematic Diagram 5

CONTENTS

Page Page

RR-US395PC / RR-QR180P / RR-QR180PC / RR-QR170P

RR-US395

USB cable (K2KZ4CB00010)...................................1pc.

3 Replacement Parts List

Note:

All parts are supplied by SPC.

Supply of CD-ROM, in accordance with license protection,

is allowable as replacement parts only for customers who

accidentally damaged or lost their own.

Ref.

No.

Part No. Part Name &

Description

Pcs Remarks

A1 RQT8525-P O/I BOOK 1 (RR-QR170P)

English

A1 RQT8526-P O/I BOOK 1 (RR-

QR180P/PC)

English

A1 RQT8531-P O/I BOOK 1 (RR-US395PC)

English

A2 RQT8527-C O/I BOOK 1 (RR-

US395PC/QR180

PC)

Canadian/Fren

A3 K2KZ4CB00010 USB CABLE 1 (RR-US395PC)

A4 RFE0183-S CD-R,VOICE EDITING

1(RR-US395PC)

SEE “NOTES”

A5 RFE0184-S CD-R,VOICE EDITING

1(RR-US395PC)

SEE “NOTES”

CD-ROM

(Voice Editing Ver.1.0 Premium Edition).....................1pc.

1 Accessories

2 Control Guide

RR-US395PC / RR-QR180P / RR-QR180PC / RR-QR170P

4.1. Schmatic Diagram Notes

(This schematic diagram may be modified at any time with

development of new technology.)

S1 : Stop switch ( ).

S2 : Playback switch ( ).

S3 : Fast forward switch ( ).

S4 : Rewind switch( ).

S5 : Folder, Menu switch ( ).

S6 : Recording mode switch (REC MODE).

S7 : Erase switch (ERASE).

S8 : Recording/Stop switch (REC/STOP).

S9 : Volume (+) switch.

S10 : Volume (-) switch.

S13 : Hold switch (HOLD) in “OFF” position.

S14: Batt. cover open det. switch.

S18: Meeting/Dictation select switch

(MEETING/DICTATION) in “MEETING” position.

Important safety notice

Components identified by ; mark have special

characteristics impotant for safety.

When replacing any of components, use only

manufacturer’s specified parts.

4 Schematic Diagram

RR-US395PC / RR-QR180P / RR-QR180PC / RR-QR170P

4.2. Schematic Diagram

RR-US395PC / RR-QR180P / RR-QR180PC / RR-QR170P
