Panasonic Viera TH-L32XV6A Instrucciones de montaje

HELP

English

TH-L32XV6A

- 2 -

Watching

Basic

•Basic connection 8

•Selecting channel 10

•Information banner 10

•Option Menu 12

•Subtitle 13

•Off Timer 13

•Still 13

•Last view 14

•Adjusting time 14

External equipment

•External connection 15

•Watching external input 17

•HDMI features 17

•Valid input signals 19

For best picture

•Viewing Mode 19

•Ambient Sensor 20

•Auto power standby function 20

•Aspect 20

•Advanced Settings 21

•Copy Adjustment 23

For best audio

•Sound mode 24

TV Guide

•Using TV Guide 24

Tuning and editing channels

•Setting menu 26

•Favourites Edit 26

•Channel List 28

•Auto Tuning 29

•Manual Tuning 29

- 3 -

•Update Channel List 30

•New Channel Message 30

•Signal Condition 30

Home network

DLNA / Web Browser

•Information for DLNA 32

•Using DLNA 34

•Using Web Browser 35

Network connections

•DLNA connection 36

•Internet connection 38

•Note 38

Network settings

•Network Connection 39

•Custom - Wireless 40

•Custom - Wired 42

•Custom - Wireless Access Point 44

•Network Status 45

•VIERA remote Settings 45

•Network Link Settings 46

•Software Update 46

•New Software Message 47

Photos

•Selecting file 47

•Viewing photo 48

•Using slideshow 48

Videos

•Selecting file 49

•Watching video 50

•Video Setup 51

•Audio output settings 52

- 4 -

Music

•Selecting file 53

•Playing music 53

•Music Setup 54

DIGA Recorder

•Controlling DIGA Recorder 54

Technical information

•Photo format 55

•Video format 55

•Music format 57

Media Player

Using Media Player

•Information 59

•Selecting device / mode 60

Photo mode

•Selecting file 61

•Viewing photo 62

•Sorting photos 62

•Using slideshow 63

Video mode

•Selecting file 66

•Watching video 67

•Video Setup 68

•Audio output settings 69

Music mode

•Selecting file 70

•Playing music 70

•Music Setup 71

USB Sharing

•USB Sharing 71

- 5 -

Technical information

•Device handling caution 73

•USB devices 73

•Photo format 73

•Video format 74

•Music format 76

Functions

VIERA TOOLS

•Using VIERA TOOLS 78

VIERA Link “HDAVI Control™”

•Summary of VIERA Link 79

•Preparations 83

•Easy playback 83

•Power on Link 83

•Power off Link 83

•Standby Power Save 84

•Intelligent Auto Standby 84

•VIERA Link Control 84

•Speaker Selection 85

•Note 86

Child Lock

•Using Child Lock 86

•PIN number 87

•Parental Rating 87

Shipping Condition

•Shipping Condition 88

Updating the TV Software

•Information 89

•Auto update 89

•Manual update 89

Setting characters

•Using numeric buttons 90

- 6 -

Settings

Setting menu

•How to use 91


•Viewing Mode 92

•Basic settings 93

•Ambient Sensor 93

•Noise reduction settings 93

•Advanced Settings 94

•Option Settings 94

•Screen Settings 95

•Copy Adjustment 95

•Reset Picture Defaults 95

Sound

•Mode 96

•Basic settings 96

•Volume settings 97

•Audio Description 97

•Advanced settings 98

•Reset Sound Defaults 100

Network

•Network Connection 100

•Network Status 100

•VIERA remote Settings 100

•Network Link Settings 100

•Other settings 100

Timer

•Off Timer 101

•Clock Settings 101

•Auto Standby 102

•No signal Power off 102

Setup

•Eco Navigation 102

- 7 -

•USB Device Setup 102

•Child Lock 102

•Tuning Menu 102

•Display Settings 104

•VIERA Link Settings 104

•System Menu 105

•Other Settings 105

Support

FAQs

•Picture 106

•Digital TV 107

•Sound 109

•HDMI 109

•Network 110

•Other 111

Maintenance

•Care and Cleaning 112

Information

•Using Help menu 112

Optional accessories

•Wall-hanging bracket 113

Licence

•Licence 113

OK Letters enclosed in a box indicate remote control buttons.

Menu Letters in cyan indicate on-screen display items.

References in this eHELP

●The images shown in this eHELP are for illustrative purposes only.

- 8 -

Watching

Basic

Basic connection

Please ensure that the unit is disconnected from the mains socket before

attaching or disconnecting any cables.

■Aerial

Aerial terminal

RF cable

Aerial

●Keep RF (antenna) cable away from the mains lead to avoid and minimise

mains interference pickup.

●Do not place the RF cable under the TV.

●Anaerial,correctcable(75Ωcoaxial)andcorrectterminatingplugare

required to obtain optimum quality picture and sound.

●If a communal aerial system is used, you may require the correct

connection cable and plug between the wall aerial socket and the TV.

●Your local Television Service Centre or dealer may be able to assist you

in obtaining the correct aerial system for your particular area and the

accessories required.

●Any matters regarding aerial installation, upgrading of existing systems or

accessories required, and the costs incurred, are the responsibility of you,

the Customer.

- 9 -

■DVD Recorder / VCR

Aerial terminal

RF cable

DVD Recorder / VCR

Aerial

HDMI terminal

HDMI cable

●For VIERA Link connections

Functions VIERA Link “HDAVI Control™” Summary of VIERA Link

■Set top box

HDMI terminal

HDMI cable

Set top box

Satellite dish

●For VIERA Link connections

Functions VIERA Link “HDAVI Control™” Summary of VIERA Link

= Note =

●External equipment and cables shown are not supplied with this TV.

●Please also read the manual of the equipment being connected.

●Keep the TV away from electronic equipment (video equipment, etc.) or

equipment with an infrared sensor, otherwise distortion of image / sound

may occur or operation of other equipment may be affected.

●When using an HDMI cable, it is recommended to use fully wired one.

- 10 -

●Check the terminal type and cable plugs are correct when connecting.

Selecting channel

1. Select Digital TV or Analogue TV with TV

●You can also select the mode pressing INPUT/OK/HOLD for MENU

button repeatedly on the control panel of the TV.

●The selected mode is displayed on the top left of the screen.

2. Select a channel with Channel Up / Down or numeric buttons

●Press the numeric buttons to select a channel position with 2 or more-

digit (e.g. 399, press ).

■To select a channel from the channel list

1. Display the channel list with OK

2. Select a channel from the list with / and press OK to watch

■To select a channel using information banner

1. Display information banner with INFO if it is not displayed

2. Select a channel with / and press OK to watch while the banner is

displayed

Watching Basic Information banner

■To select a channel using TV Guide

1. Display TV Guide with GUIDE

2. Select the current programme or channel with / / / and press

OK to watch

Watching TV Guide Using TV Guide

Information banner

Display information banner with INFO.

●Also appears when changing a channel.
