Panasonic RX-ES22E Manual de usuario

Order No: MD0201021C2

PortableStereo CD System

RX-ES22E / RX-ES22EB / RX-ES22EG

Colour

(S)..........Silver Type

Tape Deck: SG2Mechanism Series

Traverse deck: RAE0155Z-1V Mechanism Series

SPECIFICATIONS

RADIO

Frequencyrange

AM 522-1629 kHz (9kHz steps)

FM 87.5-108 MHz (50 kHz steps)

TAPE RECORDER

Track System 4 track, 2channel, stereo

Recording system AC bias

Erasing system Multi Polemagnet

Monitorsystem Variablesound monitor

Frequencyrange

Normal position 50-14000 Hz

CD PLAYER

Sampling frequency 44.1kHz

Decoding 16 bit linear

Beam source Semiconductorlaser

(wavelength780 nm)

No. of channels 2channel, stereo

Wowand flutter Belowmeasurablelimit

D/Aconverter MASH (1bit DAC)

GENERAL

Power requirement

AC 230-240 V, 50 Hz

Power consumption 23 W

Battery 12 V [Eight R20/LR20 (D, UM-1)

batteries]

Donot use rechargeabletypebatteries

Memorybackup forcomputer/

clock 6V [FourR6/LR6(AA, UM-3)

batteries]

Donot use rechargeabletypebatteries

Speakers 8 cm 2.7 x2

Jacks

Output Phones: 3.5mm stereo(16-32 )

Dimensions(WxH xD) 529 x144 x276 mm

Mass 4.0kgwithout batteries

Notes:

1. Mass and dimensionsshown areapproximate.

2. Specificationsaresubject to changewithoutnotice.

Unauthorized copying and distribution isaviolation of law.

1. Before Repair and Adjustment

Disconnect AC power, discharge PowerSupplyCapacitors C301 through a 10 , 5 W resistor

toground. DO NOTSHORT-CIRCUITDIRECTLY (witha screwdriverblade, forinstance), as this

maydestroysolidstate devices.

Afterrepairs are completed, restore powergraduallyusing a variac, toavoidovercurrent.

Current consumption at AC 220 V, 240 V, 60 Hz inNO SIGNALmode shouldbe ~100 mA

respectively.

2. Protection Circuitry

The protection circuitrymayhave operatedif eitherof the following conditions are noticed:

-Nosound isheard when the power isturned on.

-Stops during aperformance.

The function of this circuitryis toprevent circuitrydamage if, forexample, the positive and

negative speakerconnection wires are “shorted”, orif speakersystems withanimpedance less

thanthe indicatedratedimpedance of the amplifierare used.

If this occurs, followthe procedure outlines below:

1. Turn off the power.

2. Determine the cause of the problem and correct it.

3. Turn on the power once againafter one minute.

Note:

Whenthe protection circuitryfunctions, the unit will not operate unless the poweris first turned

off and thenon again.

3. Accessories Remote Control Transmitter.....1 pc

AC Mains Lead(E/EG).....1 pc

AC Mains Lead(EB).....1 pc

4. Handling Precautions For Traverse Deck

The laserdiode inthe traverse deck (optical pickup) maybreak downdue topotential difference

causedbystatic electricityof clothes orhumanbody. So, be careful of electrostatic breakdown

during repairof the traverse deck (optical pickup).

-Handling of traverse deck (optical pickup)

1. Donot subject the traverse deck (optical pickup) to static

electricityas itisextremelysensitive to electrical shock.

2. To prevent the breakdownof the laser diode, an antistatic

shorting pinisinserted into the flexibleboard (FFCboard).

3. Take care not to applyexcessive stress to the flexibleboard (FFC

board). When removing or connecting the short pin, finish the job

inas short time as possible.

4. Donot turn the variableresistor (laser power adjustment). Ithas

alreadybeen adjusted.

-Grounding for electrostaticbreakdownprevention

1. Human bodygrounding

Use the anti-staticwrist strap to discharge the staticelectricity

from your body.

2. Work tablegrounding.

Put aconductive material (sheet) or steel sheet on the area where

the traverse deck (optical pickup) isplace, and ground the sheet.

Caution:

The staticelectricityof your clothes will not be grounded through

the wrist strap. So, take care not to let your clothes touch the

traverse deck (optical pickup). /

Caution whenreplacing the Traverse Deck

The traverse deck has ashort point shorted with solder to protect

the laser diode against electrostatics breakdown. Besure to

remove the solder from the short point before making connections.

5. Precaution of Laser Diode

Caution:

Thisproduct utilizers aclass 1laser. Invisiblelaser radiation is

emitted from the optical pick up lens.

When the unitisturned on:

1. Donot disassemblethe optical pick up unit, since radiation from

exposed laser diode isdangerous.

2. Donot adjust the variableresistor on the pick up unit. Itwas

alreadyadjusted.

3. Donot look at the focus lens using optical instruments.

4. Recommend not to look at pick up lens for along time.

ACHTUNG:

Dieses Produkt enthälteine Laserdiode. Imenigeschalteten

Zustand wird unsichtbare Laserstrahlung von der Lasereinheit

abgestrahlt. / Wellenlänge :780nm / MaximaleStrahlungsleistung

der Lasereinheit:100 W/VDE/ DieStrahlung an der Lasereinheit

ist ungefährlich, wenn folgende Punkte beachtet werden:

1. DieLasereinheitnicht zerlegen, da dieStrahlung an der

freigelegten Laserdiode gefährlich ist.

2. Den werkseitigjustierten Einstellregler der Lasereinhitnicht

verstellen.

3. Nicht mitoptischen Instrumenten indieFokussierlinse blicken.

4. Nicht über längere ZeitindieFokussierlinse blicken.

ADVARSEL: I dette a apparat anvendes laser.

CAUTION!

THIS PRODUCTUTILIZES A LASER.

USE OFCONTROLS OR ADJUSTMENTS OR PERFORMANCE OFPROCEDURES OTHER THAN

THOSE

SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

Use of Caution Labels

6. Caution for AC Mains Lead

7. Location of Controls

8. The Remote Control

9. Self Diagnostic Function

9.1. Setting of self-diagnosisFunction

9.1.1. Setting of CD self-diagnosismode /

1. Remove the cassette from the deck.

2. Switch to CD function.

3. Press the CD/TAPE STOPkeyof the mainset for more than 2

seconds. Whilepressing thiskey, press the FF keyon the main

set for another 2seconds to enter into the Self-Diagnosismode.

*Even ifSTOP/ FUNCTIONkeyof the mainset ispressed while

the SelfDiagnosismode ison, function shall not be switched.

Instead, confirmation of error numbers shall begin. /

9.1.2. Setting of cassettemechanism self-diagnosismode /

1. Activate the SelfDiagnosismode with the Deck unloaded.

2. The test mode display([T]at the 1st digitshowsTEST )shall be

made and detection shall be executed to check RECINH SW,

HALFSW are inOFF state.

(the tape counter displayisretained )

3. Load acassette tape (with recording preventive tab present )into

adeck and close the cassette holder.

4. Atthisinstant with the cassette loaded inRECINH SW, HALF SW
