Panasonic KX-TVP200BX Manual de usuario

ORDERNO. KMS0006840S3

VOICEPROCESSING SYSTEM

KX-TVP200BX / KX-TVP204X

(for Asia, MiddleNear East and Other areas)

Please fileand use thissupplement manual together with the

service manual for Model KX-TVP200C.

Unauthorized copying and distribution isaviolation of law.

Note:Supplement-1~3 have alreadysuppliedwithprintedmatter. Soplease refertothat.

1. CHANGES

1.1. Subject

Suffix Reason forsuffix change

G H Not Used

H I Change of the software forHardDisk Drive Unit. (H.D.D.1 : Ver. VC1220 VJ11AB)

I J Change of the HardDisk Drive Unit. (There is no change inthe replacement parts list.)

J K Change of the software forHardDisk Drive Unit (H.D.D.1 : Ver. VJ11AB VJ11AC) /

and

change of the software. (IC306 ROM Ver. VC11A VI11A)

1.2. Suffixlocation

1.3. REPLACEMENTPARTS LIST

Ref. No. Part No. Part Name & Description Pcs Remarks Notes

Original Part NewPart

CABINETAND ELECTRICALPARTS

7PSWEVP200BX1 PSWEVP200BX4 HARD DISK DRIVE UNIT 1 1 X

PSWEVP200BX4 PSWEVP200BX5 HARD DISK DRIVE UNIT 1 1 X

CPU CARD PARTS

IC306 PSWITVS200M PSWITVS200M1 IC (ROM) 1 1 X

N.T.(Q)/ KXTVP200BX/ Printed inJapan

MC-Service

Reason

forChange (Symbol:A)Following 1-8reasonsareindicated on the Notesinthe bottomcolumn.

Improve

performance Remarks:

*1. The partsmarked *1hasbeen changed at the sametime.

Change

of materialordimension

meet approved specification

Standardization

Addition

Deletion

Correction

Other

Interchangeability

Code (Symbol:B)Following V-Z interchange abilitiesareindicated on the Notesinthe bottomcolumn.

Parts

Set Production

Original

New

Early(beforechange)

Late(afterchange) Originalornew partsmaybe used inearlyorlateproduction sets.

Useoriginalpartsuntil exhausted, then stocknew parts.

Original

New

Early(beforechange)

Late(afterchange) Originalpartsmaybe used inearlyproduction setsonly. New partsmaybe used inearlyor

late

production sets. Useoriginalpartswherepossible, then stocknew parts.

Original

New

Early(beforechange)

Late(afterchange) New partsonlymaybe used inearlyorlateproduction sets.

Stocknew parts.

Original

New

Early(beforechange)

Late(afterchange) Originalpartsmaybe used inearlyproduction setsonly. New partsmaybe used inlate

production

setsonly. Stockbothoriginaland new parts.

Other

KX-TVP200C

Ref.

No. Part No. Part Name&Description Pcs Remarks Notes Timeof

change

(Suffix)

Original(Old) New

CABINET

AND ELECTRICALPARTS

PQUS141Z PSUS1022Z SPRING 2 *1 1 W

PQHD10011X PQHD10011V SCREW 2 *1 1 W

PSWETVP200C7 PSWETVP200C8 HARD DISK DRIVE UNIT 1 1 X R

2SUP-7(KMS0303680S1)

3SUP-6(KMS0110320S1)

4SUP-5(KMS0106233S1)

5SUP-4(KMS0006841S1)

T.H.

KXTVP200C

KXTVP204CTOP

rights reserved. Unauthorized copying and

distribution is a violation of law.

KX-TVP200C

KX-TVP204C

(for Canada)

VOICE PROCESSING SYSTEM

Please file and use this supplement manual together with the service manual for Model KX-TVP200C,

Order No. KMS9704242A1.

Note:Supplement-1~3 have already supplied with printed matter. So please refer to that.

ORDER NO. KMS0006841S1

1 CHANGES

1.1. Subject

Suffix Reason for suffix change

H→IChange of the software for Hard Disk Drive Unit. (H.D.D.1 : Ver. VCB250→VJB10A)

I→JChange of the software for Hard Disk Drive Unit (H.D.D.1 : Ver. VJB10A→VJB1AB)

and change of the software. (IC306:ROM Ver. V011A→VI11AA)

1.2. Suffix location

1.3. REPLACEMENT PARTS LIST

Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change

(Suffix)

Original Part New Part

CABINET AND ELECTRICAL PARTS

7PSWEVP200C2 PSWETVP200C3 HARD DISK DRIVE UNIT 1 8 X I

PSWETVP200C3 PSWETVP200C4 HARD DISK DRIVE UNIT 1 1 X J

CPU CARD PARTS

IC306 PSWITVS200M PSWITVS200M1 IC (ROM) 1 1 X J

KX-TVP200C / KX-TVP204C

N.T.(Q)

KXTVP200C

Printed in Japan

rights reserved. Unauthorized copying and

distribution is a violation of law.

KX-TVP200C

KX-TVP204C

(for Canada)

Voice Processing System

Please file and use this supplement manual together with the service manual for Model No. KX-TVP200C,

Order No. KMS9704242A1.

Note:Supplement-1~3 have already supplied with printed matter. So please refer to that.

ORDER NO. KMS0303680S1

1 CHANGES

1.1. SUBJECT

KX-TVP200C

Suffix Reason for suffix change

N→OApply to the regulation for Canada. There is no change in the replacement part list.

O→PChange of the software for Hard Disk Drive Unit. ( Ver. VJB1AD→VJB1AE)

P→QChange of H.D.D.

There is no changed in the replacement parts list.

1.2. SUFFIX LOCATION

1.3. REPLACEMENT PARTS LIST

Reason for Change (Symbol:A) Following 1-8 reasons are indicated on the Notes in the bottom column.

1. Improve performance Remark:

*1. Change of company name.

2. Change of material or dimension

3. To meet approved specification

4. Standardization

5. Addition

6. Deletion

7. Correction

8. Other

Interchangeability Code (Symbol:B) Following V-Z interchange abilities are indicated on the Notes in the bottom column.

Parts Set Production

VOriginal

New Early (before change)

Late (after change) Original or new parts may be used in early or late production sets.

Use original parts until exhausted, then stock new parts.

WOriginal

New Early (before change)

Late (after change) Original parts may be used in early production sets only. New parts may be used in early

or late production sets. Use original parts where possible, then stock new parts.

XOriginal

New Early (before change)

Late (after change) New parts only may be used in early or late production sets.

Stock new parts.

YOriginal

New Early (before change)

Late (after change) Original parts may be used in early production sets only. New parts may be used in late

production sets only. Stock both original and new parts.

ZOther

KX-TVP200C

Ref. No. Part No. Part Name & Description Pcs Remarks Notes Time of change

(Suffix)

Original (Old) New

CABINET AND ELECTRICAL PARTS

7PSWETVP200C6 PSWETVP200C7 HARD DISK DRIVE UNIT 1 1 X P

36 PQKM10086E1 PQKM10606N1 CABINET BODY 1 8 W

ACCESSORIES AND PACKING MATERIALS

P1 PSPK1253Z PSPK12553Y PACKING CASE 1*1 8 X

KX-TVP200C / KX-TVP204C

K.H.

KXTVP200C

KXTVP204C

rights reserved. Unauthorized copying and

distribution is a violation of law.

KX-TVP200C

KX-TVP204C

(for Canada)

VOICE PROCESSING SYSTEM

Please file and use this supplement manual together with the service manual for Model No. KX-TVP200C,

Order No. KMS9704242A1.

Note:Supplement-1~3 have already supplied with printed matter. So please refer to that.

ORDER NO. KMS0110320S1
