Panasonic AK-HRP1015G Manual de usuario

DVQP2531ZAW0321AM0 -PS

ENGLISH

For details of operating Remote Operation Panel AK-HRP1015G, please

visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.

html), and refer to the Operating Instructions (HTML or PDF).

Read this document when using the AK-HRP1015G Remote Operation Panel

in conjunction with AW-UE70 Series 4K Integrated Cameras or AW-HE35/

AW-HE38/AW-HE40/AW-HE70 Series HD Integrated Cameras.

Operating Guide

Remote Operation Panel

Model No. AK-HRP1015G

Connecting the Unit to AW-UE70/AW-HE35/AW-

HE38/AW-HE40/AW-HE70 Series Cameras 3

Connection examples 3

Connections 5

Compatible Functions List 6

ROP Menu (when AW-UE70/AW-HE35/AW-

HE38/AW-HE40/AW-HE70 is connected) 9

ROP menu list 9

01 SCENE 13

02 SHUTTER SPEED 14

03 FILTER 15

04 CHROMA 16

05 GAIN 17

06 WHITE BALANCE 18

07 GAMMA 19

08 DETAIL 20

09 COLOR CORRECTION 21

10 DNR 24

11 CONTRAST 25

12 LENS CONTROL 26

13 IRIS RELATIVE 27

14 SYSTEM CAM 28

15 CAMERA MENU CONTROL 29

16 ROP SETTING 30

17 CONNECT SETTING 31

18 ROP IP SETTING 32

19 CAMERA IP SETTING 32

20 SWITCHER LINK 32

21 AW CONTROLLER LINK 32

- 2 -

Table of Contents

Connecting the Unit to AW-UE70/AW-HE35/AW-

HE38/AW-HE40/AW-HE70 Series Cameras

Connection examples

Serial connection with AW-UE70

Supplied AC adapter

[RS-422] connector

AW-UE70

* Prepare a cable that is in accordance

with the following serial connection

cable specifications.

PoE compatible

switching hub or injector

IP connection with AW-UE70

AW-UE70

Supplied AC adapter

LAN cable (straight cable)

Switching hub with

PoE support

[LAN ACT/LINK] connector

- 3 -

Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras

Serial connection with AW-HE35/AW-HE38/AW-HE40/AW-HE70

AW-HE35/AW-HE38/

AW-HE40/AW-HE70

Supplied AC adapter

[RS-422] connector

* Prepare a cable that is in accordance

with the following serial connection

cable specifications.

PoE compatible

switching hub or injector

IP connection with AW-HE35/AW-HE38/AW-

HE40/AW-HE70

Supplied AC adapter

AW-HE35/AW-HE38/

AW-HE40/AW-HE70

LAN cable (straight cable)

Switching hub with

PoE support

[LAN ACT/LINK] connector

Serial connection cable specifications

ヒヤモヮチチュモヵユドラナ⾺⾺⾼⾼ビヤヰヮチチュモヵユドロナピヤヰヮチチヤヰワヵドラナフヤヰヮチチヤヰワヵドロナヤモヮēチンヰヱヤモヮēチンヰヱンヰヱチēチヤモヮンヰヱチēチヤモヮブヤヰヮチチワㄐハチモプヤヰヮチチワㄐハチャヘヤヰヮチチワㄐハチヤベヤヰヮチチワㄐハチュペ

ヒビチヷ

ヒパヨワュヒヨンュヵモロロヺンヹュノヵヹュノヵヹュヌンヹュヌチ⾼チ⾼ビピフブプヘベラㄊㄓㄐㄔㄆホチランヒパモノヒパヱノヒパブドヘピナAW-UE70/AW-HE35/AW-HE38/

AW-HE40/AW-HE70

[RS-422] connector side (RJ45)

AK-HRP1015G

[CCU] connector side

Pin No. Function Polarity Flow of signal

- 4 -

Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras

Connections

Set the connection setting to [Serial(AW3)] or [LAN(AW3)] in the [CONNECT SETTING] menu.

ヒチバチヒヘ

ヤヰワワユヤヵチヴユヵヵリワヨヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤモヮビヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤモヮブヤモヮピヤモヮプヤモヮヒヤモヮフヴㄆㄓㄊ㄂ㄍドモヸピナロモワドモヸピナワヰワワヰワワヰワワヰワ

NOTE

To connect with the AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70, upgrade the system version of the unit to

2.00-00-0.00 or later.

When connecting, observe the following points.

Serial connection

Use a dedicated cable to connect the [CCU] connector of this unit to the [RS-422] connector of the AW-UE70/AW-

HE35/AW-HE38/AW-HE40/AW-HE70.

Use a PoE power supply for the power supply.

LAN connection

Connect the [LAN] connector on this unit to the [LAN ACT/LINK] connector on the AW-UE70/AW-HE35/AW-HE38/AW-

HE40/AW-HE70 using a LAN cable (sold separately).

Configure the camera IP address and port number settings of the connection destinations in [CAMERA IP SETTING] as

well.

This unit can be powered using PoE. Use a switching hub with PoE support.

Use a straight cable (category 5e or higher; up to 100 m (328.0 ft) in length) for the LAN cable (STP).

For details on switching hubs and PoE injectors that have been verified to support PoE, consult with your dealer.

- 5 -

Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras

Compatible Functions List

When the unit is used in conjunction with an AW-UE70 Series 4K Integrated Camera or AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series

HD Integrated Camera, there will be functions that are limited or disabled for some of the unit’s buttons, dials, and other controls. Be sure to

refer to the following table.

Front panel 1

Front panel 2

Front panel 3

Front panel 4

Front panel 5

Front panel 6

Number Part name

✓: Enabled

×: Disabled

Remarks

Front panel 1

[PANEL LOCK] button ✓

[AUTO] button ✓If auto setup has been assigned, this will not

operate.

[BARS] button ✓Only the ON/OFF for the color bar signal

output will function.

[TALLY/CALL] lamp/button ×

[REF. RECALL] button ×

[FILES] button ✓This is always lit.

[SETUP] button ✓

[AUTO IRIS] button ✓

Front panel 2

Function buttons ✓

LCD panel ✓

Menu operation dials ✓

- 6 -

Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras

Number Part name

✓: Enabled

×: Disabled

Remarks

Front panel 3

[GAIN] button ✓When this button is pressed, the gain menu

appears on the LCD panel. The button is lit

during menu display.

[SHT] button ✓When this button is pressed, the shutter

menu appears on the LCD panel. The button

is lit during menu display.

[COLOR] button ✓The menus will switch with each press of the

button. The button is lit during menu display.

[CHROMA] > [COLOR CORRECTION] >

Menu off (status screen)

[FILTER] button ✓When this button is pressed, the filter menu

appears on the LCD panel. The button is lit

during menu display.

[GAMMA] button ✓When this button is pressed, the gamma

menu appears on the LCD panel. The button

is lit during menu display.

[FLARE] button ×

[KNEE] button ×

[DTL] button ✓The menus will switch with each press of the

button. The button is lit during menu display.

[DETAIL] > [DNR] > Menu off (status screen)

Front panel 4

[GAIN], [TEMP], [GAMMA], [SKIN]

adjustment block

✓When [GAIN] is lit, [GAIN R] and [GAIN B] are

adjusted using the red (R) and blue (B)

adjustment dials respectively.

When [TEMP] is lit, [COLOR TEMP] is

adjusted using the green (G) adjustment

dial.

When [GAMMA] is lit, the master gamma is

adjusted using the green (G) adjustment

dial.

[SKIN] adjustment is disabled.

[PED], [FLARE], [B.GAM] adjustment block ✓When [PED] is lit, [M.PED] is adjusted using

the green (G) adjustment dial.

[FLARE] and [B.GAM] adjustment is

disabled.

- 7 -

Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras

Number Part name

✓: Enabled

×: Disabled

Remarks

Front panel 5

[ALM] indicator ✓

[OPT] indicator ×

[EXT] indicator ×

[D.EXT] indicator ✓

Adjustment value display ✓A value is also not displayed when

[SHUTTER] is [SYNC]. The display will be bar

display.

When the shutter speed value is “10000”,

“9999” is displayed.

[ND] indicator ✓This is enabled only for the AW-UE70.

[CC] indicator ✓This lights but does not function.

[IRIS] indicator ✓The iris value is not displayed.

[GAIN] indicator ✓

[PED] indicator ✓

[SHT] indicator ✓

[SYNC] indicator ✓

[DISP] button ✓

[UP (FREE)] button ✓

[DOWN (CHARA)] button ✓

[LOCK] indicator ✓

[SEL] dial ✓

Front panel 6

Memory card slot ✓

Memory card access indicator ✓

Camera number/tally display ✓

[IRIS RELATIVE] button ✓

Torque adjustment screw ✓

IRIS lever ✓

Master pedestal dial ✓

[PREVIEW] button ×

- 8 -

Connecting the Unit to AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 Series Cameras

ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-

HE40/AW-HE70 is connected)

ROP menu list

When an AW-UE70 4K Integrated Camera or AW-HE35/AW-HE38/AW-HE40/AW-HE70 HD Integrated Camera is connected, the ROP

menu will be as follows.

For details on menu operations, refer to the following sections in the Operating Instructions.

“Displaying menus”

“Basic menu operations”

01 SCENE

MANUAL1(push) “MANUAL1(push)” (see page 13)

MANUAL2(push) “MANUAL2(push)” (see page 13)

MANUAL3(push) “MANUAL3(push)” (see page 13)

FULL AUTO(push) “FULL AUTO(push)” (see page 13)

02 SHUTTER SPEED

MODE “MODE” (see page 14)

SPEED “SPEED” (see page 14)

03 FILTER ND “ND” (see page 15)

04 CHROMA LEVEL “LEVEL” (see page 16)

05 GAIN

GAIN “GAIN” (see page 17)

AGC MAX GAIN “AGC MAX GAIN” (see page 17)

06 WHITE BALANCE

MODE “MODE” (see page 18)

COLOR TEMP “COLOR TEMP” (see page 18)

GAIN R “GAIN R” (see page 18)

GAIN B “GAIN B” (see page 18)

07 GAMMA

TYPE “TYPE” (see page 19)

LEVEL “LEVEL” (see page 19)

DRS “DRS” (see page 19)

08 DETAIL

DTL “DTL” (see page 20)

LEVEL H “LEVEL H” (see page 20)

LEVEL L “LEVEL L” (see page 20)

FLESH TONE MD “FLESH TONE MD” (see page 20)

- 9 -

ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected)

09 COLOR CORRECTION

TYPE “TYPE” (see page 22)

COLOR CORRECT “COLOR CORRECT” (see page 22)

SAT “SAT” (see page 22)

PHASE “PHASE” (see page 22)

SAT B “SAT B” (see page 22)

PHASE B “PHASE B” (see page 22)

SAT B_B_Mg “SAT B_B_Mg” (see page 22)

PHASE B_B_Mg “PHASE B_B_Mg” (see page 22)

SAT B_Mg_Mg “SAT B_Mg_Mg” (see page 22)

PHASE B_Mg_Mg “PHASE B_Mg_Mg” (see page 22)

SAT Mg “SAT Mg” (see page 22)

PHASE Mg “PHASE Mg” (see page 22)

SAT Mg_R “SAT Mg_R” (see page 23)

PHASE Mg_R “PHASE Mg_R” (see page 23)

SAT R “SAT R” (see page 23)

PHASE R “PHASE R” (see page 23)

SAT R_R_Yl “SAT R_R_Yl” (see page 23)

PHASE R_R_Yl “PHASE R_R_Yl” (see page 23)

SAT R_Yl_Yl “SAT R_Yl_Yl” (see page 23)

PHASE R_Yl_Yl “PHASE R_Yl_Yl” (see page 23)

SAT Yl “SAT Yl” (see page 23)

PHASE Yl “PHASE Yl” (see page 23)

SAT Yl_Yl_G “SAT Yl_Yl_G” (see page 23)

PHASE Yl_Yl_G “PHASE Yl_Yl_G” (see page 23)

SAT Yl_G_G “SAT Yl_G_G” (see page 23)

PHASE Yl_G_G “PHASE Yl_G_G” (see page 23)

SAT G “SAT G” (see page 23)

PHASE G “PHASE G” (see page 23)

SAT G_Cy “SAT G_Cy” (see page 23)

PHASE G_Cy “PHASE G_Cy” (see page 23)

SAT Cy “SAT Cy” (see page 23)

PHASE Cy “PHASE Cy” (see page 23)

SAT Cy_Cy_B “SAT Cy_Cy_B” (see page 23)

PHASE Cy_Cy_B “PHASE Cy_Cy_B” (see page 23)

SAT Cy_B_B “SAT Cy_B_B” (see page 23)

PHASE Cy_B_B “PHASE Cy_B_B” (see page 23)

10 DNR DNR “DNR” (see page 24)

11 CONTRAST

CONTRAST MODE “CONTRAST MODE” (see page 25)

CONTRAST LEVEL “CONTRAST LEVEL” (see page 25)

FRAME MIX “FRAME MIX” (see page 25)

A.F.MIX MAX GAIN “A.F.MIX MAX GAIN” (see page 25)

DAY/NIGHT “DAY/NIGHT” (see page 25)

12 LENS CONTROL

FOCUS MODE “FOCUS MODE” (see page 26)

FOCUS SPEED “FOCUS SPEED” (see page 26)

FOCUS “FOCUS” (see page 26)

ZOOM WIDE “ZOOM WIDE” (see page 26)

ZOOM SPEED “ZOOM SPEED” (see page 26)

ZOOM TELE “ZOOM TELE” (see page 26)

- 10 -

ROP Menu (when AW-UE70/AW-HE35/AW-HE38/AW-HE40/AW-HE70 is connected)

Otros manuales para AK-HRP1015G

Tabla de contenidos

Otros manuales de Mando a distancia de Panasonic

Panasonic

Panasonic TNQ2AE013 Manual de usuario

Panasonic

Panasonic TY-RM50VW Manual de usuario

Panasonic

Panasonic EUR511112 Manual de usuario

Panasonic

Panasonic EUR7702KE0 Manual de usuario

Panasonic

Panasonic WVCU360C - SYSTEM CONTROLLER Manual de usuario

Panasonic

Panasonic EUR511110 Manual de usuario

Panasonic

Panasonic EUR511170B Manual de usuario

Panasonic

Panasonic CZ-RD52CU Manual de usuario

Panasonic

Panasonic aw-he40 series Manual de usuario

Panasonic

Panasonic RAK-P001 Instrucciones de funcionamiento

Panasonic

Panasonic CZ-RTC6BL Manual de usuario

Panasonic

Panasonic CZ-RTC4 Manual de usuario

Panasonic

Panasonic EUR511500 Manual de usuario

Panasonic

Panasonic cz-rd515u Manual de usuario

Panasonic

Panasonic CZ-RD514C Manual de instalación y operación

Panasonic

Panasonic AW-RP150G Manual de usuario

Panasonic

Panasonic EUR501453 Manual de usuario

Panasonic

Panasonic CZ-RWST2U Manual de usuario

Panasonic

Panasonic CZ-RTC5B Manual de usuario

Panasonic

Panasonic AKHRP931P - RMT PANEL - AKHC930 Manual de usuario

Panasonic

Panasonic EUR511170 Manual de usuario

Panasonic

Panasonic WV-CU161 Manual de usuario

Panasonic

Panasonic EUR7603Z50 Manual de usuario

Panasonic

Panasonic CZ-RL511D Manual de instalación y operación

Manuales populares de Mando a distancia de otras marcas

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación

Invacare

Invacare G91S Manual de usuario
