Panasonic Projector RS-232C Control Specifications

PT-DW5100/D5700/D4000

2/51

Using the Serial Terminals

1.Basic Format

Transmission from the computer begins with STX, then the ID, command, parameter, and ETX are sent in this

order. Add parameters according to the details of control.

Basic control command (without parameter)

Start

(STX) ID Separator

(semicolon) Command End

(ETX)

1 byte 4 bytes 1 byte 3 bytes 1 byte

Basic control command (with parameters)

Start

(STX) ID Separator

(semicolon) Command Separator

(colon) Parameters End

(ETX)

1 byte 4 bytes 1 byte 3 bytes 1 byte Undefined length 1 byte

Basic control command (with subcommand)

Start

(STX) ID Separator

(semicolon) Command Separator

(colon)

1 byte 4 bytes 1 byte 3 bytes 1 byte

Subcommand Operation Sign Parameters End

(ETX)

5 bytes 1 byte 1 byte 5 bytes 1 byte

Operation

Specifies the method of processing the value specified by parameters.

Code Description

=Sets the value specified by the parameter.

_ (underbar) Adds the value specified by the parameter to the current value.

Sign

Specifies positive or negative of the value specified by parameters.

Code Description

+The value specified by the parameter is a positive value or 0 (zero).

The value specified by the parameter is a negative value.

Parameters

Specify the setting or adjustment value by right justification (0 is not suppressed).

For example, when the setting value is "1", set it as "00001".

3/51

ID of the basic control command



ID 4 bytes

String



ID 4 bytes

String



ID 4 bytes

String



ID 4 bytes

String

ALL ADZZ



ID23 AD23



ID46 AD46 Group E AD0E

ID1 AD01



ID24 AD24



ID47 AD47 Group F AD0F

ID2 AD02



ID25 AD25



ID48 AD48 Group G AD0G

ID3 AD03



ID26 AD26



ID49 AD49 Group H AD0H

ID4 AD04



ID27 AD27



ID50 AD50 Group I AD0I

ID5 AD05



ID28 AD28



ID51 AD51 Group J AD0J

ID6 AD06



ID29 AD29



ID52 AD52 Group K AD0K

ID7 AD07



ID30 AD30



ID53 AD53 Group L AD0L

ID8 AD08



ID31 AD31



ID54 AD54 Group M AD0M

ID9 AD09



ID32 AD32



ID55 AD55 Group N AD0N

ID10 AD10



ID33 AD33



ID56 AD56 Group O AD0O

ID11 AD11



ID34 AD34



ID57 AD57 Group P AD0P

ID12 AD12



ID35 AD35



ID58 AD58 Group Q AD0Q

ID13 AD13



ID36 AD36



ID59 AD59 Group R AD0R

ID14 AD14



ID37 AD37



ID60 AD60 Group S AD0S

ID15 AD15



ID38 AD38



ID61 AD61 Group T AD0T

ID16 AD16



ID39 AD39



ID62 AD62 Group U AD0U

ID17 AD17



ID40 AD40



ID63 AD63 Group V AD0V

ID18 AD18



ID41 AD41



ID64 AD64 Group W AD0W

ID19 AD19



ID42 AD42



Group A AD0A Group X AD0X

ID20 AD20



ID43 AD43



Group B AD0B Group Y AD0Y

ID21 AD21



ID44 AD44



Group C AD0C Group Z AD0Z

ID22 AD22



ID45 AD45



Group D AD0D

4/51

Response (Callback) of the basic control command

In the period when commands can be accepted

Differs according to each command.

In the period when commands cannot be accepted

Hexadecimal 02h 45h 52h 34h 30h 31h 03h

Character ER401

In case of the parameter error or REMOTE2 effective

Hexadecimal 02h 45h 52h 34h 30h 32h 03h

Character ER402

Attention:

• No command may be sent or received for 10 to 60 seconds after the lamp starts lighting. Try sending any

command after that period has elapsed.

• When sending several commands, be sure to wait for a response from the projector, and send the next

command after 0.5 seconds or more pass.

• It might take time by the time the response returns because the command is processed in the projector.

Set the time-out to ten seconds or more.

Note:

• This projector will respond to the computer only in the following cases:

If the sent ID coincides with the projector ID,

VPS SYSTEM in RS232C settings of this projector is MASTER and the sent ID is ALL, or

If Group (AZ) of the sent ID coincides with GROUP in RS232C settings of this projector and GROUP in

RS232C settings of this projector is MASTER.

5/51

2.Basic Control Command

Explanatory notes

Yes: Enable

No: Disable

2.1. Power ON (Lamp ON)

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 50h 4Fh 4Eh 03h

Character ADZZ;PON

Response (Callback)

In the period when the command can be accepted (This command in power-on condition is included)

Hexadecimal 02h 50h 4Fh 4Eh 03h

Character PON

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

Yes Yes Yes Yes Yes Yes (Yes)

Note:

• When you confirm whether to have succeeded in power-on, confirm it by QPW (query power condition) command after

receiving the callback of PON command.

• REMOTE2 is given to priority. Calls back ER402 when the parameter is different from the setting of REMOTE2.

2.2. Power OFF (Standby)

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 50h 4Fh 46h 03h

Character ADZZ;POF

Response (Callback)

In the period when the command can be accepted (This command in power-off condition is included)

Hexadecimal 02h 50h 4Fh 46h 03h

Character POF

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

Yes Yes Yes Yes Yes Yes (Yes)

Note:

• When you confirm whether to have succeeded in power-off, confirm it by QPW (Query Power) command after receiving

the callback of POF command.

• REMOTE2 is given to priority. Calls back ER402 when the parameter is different from the setting of REMOTE2.

2.3. FREEZE

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 46h 5Ah 3Ah *1 03h

Character ADZZ;OFZ:*2

Parameters (*1, *2)

Freeze OFF Freeze ON

Hexadecimal 30h 31h

Character 01

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 46h 5Ah 3Ah *1 03h

Character OFZ:*2

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No No No Yes Yes Yes

2.4. AUTO SETUP

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 41h 53h 03h

Character ADZZ;OAS

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 41h 53h 03h

Character OAS

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No No No Yes Yes Yes

Note:

• This command is acceptable only when analog RGB signals (except a part of high dot clock signals) or DVI signals are

input. In other cases, ER401 is returned.

6/51

2.5. SHUTTER

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 48h 3Ah *1 03h

Character ADZZ;OSH:*2

Parameters (*1, *2)

Shutter OFF Shutter ON

Hexadecimal 30h 31h

Character 01

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 48h 3Ah *1 03h

Character OSH:*2

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

Yes No Yes Yes Yes Yes No

Note:

• REMOTE2 is given to priority. Calls back ER402 when the parameter is different from the setting of REMOTE2.

2.6. Input Select

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 49h 49h 53h 3Ah

Character ADZZ;IIS:

Hexadecimal *1 *3 *5 03h

Character *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

RGB1 RGB2

Hexadecimal 52h 47h 31h 52h 47h 32h

Character RG1RG2

VIDEO S-VIDEO

Hexadecimal 56h 49h 44h 53h 56h 44h

Character VIDSVD

DVI

Hexadecimal 44h 56h 49h

Character DVI

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 49h 49h 53h 3Ah *1 *3 *5 03h

Character IIS:*2 *4 *6

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No Yes Yes Yes Yes (Yes)

Note:

• REMOTE2 is given to priority. Calls back ER402 if the input select of REMOTE2 is available.

2.7. TEST PATTERN

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 54h 53h 3Ah

Character ADZZ;OTS:

Hexadecimal *1 *3 03h

Character *2 *4

Parameters (*1, *2, *3, *4)

OFF White Black Flag Window

Hexadecimal 30h 30h 30h 31h 30h 32h 30h 33h 30h 35h

Character 0001020305

Reversed

window Focus Colorbar Window *

Hexadecimal 30h 36h 30h 37h 30h 38h 31h 30h

Character 06070810

* The frame of 16:9 is displayed for PT-D5700 series, and the frame of 4:3 is displayed for PT-DW5100 series.

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 54h 53h 3Ah *1 *3 03h

Character OTS:*2 *4

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No Yes Yes Yes Yes Yes

7/51

2.8. ON SCREEN

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Fh 53h 3Ah *1 03h

Character ADZZ;OOS:*2

Parameters (*1, *2)

OSD OFF OSD ON

Hexadecimal 30h 31h

Character 01

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Fh 53h 3Ah *1 03h

Character OOS:*2

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No Yes Yes Yes Yes Yes

2.9. MENU key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Dh 4Eh 03h

Character ADZZ;OMN

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Dh 4Eh 03h

Character OMN

2.10. ENTER key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 45h 4Eh 03h

Character ADZZ;OEN

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 45h 4Eh 03h

Character OEN

2.11. Up () key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 55h 03h

Character ADZZ;OCU

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 55h 03h

Character OCU

2.12. Down () key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 44h 03h

Character ADZZ;OCD

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 44h 03h

Character OCD

2.13. Left () key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 4Ch 03h

Character ADZZ;OCL

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 4Ch 03h

Character OCL

2.14. Right () key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 52h 03h

Character ADZZ;OCR

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 52h 03h

Character OCR

2.15. STD key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 54h 03h

Character ADZZ;OST

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 54h 03h

Character OST

8/51

2.16. FUNC1 key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 46h 43h 31h 03h

Character ADZZ;FC1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 46h 43h 31h 03h

Character FC1

2.17. SYSTEM SEL key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 53h 4Ch 03h

Character ADZZ;OSL

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 4Ch 03h

Character OSL

2.18. ASPECT key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 53h 31h 03h

Character ADZZ;VS1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 53h 31h 03h

Character VS1

2.19. Numeric key

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Eh 4Bh 3Ah *1 03h

Character ADZZ;ONK:*2

Parameters (*1, *2)

0 key 1 key 2 key 3 key 4 key 5 key 6 key 7 key 8 key 9 key

Hexadecimal 30h 31h 32h 33h 34h 35h 36h 37h 38h 39h

Character 0123456789

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Eh 4Bh 3Ah *1 03h

Character ONK:*2

2.20. LAMP SELECT

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Ch 50h 4Dh 3Ah *1 03h

Character ADZZ;LPM:*2

Parameters (*1, *2)

DUAL SINGLE LAMP1 LAMP2

Hexadecimal 30h 31h 32h 33h

Character 0123

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Ch 50h 4Dh 3Ah *1 03h

Character LPM:*2

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No Yes Yes Yes No Yes Yes

Note:

• Calls back ER401 while the lamp has been switched.

2.21. Installation (FRONT/REAR & DESK/CEILING)

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 49h 4Ch 3Ah *1 03h

Character ADZZ;OIL:*2

Parameters (*1, *2)

FRONT/DESK REAR/DESK FRONT/CEILING REAR/CEILING

Hexadecimal 30h 31h 32h 33h

Character 0123

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 49h 4Ch 3Ah *1 03h

Character OIL:*2

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No Yes Yes Yes No Yes Yes

9/51

2.22. LAMP POWER

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Ch 50h 3Ah *1 03h

Character ADZZ;OLP:*2

Parameters (*1, *2)

HIGH LOW

Hexadecimal 30h 31h

Character 01

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Ch 50h 3Ah *1 03h

Character OLP:*2

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No Yes Yes Yes No Yes Yes

2.23. SUB MEMORY CHANGE

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 43h 53h 3Ah

Character ADZZ;OCS:

Hexadecimal *1 *3 03h

Character *2 *4

Parameters (*1, *2, *3, *4)

Sets 00 when the sub memory is not used.

Not used 1234

Hexadecimal 30h 30h 30h 31h 30h 32h 30h 33h 30h 34h

Character 0001020304

5678

Hexadecimal 30h 35h 30h 36h 30h 37h 30h 38h

Character 05060708

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 53h 3Ah *1 *3 03h

Character OCS:*2 *4

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No No Yes No Yes Yes

2.24. SUB MEMORY STORE

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 45h 53h 3Ah

Character ADZZ;OES:

Hexadecimal *1 *3 03h

Character *2 *4

Parameters (*1, *2, *3, *4)

1234

Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h

Character 01020304

5678

Hexadecimal 30h 35h 30h 36h 30h 37h 30h 38h

Character 0 5 0 6 0 7 0 8

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 45h 53h 3Ah *1 *3 03h

Character O E S : *2 *4

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No No Yes No Yes Yes

10/51

2.25. SUB MEMORY DELETE

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 44h 53h 3Ah

Character A D Z Z ; O D S :

Hexadecimal *1 *3 03h

Character *2 *4

Parameters (*1, *2, *3, *4)

1 2 3 4

Hexadecimal 30h 31h 30h 32h 30h 33h 30h 34h

Character 0 1 0 2 0 3 0 4

5 6 7 8

Hexadecimal 30h 35h 30h 36h 30h 37h 30h 38h

Character 0 5 0 6 0 7 0 8

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 44h 53h 3Ah *1 *3 03h

Character O D S : *2 *4

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No No Yes No Yes Yes

2.26. PICTURE MODE

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 50h 4Dh 3Ah

Character A D Z Z ; V P M :

Hexadecimal *1 *3 *5 03h

Character *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

DYNAMIC GRAPHIC

Hexadecimal 44h 59h 4Eh 47h 52h 41h

Character D Y N G R A

STANDARD CINEMA NATURAL

Hexadecimal 53h 54h 44h 43h 49h 4Eh 4Eh 41h 54h

Character S T D C I N N A T

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 50h 4Dh 3Ah *1 *3 *5 03h

Character V P M : *2 *4 *6

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No Yes Yes No Yes Yes

2.27. COLOR

Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 43h 4Fh 3Ah

Character A D Z Z ; V C O :

Hexadecimal *1 *3 *5 03h

Character *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

31 30 29

Hexadecimal 30h 30h 31h 30h 30h 32h 30h 30h 33h

Character 0 0 1 0 0 2 0 0 3

+29 +30 +31

Hexadecimal 30h 36h 31h 30h 36h 32h 30h 36h 33h

Character 0 6 1 0 6 2 0 6 3

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 43h 4Fh 3Ah *1 *3 *5 03h

Character V C O : *2 *4 *6

Acceptability

SECURITY STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2

No No No Yes No Yes Yes

Otros manuales para PT-D4000

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Proyector de Panasonic

Panasonic

Panasonic PT-L780NTE Manual de usuario

Panasonic

Panasonic PT-RZ670 series Instrucciones de instalación

Panasonic

Panasonic PT-51G44 Manual de usuario

Panasonic

Panasonic PTL5 - LCD PROJECTOR Manual de usuario

Panasonic

Panasonic PT-D5700 Manual de usuario

Panasonic

Panasonic PT-FW300NT Manual del sistema

Panasonic

Panasonic PT-D5700U - XGA DLP Projector Manual de usuario

Panasonic

Panasonic PT-EZ770 Series Manual de usuario

Panasonic

Panasonic PTL592U - LCD PROJECTOR Manual de usuario

Panasonic

Panasonic PT-AE3000E Manual de usuario

Panasonic

Panasonic PT-VW431DU Manual de usuario

Panasonic

Panasonic PT-LC75E Manual de usuario

Panasonic

Panasonic PT-LB78 Manual de usuario

Panasonic

Panasonic PT-RW330 Guía

Panasonic

Panasonic PT-DS20KU Manual de usuario

Panasonic

Panasonic PT51G53 - 51" PROJECTION TV Manual de usuario

Panasonic

Panasonic PTL795U - LCD PROJECTION Manual de usuario

Panasonic

Panasonic PTLB20NTU - PROJECTOR- NETWORK IB Manual de usuario

Panasonic

Panasonic PT-DW7000E-K Manual de usuario

Panasonic

Panasonic PTL520U - LCD PROJECTOR Manual de usuario

Panasonic

Panasonic PT-F200NT Manual de usuario

Panasonic

Panasonic PT-D4000E Manual de usuario

Panasonic

Panasonic PT-LB3U Manual de usuario

Panasonic

Panasonic PTP1SDU - LCD PROJECTOR Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Epson

Epson VS400 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Epson

Epson PowerLite Pro Cinema 6020UB Manual de usuario

Epson

Epson PowerLite Home Cinema 705HD Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario
