Panasonic Projector RS-232C Control Specifications

PT-FW300NT/FW300/F300NT/F300

2/49

Using the Serial Terminal

1. Basic Format

Transmission from the computer begins with STX, then the command, parameter and ETX are sent in this

order.

Add parameters according to the details of control.

Basic control command (without parameter)

Start (STX) Command End (ETX)

1 byte 3 bytes 1 byte

Basic control command (with parameters)

Start (STX) Command Separator

(colon)

Parameters End (ETX)

1 byte 3 bytes 1 byte Undefined length 1 byte

Response (Callback) of the basic control command

In the period when the command can be accepted

Differs according to each command.

In the period when commands cannot be accepted or the command does not exist

Hexadecimal 02h 45h 52h 34h 30h 31h 03h

Character E R 4 0 1

In case of the parameter error

Hexadecimal 02h 45h 52h 34h 30h 32h 03h

Character E R 4 0 2

Notes:

• When sending several commands, be sure to wait for a response from the projector, and send the next

command after 0.5 seconds or more pass.

• It might take time by the time the response returns because the command is processed in the

projector. Set the time-out to 10 seconds or longer.

3/49

2. Basic Control Command

Explanatory notes

○: Yes (Enable)

×: No (Disable)

△: Case by case (Refer to the note.)

2.1. Power ON (Lamp ON)

Hexadecimal 02h 50h 4Fh 4Eh 03h

Character P O N

Response (Callback)

In the period when the command can be accepted (This command in power-on condition is included.)

Hexadecimal 02h 50h 4Fh 4Eh 03h

Character P O N

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○○○○△

Notes:

• When you confirm whether to have succeeded in power-on, confirm it by QPW (Query Power) command after

receiving the callback of PON command.

• When REMOTE is effective, ER401 is returned as a response (callback).

2.2. Power OFF (Standby)

Hexadecimal 02h 50h 4Fh 46h 03h

Character P O F

Response (Callback)

In the period when the command can be accepted (This command in power-off condition is included.)

Hexadecimal 02h 50h 4Fh 46h 03h

Character P O F

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○○○○△

Notes:

• When you confirm whether to have succeeded in power-off, confirm it by QPW (Query Power) command after

receiving the callback of POF command.

• When REMOTE is effective, ER401 is returned as a response (callback).

2.3. AUTO SETUP

Hexadecimal 02h 4Fh 41h 53h 03h

Character O A S

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 41h 53h 03h

Character O A S

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××△×○

Note:

• During NO SIGNAL, this command is available only when SIGNAL SEARCH is ON.

2.4. AV MUTE

Hexadecimal 02h 4Fh 53h 48h

3Ah

*1 03h

Character O S H : *2

Parameters (*1, *2)

AV MUTE OFF AV MUTE ON

Hexadecimal 30h 31h

Character 0 1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 48h 3Ah *1 03h

Character O S H : *2

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××○○○

4/49

2.5. FREEZE

Hexadecimal 02h 4Fh 46h 5Ah

3Ah

*1 03h

Character O F Z : *2

Parameters (*1, *2)

FREEZE OFF FREEZE ON

Hexadecimal 30h 31h

Character 0 1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 46h 5Ah 3Ah *1 03h

Character O F Z : *2

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.6. INPUT SELECT

Hexadecimal 02h 49h 49h 53h 3Ah

*1 *3 *5 03h

Character I I S : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

COMPUTER1 COMPUTER2

Hexadecimal 52h 47h 31h 52h 47h 32h

Character R G 1 R G 2

VIDEO S-VIDEO

Hexadecimal 56h 49h 44h 53h 56h 44h

Character V I D S V D

DVI NETWORK

Hexadecimal 44h 56h 49h 4Eh 57h 50h

Character ＤV I N W P

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 49h 49h 53h 3Ah *1 *3 *5 03h

Character I I S : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

×△○○△

Notes:

• During STANDBY, this command is available only when IN STANDBY MODE is ON.

• REMOTE is given to priority. Calls back ER402 if INPUT SELECT by REMOTE is effective.

2.7. MENU

Hexadecimal 02h 4Fh 4Dh 4Eh 03h

Character O M N

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Dh 4Eh 03h

Character O M N

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

2.8. ENTER

Hexadecimal 02h 4Fh 45h 4Eh 03h

Character O E N

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 45h 4Eh 03h

Character O E N

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

5/49

2.9. Navigation Up (↑)

Hexadecimal 02h 4Fh 43h 55h 03h

Character O C U

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 55h 03h

Character O C U

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

2.10. Navigation Down (↓)

Hexadecimal 02h 4Fh 43h 44h 03h

Character O C D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 44h 03h

Character O C D

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

2.11. Navigation Left (←)

Hexadecimal 02h 4Fh 43h 4Ch 03h

Character O C L

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 4Ch 03h

Character O C L

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

2.12. Navigation Right (→)

Hexadecimal 02h 4Fh 43h 52h 03h

Character O C R

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 43h 52h 03h

Character O C R

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

2.13. DEFAULT

Hexadecimal 02h 4Fh 53h 54h 03h

Character O S T

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 53h 54h 03h

Character O S T

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

2.14. RETURN

Hexadecimal 02h 4Fh 42h 4Bh 03h

Character O B K

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 42h 4Bh 03h

Character O B K

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

○×○×○

6/49

2.15. VOLUME +

Hexadecimal 02h 41h 55h 55h 03h

Character A U U

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 41h 55h 55h 03h

Character A U U

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

×△××○

Note:

• During STANDBY, this command is available only when IN STANDBY MODE is ON.

2.16. VOLUME -

Hexadecimal 02h 41h 55h 44h 03h

Character A U D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 41h 55h 44h 03h

Character A U D

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

×△××○

Note:

• During STANDBY, this command is available only when IN STANDBY MODE is ON.

2.17. INDEX-window

Hexadecimal 02h 4Fh 49h 58h 03h

Character O I X

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 49h 58h 03h

Character O I X

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.18. DIGITAL ZOOM +

Hexadecimal 02h 44h 5Ah 55h 03h

Character D Z U

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 44h 5Ah 55h 03h

Character D Z U

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.19. DIGITAL ZOOM -

Hexadecimal 02h 44h 5Ah 44h 03h

Character D Z D

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 44h 5Ah 44h 03h

Character D Z D

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

7/49

2.20. COMPUTER SEARCH

Hexadecimal 02h 4Fh 50h 43h 03h

Character O P C

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 50h 43h 03h

Character O P C

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××○×○

Note:

• This command is available only for PT-FW300NT**/F300NT**.

2.21. PAGE Up (↑)

Hexadecimal 02h 4Fh 55h 50h 03h

Character O U P

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 55h 50h 03h

Character O U P

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.22. PAGE Down (↓)

Hexadecimal 02h 4Fh 44h 50h 03h

Character O D P

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 44h 50h 03h

Character O D P

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.23. MULTI-LIVE

Hexadecimal 02h 4Fh 4Dh 4Ch 03h

Character O M L

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 4Dh 4Ch 03h

Character O M L

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

8/49

2.24. PICTURE MODE

Hexadecimal 02h 56h 50h 4Dh 3Ah *1 *3 *5 03h

Character V P M : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

DYNAMIC NATURAL STANDARD BLACKBOARD

Hexadecimal 44h 59h 4Eh 4Eh

41h

54h

53h

54h

44h 42h 42h 44h

Character D Y N N A T S T D B B D

CINEMA

Hexadecimal 43h 49h 4Eh

Character C I N

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 50h 4Dh

3Ah

*1 *3 *5 03h

Character V P M : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

Note:

• Parameters "NAT" is available when still image is displayed and "CIN" is available when moving image is

displayed.

2.25. CONTRAST

Hexadecimal 02h 56h 43h 4Eh

3Ah

*1 *3 *5 03h

Character V C N : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

－32 －31 －30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character －3 2 －3 1 －3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 43h 4Eh 3Ah *1 *3 *5 03h

Character V C N : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.26. BRIGHTNESS

Hexadecimal 02h 56h 42h 52h

3Ah

*1 *3 *5 03h

Character V B R : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

－32 －31 －30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character －3 2 －3 1 －3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 42h 52h 3Ah *1 *3 *5 03h

Character V B R : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

9/49

2.27. COLOR

Hexadecimal 02h 56h 43h 4Fh

3Ah

*1 *3 *5 03h

Character V C O : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

－32 －31 －30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character －3 2 －3 1 －3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 43h 4Fh 3Ah *1 *3 *5 03h

Character V C O : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

Note:

• This command is acceptable only when moving image is displayed. In other cases, ER401 is returned.

2.28. TINT

Hexadecimal 02h 56h 54h 4Eh

3Ah

*1 *3 *5 03h

Character V T N : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

－32 －31 －30

Hexadecimal 2Dh 33h 32h 2Dh

33h 31h 2Dh

33h 30h

Character －3 2 －3 1 －3 0

30 31 32

Hexadecimal 30h 33h 30h 30h 33h 31h 30h 33h 32h

Character 0 3 0 0 3 1 0 3 2

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 54h 4Eh 3Ah *1 *3 *5 03h

Character V T N : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

Note:

• This command is acceptable only when moving image is displayed. In other cases, ER401 is returned.

2.29. SHARPNESS

Hexadecimal 02h 56h 53h 52h

3Ah

*1 *3 *5 03h

Character V S R : *2 *4 *6

Parameters (*1, *2, *3, *4, *5, *6)

0 1 2

Hexadecimal 30h 30h 30h 30h 30h 31h 30h 30h 32h

Character 0 0 0 0 0 1 0 0 2

13 14 15

Hexadecimal 30h 31h 33h 30h 31h 34h 30h 31h 35h

Character 0 1 3 0 1 4 0 1 5

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 53h 52h 3Ah *1 *3 *5 03h

Character V S R : *2 *4 *6

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

10/49

2.30. COLOR TEMPERATURE

Hexadecimal 02h 4Fh 54h 45h

3Ah

*1 03h

Character O T E : *2

Parameters (*1, *2)

LOW DEFAULT HIGH

Hexadecimal 30h 31h 32h

Character 0 1 2

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 4Fh 54h 45h 3Ah *1 03h

Character O T E : *2

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

2.31. DAYLIGHT VIEW

Hexadecimal 02h 56h 58h 58h

3Ah

44h

4Ch

56h

49h

Character V X X : D L V I

Hexadecimal 30h 3Dh 2Dh *1 *3 *5 *7 *9 03h

Character 0 = + *2 *4 *6 *8 *10

Parameters (*1, *2, *3, *4, *5, *6, *7, *8, *9, *10)

FRONT INSTALLATION

OFF

Hexadecimal 30h 30h 30h 30h 30h

Character 0 0 0 0 0

AUTO

Hexadecimal 30h 30h 30h 30h 31h

Character 0 0 0 0 1

Hexadecimal 30h 30h 30h 30h 32h

Character 0 0 0 0 2

REAR INSTALLATION

OFF

Hexadecimal 30h 30h 30h 30h 30h

Character 0 0 0 0 0

Hexadecimal 30h 30h 30h 30h 31h

Character 0 0 0 0 1

Response (Callback)

In the period when the command can be accepted

Hexadecimal 02h 56h 58h 58h 3Ah 44h 4Ch 56h 49h

Character V X X : D L V I

Hexadecimal 30h 3Dh 2Dh *1 *3 *5 *7 *9 03h

Character 0 = + *2 *4 *6 *8 *10

Acceptability

SECURITY STANDBY NO SIGNAL

AV MUTE

REMOTE

××××○

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Proyector de Panasonic

Panasonic

Panasonic PT-TW231RU Manual de usuario

Panasonic

Panasonic PT-VX41U Manual de usuario

Panasonic

Panasonic PT-TX430 Instrucciones de funcionamiento

Panasonic

Panasonic PT-EZ770 Series Manual de usuario

Panasonic

Panasonic PT-REQ12 Series Manual de usuario

Panasonic

Panasonic PT-TW340 Manual de usuario

Panasonic

Panasonic PTL797U - LCD PROJECTOR Manual de usuario

Panasonic

Panasonic PTF100U - LCD PROJECTOR Manual de usuario

Panasonic

Panasonic PT-RZ470EAK Instrucciones de funcionamiento

Panasonic

Panasonic PTLB10SU - LCD PROJECTOR Manual de usuario

Panasonic

Panasonic PT-CX200U Manual de usuario

Panasonic

Panasonic PT-LB90 Series Manual de usuario

Panasonic

Panasonic PT-LW330 Manual de usuario

Panasonic

Panasonic DLP PT-DZ12000E Manual de usuario

Panasonic

Panasonic PT-VW330U Instrucciones de instalación

Panasonic

Panasonic PT-LB10NTU - Mobile Proj XGA 2000 Lumens 4.9LBS Cross Platform... Manual de usuario

Panasonic

Panasonic Tentative PT-LB50NTU Manual de usuario

Panasonic

Panasonic PT-LC56E Manual de usuario

Panasonic

Panasonic PT-DW10000 Manual de usuario

Panasonic

Panasonic PT-DW7000 Manual de usuario

Panasonic

Panasonic PT-D4000 Manual del sistema

Panasonic

Panasonic PT-F100NT Manual del sistema

Panasonic

Panasonic PT-LB3E Manual del propietario

Panasonic

Panasonic PT-DW530 Manual del sistema

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Epson

Epson VS400 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Epson

Epson PowerLite Pro Cinema 6020UB Manual de usuario

Epson

Epson PowerLite Home Cinema 705HD Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario
