Panasonic WORKIO DP-CL21 Manual de usuario

Settings and Printing Network

Maintenance and Spec.

User Replaceable Components . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Upgrade Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Cleaning the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

External . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Internal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Clearing a Jam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Jam 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Jam 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Jam 3, 5, 6, 8, 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Jam 4, 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Jam 21, 22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Jam 31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Warning / Printer Error Messages . . . . . . . . . . . . . . . . . . . . . . . 52

Printer LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Repacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

HOST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Parallel (IEEE1284) Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

USB (Universal Serial Bus) Interface. . . . . . . . . . . . . . . . . . . . . . . 102

Network Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Maintenance and

Specifications

User Replaceable Components

Settings and Printing Network

Maintenance and Spec.

When the printer panel indicates that a supply needs to be replaced, make sure that you have

replacement supplies (see below) on hand. The printer may continue to print until the supply is

completely used up.

• Toner cartridge

• Waste toner cartridge

• Print cartridge

• Fuser unit

• Accumulator unit

• Transfer roller

Please contact the reseller from which the printer was purchased.

*1The rated life expectancy of each consumable is based on printing under specific operating

conditions such as page coverage for a particular page size (5% coverage per color at 600 x 600

dpi resolution on letter size paper). The actual consumables life will vary depending on its use

and other printing variables including page coverage, page size, media type, print resolution,

continuous or intermittent printing, number of color planes, ambient temperature and humidity.

*2Printer includes free starter toner cartridges that yield 2,500 pages (based on 5% page coverage

per color).

*3Ready, Ready(PCM), Processing, Printing or Power Save etc. is displayed in the upper line of

LCD.

User Replaceable Components

Printer component Printer panel message Average life*1

Toner cartridge

(Have the <Color> toner cartridge available.)

5,000 pages*2

(5% coverage)

(Replace the <Color> toner cartridge.)

(Status)*

Low <Color> Toner

TC- <Color>

Replace

User Replaceable Components

Settings and Printing Network

Maintenance and Spec.

*1Ready, Ready(PCM), Processing, Printing or Power Save etc. is displayed in the upper line of

LCD.

Printer component Printer panel message Average life

Waste toner cartridge

(Have the waste toner cartridge available.)

24,000 pages

(Black and White -

5% coverage)

6,000 pages

(Full color -

5% coverage)

(Replace the waste toner cartridge.)

Print cartridge

(Have the black print cartridge available.)

13,000 pages

(Replace the black print cartridge.)

(Have the color print cartridge available.)

13,000 pages

(Replace the color print cartridge.)

Fuser unit

(Have the fuser unit available.)

100,000 pages

(Replace the fuser unit.)

(Status)*

WTC Full

WTC

Replace

(Status)*

PC-Black wearing out

(Status)*

PC-Black Replace

(Status)*

PC-Color wearing out

(Status)*

PC-Color Replace

(Status)*

FSR wearing out

(Status)*

FSR Replace

User Replaceable Components

Settings and Printing Network

Maintenance and Spec.

*1Ready, Ready(PCM), Processing, Printing or Power Save etc. is displayed in the upper line of

LCD.

Printer component Printer panel message Average life

Accumulator unit

(Have the accumulator unit available.)

83,000 pages

(Replace the accumulator unit.)

Transfer roller

(Have the transfer roller available.)

100,000 pages

(Replace the transfer roller.)

(Status)*

AU wearing out

(Status)*

AU Replace

(Status)*

TR wearing out

(Status)*

TR Replace

User Replaceable Components

Settings and Printing Network

Maintenance and Spec.

Example (5% coverage)

!Waste Disposal Method

Waste material may be dumped or incinerated under conditions which meet all federal, state and local

environmental regulations.

WARNING

• Do not incinerate toner or toner containers. Toner dust may cause flashback when exposed to an

open flame.

Congratulations on your purchase of the XX-XXXX, the three-in-one solution to today's office

needs. This amasing little desktop unit can be used as a : Printer, Scanner, Copier.

Printing Method:

Print Speed:

Resolution:

Paper Feed:

Paper Outout:

Software Emulation:

Paper Size/Weight:

Memory Capacity:

Dimensions:

Mass (Weight):

Consumables:

Noise Level:

CPU:

Operating Environment:

Storing Environment:

Congratulations on your purchase of the XX-XXXX, the three-in-one solution to today's office

needs. This amasing little desktop unit can be used as a : Printer, Scanner, Copier.

Personal Image Editing System

Model No. XX-XXXX

Printer Specification

Other Specification

Feature:

❈Application Soft : Text Bridge, Card Scan

Semiconductor Laser Electro-Photography

X ppm maximum (A4 size paper, text mode, 5 % image area)

600 dpi X 600 dpi

1 Multi-purpose manual feed up to 250 sheets of paper [75 g/m2(20 lbs.)]

Face-down paper ejection (up to 150 sheets) [75 g/m2(20 lbs.)]

GDI + Soft XXXX

Letter, Legal, A4, Envelope, Executive, OHP, Label

2 MB

399 (W) X 390 (D) X 254 (H) mm (15.7" X 15.4" X 10")

Approx. 10 Kg (22 lbs.)

Starter toner cartridge : 20,000 pages average

Toner cartridge: 4,000 pages average

Drum unit: 20,000 pages average

Printing: 48 dBA

Stadby: 27 dBA

Intel 80C51 compatible

10 to 32.5ûC [50 to 90.5ûF] 20 to 80% RH

0 to 35ûC [32 to 95ûF] 20 to 80% RH

User Replaceable Components

Settings and Printing Network

Maintenance and Spec.

The following upgrade options can be installed in the printer.

Please contact the reseller from which the printer was purchased.

CLHD20: Hard Disk Drive (20 GB 2.5")

The Check and Print, Memory Print, and Confidential Print (PCL printer driver only) are available

in Windows only (not available in Macintosh) by installing this option.

Refer to the installation manual included in the option's carton to install it.

DA-DS1: Optional Paper Feeder

An additional cassette can be used by installing this option. This option can be installed up to two

units. Refer to the installation manual included in the option's carton to install it.

CLEM256: 256MB DIMM (Optional Memory)

It is strongly recommended to install this option if printing documents in Enhance mode or Duplex

mode. If the printer is not equipped with the optional memory, the Memory Overflow error may

occur and it causes the deterioration of the image quality. Refer to the installation manual included

in the option's carton to install it.

DA-MC1: Upgrade Kit (for PostScript 3)

Printing for PostScript is available from Windows or Macintosh by installing this option.

This option is for DP-CL21P only.

Refer to the installation manual included in the option's carton to install it.

Upgrade Options

Cleaning the Printer

Settings and Printing Network

Maintenance and Spec.

Periodic cleaning of the printer is recommended. The frequency of cleaning is dependent upon the

environment in which the printer is used. You should clean the printer:

• At least once a month.

• When the printer experiences frequent media jams.

• When print quality has become deteriorated.

1Turn the power OFF.

2Clean all the covers with a soft cloth. Use any mild commercial cleaner.

CAUTION

• Do not use benzene, thinner, aerosol cleaners, or any abrasive powder.

When using isopropyl alcohol with a lint-free cloth, make sure that the alcohol is at least 90% pure,

obtainable from your local pharmacy. (Do not use rubbing alcohol; it can damage the printer.)

NOTE:

• If using the multi-purpose tray or opening the tray cover, be sure to push the multi-purpose tray and

close the tray cover before you pull the media tray out of the printer or open the front door.

Cleaning the Printer

External

Internal

Cleaning the Printer

Settings and Printing Network

Maintenance and Spec.

1Pull the media tray out of the printer while slightly raising its front portion.

CAUTION

• Be sure to hold the media tray with both hands so you do not drop it.

2Remove media from the media tray.

3Turn over the media tray.

Cleaning the Printer

Settings and Printing Network

Maintenance and Spec.

4Pull the delay pad (2) while pushing the tab (1), then remove the delay

pad (3).

5Clean the pad.

6Turn over the media tray.

Cleaning the Printer

Settings and Printing Network

Maintenance and Spec.

7Remove the pickup roller (2) while pushing the tab (1).

8Wipe the rollers with a lint-free cloth that has been moistened with

isopropyl alcohol while rotating it.
