Panasonic Network Printing DP2000/2500 Manual de usuario

DP2000/2500

Network Printing

Setup Guide

30/05/02 Document Systems Support V1.0 

Disclaimer

Whilst every care has been taken in producing this guide, however, it’s accuracy

cannot be guaranteed. If you do find any errors or omissions please email your

comments to [email protected].

Panasonic Business Systems do not accept any responsibility for any loss, disruption

or damage to your data or your computer systems, which may occur by using this

guide or programs, mentioned in it.

By using this guide you accept the above conditions.

If you are in any doubt concerning the contents of this guide please

consult your network Administrator at once before proceeding.

Please read this guide thoroughly before proceeding with any installation.

Acknowledgements

Windows is a trademark of the Microsoft Corporation.

30/05/02 Document Systems Support V1.0 

Index

Page Topic

4 Introduction

5 Peer to Peer printing in Windows 95/98/Me

9 Peer to Peer printing in Windows NT4/2000

15 Server Set-Up in Windows NT4/2000

21 Client Set-Up for Server based printing in Windows

95/98/Me/NT4/2000

27 Printer Driver Overview (GDI)

29 Driver Overview (PCL6)

30 Network Glossary

********************

30/05/02 Document Systems Support V1.0 

Introduction

The network interface card in the DP series works only with the TCP/IP protocol (the

same protocol used by the Internet). This protocol must be loaded on your desktop

PC and/or Server for network printing to work.

If you are not currently running this protocol it can be added to your system from

your Windows CD, please consult your Windows documentation for further

information.

The DP series also requires a static TCP/IP address. If your Server is using DHCP

you will need to give an address outside the DHCP scope or if it is within the scope a

reservation must be added. Please consult your Network Administrator if you are

unsure if your network uses DHCP or not.

The network interface card in the DP series has a RJ45 connection only. If you have

any other type of connector please refer to your network administrator for

assistance.

The network interface card also auto-detects your network speed, either 10 or 100

megabits per second.

30/05/02 Document Systems Support V1.0 

Windows 95/98/Me

Peer to Peer Printing

You can print to your DP series unit from the above operating systems without the

need of a Server. You can also use this method of printing even if you have a Server

but would prefer to print directly to your DP unit.

Stage 1

What you will need

Your DP unit will need an TCP/IP address e.g. 192.168.10.1, a sub-net mask e.g.

255.255.255.0 and a gateway address e.g. 192.168.10.100. Your network

administrator may need to give you these addresses.

Once you have these addresses you will need to input these into the DP unit. Follow

these instructions to input these settings.

1. With the unit turned on press the “function” key located on the dashboard at

the top towards the right.

2. Use the arrow button (DP2500) or the toggle button (DP2000) to select page

2 of the menu.

3. Scroll down to “Key operator code”

4. Input “000” then either OK or SET (if this code is incorrect consult your

Dealer)

5. Scroll down until you see “TCP/IP Address”

6. Input the information as requested. Remember to use the full three digit

number for the address e.g. if the address for one segment is “10” input

“010”. If you make a mistake, use the “clear” button to erase your entry.

Repeat the above for the Sub-Net Mask and Gateway.

7. After you have entered the address remember to press the “set/OK” button to

8. After entering all of the information press the “reset” button to get back to

the main menu then switch the unit off and then back on for the changes to

take effect.

9. You can check to see if your settings have been accepted by going back into

the menu’s previously mentioned.

10. In case of difficulty your Dealer can test the unit using an engineering mode,

please ask them for assistance.

30/05/02 Document Systems Support V1.0 

Stage 2

What Next?

Now you have programmed your DP unit you now need to install the printer driver

on your PC.

Follow these instructions to add the DP unit as a printer. You will need the CD-ROM

that came with your DP unit. This contains the printer driver and the program that’s

needed to enable peer to peer printing.

You can download the latest printer driver from our Web Site at the following link:

http://www.panasonic.co.jp/mgcs/download/index.html

1. Place the CD-ROM into your computer drive; the disk will auto run and display

a menu, you can read the manual from here or simply close this window to

proceed.

2. Open Windows Explorer and browse to the following folder:

E:\english\lpr (Where E: is the letter of your CD ROM drive)

3. Double click on the file “Setup.exe”

4. Follow the instructions on the screen to install this program. You will need to

re-boot your system after this program has installed.

5. After re-booting your system, leave the CD-ROM in your drive and proceed as

follows.

6. Click on “start” the “settings” then “printers”

7. Double click on “add printer”

8. Choose “next”

9. Click “local printer”

10. Then choose “have disk”

11. Browse your CD-ROM drive and scroll down to the printer driver folder which

can be found at e:\english\driver\win9x (where “e:\” is the letter of your

CD ROM drive).

12. Click “OK”.

13. Click “OK”.

14. Choose your DP unit model’s number.

15. When you get the port menu choose “LPT1” – we will alter this later for

network printing.

16. Windows will now install the driver files.

17. When finished you should end up with a printer icon in your printer’s folder.

Do a right hand mouse click and highlight “properties” this will then bring up

a menu.

30/05/02 Document Systems Support V1.0 

18. We now need to configure the driver to work with your DP unit. You will only

need to do this once.

19. Click on “device options”

20. Select the accessories you have fitted to your DP unit.

21. Click on “paper/layout” and make sure the default is set to A4

22. Now go to the details tab

23. You will see here which port your copier is set to print to, we will now change

this to a network port.

24. Click on “add port”

25. You should now get a menu that looks like this.

26. Click on “other” and select the top menu choice “HLPRMON”, you should get a

menu like this.

30/05/02 Document Systems Support V1.0 

27. Enter the TCP/IP address of the copier then type a colon:and then lp

(lowercase no spaces). Just like in the example shown below:

28. Now click on the “general” tab and choose “print a test page”

29. The DP unit should produce a standard test page confirming that everything

has been set up. It will also display a list of the files used.

Stage 3

Operating Instructions

30. For comprehensive operating instructions, please refer to the manual, which

can be found on the CD that came with your unit.

Problems?

No Network Connection

1. Check the obvious things; is the unit switched on and “on-line” (the on-line light

should be on, if it isn’t press the “Printer” key on the left side of the copier

dashboard and then press “on-line”. The copier should bleep to confirm.

2. Check the cable connections and if possible use a known good cable and

network port.

3. Have you programmed the IP address of the copier, Sub-Net and Gateway

correctly? Please refer to the start of the installation procedure to double-check

this.

4. Even if you don’t have a Gateway, an address must be inputted. Choose a spare

IP address for the Gateway if required.

5. Have you properly configured the LPR port on your PC? Again, refer to the start

of this guide to check this.

6. Where you plug the network cable into the back of the copier, do you have a

green “link light” showing. If not try an alternative network port. If you do not

get a green link light, please contact your Dealer for further assistance.

30/05/02 Document Systems Support V1.0 

7. If you do have a green “link light”, try to “ping” the network card in the copier

by typing the following from a DOS prompt on your PC:

Ping 192.168.10.1

(Please substitute the IP address with the correct address you are using)

8. If you get a “reply” then you have a network connection. Double check numbers

1 through 5 and if necessary, re-install the LPR software and print driver.

9. If you do not get a “reply” contact your Dealer for further assistance.

Print Driver Issues

1. If the copier “bleeps” and doesn’t print anything, check the defaults of the

printer driver especially the default paper size. Make sure this is set to A4.

2. Have you got “security print” enabled? Again, double-check the defaults and

make sure the driver is configured correctly.

3. If your unit picks paper from a different tray than selected, check within your

application software for the correct page defaults and these will usually override

the printer driver settings.

4. The latest printer drivers can be downloaded from the following Web Site.

http://www.panasonic.co.jp/mgcs/download/index.html

30/05/02 Document Systems Support V1.0 

Windows NT4/2000

Peer to Peer Printing

You can print to your DP series unit from the above operating systems without the

need of a Server. You can also use this method of printing even if you have a Server

but would prefer to print directly to your DP unit. You may need to have

Administrator access rights to perform the following operations, please consult with

your Network Administrator if you are unsure.

Stage 1

What you will need

Your DP unit will need a TCP/IP address e.g. 192.168.10.1, a sub-net mask e.g.

255.255.255.0 and a gateway address e.g. 192.168.10.100. Your network

administrator may need to give you these addresses. Your PC will also need to have

TCP/IP printing services installed, this is built in to Windows 2000 but not in NT4 so

you may need to load this from your Windows CD ROM. Please consult your

Windows documentation for further information.

Once you have these addresses you will need to input these into the DP unit. Follow

these instructions to input these settings.

1. With the unit turned on press the “function” key located on the dashboard at the

top towards the right.

2. Use the arrow button (DP2500) or the toggle button (DP2000) to select page 2

of the menu.

3. Scroll down to “Key operator code”

4. Input “000” then either OK or SET (if this code is incorrect consult your Dealer)

5. Scroll down until you see “TCP/IP Address”

6. Input the information as requested. Remember to use the full three digit number

for the address e.g. if the address for one segment is “10” input “010”. If you

make a mistake, use the “clear” button to erase your entry. Repeat the above

and the Sub-Net Mask and Gateway.

7. After you have entered the address remember to press the “set” button to

8. After entering all of the information press the “reset” button to get back to the

main menu then switch the unit off and then on for the changes to take effect.

9. You can check to see if your settings have been accepted by going back into the

menu’s previously mentioned.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora de Panasonic

Panasonic

Panasonic AGEP50 - COLOR VIDEO PRINTER Manual de usuario

Panasonic

Panasonic KX-P19 Manual de usuario

Panasonic

Panasonic SV-P10U Manual de usuario

Panasonic

Panasonic KX-P2124 Manual de usuario

Panasonic

Panasonic KX-PX20M - Photo Printer - 20 Sheets Manual de usuario

Panasonic

Panasonic KX-CL400 Manual de usuario

Panasonic

Panasonic KX-P1180 Manual de usuario

Panasonic

Panasonic SVAP10U - SD PRINTER Manual de usuario

Panasonic

Panasonic SP28P Instrucciones de funcionamiento

Panasonic

Panasonic KX-P1131 - KX-P 1131 B/W Dot-matrix Printer Manual de usuario

Panasonic

Panasonic KX-MC6040 - Color Laser Multi-Function... Manual de usuario

Panasonic

Panasonic Workio DP-CL18 Manual de usuario

Panasonic

Panasonic KX P2023 - KX-P 2023 B/W Dot-matrix Printer Manual de usuario

Panasonic

Panasonic NV-MPD1EN Manual de usuario

Panasonic

Panasonic NV-MP20E Manual de usuario

Panasonic

Panasonic WORKIO DP-CL21 Manual de usuario

Panasonic

Panasonic DP-MC210 Manual de usuario

Panasonic

Panasonic AGEP50 - COLOR VIDEO PRINTER Manual de usuario

Panasonic

Panasonic KXPX10M - DIGITAL VIDEO PRINTER Manual de usuario

Panasonic

Panasonic KX-P1150 - KX-P 1150 B/W Dot-matrix Printer Manual de usuario

Panasonic

Panasonic Jetwriter KX-P4440 Manual de usuario

Panasonic

Panasonic SV-P20 Manual de usuario

Panasonic

Panasonic Workio DP-CL18 Manual de usuario

Panasonic

Panasonic KX-MC6040 - Color Laser Multi-Function... Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario
