Panasonic BT-LH900E Manual de usuario

Panasonic Broadast

Mechanical Parts List

MODEL:

BT-LH900AP,E,MC

CONTENTS

CASING PARTS ASSEMBLY ..........................................................................................................MPL-1

PACKING PARTS ASSEMBLY........................................................................................................MPL-3

CABLE LIST .....................................................................................................................................MPL-5

CED-SBVC

.A.B.C

IDS

B.C

.A.B.

BUS

WOP

.A.B.C

A.B

NORF

.A.B.CHCTIWS

.A.B.CNIA

.A.B.C

31 43

121

221

121

221

111

101

201

116

301

401 3

401

221

501

121

101

411

811

411 411

411

311

115

511

711

911

411

311

101

50 49

SDI

C.B.A

114

108

110

112

114

122

114

TALLY C.B.A

MPL-1

Components identified with the mark have the special characteristics for safety.

When replacing any of these components, use only the same type.

CASING PARTS ASSEMBLY

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

120 XQN2+A3FJ SCREW 3

1 VYP9157 FRONT CASE ASS'Y 1 121 XWA26BFJK WASHER 8

2 84LHS03 BACKLIGHT 1 122,23 VMX3348 WASHER 3

3 VGF1000 LED COVER 5

4 VMT1543 GASKET B 2

5 VMT1542 GASKET A 2

6 VMP7859 FRONT ANGLE 2 E1 VEP16104C MAIN P.C.BOARD 1

7 VMT1520 PROTECT PANEL SPONGE (B) 2 E2 VEP13114B SUB P.C.BOARD 1

8 VGQ7597 PROTECT PANEL 1 E3 VEP13115A CVBS-DEC P.C.BOARD 1

9 VMT1509 PROTECT PANEL SPONGE (A) 2 E4 VEP10119A SDI SUB P.C.BOARD 1

10 VMG1599 HEATING SHEET (F) 2 E5 VEP10120C SDI P.C.BOARD 1

11 VMG1596 HEATING SHEET (C) 2 E6 VEP11110A POWER SUB P.C.BOARD 1

12 K1TZB9A00051 SDI COAXIAL CABLE (R) 2 E7 VEP10117A TALLY P.C.BOARD1

13 VMT1435 CONNECTOR CUSHION 4 E8 VEP10115B FRONT P.C.BOARD 1

14 VGQ7598 TRIPOD FIX BLOCK 2 E9 VEP10116A SW P.C.BOARD 1

15 VGH4891 SW BOX NAME PLATE 1 E10 VEP80D49B EXT DC P.C.BOARD 1

16 VJF1535 CLAMPER 5

17 L5EDD2Q00010 LCD PANEL 1

18 VMP7842 MAIN P.C.B BASE 1

19 VGU7459 TACT SW KNOB 5

20 VGU9566 ROTARY KNOB 4

21 K1YE25000007 SCREW 4

22 VMT1510 SW BOX COVER CUSHION 1

23 VMG1598 HEATING SHEET (E) 1

24 N0DE2GD00002 INVERTER ASS'Y 1

25 VGF0992 SW BOX COVER 1

26 VEP10125A VR FLEX. P.C.BOARD 4

27 VGM2163 SW BOX 1

28 VMP8325 VR FIX. ANGLE 1

29 VMP8323 SDI HOLD ANGLE 2

30 VMZ3400 INSULATION SHEET (BOTTOM) 1

31 VWJ1703 OPERATION SECTION CABLE 1

32 VGM2162 BACK CASE 1

33 VGF0991 MAINTENANCE COVER 1

34 VJF1347A ANTON BRACKET 1

35 VGF0709 BACK CASE COVER 1

36 VGF0997 BATTERY CABLE HOLDER 1

37 VEE0Z60 CABLE 1 MAIN-OPERATION TERMINAL

38 VEE0Y89 POWER SW CABLE 1

39 VMX0998 CORD BUSH 1

40 VHN0361 SCREW SPACER 1

41 VMZ3454 CUSHION 1

42 VJF1500 FG CLAMPER 1

43 VMZ3240 SPACER 1

46 VMT1503 P.C.B. HOLDER RUBBER 1

47 VMP8043 CORE MOUNT ANGLE 1

48 J0KE00000084 FERRITE CORE 1

49 J0KE00000083 FERRITE CORE 1

50 VMT1562 SHEET 1

51 K1TZB9A00037 SDI COAXIAL CABLE (B) 1

52 VMG1591 CUSHION 1

53 VMG1595 CONDUCTIVE SHEET (B) 3

54 VMZ3321 CONDUCTIVE TAPE 1

55 VEE0Y94 CABLE 1 MAIN(P6700)-LCD PAENL

101 XVE26A6FP SCREW 8

102 XSB3+6FZ SCREW 10

103 XSB3+10FJK SCREW 4

104 XTB3+10GFJK SCREW 3

105 XTB3+6FFJK SCREW 6

106 XSB26+4FJK SCREW 2

107 XSN26+6FC SCREW 2

108 XYN3+J6FJ SCREW 2

110 XYN26+F8FJ SCREW 1

111 XYN3+J4FJ SCREW 1

112 XQN2+A3FJ SCREW 6

113 XSB26+8FJK SCREW 4

114 XYN26+J5FJ SCREW 19

115 XSB26+6FJK SCREW 4

116 XYN26+J5FJK SCREW 2

117 XSB3+8FJK SCREW 2

118 XYN3+J5FJ SCREW 5

119 XSB26+5FJ SCREW 2

CASING PARTS ASSEMBLY

MPL-2

9MC only

PACKING PARTS ASSEMBLY

Components identified with the mark have the special characteristics for safety.

When replacing any of these components, use only the same type.

MPL-3

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

1 VQT0X58 OPERATING INSTRUCTIONS 1 FOR BT-LH900AP/E

1 VQT0X59 OPERATING INSTRUCTIONS 1 FOR BT-LH900AMC

2 VEJ1672 BATTERY ADAPTOR ASS'Y 1

3 VPN6082 CUSHION (L) 1

4 VPN6083 CUSHION (R) 1

5 VPG0V15 PACKING CASE 1

6 VQL1K05 PACKING LABEL 1 FOR BT-LH900AP/MC

6 VQL1K06 PACKING LABEL 2 FOR BT-LH900AE

7 VPF0672 DECK PROTECT BAG 1

8 VPN2745 PROTECT MAT 1

9 VPG0W85 PACKING CASE (OUT) 1 FOR BT-LH900AMC

PACKING PARTS ASSEMBLY

MPL-4

Ref.No. Part No. Part Name & Description

Remarks Ref.No. Part No. Part Name & Description

Remarks

1 K1TZB9A00051 SDI COAXIAL CABLE (R) 2 SDI J1,J2 - SDI SUB J505,J

2 VEE0Y85 CABLE 1 MAIN P6101 - TALLY P401

3 VEE0Y86 CABLE 1 SDI SUB P500 - SUB P3604

4 VEE0Y87 CABLE 1 MAIN P6102 - SUB P3603

5 VEE0Y88 CABLE 1 MAIN P6800 - POWER SUB P10

6 VEE0Y89 POWER SW CABLE 1 POWER SW P102 - POWER SW

7 VEE0Y90 CABLE 1 POWER SUB P101 - DC IN

8 VEE0Y91 CABLE 1 POWER SUB P103 - ANTON BAT

9 VEE0Y92 CABLE 1 MAIN P6801 - INVERTER

10 VEE0Y93 CABLE 1 SUB P3101 - CVBS DEC P100

11 VEE0Y94 CABLE 1 MAIN P6700 - LCD PANEL

12 VEE0Z60 CABLE 1 MAIN P6103 - FRONT

13 VEE0Z22 CABLE 1 FRONT P202 - SW P301

14 VEK0K20 SHIELD FLEX. CABLE 1 MAIN P6106 - SUB 3602

15 VWJ1703 OPERATION SECTION CABLE 1 FRONT P201 - CONTROL

CABLE LIST

MPL-5
