Panasonic VL-MWD501 Manual de usuario

1 by Multi Video Intercom System

Installation Guide

Table of Contents - 1

1-1 Comparison P.5

1-2 System Overview P.6

1-3 Product ine-up P.7

1-4 Module ine-up P.8

1-5 obby Station-1 P.9

1-6 obby Station-2 P.10

1-7 Distributor : V -VM701 P.11

1-8 High Power Type PSU : V -PS2410 P.12

1. Specifications

2-1 Stylish Design P.14

2-2 Compact Design P.15

2-3 Customization with Each Module – 1 P.16

2-4 Customization with Each Module – 2 P.17

2-5 Customization with Each Module – 3 P.18

2-6 Easy Accessible Name Plate P.19

2-7 Camera Angle P.20

2-8 E-lock & Access Control P.21

2. Features

3-1 V -MWD501 series P.23

3-2 V -MVN511 series P.24

3-3 V -MV10EX1/EX2(French Model) P.25

3-4 Function Table P.26

3. Monitor ine Up

Table of Contents -2

4-1 obby Station Assembly-1 P.28

4-2 obby Station Assembly-2 P.29

4-3 Setting for obby Station P.30

4-4 System Overview P.31

4-5 Wiring & Power Supply Unit

(Star Shape Wiring) P.33

4-6 Room No. Setting (Star Shape Wiring) P.34

4-7 Setting for Distributer ID (Bus-wiring) P.36

4-8 Room No. Setting -1 (Bus Wiring) P.37

4-9 Room No. Setting -2 (Bus Wiring) P.38

4-10 Room No. Setting -3 (Bus Wiring) P.39

4-11 Room No. Setting -4 (Bus Wiring) P.40

4-12 Wiring & Power Supply Unit

(Bus Wiring) P.41

4-13 Install obby Station P.42

4-14 Bundled Items P.43

4. Installation 5. Appendix

1. Specifications

1-1. Comparison

Item VL-VM Series ( 1 by Multi ) VL-V900 series ( nalog)

System diagram Example

General

Expandability 32 560 ( Enhanced System : 2240 )

Power Source DC 24V DC 24V

IP / IK rating IP55 / IK08 IP55 / IK07

Operating environment - 15 deg. To 55 deg. Celsius - 10 deg. To 55deg. Celsius

Surface material Metal (Machine cut aluminum) Stainless steel (partially BS and PC)

Camera

Unit

Image sensor pprox. 1M pixels C-MOS sensor pprox. 1M pixels C-MOS sensor

Camera angle H. 170 degrees V. 110 degrees H. 170 degrees V. 115 degrees

Lighting method White color LED White color LED

Minimum illuminance 1 lx 1 lx

Calling

I/F

Calling Method

Back lighting

Direct Call Button

Name plate access from front side

White color LED

Call by input Key Room Number or

selecting List of Phone book

White color LED

CCTV

Security

Camera

Control Box

PBX

Lift Controller

Terminal

Distribution Box

Door Station

Lobby station

Monitor

distributor

Monitor Bus wiring

Star-shape wiring

1. Specifications

*Some Power Supply Units (PSUs) are abbreviated in figures. The configuration of PSUs depends on system requirement and specification of devices selected in each system.

1. Specifications

1-2. System Overview

Distributor

ID #8

Distributor

ID #5

Distributor

ID #4

Distributor

ID #3

Distributor

ID #2

Distributor

ID #6

Distributor

ID #1

Lobby

Station

Star shape wiring Bus wiring

Distributor

ID #7

PSU

Call & Talk

E-lock open

Monitoring

- up to 32 room monitors

E-lock

Vigik

Room

Monitor

E-lock

Vigik

/C Call & Talk

E-lock open

Monitoring

Panasonic system is only available for both wiring topology.

PSU

*3rd Party

*Some Power Supply Units (PSUs) are abbreviated in figures. The configuration of PSUs depends on system requirement and specification of devices selected in each system.

- up to 8

distributors

IP Video Intercom Product

2. Specifications

1-3. Product ine-up

1. Specifications

Product Image

Camera Module

V -VM101

1-Button Module

V -VM301

2-Button Module

V -VM302

3-Button Module

V -VM303

4-Button Module

V -VM304

Surface Mount Cover

(Smaller Type)

V -VM502

Surface Mount Cover

( arge Type)

V -VM503

Back Box (Small Type)

V -VM602

Back Box ( arge Type)

V -VM603

Blank Panel

V -VM901

Distributor

V -VM701

High Power Type PSU

V -PS2410

Room Monitor

V -MWD501/V -MVN511/V -MV10EX

Vigik Panel

V -VM902

Extension Cable

V -VM801

*Vigik module is sold by 3rd party.

PSU

V -PS240

1. Specifications

1-4. Module ine-up

Model No. Module Image Size Description

VL-VM101EX Camera module Full module size

Central unit with a camera , speaker and

microphone.

*Camera = 1M pixels

VL-VM301EX 1-button module

Half module size Call button with backlight

VL-VM302EX 2-buttons module

VL-VM303EX 3-buttons module

VL-VM304EX 4-buttons module

VL-VM502EX Surface Mount Cover

(Small Type) -Cover for surface mount

VL-VM503EX Surface Mount Cover

(Large Type)

VL-VM602EX Back Box (Small Type)

- Flush mount box

VL-VM603EX Back Box (Large Type)

VL-VM901EX Blank Panel Half module size Panel for unfilled space.

VL-VM902EX Vigik Panel Half module size

VL-VM801 Extension Cable - Cable for extension

VL-VM701EX Distributer - Distribution box for room monitor

VL-PS2410 High Power Type PSU - High-power type PSU

VL-PS240 PSU - Standard type PSU 8

1. Specifications

1-5. obby Station-1

Features

- Electric locks (3rd party)

- ccess control (3rd party)

- 1M pixels camera

-Wide angle camera (Horizontally=approx.170˚, Vertically=approx.110˚)

- White key backlit with illuminance sensor.

-Front accessible name plate (Inaccessible type is also available)

- White coloured LED※lights for night colour vision with illuminance sensor

(※The life of a Key backlight LED : 23 years)

- Status Indicators (Calling/Talking/Door Opening)

- udio guidance for DD . (Door opening=EN, FR, DE, ES, IT, NL, R, F )

-IP55/IK08 (Aluminum panel)

Connectable devices

Role of the obby Station

Door entry panel for the public entrance of housing complexes.

Direct button to call resident.

(1) Camera lens

(2) Light (for night vision)

(3) Speaker

(4) Mic

(5) Status indicator (Calling/Talking/Door opening)

(6) Terminal for bus wiring

(7) Vigik module input

(8) K-OUT for NC/NO

1. Specifications

1-6. obby Station-2

(5)

(1)

(2)

(4)

(3)

(9) Dip switch for setting

(10) Connector cable for module connection

(11) Connector for DD module (TBD)

(12) Connector for 12key module (TBD)

(13) Power switch

(14) Terminal for DC in

(15) K-IN

(16) Terminal foe star shape wiring

(9) (10)

(13)

(14)

(15)

(16)

(6)

(7)

(8)

(11)

(12)
