Panasonic KX-NS Manual de usuario

KX-NS Step by Step Guide

KX-NTV / KX-HDV430

September 29, 2016

Specifications are subject to change without notice.

Panasonic System Networks

PBX SE team

2

PBX, phone and security camera can be provided by Panasonic.

Other major PBX maker do not have security camera.

1. Introduction

Office

LAN

Ext 101 Ext 102 Ext 103

KX-HDV430

KX-NTV150

Ext 115

KX-NTV160

Ext 116

Panasonic

IP-PBX KXT7765

Internet

Ext 301 Ext 302

Bria SIP Software

phone with Video

Remote connection by

MRG is available.

3

2. Basic Specifications

KX-NTV150 : Communication SIP Camera

- PoE / Wi-Fi (*)

- Built-in Speaker and Microphone

- Call button

(*) AC Adaptor KX-A239 is required.

KX-NTV160 : SIP based Video Doorphone

- PoE only

- Built-in Speaker and Microphone

- Call button

-IP-Grade : IP43

4

KX-NS300/500/700/1000 version 4.3 or later with DSP

Version 4.2 can be used for demo only.

KX-NTV does NOT work with other PBX including SIP server.

Video call of KX-NTV is available with only following phones.

KX-HDV430

SIP software phone Bria by CounterPath for PC, tablet or smart-phone

(Other SIP video phones such as Grandstream are not recommended.)

3. Requirement

Phone Protocol Virtual card AK for KX-NS

KX

-NT MGCP V-IPEXT card KX-NSM5xx

KX

-HDV / KX-NTV SIP V-SIPEXT card KX-NSM5xx

3

rd party SIP phone SIP V-SIPEXT card KX-NSM7xx

http://www.counterpath.com/bria/

KX-NTV supports H.264. But X-Lite by CounterPath supports H.263.

5

4. Table of Contents

Chapter Contents

1KX-NS programming

2KX-NTV : Initial setup

3KX-NTV : SIP registration and video

4KX-HDV430 programming

5Bria

6KX-NTV : Maintenance

6

Chapter 1

KX-NS Programming

7

11. Make SIP Account for KX-NTV.

See step by step guide No.12 for details.

8

Chapter 2

KX-NTV : Initial Setup

9

21. Initialize KX-NTV.

If KX-NTV has bee already registered to other PBX, it is required to

initialize. Keep pressing reset button for 30s.

<KX-NTV150> <KX-NTV160>

10

22. Connect KX-NTV to PoE L2-Switch.

Connect KX-NTV150/160 to KX-HTS through PoE L2-Switch.

KX-NTV150/160 gets IP address.

(KX-NTV is not registered as SIP extension automatically.)

- Wait until yellow LED starts flashing.

- LED : Red (15s) -> Off (10s)-> Red (20s) -> Yellow Flash

Panasonic

KX-NS Panasonic

L2 Switch (PoE)

for example
