English

Operating Instructions

Air-to-Water Hydromodule + Tank

Thank you for purchasing Panasonic

product.

Before operating the system, please read these

operating instructions thoroughly and keep them

for future reference.

Installation Instructions attached.

Serial number and production year please refer to

name plate.

ACXF55-03410

Operating Instructions

Air-to-Water Hydromodule + Tank

Model No.

Indoor Unit

WH-ADC0309H3E5UK

Outdoor Unit

WH-UD03HE5-1

WH-UD05HE5-1

WH-UD07HE5-1

WH-UD09HE5-1

Manufactured by:

Panasonic Appliances Air-Conditioning Malaysia Sdn. Bhd.

Lot 2, Persiaran Tengku Ampuan, Section 21,

Shah Alam Industrial Site, 40300 Shah Alam,

Selangor Darul Ehsan, Malaysia.

Table of contents

Safety precautions .........................................................4-6

Remote Controller buttons and display .........................7-9

Initialization .......................................................................9

Quick Menu ....................................................................10

Menus ........................................................................10-23

For user

1 Function setup ...................................................10-11

1.1 Weekly timer

1.2 Holiday timer

1.3 Quiet timer

1.4 Room heater

1.5 Tank heater

1.6 Sterilization

1.7 DHW mode

2 System check .........................................................12

2.1 Energy monitor

2.2 Water temperatures

2.3 Error history

2.4 Compressor

2.5 Heater

3 Personal setup ...................................................12-13

3.1 Touch sound

3.2 LCD contrast

3.3 Backlight

3.4 Backlight intensity

3.5 Clock format

3.6 Date & Time

3.7 Language

3.8 Unlock password

4 Service contact .......................................................13

4.1 Contact 1 / Contact 2

For installer

5 Installer setup > System setup ..........................14-18

5.1 Optional PCB connectivity

5.2 Zone & Sensor

5.3 Heater capacity

5.4 Anti freezing

5.5 Buffer tank connection

5.6 Base pan heater

5.7 Alternative outdoor sensor

5.8 Bivalent connection

5.9 External SW

5.10 Solar connection

5.11 External error signal

5.12 Demand control

5.13 SG ready

5.14 External compressor SW

5.15 Circulation liquid

5.16 Heat-Cool SW

6 Installer setup > Operation setup ......................18-22

6.1 Heat

6.2 Cool

6.3 Auto

6.4 Tank

7 Installer setup > Service setup ..........................22-23

7.1 Pump maximum speed

7.2 Pump down

7.3 Dry concrete

7.4 Service contact

Cleaning instructions ......................................................24

Troubleshooting .........................................................25-26

Information ......................................................................27

Operating conditions

HEATING

(TANK)

HEATING

(CIRCUIT)

COOLING

(CIRCUIT)

Water outlet temperature (°C)

(Min. / Max.) - / 65* 20 / 55 5 / 20

Outdoor ambient temperature (°C)

(Min. / Max.) -20 / 35 16 / 43

* Above 55 °C, only possible with backup heater operation.

When the outdoor temperature is out

of the range in the table, the heating

capacity will drop signiﬁcantly and the

outdoor unit may stop operating for its

protection.

The unit will restart automatically after

the outdoor temperature returns to the

speciﬁed range.

English

Before use, make sure the system has been installed correctly by an

authorised dealer according to the given instructions.

• Panasonic Air-to-Water is a split system, consisting of two units: indoor and outdoor units. The indoor unit consist of

the hydromodule and 200L sanitary water tank.

• These operating instructions describe how to operate the system using the indoor and outdoor units.

• As for the operation of other products such as radiator, external thermo controller, and underﬂoor units, refer to the

operating instructions of each product.

• System could be locked to operate in HEAT mode and disable COOL mode.

• Some functions described in this manual may not be applicable to your system.

• Consult your nearest authorised dealer for further information.

*1 The system is locked to operate without COOL mode. It can be unlocked only by authorised installers or our authorised

service partners.

*2 Only displayed when COOL mode is unlocked (This means when COOL mode is available)

System overview

Radiator

Shower

Fan Coil

Unit

Floor

Heating

Outdoor Unit

Solar Panel

Power Supply

The illustrations in this manual are for explanation purposes only and may differ from the actual unit.

They are subject to change without notice for future improvement.

Note:

Not recommended to open the Front Plate.

(For authorised dealer/specialist use only)

Indoor Unit

Remote Controller

Front Plate

Safety precautions

To prevent personal injury, injury to

others or property damage, please

comply with the following:

Incorrect operation due to failure to

follow instructions below may cause

harm or damage, the seriousness of

which is classiﬁed as below:

WARNING

This sign warns of

death or serious

injury.

CAUTION

This sign warns of

injury or damage

to property.

The instructions to be followed are

classiﬁed by the following symbols:

This symbol denotes

an action that is

PROHIBITED.

These symbols denote

actions COMPULSORY.

WARNING

Indoor unit and outdoor

unit

This appliance may be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved. Children

shall not play with the appliance.

Cleaning and user maintenance

shall not be made by children

without supervision.

Please consult an authorised

dealer or specialist to clean the

internal parts, repair, install,

remove and reinstall the unit.

Improper installation and

handling will cause leakage,

electric shock or ﬁre.

Conﬁrm with an authorised

dealer or specialist on usage of

any speciﬁed refrigerant type.

Using refrigerant type other than

the speciﬁed may cause product

damage, burst and injury etc.

English

Do not install the unit in

a potentially explosive or

ﬂammable atmosphere. Failure

to do so could result in ﬁre.

Do not insert your ﬁngers

or other objects into the

indoor or outdoor unit; the

rotating parts may cause

injury.

Do not touch the outdoor unit

during lightning, it may cause an

electric shock.

Do not sit or step on the

unit, you may fall down

accidentally.

Do not install the indoor unit

outdoors. This is designed for

indoor installation only.

Power supply

Do not use a

modiﬁed cord, joint

cord, extension

cord or unspeciﬁed

cord to prevent

overheating and ﬁre.

To prevent overheating, ﬁre or

electric shock:

• Do not share the same power

outlet with other equipment.

• Do not operate with wet hands.

• Do not bend or twist power

supply cord.

If the supply cord is damaged,

it must be replaced by the

manufacturer, service agent or

similarly qualiﬁed persons in

order to avoid a hazard.

This unit is equipped with

Residual Current Circuit

Breaker/Earth Leakage Circuit

Breaker (RCCB/ELCB). Ask

an authorised dealer to check

RCCB/ELCB operation regularly,

especially after installation,

inspection, and maintenance.

RCCB/ELCB malfunction may

result in electric shock and/or

ﬁre.

It is strongly recommended that

Install Residual Current Device

(RCD) on-site to prevent electric

shock and/or ﬁre.

Before obtaining access to

terminals, all supply circuits must

be disconnected.

Stop using the product if any

abnormality/failure occurs and

disconnect the power supply.

(Risk of smoke/ﬁre/electric

shock)

Examples of abnormality/failure

• RCCB/ELCB trips frequently.

• Burning smell is observed.

• Abnormal noise or vibration of

the unit is observed.

• Hot water leaks from the indoor

unit.

Contact your local dealer

immediately for maintenance/

repair.

Wear gloves during inspection

and maintenance.

Safety precautions

This equipment must be earthed

to prevent electrical shock or ﬁre.

Prevent electric shock by

disconnecting the power supply

- Before cleaning or servicing.

- When extended non-use.

This appliance is for multiple

uses. To avoid electric shock,

burn and/or fatal injury, make

sure to disconnect all power

supplies before accessing any

terminal in the indoor unit.

CAUTION

Indoor unit and outdoor

unit

Do not wash the indoor unit

with water, benzine, thinner

or scouring powder to avoid

damage or corrosion on the unit.

Do not install the unit close

to any combustibles or at

bathroom. Otherwise, it may

cause electric shock and/or ﬁre.

Do not touch the water discharge

pipe of the indoor unit during

operation.

Do not place any material on the

unit or under it.

Do not touch the sharp

aluminium ﬁn; sharp parts

may cause injury.

Do not use the system during

sterilisation in order to prevent

scalding with hot water, or

overheating of shower.

Prevent water leakage by

ensuring that the drainage pipe

is connected properly.

After a long period of use, make

sure the installation rack is not

deteriorated. The deteriorated

rack may cause the unit to fall

down.

Ask an authorised dealer

to determine the level of

sterilisation function ﬁeld settings

according to the local laws and

regulations.

Remote Controller

Do not wet the Remote

Controller. Failure to do so may

result in electric shock and/or

ﬁre.

Do not press the buttons on the

Remote Controller using hard

and sharp objects. Failure to do

so may cause damage to the

unit.

Do not wash the Remote

Controller using water, benzine,

thinner or scouring powder.

Do not inspect or maintain the

Remote Controller by yourself.

Consult an authorised dealer in

order to prevent personal injury

caused by incorrect operation.

English

Remote Controller buttons and display

Buttons / Indicator

Quick Menu button

(For more details, refer to the separate

Quick Menu Guide.)

2Back button

Returns to the previous screen

3LCD Display

4Main Menu button

For function setup

5ON/OFF button

Starts/Stops operation

Operation indicator

Illuminates during operation, blinks during

alarm.

Press centre

No glove

No pen

Cross key buttons

Selects an item.

Enter button

Fixes the selected content.

Down

Left Right

Safety precautions / Remote Controller buttons and display

Remote Controller buttons and display

Display

1Mode selection

AUTO • Depending on the preset outdoor

temperature, the system selects

HEAT or *1COOL operation mode.

Auto Heat Auto Cool

*1, *2 COOL • The fan coil unit is either turned

ON or OFF.

• The outdoor unit provides cooling

to the system.

AUTO

+ TANK

• Depending on the preset outdoor

temperature, the system selects

HEAT + TANK or *1COOL + TANK

operation mode.

Auto Heat Auto Cool

*1, *2 COOL

+ TANK

• The outdoor unit provides cooling

to the system.

• The system controls the booster

heater in the water tank.

HEAT • The panel/ﬂoor HEAT operation is

either turned ON or OFF.

• The outdoor unit provides heat to

the system.

TANK • The water tank is either turned

ON or OFF.

• The outdoor unit provides heat to

the water tank.

HEAT

+ TANK

• The outdoor unit provides heat to

the water tank and the system.

• This mode can be selected only

when the water tank is installed.

* The direction icons point to the currently

active mode.

• Room operation / Tank operation.

• Deice operation.

2Operation icons

The status of operation is displayed.

Icon will not display (under operation OFF screen) whenever operation is OFF except weekly timer.

Holiday operation status Weekly Timer operation status Quiet operation status

Zone:Room Thermostat

→Internal sensor status Powerful operation status Demand Control or

SG ready or SHP status

Room Heater status Tank Heater status Solar status

Bivalent status

(Boiler)

*1 The system is locked to operate without COOL mode. It can be unlocked only by authorised installers or our authorised service partners.

*2 Only displayed when COOL mode is unlocked (This means when COOL mode is available).

2 43

English

Initialization

Before starting to install the various menu settings, please initiate the Remote Controller by selecting the language of

operation and installing the date and time correctly.

It is recommended that the installer conducts the following initialization of the Remote Controller.

Selecting the language LCD blinking

Press and wait while the display is

initializing.

1Scroll with and to select the language.

2Press to conﬁrm the selection.

Setting the clock

1Select with or how to display the time,

either 24h or am/pm format (for example, 15:00

or 3 pm).

2Press to conﬁrm the selection.

3Use and to select year, month, day,

hour and minutes. (Press to conﬁrm the

selection each time.)

4Once the time is set, time and day will appear

on the display even if the Remote Controller is

turned OFF.

3Temperature of each zone

4Time and day

5Water Tank temperature

6Outdoor temperature

7Sensor type/Set temperature type icons

Water Temperature

→Compensation curve

Water Temperature

→Direct Pool only

Room Thermostat

→External

Room Thermostat

→Internal

Remote Controller buttons and display / Initialization

Menus For user

Select menus and determine settings according to the system

available in the household. All initial settings must be done by an

authorised dealer or a specialist. It is recommended that all alterations

of the initial settings are also done by an authorised dealer or a

specialist.

• After initial installation, you may manually adjust the settings.

• The initial setting remains active until the user changes it.

• The Remote Controller can be used for multiple installations.

• Ensure the operation indicator is OFF before setting.

• The system may not work properly if set wrongly.

Please consult an authorised dealer.

To display <Main Menu>:

To select menu:

To conﬁrm the selected content:

After the initial settings have been completed, you can select a quick menu from the following options and edit the setting.

1Press to display the quick menu.

Force DHW Powerful Quiet Force Heater

Weekly Timer Force Defrost Error Reset R/C Lock

2Use to select menu.

3Press to turn on/off the select menu.

Quick Menu

Menu Default Setting Setting Options / Display

1 Function setup

1.1 Weekly timer

Once the weekly timer is set up,

User can edit from Quick Menu.

To set up to 6 patterns of

operation on a weekly basis.

• Disabled if Heat-Cool SW is

pressed or if Force Heater

is on.

Timer setup

Select day of the week and

set the patterns needed

(Time / Operation ON/OFF / Mode)

Timer copy

Select day of the week

Otros manuales para WH-UD09HE5-1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de calor de Panasonic

Panasonic

Panasonic WH-SDC0509L3E5 Manual de usuario

Panasonic

Panasonic WH-MDC07H3E5 Manual de usuario

Panasonic

Panasonic 26PET1U6 Manual de usuario

Panasonic

Panasonic WH-MDC09C3E5 Manual de usuario

Panasonic

Panasonic UQ09 E8 Series Manual de usuario

Panasonic

Panasonic WH-MXF09D3E8 Manual de usuario

Panasonic

Panasonic Aquarea WH-MDF09C3E5 Manual de usuario

Panasonic

Panasonic WH-ADC0509L3E5B Manual de usuario

Panasonic

Panasonic WH-SDC12K6E5 Manual de usuario

Panasonic

Panasonic WH-SHF09F3E5 Manual de usuario

Panasonic

Panasonic S-80MW1E5 Manual de servicio

Panasonic

Panasonic WH-MDC09C3E8 Manual de usuario

Panasonic

Panasonic WH-SXC09D3E5 Manual de usuario

Panasonic

Panasonic Aquarea WH-MDF06E3E5 series Manual de usuario

Panasonic

Panasonic WH-MXC16G9E8 Manual de usuario

Panasonic

Panasonic WH-SDC09C3E8 Manual de usuario

Panasonic

Panasonic WH-SDF09C3E8 Manual de usuario

Panasonic

Panasonic Aquarea WH-SDC12H6E5 Manual de usuario

Panasonic

Panasonic WH-MDC05F3E5 Manual de usuario

Panasonic

Panasonic LIAC7IM3 Manual de usuario

Panasonic

Panasonic WH-SDC0509L3E5 Manual de usuario

Panasonic

Panasonic WH-UD09HE5-1 Manual de usuario

Panasonic

Panasonic Aquarea WH-ADC0916H9E8 Manual de usuario

Panasonic

Panasonic WH-SD24BE5 Manual de usuario

Manuales populares de Bomba de calor de otras marcas

MICROWELL

MICROWELL HP 1000 GREEN Manual de usuario

Sanyo

Sanyo SAP120FCH Manual de usuario

Daikin

Daikin EHYHBH05AA Manual de usuario

Bryant

Bryant 544B Manual de usuario

Airxcel

Airxcel 45000 Series Manual

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manual de usuario

Dimplex

Dimplex LI 16I-TUR Guía del usuario

Carrier

Carrier WSHP Open v3 Guía de configuración rápida

TGM

TGM CTV14CN018A Manual de usuario

Carrier

Carrier 38MGQ Series Manual de usuario

Kokido

Kokido K2O K880BX/EU Guía de solución de problemas

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guía rápida

Carrier

Carrier 48EZN Manual de usuario

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Instrucciones de funcionamiento

Ariston

Ariston NIMBUS Manual de usuario

Weishaupt

Weishaupt WWP L 7 Guía del usuario

GE Zoneline AZ85H09EAC Manual de usuario

Bryant

Bryant Preferred Series Manual de usuario
