Panasonic EH-KA12 Manual de usuario

ing and distribution is a violation of law.

PEWT1202Z33CE

(Household) Hair Styler

Model No. EH-KA12

Model No. EH-KA23

Model No. EH-KA42

CHINA

TABLE OF CONTENTS

PAGE PAGE

1 Warning -------------------------------------------------------------- 2

2 Specifications ----------------------------------------------------- 2

3 Troubleshooting Guide ----------------------------------------- 3

4 Disassembly and Assembly Instructions ---------------- 4

4.1. Disassembly Instructions -------------------------------- 4

4.2. Assembly Instructions ------------------------------------ 4

5 Wiring Connection Diagram ---------------------------------- 6

6 Schematic Diagram ---------------------------------------------- 7

7 Exploded View and Replacement Parts List ------------ 8

7.1. Model No. : EH-KA12 Exploded View for EH-

KA12 ---------------------------------------------------------- 8

7.2. Model No. : EH-KA12 Parts List ---------------------- 9

7.3. Model No. : EH-KA23 Exploded View for EH-

KA23 -------------------------------------------------------- 10

7.4. Model No. : EH-KA23 Parts List--------------------- 11

7.5. Model No. : EH-KA42 Exploded View for EH-

KA42 -------------------------------------------------------- 12

7.6. Model No. : EH-KA42 Parts List--------------------- 13

1Warning

Caution:

- Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) a higher.

Please use soldering iron with temperature control and adjust it to 750 ± 20°F. (400 ± 10°C).

In case of using high temperature soldering iron, please be careful not to heat too long.

- Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).

2 Specifications

Sell Area or Country China

(495)

Number of Model EH-KA12

EH-KA23

EH-KA42

Power source AC 220V / 50Hz

Power consumption 550W

Air volume with attachment 0.43 m3/min

Air flow temperature

(in case of room temperature 30°C)

120°C

Cord length A2 Plug : 1.7 m.

Weight Roller Brush 320 g

Nozzle 290 g

Blow Brush 310 g

Slim Roller Brush 300 g

3 Troubleshooting Guide

4 Disassembly and Assem-

bly Instructions

4.1. Disassembly Instructions

1. Remove the two Torx screws from the Escutcheon, then

remove Escutcheon, the Filter and the Fixing ring.

2. Separate the Housing A and B by unfastening Housing

B at indicated area.

4.2. Assembly Instructions

1. Assembly Select switch to Heater blocka and Connector

cover by soldering Lead wires connect to the positions.

2. Assembly Connector cover block to Heater block by sol-

dering Lead wires connect to the positions.

3. Assembly Rectifier ass'y block to Heater block by solder-

ing Lead wires connect to the positions.

4. Insert Heater base board C to Motor ass'y block and

assembly Diode bridge of Rectifier ass'y block to Motor 's

terminalsby solder.

5. Assembly Select switch to Motor ass'y block ,insert two

Lead wires (Black and Red) into slot of Air flow regulator.

6. Assembly Parts into Housing B step by step.

7. Assembly Housing A&B together, assembly Fixing ring,

Filter, Escutcheon to Housing A&B and in the end tighter

two Torx screws.

5 Wiring Connection Diagram

6 Schematic Diagram

7 Exploded View and Replacement Parts List

7.1. Model No. : EH-KA12 Exploded View for EH-KA12

7.2. Model No. : EH-KA12 Parts List

Remarks : *1 Individual Available

All parts are supplied from PMF-Thailand through PLAP

Safety Ref. No. Part No. Part Name & Description Pcs Remarks

1 EHKA12HSWW HOUSING AB 1

2 EHKA12FTWW FILTER 1

3 EHKA12FRHW FIXING RING (GRAY) 1

4 EHKA12CTB9W CONNECTOR COVER BLOCK 1

5 EHKA12PCH9W POWER CORD 1 (B2-PLUG)

6 EHKA12MB9W MOTOR BLOCK 1

7 EHKA12SSW SELECT SWITCH 1 (INCLUDE 3 INSULATION TUBES)

8 EHKA12ITBW INSULATION TUBE 3 (3PCS/PACK)

9 EHKA12ASPWW ARM SWITCH PLATE 1

10 EHKA12HB9W HEATER ASSEMBLY BLOCK 1

11 EHKA12RFB9W RECTIFIER ASSEMBLY BLOCK 1

12 EHKA12CSHW COIL SPRING 1

13 EHKA12PBWW PUSH BUTTON 1

14 EHKA12SPWW SWITCH PLATE 1

15 EHKA12T2604W TORX SCREW 2 *1

16 EHKA12ESW ESCUTCHEON 1

17 EHKA12BAWW BLOW BRUSH 1

- EHKA1249503W OPERATING INSTRUCTUIONS 1

- EHKA1249501W INDIVIDUAL PACKAGE 1

- EHKA12S09W FILLER FOR PACKAGE 1

7.3. Model No. : EH-KA23 Exploded View for EH-KA23
