Operating Instructions
Rechargeable Professional Hair Clipper
Model No. ER‑GP21
Thank you for purchasing this Panasonic product.
Before operating this unit, please read these instructions completely and save them for future use.
Safety precautions..................2
Important information .....................6
Parts identication ..........................6
Charging the clipper........................7
Using the clipper .............................8
Care...................................................8
Troubleshooting ............................10
Removing the built-in
rechargeable battery .....................11
Specications ................................11
Contents
2
Safety precautions
To reduce the risk of injury, loss of life, electric shock,
re, and damage to property, always observe the
following safety precautions.
Explanation of symbols
The following symbols are used to classify and
describe the level of hazard, injury, and property
damage caused when the denotation is disregarded
and improper use is performed.
DANGER
Denotes a potential
hazard that will result in
serious injury or death.
WARNING
Denotes a potential
hazard that could
result in serious
injury or death.
CAUTION
Denotes a hazard
that could result in
minor injury or
property damage.
The following symbols are used to classify and
describe the type of instructions to be observed.
This symbol is used to alert users to a specic
operating procedure that must not be performed.
This symbol is used to alert users to a specic
operating procedure that must be followed in
order to operate the unit safely.
WARNING
►Power supply
Do not connect or disconnect the power plug
to a household outlet with a wet hand.
‑ Doing so may cause electric shock or injury.
Do not immerse the appliance and AC
adaptor in water or wash it with water.
Do not place the appliance and AC adaptor
over or near water lled sink or bathtub.
Never use the appliance if the AC adaptor is
damaged or if the power plug ts loosely in a
household outlet.
Do not damage the cord or power plug.
•Do not deface, modify, forcefully bend or
pull the cord or the power plug. Also, do
not place anything heavy on, twist or
pinch the cord.
‑ Doing so may cause burn, electric shock or re
due to a short circuit.
Keep the appliance dry.
3
WARNING
Do not use in a way exceeding the rating of
the household outlet or the wiring.
‑ Exceeding the rating by connecting too many
plugs to one household outlet may cause re
due to overheating.
Do not use anything other than the supplied
AC adaptor for any purpose. Also, do not use
any other product with the supplied AC
adaptor. (See page 6.)
‑
Doing so may cause burn or re due to short circuit.
Always ensure the appliance is operated on
an electric power source matched to the
rated voltage indicated on the AC adaptor.
Fully insert the power plug.
‑
Failure to do so may cause re or electric shock.
Always unplug the power plug from a
household outlet when cleaning.
‑
Failure to do so may cause electric shock or injury.
Regularly clean the power plug and the charging
plug to prevent dust from accumulating.
‑
Failure to do so may cause re due to insulation
failure caused by humidity.
Disconnect the power plug and wipe with a dry cloth.
►In case of an abnormality or malfunction
Immediately stop using and remove the power
plug if there is an abnormality or malfunction.
‑ Failure to do so may cause re, electric shock,
or injury.
<Abnormality or malfunction cases>
•The main unit or AC adaptor is deformed or
abnormally hot.
•The main unit or AC adaptor smells of burning.
•There is abnormal sound during use or
charging of the main unit or AC adaptor.
‑ Immediately request inspection or repair at an
authorized service center.
►This product
This product has a built-in rechargeable
battery. Do not throw into ame or heat.
‑ Doing so may cause uid leak, overheating, or
explosion.
Do not modify or repair.
‑
Doing so may cause re, electric shock, or injury.
Contact an authorized service center for repair
(battery change, etc.).
Never disassemble except when disposing of
the product.
‑
Doing so may cause re, electric shock, or injury.
4
WARNING
►Preventing accidents
Do not store within the reach of children or
infants. Do not let them use it.
‑ Putting parts or accessories in the mouth may
cause an accident or injury.
If the oil is consumed accidentally, do not
induce vomiting, drink a large amount of
water, and contact a physician.
If the oil comes into contact with eyes,
immediately wash thoroughly with running
water, and contact a physician.
‑
Failure to do so may result in physical problems.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
‑
Failure to do so may cause an accident or injury.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualied persons in order
to avoid a hazard.
‑
Failure to do so may cause an accident or injury.
CAUTION
►Protecting the skin
Do not press the blade strongly the skin.
Do not use the clipper for any purpose other
than hair trimming.
Do not directly apply the blades on ears or rough
skin (such as swellings, injuries or blemishes).
‑
Doing so may cause injury to ears or uneven skin.
Check that the blades are not damaged or
deformed before use.
‑ Failure to do so may cause skin injury.
►Note the following precautions
Do not allow metal objects or trash to adhere
to the power plug or the charging plug.
‑ Doing so may cause electric shock or re due
to a short circuit.
Do not drop or hit against other objects.
‑ Doing so may cause injury.
Do not wrap the cord around the AC adaptor
and main body when storing.
‑ Doing so may cause the wire in the cord to
break with the load, and may cause re due to
short circuit.
Disconnect the power plug from the
household outlet when not charging.
‑ Failure to do so may cause electric shock or re
due to electrical leakage resulting from
insulation deterioration.
5
CAUTION
Disconnect the power plug by holding onto
the power plug instead of the cord.
‑
Failure to do so may cause electric shock or injury.
Handling of the removed battery when disposing
DANGER
•The rechargeable battery is exclusively for
use with this appliance. Do not use the
battery with other products.
•Do not charge the battery after it has been
removed from the product.
•Do not throw into re or apply heat.
•Do not solder, disassemble, or modify the battery.
•Do not let the positive and negative
terminals of the battery get in contact with
each other through metallic objects.
•Do not carry or store the battery together
with metallic jewellery such as necklaces
and hairpins.
•Never peel off the tube.
‑ Doing so may cause uid leak, overheating, or
explosion.
The battery contains alkaline uid. If it comes
in contact with the eyes, do not rub the eyes,
and thoroughly rinse with clean water, such
as tap water.
‑ Failure to do so may cause loss of vision.
Consult a physician immediately.
WARNING
After removing the rechargeable battery, do
not keep it within reach of children and infants.
‑
The battery will harm the body if accidentally
swallowed.
If this happens, consult a physician immediately.
The battery contains alkaline uid. If it comes
in contact with the skin or clothes, rinse off
with clean water, such as tap water.
‑ Failure to do so may cause skin injury.
6
Important information
• This clipper is designed for professional use to trim
hair. It can be operated on rechargeable battery.
•
Apply the oil to the blade before and after each use.
(See page 9.)
Failure to apply the oil may cause the following problems.
‑ The clipper has become blunt.
‑ Shorter operating time.
‑ Louder sound.
• You should not allow permanent wave lotion, hair
dyeing or hair spray to come into contact with the
main body or the blades.
Doing so may result in cracking or corrosion.
• Before using an attachment, check that it has been
installed correctly. Failure to do so may cause hair to
be cut too short.
• The following symbol indicates that a specic
detachable power supply unit is required for
connecting the electrical appliance to the supply
mains. The type reference of power supply unit is
marked near the symbol.
• Charge the appliance correctly according to these
Operating Instructions. (See page 7 “Charging the
clipper”.)
• This appliance contains battery that is only
replaceable by skilled persons. Please contact an
authorized service center for the details of repair.
Parts identication
AMain body
1 Power switch [ / ]
2 Charge indicator lamp
()
3Appliance socket
BBlade
4Mounting hook
5 Cleaning lever
6 Moving blade
7Stationary blade
C
3 mm comb attachment
D
6 mm comb attachment
EAC adaptor (RE9-98)
8Charging plug
9 Comb attachment
shelves
:Cord
; Power plug
Accessories
FCleaning brush
GOil
7
Charging the clipper
• Make sure that the clipper is turned off.
1
1Place the clipper on the
AC adaptor.
2
2Insert the power plug into
a household outlet.
• Charging is completed after
approx. 8 hours.
• Check the charge indicator
lamp ( ) glows.
2
2
1
1
3
3Disconnect the power plug after charging
is completed.
(for safety and to reduce energy usage)
• The charge indicator lamp ( ) continues to glow
after charging is complete. There is no indication
to show that “charging is complete”.
Notes
• If there is noise from the radio or other sources while
using or charging the appliance, move to a different
location to use the appliance.
• When the appliance is not used for 6 months or more,
the battery will weaken (leak battery uid, etc.). Fully
charge the battery once every 6 months.
• When charging the clipper for the rst time or when it
has not been in use for more than 6 months, the lamp
on the main body may not glow for a few minutes, or
the operating time may shorten. Please charge it for
more than 16 hours in such cases.
• Recommended ambient temperature for charging is
0 °C – 35 °C. Battery performance may decrease
outside of the recommended temperature.
• A full charge will provide approximately 40 minutes of
continuous operation. (Based on dry using at
20 °C – 30 °C.)
The operating time may differ depending on the
frequency of use and the operating method.
• You can charge the battery before it is completely
discharged. However, it is recommended to charge
when the battery is completely discharged. The
battery life depends strongly on factors such as how it
is used and stored.
8
Using the clipper
• Make sure that the clipper is turned off.
• The appliance may not operate in an ambient
temperature approximately 0 °C or lower.
1
1Select the trimming heights indicated on
the insides and sides of the attachments.
2
2Slide the power switch on the main body
to the “ ” position to turn on the clipper.
Removing and mounting the comb attachments
Mounting the attachment
(Example: in the case of
3 mm)
Slide the attachment until
it clicks.
Removing the attachment
Remove the attachment by
pressing with your thumb.
3mm
click
Care
• Do not use thinner, benzine, alcohol or other
chemicals. Doing so may cause failure, cracking or
discoloration of the main body. Clean the main body
only with a soft cloth slightly dampened with tap water
or soapy tap water.
Removing and mounting the blade
• Make sure that the clipper is turned off.
Removing the blade
Hold the clipper with the switch
facing upward and push the
blade with your thumb while
catching the blade in your
other hand.
Mounting the blade
Fit the mounting hook into the blade mounting on the
clipper and push in until it clicks.
9
Cleaning
• Clean the clipper and the blade after each use.
(If not cleaned, the motion will become poor and the
sharpness will worsen.)
• Make sure that the clipper is turned off.
1. Brush off any hairs from the
clipper and from around the
blade.
2. Brush off the hairs from the
blade edge.
3. Brush the hairs out from
between the stationary
blade and the moving blade
while pressing down on the
cleaning lever (a) to raise
the moving blade.
Lubrication
• Apply the oil to the blade before and after each use.
1
1Remove the blade.
(See page 8.)
2
2Apply a drop of the
oil to each indicated
point.
3
3Attach the blade to
the main body, turn
on the power and
allow to run for
approximately
5 seconds.
►Replacement parts
Replacement part is available at your dealer or Service
Center.
Replacement parts for
ER‑GP21 Blade WER9352
10
Cleaning the AC adaptor
Use the cleaning brush to clean hair trimmings and
dust in the charging plug, the comb attachment shelves
or in the hole on the bottom surface.
Storing comb attachments
You can store your comb
attachments in the comb
attachment shelves.
Troubleshooting
Problem Action
The clipper has
become blunt.
Operating time is
short.
Clipper stopped
functioning.
Until problems are solved,
please follow each procedure
as follows;
1. Charge the clipper.
(See page 7.)
2. Clean the blade and apply
oil. (See page 9.)
3. Replace the blade.
(See page 8.)
4. Have the battery replaced by
an authorized service center.
The clipper cannot
be charged.
Push the main body into the
charging stand or appliance
plug all the way.
Charge within the
recommended charging
temperature of 0 °C to 35 °C.
Makes a loud sound.
Apply oil.
(See page 9.)
Have the battery replaced by
an authorized service center.
If the problems still cannot be solved, contact the store
where you purchased the appliance or a service center
authorised by Panasonic for repair.
Otros manuales para ER-GP21
2
Tabla de contenidos
Otros manuales de Cortapelos de Panasonic
Panasonic
Panasonic ER-145 Manual de usuario
Panasonic
Panasonic ER-GC70 Manual de usuario
Panasonic
Panasonic ER1421 Manual de usuario
Panasonic
Panasonic ER5209 Manual de usuario
Panasonic
Panasonic ER-206 Manual de usuario
Panasonic
Panasonic ER-GP80 Manual de usuario
Panasonic
Panasonic ER-DGP82 Manual de usuario
Panasonic
Panasonic ER1420 Manual de usuario
Panasonic
Panasonic ER-GC30 Manual de usuario
Panasonic
Panasonic ER-CA70 Manual de usuario
Panasonic
Panasonic ER HGP84 Manual de usuario
Panasonic
Panasonic ER-GC71 Manual de usuario
Panasonic
Panasonic ER-GC70 Manual de usuario
Panasonic
Panasonic ER-FGP86 Manual de usuario
Panasonic
Panasonic ER-HGP72 Manual de usuario
Panasonic
Panasonic ER1611 Manual de usuario
Panasonic
Panasonic ER-GC52 Manual de usuario
Panasonic
Panasonic ER1511 Manual de usuario
Panasonic
Panasonic ER-GC71 Manual de usuario
Panasonic
Panasonic ER-SC60 Manual de usuario
