Panasonic ES2044-E8 Manual de usuario

1 SCHEMATIC DIAGRAM 2

2 WIRING DIAGRAM 2

3 DISASSEMBLY INSTRUCTIONS 3

reserved. Unauthorized copying and distribution is a

violation of law.

ES2044-E8

ES2047-E8

4 ASSEMBLY INSTRUCTIONS 4

5 TROUBLESHOOTING GUIDE 5

6 EXPLODED VIEW and REPLACEMENT PARTS LIST 6

Epilator

SPECIFICATIONS

Power source

C 220-240V, 50-60Hz

Power consumption

pprox. 5W

Motor voltage 12V DC

Charging time 12 hours

Weight 135g (unit with the big epilation head)

130g (unit with the small epilation head / unit with the shaver head)

Supplied accessories Soft case

Cleaning brush

CONTENTS

Page Page

ORDER NO. PCD0606E34CE

1 SCHEMATIC DIAGRAM

2 WIRING DIAGRAM

ES2044-E8 / ES2047-E8

1. Remove the cap and the epilation head.

Loosen three screws on top.

2. Remove the head mounting base, side panel, switch and

switch cam. Remove the chassis with pushing the head

release buttons.

3. Loosen two screws and take out the plug block with using

the plug remove jig.

Insert the jig and push into the plug connector and take it

out.

3 DISASSEMBLY INSTRUCTIONS

3.1. MAIN UNIT

Follow the procedure below to disassemble the main body.

ES2044-E8 / ES2047-E8

1. Remove the foil frame, inner blade and trimmer driving bar.

NOTE: Lift the trimmer driving bar up by using

something like a slotted head screwdriver as shown in

figure with care of breakage.

For assembly, reverse the order of disassembly.

1. Confirm the colors of each lead wire when soldering with

motor.

2. Press fit the lead wires into housing neatly.

3. Put fuse into frame located side of chassis and fixed it with

an adhesive tape.

3.2. SHAVER HEAD

4 ASSEMBLY INSTRUCTIONS

4.1. MAIN UNIT

ES2044-E8 / ES2047-E8

5 TROUBLESHOOTING GUIDE

(Refer to WIRING CONNECTION DIAGRAM)

Motor does not operate. <CHECK POWER ADAPTOR.> NO Replace charging

→

→→

→Connect to rated voltage with the charging adaptor. →

→→

→adaptor.

OK if it is approximately DC4V.

↓

↓↓

↓OK

<CHECK EPILATION HEAD.> NO Replace epilation head.

Check if there is any deformation with skin protector. →

→→

→

↓

↓↓

↓OK

<CHECK DRIVING BLOCK.> NO Repair connection of

Check continuities between (+) terminal of plug chassis and (+) terminal of →

→→

→soldering part.

motor, or (-) terminal of plug chassis and (-) terminal of motor.

OK if there is continuities with switching ON without connecting charging adaptor.

↓

↓↓

↓NO

<CHECK CONNECTING POINTS.> NO Repair connection of

Check conditions of soldering part at motor terminals, plug chassis and printed →

→→

→soldering part.

circuit boards. OK Replace switch terminal

→

→→

→plate.

↓

↓↓

↓OK

<CHECK MOTOR.> NO Replace the motor.

The motor should turn when 12V DC is applied to terminals. →

→→

→

Does not charge. <CHECK RECHARGEABLE BATTERY.> NO Replace rechargeable

Does not light the →

→→

→Okay if the voltage of rechargeable battery is more than approximately →

→→

→battery.

charging indication 2.8V DC at fully charged and 2.0V DC at empty between (+) and (-) terminals.

lamp.

↓

↓↓

↓OK

<CHECK MODULE.> NO Replace module.

Replace the (+) terminal of battery and connect the rated voltage with switch →

→→

→

OFF position.

Check charging current, if it is in between 115mA to 175mA.

ES2044-E8 / ES2047-E8

6 EXPLODED VIEW and REPLACEMENT PARTS LIST

6.1. ES2044 EXPLODED VIEW

ES2044-E8 / ES2047-E8

6.2. ES2044 REPLACEMENT PARTS LIST

NOTE:

*A=available as an optional accessory

*B=only available as set

*C=available individually

Ref. No. Part No. Part Name & Description Remarks Per Unit

1WES2044A7158 PROTECTIVE CAP *C (BG) 2

2WES2044A3108 BIG EPILATION HEAD FRAME (BG) 1

3WES2044W1068 BIG EPILATION HEAD for LEGS/ARMS (BG) 1

4WES331B9257 TAPPING SCREW *C K2-8 2

5WES2047L3387 BUTTON MOUNTING BASE B (BG) 1

6WES2045L9008 TAPPING SCREW *C K2-6 (BG) 4

7WES2047W3117 HEAD MOUNTING BASE (BG) 1

8WES2044W3068 HOUSING (BG) 1

9WES2047W3207 SWITCH HANDLE (BG) 1

10 WES2044A3068 SIDE PANEL (BG) 1

11 WES2044A3278 HEAD RELEASE BUTTON W/SPRING (BG) 1

12 WES2047W1247 SWITCH CAM A (BG) 1

13 WES2047K0987 SWITCH O-RING (BG) 1

14 WES2047K0997 HOUSING O-RING (BG) 1

15 WES701S9706 SCREW *C SUS2-12 (BG) 2

16 WES2047S9707 SCREW SUS2-8 (BG) 1

17 WES2047L0337 O-RING B *B (3PCS/PK) (BG) 3

18 WES2047L4207 BUTTON MOUNTING BASE A (BG) 1

19 WES2047L2447 SWITCH PLATE (BG) 1

20 WES2047W1257 SWITCH CAM B (BG) 1

21 WES2047L2148 MODULE (BG) 1

22 WES2045L1008 MOTOR ASSEMBLY (BG) 1

23 WES2047L4197 PLUG CHASSIS (BG) 1

24 WES2047L0327 O-RING A *B (2PCS/PK) (BG) 2

25 WES2047L2508 RECHARGEABLE BATTERY *B NI-MH TYPE (2PCS/PK) (BG) 2

26 WES2047L0977 WASHER & O-RING SET *B (2PCS/PK) (BG) 2

27 WES2044A3128 SMALL EPILATION HEAD FRAME (BG) 1

28 WES2047W1078 SMALL EPILATION HEAD for UNDERARMS/BIKINI-LINE (BG) 1

29 WES2047W7664 POWER ADAPTOR C-2 PLUG (BG) 1

30 WES2047H6767 CLEANING BRUSH (BG) 1

31 WES2047W7008 SOFT CASE (BG) 1

-WES2047P8108 OPERATING INSTRUCTIONS (BG) 1

ES2044-E8 / ES2047-E8

6.3. ES2047 EXPLODED VIEW

ES2044-E8 / ES2047-E8

6.4. ES2047 REPLACEMENT PARTS LIST

NOTE:

*A=available as an optional accessory

*B=only available as set

*C=available individually

Ref. No. Part No. Part Name & Description Remarks Per Unit

1WES2047P7158 PROTECTIVE CAP *C (BG) 2

2WES2045P3108 BIG EPILATION HEAD FRAME (BG) 1

3WES2047W1067 BIG EPILATION HEAD for LEGS/ARMS (BG) 1

4WES331B9257 TAPPING SCREW *C K2-8 2

5WES2047L3387 BUTTON MOUNTING BASE B (BG) 1

6WES2045L9008 TAPPING SCREW *C K2-6 (BG) 4

7WES2047W3117 HEAD MOUNTING BASE (BG) 1

8WES2047W3068 HOUSING (BG) 1

9WES2047W3207 SWITCH HANDLE (BG) 1

10 WES2047P3068 SIDE PANEL (BG) 1

11 WES2047P3277 HEAD RELEASE BUTTON W/SPRING (BG) 1

12 WES2047W1247 SWITCH CAM A (BG) 1

13 WES2047K0987 SWITCH O-RING (BG) 1

14 WES2047K0997 HOUSING O-RING (BG) 1

15 WES701S9706 SCREW *C S2-12 (BG) 2

16 WES2047S9707 SCREW S2-8 (BG) 1

17 WES2047L0337 O-RING B *B (3PCS/PK) (BG) 3

18 WES2047L4207 BUTTON MOUNTING BASE A (BG) 1

19 WES2047L2447 SWITCH PLATE (BG) 1

20 WES2047W1257 SWITCH CAM B (BG) 1

21 WES2047L2148 MODULE (BG) 1

22 WES2045L1008 MOTOR ASSEMBLY (BG) 1

23 WES2047L4197 PLUG CHASSIS (BG) 1

24 WES2047L0327 O-RING A *B (2PCS/PK) (BG) 2

25 WES2047L2508 RECHARGEABLE BATTERY *B NI-MH TYPE (2PCS/PK) (BG) 2

26 WES2047L0977 WASHER & O-RING SET *B (2PCS/PK) (BG) 2

27 WES2045P3558 BIKINI COMB (BG) 1

28 WES2045W4038 FOIL FRAME (BG) 1

29 WES2047W0787 SHAVER HEAD (BG) 1

30 WES9753Y OUTER FOIL 1

31 WES9752Y INNER BLADE 1

32 WES2047P3128 SMALL EPILATION HEAD FRAME (BG) 1

33 WES2047W1078 SMALL EPILATION HEAD for UNDERARMS/BIKINI-LINE (BG) 1

34 WES2047W7664 POWER ADAPTOR C-2 PLUG (BG) 1

35 WES2047H6767 CLEANING BRUSH (BG) 1

36 WES2047W7008 SOFT CASE (BG) 1

-WES2047P8108 OPERATING INSTRUCTIONS (BG) 1

ES2044-E8 / ES2047-E8
