Operating Instructions

使用说明书

AC/Rechargeable Shaver

交流 / 充电式剃须刀

Model No.

型号 ES8253

Before operating this unit, please read these instructions completely and save them.

在使用本产品前，请仔细阅读本说明书并妥善保管。

ES8253_CH.indb 1 2007/07/24 19:04:52

English

Important

Using the shaver

Caution - The outer foil is very thin and can be damaged if not

used correctly. Check that the foil is not damaged before using

the shaver. Do not use the shaver if the foil etc. is damaged as

you will cut your skin.

Charging the shaver

Do not use any power cord or AC adaptor other than one

speciﬁcally designed for this model.Plug in the adaptor into a

household outlet where there is no moisture and handle it with

dry hands.The shaver may become warm during use and

charging. However, this is not a malfunction. Do not charge the

shaver where it will be exposed to direct sunlight or other heat

sources.Hold the adaptor when disconnecting it from the

household outlet. If you tug on the power cord, you may damage

it. Contact an authorized service center if the power cord gets

damaged.

Adequate ambient temperature for charging is 15-35 °C.

If the indicators on the LCD panel do not glow, wait for a short

while until it glows.

Cleaning the shaver

Warning - Disconnect the power cord from the shaver before

cleaning it to prevent electric shock.

Keep both the inner blades inserted. If only one of the inner

blades is inserted, the shaver may be damaged.If you clean the

shaver with water, do not use salt water or hot water. Do not

soak the shaver in water for a long period of time.Wipe it with a

cloth dampened with soapy water. Do not use thinner, benzine

or alcohol.

Storing the shaver

Disconnect the power cord when storing the shaver.Do not

bend the power cord or wrap it around the shaver. Do not leave

this shaver within the reach of small children. Keep these

operating instructions in a safe place.



SPECIFICATIONS

Model: ES8253

Rated input: a.c 100-240 V, 150 mA

Rated output: d.c 5.7 V, 1.0 A

Charging time: 1 hour

This product is intended for household use only.

The unit is applied to the Chinese standard GB4706.1 appendix

B, GB4706.9 and Q/(GZ) PEWWBG 6.

Parts identiﬁcation



































Protective cap

System outer foil

3Inner blades

4System outer foil

release buttons

5Finger rest

6Pivot action

selector

70/1 switch

8LCD panel

9Appliance socket

Trimmer

Trimmer handle

Adaptor (RE7-40)

Power cord

Appliance plug

Case

Cleaning brush

Oil

•

ES8253_CH.indb 2 2007/07/24 19:04:52

English

Charging

Charge

1Insert the appliance plug

into the shaver.

2Plug in the adaptor into a

household outlet.

The indicators on the LCD panel glow

and charging starts.

Charging is completed when the

indicators on the LCD panel blink.

(Max. 1 hour later)

•

Cord shaving

If you insert the appliance plug to the shaver and plug in the

adaptor into a household outlet, you can use it even if the battery

capacity is low.

If the shaver does not work, continue charging it for approx.1

minute.



•

About the LCD panel

The LCD panel shows the remaining battery capacity from 0% to

100%, in 10% increments.

While charging After charging is

completed

10 minutes after

charging is

completed

The indicators

glow.

The indicators

blink once every

second.

The indicators blink

once every 2

seconds.

During use After use

min.used

The used time is shown.

The shown time returns to

[0’00”] after 10 minutes.

•

The used time and the

remaining battery capacity

are shown alternately after

turning off the shaver.

When the battery capacity is low

You can shave 1 to 2 times after “10%”appears.

(This will differ depending on usage.)

•

“10%” appears and blinks.

A full charge will supply enough power for approx. 14 shaves of

3 minutes each.

•

ES8253_CH.indb 3 2007/07/24 19:04:53

English

Using the shaver

Shave

90˚

1Press the 0/1

switch. 2

2Hold the shaver as

illustrated above and

shave.

Start out shaving by applying gentle pressure to your face.

Stretch your skin with your free hand and move the shaver

back and forth in the direction of your beard.You may gently

increase the amount of pressure as your skin becomes

accustomed to this shaver. Applying excessive pressure does

not provide a closer shave.

•

Pivot action selector

Use to select “SOFT”(soft) or “LOCK” (lock).

You can change the pivot action whether the

shaver is turned on or off.

SOFT

LOCK

Using the trimmer

Slide the trimmer handle up.Place

at a right angle to your skin and

move downwards to trim your

sideburns.



Cleaning

Clean

We recommend that you clean your

shaver with the “sonic”vibration

turbo-cleaning mode when the

faucet symbol appears on the

LCD panel.

1. Disconnect the power cord from

the shaver.

2. Apply some hand soap and some

water to the outer foil.

3. Press the 0/1 switch for more than

2 seconds to activate the turbo

mode for “sonic” vibration

cleaning.

appears on the LCD panel.

After about 20 seconds, it will be

automatically turned off, or you

can turn it off by pressing the

0/1 switch.

Remove the system outer foil and

press the 0/1 switch for more than

2 seconds to activate the turbo

mode for “sonic” vibration cleaning

and clean it with running water.

5. Wipe off any drops of water with a

dry cloth.

6. Remove the system outer foil to

allow it to dry completely.

The mark on the left

is for a washable

shaver and indicates

it can be cleaned

with water.

•

ES8253_CH.indb 4 2007/07/24 19:04:53

English

Caution for turbo mode

Shaving in turbo mode may damage your skin.Turn the shaver

off and then on again to cancel turbo mode.

Do not place your ﬁngers on the 0/1 switch while using the

shaver.This may cause the shaver to turn off or enter turbo

mode.Place your ﬁngers on the ﬁnger rest while using the

shaver.

•

Lubrication

To maintain shaving comfort for a long time, it is recommended

that the oil provided with the shaver is used.

1. Switch off the shaver.

2. Apply one drop of oil to each of the outer foils.

3. Raise the trimmer and apply a drop of oil.

4. Switch the shaver on, and run it for approximately ﬁve

seconds.

5. Switch off the shaver, and wipe off any excess oil from the

outer foils with a soft cloth.

Replacing the system outer foil and the inner

blades

appears on the LCD panel once a year. (This will differ

depending on usage.) We recommend checking the system outer

foil and the inner blades when it appears.

Press the 0/1 switch for more than 30 seconds to delete .

system outer foil once every year

inner blade once every two years

1. Press the system outer foil

release buttons and lift the

system outer foil upwards as

illustrated.

2 3

2. Remove the inner blades one

at a time as illustrated.

Do not touch the edges

(metal parts) of the inner

blades to prevent injury to

your hand.

3. Insert the inner blades one at

a time until they click as

illustrated.

4. Insert the system outer foil by

pushing it downwards until it

clicks.

•

ES8253_CH.indb 5 2007/07/24 19:04:54

English

Cleaning with the brush

(A) (B)

1. Clean the inner blades using

the short brush by moving it in

direction (A).

Clean the system outer foil,

the shaver body and the

trimmer using the long brush.

Do not move the short brush

in direction (B) as it will

damage the inner blades and

affect their sharpness.

Do not use the short brush to

clean the outer foils.

•

Removing the built-in rechargeable battery

Remove the built-in rechargeable battery before disposing of the

shaver. Please make sure that the battery is disposed of at an

ofﬁcially designated location if there is one.Do not dismantle or

replace the battery so that you can use the shaver again.This

could cause ﬁre or an electric shock. Replace it at an authorized

service center.

Disconnect the power cord from

the shaver when removing the

battery.

Perform steps to 7and lift the

battery, and then remove it.

•















For environmental protection and recycling of materials

This shaver contains a Lithium-ion battery.

Please make sure that the battery is disposed of at an ofﬁcially

assigned location, if there is one in your country.

ES8253_CH.indb 6 2007/07/24 19:04:54

中文

重要事项

使用剃须刀

注意-外刀网很薄，若使用不正确就可能造成损坏。使用剃须

刀前，请确认刀网是否损坏。如果刀网已损坏请不要使用该剃须

刀，因为这样会割伤皮肤。请勿用于修剪宠物的毛发。

给剃须刀充电

除了为本型号专门设计的充电器，不要使用其它任何电源线、充

电器进行充电。将充电器插入非潮湿的家用插座里，拿时双手要

保持干燥。剃须刀在使用和充电过程中可能会发热。但是，这不

是故障。不要在有阳光直射或其它热源的地方给剃须刀充电。从

家用插座上拔出充电器时要抓住充电器。如果用力拉电源线，可

能会损坏电源线。电源软线不能更换，如果软线损坏，此充电器

应废弃。

充电的合适环境温度为15至35摄氏度。

如液晶显示屏上的指示灯不亮，稍等片刻直至其亮起。

清洁剃须刀

警告-清洁剃须刀前请断开电源线，以防触电。

请在装有两个内刀头的状态进行清洗，若在仅装有一个内刀头的

状态进行清洗，可能会损坏剃须刀。可用水清洗剃须刀，不要使

用盐水或热水。不要将剃须刀长时间浸泡在水中。用蘸肥皂水的

布擦拭剃须刀。不要使用稀释剂，汽油或酒精擦拭剃须刀任何

部位。

存放剃须刀

存放剃须刀时请拔出电源线。不要折弯电源线或将电源线绕在剃

须刀上。请勿将剃须刀放在幼童可以接触到的地方。请妥善保管

本说明书。请妥善处理本产品的包装袋，避免婴幼儿窒息等意外

发生。

规格

型号： ES8253

额定输入： 交流100-240V,150mA

额定输出： 直流5.7V,1.0A

充电时间： 1小时

本产品仅限家庭使用。



本产品符合中国标准GB4706.1附录B和GB4706.9及企业标准

Q/(GZ)PEWWBG6。

各部分名称



































保护盖

外刀网

3内刀头

4外刀网释放按钮

5指握位置

6刀头浮动选择开关

70/1开关

8液晶显示屏

9电源线插孔

修剪刀

修剪刀操纵杆

充电器(RE7-40)

充电器电源线

电器插头

盒

清洁刷

润滑油

•

ES8253_CH.indb 7 2007/07/24 19:04:54

中文

充电中

充电

1将充电器电源线插头连接到

剃须刀上。

2将充电器插头插入家用电源

插座里。

液晶显示屏上的指示灯亮，充电开始。

液晶显示屏上的指示灯开始闪烁则表示

充电完成。

(最多1小时后)

•

交流电剃须

当电池电量低时，您也可以将剃须刀通过充电器连接至家用电源

插座，利用交流电进行剃须。

如果剃须刀不能工作，请充电约1分钟后使用。



•

关于液晶显示屏

液晶显示屏显示电池的剩余电量，从0%至100%，每10%一档。

充电时充电完成后充电完成10分钟后

指示灯亮指示灯每秒闪烁一

次。

指示灯每两秒闪烁一

次。

使用中使用后

min.used

显示已使用时间。

显示时间在满10分钟后归

[0’00”]。

•关闭剃须刀后，已使用时间

和剩余电量交替显示。

电池电量不足时

电量显示“10%”后您还可以使用剃须刀1到

2次。



(根据使用情况而定。)

•

显示“10%”，开始闪烁。

充足电后大约可提供14次剃须所需的电量。

（一次剃须约为3分钟）

•

ES8253_CH.indb 8 2007/07/24 19:04:55

中文

使用剃须刀

剃须

90˚

1按下0/1开关。 2

2如上图所示握住剃须刀剃

须。

轻轻地压向面部开始剃须。用另一只手绷紧脸上皮肤，逆着胡

须生长方向前后移动剃须刀。当皮肤适应剃须刀之后您可以稍

稍增加压力。但是施加过多的压力不能为您带来更服贴的剃须

效果。相反，对初次使用者可能会造成皮肤伤害。

•

刀头浮动选择开关

用来选择“SOFT”(柔和)或“LOCK”(锁定)。

不论剃须刀是否接通或关闭，你都可以改变刀头

浮动模式。

SOFT

LOCK

使用修剪刀

将修剪刀操纵杆往上推，以打开修

剪刀。将修剪刀与皮肤成直角

（90度）的位置向下移动以修剪鬓

角。



清洁中

清洁

当液晶显示屏上出现时，建议

您使用自动清洗·充电装置

或“sonic”（声波）振动清洗模

式来清洗您的剃须刀。

1.断开剃须刀的电源线。

2.在外刀网上涂抹少量洗手液和

水。

3.按下0/1开关2秒钟以上启动声

波洗净模式进行“sonic”（声

波）振动清洗。

显示在液晶显示屏上。

大约20秒钟后，它会自动关

闭，或者按0/1开关关闭它。

4.取下外刀网，按下0/1开关2秒

钟以上启动声波洗净模式进

行“sonic”（声波）振动清

洗。使用流动水来清洁。

5.用干布拭去水珠。

6.取下外刀网使其彻底干燥。

左侧符号表示剃须刀

可以全身水洗。

警告：剃须刀需与电源软线分离

后才能用水清洗。

•

ES8253_CH.indb 9 2007/07/24 19:04:56

中文

注意声波洗净模式

以声波洗净模式剃须可能会损伤皮肤。关闭剃须刀，再打开即

可取消声波洗净模式。

使用剃须刀时不要将手指放在0/1开关上。这样会导致剃须刀关

闭或进入声波洗净模式。使用剃须刀时将手指放在指握位置

上。

•

润滑

为长期保持剃须的舒适度，建议使用随剃须刀一起提供的润滑

油。

1.关闭剃须刀。

2.给每个外刀网涂一滴油。

3.推起修剪刀并涂一滴油。

4.接通剃须刀电源，运转约5秒钟。

5.关闭剃须刀，使用软布从外刀网上拭去多余的润滑油。

更换外刀网和内刀头

液晶显示屏上的每年显示一次。（根据使用次数会有所不同。）

当此信号开始显示时，我们建议您检查本产品的外刀网和内刀头。

按住0/1按钮30秒以上以清除标识。

建议外刀网每年更换一次，内刀头每两年更换一次，以维持剃须刀

剃须性能。

1.按下按钮，如图示向上提起。

2.如图示取下内刀头，每次取下

一个。

不要触摸内刀头的边沿(金属

部分)，防止您的手受到损

伤。

3.每次插入一只内刀头，如图所

示直到它们卡嗒入位。

4.向下推入外刀网直至它卡嗒入

位。

•

2 3

ES8253_CH.indb 10 2007/07/24 19:04:56

Tabla de contenidos

Otros manuales de Rasuradora eléctrica de Panasonic

Panasonic

Panasonic ER-GB96 Manual de usuario

Panasonic

Panasonic ES-LT70 Manual de usuario

Panasonic

Panasonic Smooth Operator ES-204 Manual de usuario

Panasonic

Panasonic ES-LV53 Manual de usuario

Panasonic

Panasonic ER-GK60 Manual de usuario

Panasonic

Panasonic ES-BSL4 Manual de usuario

Panasonic

Panasonic ESLA63 Manual de usuario

Panasonic

Panasonic ES?LT20 Manual de usuario

Panasonic

Panasonic ES8813 Manual de usuario

Panasonic

Panasonic ER-GB44 Manual de usuario

Panasonic

Panasonic ES-RW33 Manual de usuario

Panasonic

Panasonic ES4033-A3 Manual de usuario

Panasonic

Panasonic ES?LV95 Manual de usuario

Panasonic

Panasonic ES-WR40VP Manual de usuario

Panasonic

Panasonic ES-LV61 Manual de usuario

Panasonic

Panasonic ER?GB50 Manual de usuario

Panasonic

Panasonic ES-LV61 Manual de usuario

Panasonic

Panasonic ES-LV5B Manual de usuario

Panasonic

Panasonic ES726K Operating Manual de usuario

Panasonic

Panasonic ES-LV6U Manual de usuario

Panasonic

Panasonic ES-LV64 Manual de usuario

Panasonic

Panasonic ES-LA63A Manual de usuario

Panasonic

Panasonic ER-GN30 Manual de usuario

Panasonic

Panasonic ER-GK75 Manual de usuario

Manuales populares de Rasuradora eléctrica de otras marcas

Philips

Philips MicroAction 4402LC Manual de usuario

Philips

Philips HQ7740 Manual de usuario

Philips

Philips Norelco BG2022 Bodygroom Manual de usuario

Norelco

Norelco Quadra 7610X Manual de usuario

Philips

Philips 7616X Manual de usuario

Philips

Philips HQ802 Manual de usuario

Philips

Philips HQ7363/17 Manual de usuario

Braun

Braun WaterFlex WF2s Manual de usuario

Philips

Philips NORELCO S7371 Manual de usuario

Daga

Daga MT-400 Manual

Philips

Philips RQ119x Manual de usuario

Remington

Remington BHT100 Manual de usuario

Philips

Philips Bodygroom BG2000 Manual de usuario

Kompernass

Kompernass KH 5537 Manual de usuario

Remington

Remington BHT6100 Manual de usuario

Philips

Philips qc5365 Manual de usuario

MIA

MIA Aqua Body Manual de usuario

Philips

Philips NORELCO AT880 Manual de usuario
