Panasonic DMRE80HP Instrucciones de construcción

Service Manual

TOP NEXT

ORDER NO.DSD0306005C1

B24

DVD Video Recorder



DMR-E80HP

DMR-E80HPC

Colour

(S).......................Silver Type

Specifications

Power supply: AC120 V, 60 Hz

Power consumption: 35 W

Recording system: DVD video recording standards (DVD-RAM),

DVD video standards (DVD-R)

Optical pick-up: System with 1 lens, 2 integration units (662 nm wavelength for DVDs, 790 nm wavelength for CDs)

Recordable discs: 12 cm 4.7 GB DVD-RAM discs

12 cm 9.4 GB DVD-RAM discs

8 cm 2.8 GB DVD-RAM discs

12 cm 4.7 GB DVD-R discs

(for General Ver. 2.0)

8 cm 1.4 GB DVD-R discs

(for General Ver. 2.0)

Recording time: Max. 6 hours

(Using 4.7 GB disc): XP: 60 minutes

SP: 120 minutes

LP: 240 minutes

EP: 360 minutes

(Using built-in HDD): Max. 104 hours

XP: 17 hours

SP: 34 hours

LP: 68 hours

EP: 104 hours

(continuous recording time is 6 hours max.)

Region number: Region No.1

Discs played: 12 cm 4.7 GB DVD-RAM discs

12 cm 9.4 GB DVD-RAM discs

8 cm 2.8 GB DVD-RAM discs

12 cm 4.7 GB DVD-R discs

(for General Ver. 2.0)

8 cm 1.4 GB DVD-R discs

(for General Ver. 2.0)

DVD-VIDEOdiscs

Page

11/18/2008

CD-Audio discs (CD-DA)

Video CD discs

DVD-Audio discs

CD-R/ CD-RW discs

(CD-DA, Video CD, MP3 formatted discs)

Video system

TV system: NTSC system, 525 lines, 60 fields

Recording system: MPEG2 (Hybrid VBR)

Input: LINE (pin jack), 1.0 Vp-p; 75Ω

S connector

Y: 1.0 Vp-p; 75Ω

C: 0.286 Vp-p; 75Ω

Output: LINE (pin jack), 1.0 Vp-p; 75Ω

S connector

Y: 1.0 Vp-p; 75Ω

C: 0.286 Vp-p; 75Ω

Component video output (480p/480i):

Y: 1.0 Vp-p; 75Ω

PB: 0.7 Vp-p; 75Ω

PR: 0.7 Vp-p; 75Ω

D-connector output: Not provided

Antenna reception input: TV Channel: 2ch-69ch, 75Ω

CATV Channel: 1ch-125ch, 75Ω

RF converter output: Not provided

Audio system

Recording system: Dolby Digital (XP/SP/LP/EP)

LINEAR PCM (XP mode only)

Input: LINE (pin jack)

Reference input: 309 mVrms

FS: 2 Vrms (1 kHz, 0 dB)

Input impedance: 47 kΩ

Output: LINE (pin jack)

Reference output: 309 mVrms

FS: 2 Vrms (1 kHz, 0 dB)

Output impedance: 1 kΩ

(Load impedance: 10 kΩ)

Number of channels: Recording: 2 channels

Playback: 2 channels

Other input/output connectors: Digital audio optical output connector

Dimensions: Approx.

430 (W)×79 (H)×300 (D) mm

[Approx. 1615/ 16“(W)×31/ 8” (H)×113/ 16” (D)]

(excludingprotrusions)

Mass: Approx. 4.5 kg (9.92 lbs)

Operating temperature range: 5°C-40°C (41°F-104°F)

Operating humidity range: 10%-80% RH (no condensation)

Clock unit: Quartz-controlled 12-hour digital display

LASER Specification

Class I LASER Product

Wave length: 775-815 nm 655-666 nm

Laser power: No hazardous radiation is emitted with the safety protection.

Power consumption in standby mode:

approx. 3.1 W

Solder:

This model uses lead free solder (PbF).

Notes:

Mass and dimensions are approximate.

Specifications are subject to change without notice.

Notes:

The part of DVD RAM Drive (VXY1772) is listed separately.

Please refer to ORDER NO. RAM0301002C0.

Page

11/18/2008

distribution is a violation of law.

TOP

Page

11/18/2008

Page

11/18/2008

Page

11/18/2008

Page

11/18/2008

17 Replacement Parts List

TOP PREVIOUS NEXT

Notes:

*Important safety notice:

Components identified by mark have special characteristics important for safety.

Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound

(capacitors), low-noise (resistors), etc. are used.

When replacing any of components, be sure to use only manufactures specified parts shown in the parts

list.

*Warning: This product uses a laser diode. Refer to caution statements.

*Capacity values are in microfarads (µF) unless specified otherwise, P=Pico-farads (pF), F=Farads (F).

*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000k (OHM).

*The marking (RTL) indicates the retention time is limited for this item. After the discontinuation of this

assembly in production, it will no longer be available.

*“<IA>”-“<IB>”, marks in Remarks indicate languages of instruction manuals. [<IA>: English, <IB>:

Canadian French] All parts aresupplied by S.P.C..

Ref. No. Part No. Part Name & Description Pcs

Remarks



01 CASING/ACCESSORY/PACKING

1RKM0485-S TOP COVER 1

2 SNE2129-4 SCREW 2

3 VHD0690 SCREW 8

4ETXMM447A4G

POWER SUPPLY P.C.B. 1

(RTL)

5REP3497M MAIN P.C.B. 1

(RTL)

6REP3496F DIGITAL P.C.B. 1

(P)

6 REP3496FG DIGITAL P.C.B. 1

(PC)

7VWJ1650 FFC(40P) 1

8L6FALCCE0004 FAN MOTOR 1

9RGR0337J-B REAR PANEL 1

(P)

9 RGR0337J-C REAR PANEL 1

(PC)

10 RMX0244 PCB HOLDER 1

13 RKA0143-K LEG 2

14 RKA0144-K FOOT RUBBER 2

15 XSN3+4FZ SCREW 1

Page

11/18/2008

16 XTN3+23JFZ SCREW 2

17 XTN3+7F-C SCREW 12

18 RHD30106 SCREW 4

19 RMA1640 DIGITAL ANGLE 1

20 RYP1197A-S FRONT PANEL ASS’Y1 1

20-1 RGU2185A-K POWER BUTTON 1

20-2 RGU2186-S OPEN BUTTON 1

20-3 RGU2188-S OPERATION BUTTON 1

20-4 RGQ0327-Q IR WINDOW GUIDE 1

20-5 RKW0724-S IR WINDOW 1

20-6 RGU2187A-K CHANNEL BUTTON 1

20-8 RGK1625A-S FL ORNAMENT 1

20-9 RMR1526-H SHAFT HOLDER 1

20-10 RGK1623A-K FRONT ORNAMENT(R) 1

20-11 RGK1622-K FRONT ORNAMENT(L) 1

20-12 RKF0667-K TRAY DOOR 1

20-13 VMB3410 BLINDER SPRING 1

20-14 XTN2+6G SCREW 4

20-15 VGB0560 PANASONIC BADGE 1

20-16 RMC0539 EARTH PLATE 1

20-17 RGL0620-Q LIGHTING PIECE 1

20-18 RKF0666E-S PANEL DOOR 1

20-19 XTBS26+8J SCREW 1

20-20 RMA1639 FRONT ANGLE 1

20-21 RMX0253 DAMPER SHEET 1

20-22 RGK1651-S TRAY ORNAMENT 1

20-23 RMZ0693 SHEET 1

20-24 RGL0629-Q PANEL LIGHT(B) 2

20-25 RMX0268 DOOR DAMPER 1

21 VGQ5954 TAPE 1

22 RGQ0324-K SHEET 1

29 XTBS26+10J SCREW 8

33 REP3528DB FRONT(L) P.C.B. 1

(RTL)

34 REP3528EA FRONT(R) P.C.B. 1

(RTL)

35 RMC0549 EARTH PLATE (A) 1

36 N3CBBTM00005

HARD DISC DRIVE ASS’Y 1

38 REP3542A ATAPI P.C.B. 1

(RTL)

39 VEK0D56 FFC(40P) 1

40 VEE0U08 WIRE WITH CONNECTOR(4P) 1

41 RMA1675 HDD BRACKET 1

42 RMN0751 FAN COVER 1

43 RGU2206-Q HDD BUTTON 1

44 RGU2207-Q DVD BUTTON 1

46 RMA1674 HDD HOLDER 1

47 RMZ0700 INSULATED SHEET 1

49 RXQ1073 SUPER SHEET 1

50 VXY1772-S RAM DRIVE UNIT 1

(RTL)

Page

11/18/2008

51 XTW3+6M SCREW 4

A1 EUR7624KB0 REMOTE CONTROL ASS’Y 1

A1-1 UR76EC2403A BATTERY COVER 1

A2 K2KA6CA00001

A/V CORD 1

A3 K2CB2CB00006 AC CORD 1

A4 VJA1091 RF COAXIAL CABLE 1

K1TXAAA00001

A5 RPQF0250 ACCESSORY CASE 1

A6 RPQ1594 PAD 1

A7 RQF5175 FAN BAG ASS’Y 1

(P)

A7 RQF5253 FAN BAG ASS’Y 1

(PC)

A7-1 RPF0378 POLYETHYLENE BAG(F.B.) 1

(PC)

A7-1 RPF0375 POLYETHYLENE BAG(F.B.) 1

(P)

A7-2 RQT7143-C OPERATING INSTRUCTIONS 1

(PC)<IB>

A7-2 RQT6984-P OPERATING INSTRUCTIONS 1

<IA>

A7-4 RQCA1004 DISC CAUTION SHEET 1

A7-5 RQCA1119 HDD CAUTION SHEET 1

A7-6 RQCC2431 DVD MEDIA SHEET 1

(P)

A8 RPQ1450 PAD(A) 1

PC1 RPG6574 PACKING CASE 1

(P)

PC1 RPG6721 PACKING CASE 1

(PC)

PC2 RPN1624A CUSHION(L) 1

PC3 RPN1624B CUSHION(R) 1

PC4 VPF0505 POLYETHYLENE BAG 1



02 REP3497M

B7501 CR-2032/1GUF LITHIUM BATTERY 1

C1502 F2A1E221A210 25V 220U 1

C1503,04 F2A1A471A211 10V 470U 2

C1505,06 F2A0J471A256 6.3V 470U 2

C1507 ECJ1VB1C104K 16V 0.1U 1

C1508 F2A0J470A012 6.3V 47U 1

C1509 F2A1E4700048 25V 47U 1

C1512 F2A1E4700048 25V 47U 1

C1514 F2A1E4700048 25V 47U 1

C1528 ECJ1VB1C104K 16V 0.1U 1

C1530 F2A1E4700048 25V 47U 1

C1532 ECJ1VB1C104K 16V 0.1U 1

C3001-04 ECJ1VC1H470J 50V 47P 4

C3005 ECJ1VC1H560J 50V 56P 1

C3006,07 ECJ1VC1H390J 50V 39P 2

C3008 ECJ1VB1H103K 50V 0.01U 1

C3009 ECEA0JKS470 6.3V 47U 1

Page

11/18/2008

C3010 ECUV1H680JCV

50V 68P 1

ECJ1VC1H680J

C3011 ECJ1VC1H390J 50V 39P 1

C3012 ECJ1VB1H103K 50V 0.01U 1

C3013 ECEA0JKS470 6.3V 47U 1

C3014 ECJ1VC1H220J 50V 22P 1

C3016 ECJ1VC1H220J 50V 22P 1

C3017 ECJ1VB1H103K 50V 0.01U 1

C3018 ECJ1VC1H220J 50V 22P 1

C3019,20 ECJ1VC1H330J 50V 33P 2

C3022 ECJ1VB1H103K 50V 0.01U 1

C3023 ECJ1VB1C104K 16V 0.1U 1

C3024 ECEA0JKS470 6.3V 47U 1

C3025 ECJ1VC1H102J 50V 1000P 1

C3027 ECEA1HKS010 50V 1U 1

C3028,29 ECJ1VB1H103K 50V 0.01U 2

C3030 ECJ1VC1H561J 50V 560P 1

C3031 ECJ1VB1C104K 16V 0.1U 1

C3043 ECJ1VC1H560J 50V 56P 1

C3044 ECJ1VB1C104K 16V 0.1U 1

C3045 ECJ1VB0J105K 6.3V 1U 1

C3046 ECEA0JKS470 6.3V 47U 1

C3047 ECJ1VB1H103K 50V 0.01U 1

C3048 ECJ1VB0J105K 6.3V 1U 1

C3049 ECJ1VC1H150J 50V 15P 1

C3050 ECJ1VB1C104K 16V 0.1U 1

C3051 ECEA0JKS101 6.3V 100U 1

C3052,53 ECEA0JKS470 6.3V 47U 2

C3055 ECA0JM102 6.3V 1000U 1

C3056 ECEA0JKS101 6.3V 100U 1

C3057 ECJ1VB1C104K 16V 0.1U 1

C3058 ECJ1VC1H560J 50V 56P 1

C3059 ECA0JM102 6.3V 1000U 1

C3060 ECEA0JKS101 6.3V 100U 1

C3061 ECA0JM102 6.3V 1000U 1

C3062 ECEA0JKS101 6.3V 100U 1

C3063,64 ECEA0JKS331 6.3V 330U 2

C3066 ECJ1VB1H102K 50V 1000P 1

C3067 ECEA1HSN010 50V 1U 1

C3068 ECEA0JKS220 6.3V 22U 1

C3069 ECJ1VB1H103K 50V 0.01U 1

C3070 ECJ1VB1H472K 50V 4700P 1

C3071 ECJ1VB1H103K 50V 0.01U 1

C3072,73 ECJ1VC1H470J 50V 47P 2

C3074 ECJ1VC1H560J 50V 56P 1

C3075 ECJ1VC1H390J 50V 39P 1

C3076-84 ECJ1VB1H103K 50V 0.01U 9

C3085 ECJ1VB1H473K 50V 0.047U 1

Page

11/18/2008

Otros manuales para DMRE80HP

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de DVR de Panasonic

Panasonic

Panasonic LQ-DRM200 Manual de usuario

Panasonic

Panasonic WJ-ND300A Manual de usuario

Panasonic

Panasonic Diga DMR-E65 Manual de usuario

Panasonic

Panasonic LQ-MD800P Manual de usuario

Panasonic

Panasonic AVCCAM AG-HMR10P Manual de usuario

Panasonic

Panasonic WJHD309 - DIGITAL DISK RECORDER Manual de usuario

Panasonic

Panasonic DMR-E53EG, DMR-E55EB, DMR-E55E Manual de usuario

Panasonic

Panasonic WJHD309 - DIGITAL DISK RECORDER Manual de usuario

Panasonic

Panasonic WJHD316 - DIGITAL DISK RECORDER Manual de usuario

Panasonic

Panasonic Diga DMR-E65 Manual de usuario

Panasonic

Panasonic Diga DMR-E50 Manual de usuario

Panasonic

Panasonic DMR-EH50GN Manual de usuario

Panasonic

Panasonic WJ-RT416K Manual de usuario

Panasonic

Panasonic WJRT416 - 16CH DIGITAL RECORDER Manual de usuario

Panasonic

Panasonic WJ-HD616/1000 Manual de usuario

Panasonic

Panasonic WJ-NT104 Manual de usuario

Panasonic

Panasonic DMR-E53EG, DMR-E55EB, DMR-E55E Manual de usuario

Panasonic

Panasonic DMRHS2 - DVD RECORD.W/HD DRIV Manual de usuario

Panasonic

Panasonic DMRE100HP Manual de usuario

Panasonic

Panasonic WJ-NT104 Manual de usuario

Panasonic

Panasonic AG-MDR15P Manual de usuario

Panasonic

Panasonic TU-HDT104A Manual de usuario

Panasonic

Panasonic DMRE10 - DVD VIDEO RECORDER Manual de usuario

Panasonic

Panasonic DMR-T3040 Manual de usuario

Manuales populares de DVR de otras marcas

FLIR

FLIR M3100E Series Manual de usuario

VTRACKPRO

VTRACKPRO FPRO300 Manual de usuario

Swann

Swann NVR-7085 models Manual de usuario

XtendLan

XtendLan DVR-1670C Manual de usuario

urmet domus

urmet domus 1093/004AHD Manual de usuario

Holux

Holux M1 Manual de usuario

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manual de usuario

Whistler

Whistler D16VRS Manual de usuario

Defender Security

Defender Security 82-20235 Manual de usuario

MISUMI

MISUMI MP-WF100M Manual de usuario

Speco

Speco D8HU Manual de usuario

UST

UST DDR-E04AA Instrucciones de uso

Consolidated

Consolidated Digital Video Recorder Manual de usuario

Mace

Mace DVR0404RW Guía de inicio rápido

RCA

RCA RTD315W Manual de usuario

FSM

FSM Colibri Grande PRO Manual de usuario

Hauppauge

Hauppauge HD PVR 2 Manual de usuario

Identivision

Identivision ICR-PH161i PIONEER Manual de usuario
