Panasonic EY6932-U1 Manual de usuario

rights reserved. Unauthorized copying and

distribution is a violation of law.

EY6932-U1

Cordless Hammer Drill & Driver

Please file and use this manual together with the service manual for Model No. EY6931, Order No.

PTD0009U37C1.

SPECIFICATIONS

ORDER NO. PTD0303U30A1

F16

1 EXPLODED VIEW 3 2 REPLACEMENT PARTS LIST 4

CONTENTS

Page Page

EY6932-U1

1 EXPLODED VIEW

EY6932-U1

2 REPLACEMENT PARTS LIST

NOTE :

*B=only available as set

*C=available individually

Ref. No. Part No. Part Name & Descriptions Remarks Per Unit

1WEY6932K3078 HOUSING AB SET 1

2EYT103L6807 CHUCK FASTENING SCREW 1

3EY6930K7917 KEYLESS DRILL CHUCK 1

4EY6930K9157 SCREW *C K3-16 3

5EY6901H3227 CLUTCH HANDLE A 1

6EY509B0977 O-RING 1

7EY6901L0567 CHANGE RING 1

8EY6901L0357 PIN *B 2-31.8 2

9WEY6902H3257 CLUTCH HANDLE B 1

10 WEY6902L1137 DRIVING SHAFT 1

11 EY6900B0177 SPRING 1

12 EY6901L0907 CHANGE PLATE *B 2

13 EY6901L1387 CAM A 1

14 EY6901L0197 VIBRATION SPRING 1

15 EY6901L0457 CLICK PLATE 1

16 EY6901L0637 ADJUSTING RING 1

17 EY6901L0167 CLUTCH SPRING 1

18 EY6901L0577 CLUTCH PLATE 1

19 EY560B6967 STEEL BALL *B 5 12

20 EY6901L1797 CLUTCH CASE 1

21 EY6705L0377 ROLLER PIN *B 3.175*7.2 6

22 EY6901L1107 CARRIER 1

23 EY6901L1477 RING GEAR 1

24 EY6900B1347 PLANET GEAR *B 3

25 EY6200B0857 THRUST PLATE 1

26 WEY6902L1767 GEAR CASE 1

27 EY6930L9577 SCREW *C K3-12 4

28 WEY6902L1467 RING GEAR 1

29 WEY6902L1357 CARRIER 1

30 EY6200B1357 PLANET GEAR *B 3

31 EY6900B1127 CARRIER 1

32 EY6930B1457 RING GEAR 1

33 EY560B1367 PLANET GEAR *B 3

34 EY6901L0887 THRUST PLATE 1

35 WEY6932L1008 DC MOTOR 1

36 WEY6902L2567 RADIATING PLATE 1

37 WEY6902L6017 SEMS SCREW 2.6-7 1

38 WEY6931Y2007 SWITCH 1

39 EY6230L6037 SEMS SCREW *C M3-5 2

40 EY6481L0207 DUST PREVENTIVE PLATE 1

41 EY6406Y3238 H/L HANDLE 1

42 EY6481L0177 CLICK SPRING 1

43 WEY6402Y3247 SELECTOR HANDLE 1

44 EY6930L0177 CLICK SPRING 1

45 WEY6930K9218 SCREW *C K3-20 9

46 WEY6902L1458 GEAR BOX BLOCK 1

-WEY6932K8008 INDIVIDUAL BOX 1

-WEY6932K8108 OPERATING INSTRUCTIONS 1

** Battery Pack and Tool Case are available as an optional accessory.

See the nearest sales dealer for details.

*** For replacement parts of charger, see the charger service manual.

Charger complete set is available as an optional accessory. See the nearest sales dealer for details.

EY6932-U1
