Panasonic KX-TC1484F Manual de usuario

900MHz Cordless Phone

Operating Instructions

Model No. KX-TC1484F

KX-TC1484R

Pulse-or-tone dialing capability

PLEASE READ BEFORE USE AND SAVE.

Panasonic World Wide Web address: http://www.panasonic.com

for customers in the USA or Puerto Rico

Charge the battery for about 15 hours before initial use.

Preparation Basic Operation Advanced Operation Useful Information

Caller ID Compatible

PQQX13745ZA-103.6.259:34PMページ1

Accessories (included)

For extra orders, call 1-800-332-5368.

∑AC Adaptor (p. 7)

Order No.

PQWATC1461M

one

∑Telephone Line Cord (p. 7)

one

∑Handset Cover (p. 8)

Order No.

PQYNTC1484F (Blue)

PQYNTC1484R (Red)

one

∑Belt Clip (p. 27)

Order No.

PQZHTC1481B

one

∑Battery (p. 8)

Order No.

PQWBTC1461M

one

Please read IMPORTANT SAFETY

INSTRUCTIONS on page 34 before use.

Read and understand all instructions.

Thank you for purchasing your new Panasonic cordless

telephone.

Attach your purchase receipt here.

Caller ID and Call Waiting Service, where available, are telephone

company services. After subscribing to Caller ID, this phone will display

a caller’s name and phone number. Call Waiting Caller ID, which

displays a second caller’s name and phone number while the user is on

another call, requires a subscription to both Caller ID and Call Waiting.

For your future reference

Serial No. Date of purchase

(found on the bottom of the unit)

Name and address of dealer

Before Initial Use

PQQX13745ZA-103.6.259:34PMページ2

For assistance, please call: 1-800-211-PANA(7262)

For Best Performance

Battery Charge

A rechargeable Ni-Cd battery powers the

handset. Charge the battery for about

15 hours before initial use (p. 8).

Raise the

antenna.

Away from electrical appliances

such as a TV or personal computer.

In a HIGH and CENTRAL location

with no obstructions such as walls.

Base Unit Location

Calls are transmitted between the base unit and the handset using

wireless radio waves. For maximum distance and noise-free

operation, the recommended base unit location is:

PQQX13745ZA-103.6.259:34PMページ3

Preparation

Location of Controls ............... 5

Settings ..................................... 7

Connections ............................. 7

Installing the Battery................. 8

Battery Charge ......................... 8

Ringer Volume ......................... 9

Programmable Functions ...... 10

Display Language .................. 10

Dialing Mode .......................... 10

Basic Operation

Making Calls ........................... 11

Answering Calls ..................... 12

Caller ID Service ..................... 13

Using the Caller List .............. 15

Viewing the Caller List............ 15

Calling Back from the Caller

List........................................ 17

Editing the Caller’s Phone

Number ................................ 17

Storing Caller List Information

in the Phone Book................ 18

Erasing Caller List

Information ........................... 19

Contents

Advanced Operation

Phone Book ............................ 20

Storing Names and

Numbers............................... 20

Entering Names and

Symbols ............................... 21

Finding Stored Items .............. 22

Dialing .................................... 22

Editing .................................... 23

Erasing ................................... 24

Special Features..................... 25

Automatic Security Code

Setting .................................. 25

Handset Locator..................... 25

Temporary Tone Dialing

(For Rotary or Pulse Service

Users) ................................ 25

How to Use the PAUSE Button

(For PBX Line/Long Distance

Calls)................................... 26

For Call Waiting Service

Users.................................... 26

Useful Information

Belt Clip................................... 27

Optional Headset.................... 27

Wall Mounting......................... 28

Adding Another Phone .......... 29

Battery Replacement.............. 30

Troubleshooting ..................... 31

Important Safety

Instructions........................... 34

FCC and Other Information ... 36

Speciﬁcations ......................... 39

Index ........................................ 40

Warranty.................................. 41

PQQX13745ZA-103.6.259:34PMページ4

Location of Controls

“

Preparation

For assistance, please call: 1-800-211-PANA(7262)

Base unit

Charge Contacts

(p. 9)

IN USE/CHARGE Indicator (p. 8, 25)

(HANDSET\LOCATOR) (p. 25)

Antenna

Hook (p. 28)

PQQX13745ZA-203.6.259:35PMページ5

“

Location of Controls

Handset

Antenna

(PAUSE/REDIAL)

(p. 11, 26)

Charge Contacts (p. 9)

(––

–

/FLASH)

(p. 11, 12, 26)

(AUTO/PROGRAM)

(p. 18, 20, 22)

(MUTE/CLEAR)

(p. 12, 19, 24)

(OFF) (p. 11, 15)

RINGER Selector

(p. 9)

($) (TONE) (p. 25)

(CH/FUNCTION) (Channel)

(p. 10, 11)

LOUD/SEARCH Key

((‹), (›)) (see below)

Display (p. 14)

(EDIT) (p. 10, 17, 20)

Headset Jack (p. 27)

How to use the LOUD/SEARCH key

This key has two active areas that are indicated by arrows.

≥Pressing the up or down arrow allows you

≥—to enter into the Caller List,

≥—to select the function items,

≥—to scroll through your phone book and the Caller

List, and

≥—to adjust the receiver volume on the handset.

LOUD/

Throughout these Operating Instructions, the LOUD/SEARCH key is

indicated by the arrows (‹) or (›).

PQQX13745ZA-203.6.259:35PMページ6

Settings

“

Preparation

For assistance, please call: 1-800-211-PANA(7262)

Connections

Power Outlet

(AC 120 V, 60 Hz)

Telephone

Line Cord

Single-Line

Telephone Jack

(RJ11C)

Raise the

antenna.

AC Adaptor

Fasten the AC adaptor

cord to prevent it from being

disconnected.

Hook

≥USE ONLY WITH Panasonic AC ADAPTOR PQWATC1461M (Order No.

PQWATC1461M).

≥The AC adaptor must remain connected at all times. (It is normal for the adaptor

to feel warm during use.)

≥To connect a standard telephone on the same line, see page 29.

≥If your unit is connected to a PBX which does not support Caller ID services, you

cannot access those services.

PQQX13745ZA-203.6.259:35PMページ7

“

Settings

Battery Charge

Place the handset on the base unit and charge for about 15 hours before

initial use.

≥The IN USE/CHARGE indicator lights

and a beep sounds.

IN USE/CHARGE Indicator

Installing the Battery

Install the battery and close the handset cover, locking it into place.

Black

Lead

Red

Lead

Recharge

Recharge the battery when:

—“RECHARGE”is displayed,

—“ ” is displayed, or

—the handset beeps intermittently while it is in

use.

RECHARGE

PQQX13745ZA-203.6.259:35PMページ8

Preparation

For assistance, please call: 1-800-211-PANA(7262)

Battery information

After your Panasonic battery is fully charged (p. 8):

≥The battery operating time may be shortened depending on usage conditions,

such as viewing the Caller ID Caller List or phone book, and ambient

temperature.

≥Clean the handset and the base unit charge contacts with a soft, dry cloth

once a month. Clean more often if the unit is subject to grease, dust or

high humidity. Otherwise the battery may not charge properly.

≥If the battery is fully charged, you do not have to place the handset on the base

unit until “RECHARGE”and “”are displayed. This will maximize the battery life.

≥The battery cannot be overcharged.

Standby Mode (While the handset is off the base unit)

The handset goes into the standby mode after you ﬁnish using the

handset (making/answering a call, viewing the Caller List or phone book

etc.). The display shows “STANDBY”.

The battery operating time is conserved in this mode.

Operation Operating time

While in use (TALK) Up to about 5 hours

Up to about 5 daysWhile not in use (Standby)

Ringer Volume

Set the RINGER selector to ON or OFF.

≥When set to OFF, the unit will not ring.

PQQX13745ZA-203.6.259:35PMページ9

Programmable Functions

Display Language

You can select ENGLISH, SPANISH or FRENCH as the display

language. Your phone comes from the factory set to ENGLISH. If you

want to select the other language, program as follows:

1Press (CH/FUNCTION).

≥The current setting is displayed.

2Select “ENG”(ENGLISH), “ESP”(SPANISH)

or “FRA”(FRENCH) by using (›) or (‹).

3Press (EDIT) to save.

≥A beep sounds.

≥The handset will return to the standby mode.

LANGUAGE: ENG

IDIOMA: ESP

You can program the following function items using the handset near

the base unit.

Make sure the unit is in the standby mode.

≥You can exit the programming mode at any time by pressing (OFF).

≥If you do not press any buttons for 60 seconds, the unit will return to the standby

mode.

Dialing Mode

If you have touch tone service, set to TONE. If rotary or pulse service is

used, set to PULSE. Your phone comes from the factory set to TONE.

1Press (CH/FUNCTION) twice.

≥The current setting is displayed.

2Select “PULSE”or “TONE”by using (›) or

(‹).

3Press (EDIT) to save.

≥A beep sounds.

≥The handset will return to the standby mode.

DIAL MODE: TONE

DIAL MODE:PULSE

Ex. SPANISH is selected.

PQQX13745ZA-203.6.259:35PMページ10
