Digital Copier

Model No.

DP-130/135/150

Operating Instructions

Before operating this copier, please read

these instructions completely and keep this

operating instructions for future reference.

Making CopiesMaintenanceChecking Before OperatingOthers

INVOICE

LETTER R

LEGAL

INV

LTR

LGL

INV LTR LGL


AUTO

DARK

LIGHT

2SIDED

10 1

ZOOM

(50~200%)

START

CLEAR/STOP


AUTO

SAVER

ENERGY

DARK

LIGHT

LEGAL

79%

INVOICE

LETTER

129%

LETTER

65%

INVOICE

LEGAL

61%

INVOICE

100%

Common Features

■■

■Full Size Copying

Turn the Power

Switch On Load the paper

(See page 18)

Control Panel

Position

original 2

Select“100%” 3

Number of

copies

(Up to 99)

NOTE

Press START

■■

■Position of the original

■■

■Original Guide

Place original against guide.

CFace DOWN on platen.

CIf the original is not positioned properly, a portion of the

original may not be copied.

■■

■When manually selecting exposure control

CThe copier has auto exposure control and adjustments

are rarely required.

Select Photo to copy photos and halftones.

Select Auto to copy with Auto exposure control.

Select Dark to copy light image originals.

Select Light to copy colored background originals.

Normal Position

CRemove stacked copies from the exit tray every 200 sheets.

100%

Making Copies

Common Features ■Full Size Copying..................................................................................2

■Reduction or Enlargement Copying ....................................................15

■Zoom Copying ....................................................................................16

■Using the Sheet Bypass .....................................................................17

Maintenance

Handling ■Adding Paper ......................................................................................18

■Changing Paper Size..........................................................................19

■ChangingToner Cartridge...................................................................20

■Changing Drum Unit ...........................................................................21

■Removing a Paper Misfeed.................................................................22

Mode Functions ........................................................................................................................... 14

Checking

Others

Troubleshooting ........................................................................................................................... 24

Specifications/Consumables List ............................................................................................... 27

Table of Contents

Setup Procedure ■Before setting up ................................................................................10

■Release Scanner/Remove shipping materials ....................................11

■InstallToner Cartridge.........................................................................12

■Install paper........................................................................................13

Table of Contents

Before Operating

Precautions/Energy Star ............................................................................................................... 4

Components ■External/Internal ...................................................................................7

■Control Panel........................................................................................8

Precautions/Energy Star

For your safety

■■

■Laser Safety

Caution

This product utilizes a laser.

Use of controls or adjustments or performance of procedures other than

those specified herein may result in hazardous radiation exposure.

■■

■Caution Labels

Product complies with DHHS Rules 21

CFR Subchapter J in effect of date

of manufacture.

Utsunomiya, Tochigi, Japan

Product complies with DHHS Rules 21

CFR Subchapter J in effect of date

of manufacture.

Taytay, Rizal, Philippines

FFPTE2479

DANGER-Invisible laser

radiation when open and

interlock defeated.

AVOID DIRECT EXPOSURE

TO BEAM.

Label when manufactured in Japan.

Label when manufactured in Philippines.

The DP-130/135/150 copier complies withTier 2 of the Environmental Protection Agency’s Energy

Star Program.This voluntary program specifies certain energy consumption and usage standards

for copiers.This copier will automatically“power down”after a specified period of non-use.

The use of these Energy Star compliant copiers will reduce energy consumption and ultimately

benefit the environment.

The default functions can be adjusted depending on your office requirements.Please see your

authorized Panasonic copier dealer for more details.

Precautions/Energy Star

Precautions

Handling

■Do not look directly at exposure lamp when copying.

■Do not turn the power switch off or open the front

panel during copying.(See page 7)

CDo not drop paper clips or other metal objects into

the copier.

Toner and Paper

■Store toner cartridge and paper in cool areas with

low humidity.

CHigh quality paper of 16 lbs.- 24 lbs.(15 – 34 lbs.

via sheet bypass) may be used.

CFor optimum performance, it is recommended that

only Panasonic Brand supplies be used in the

copier.

Ventilation

■The copier should be installed in a well-ventilated

area to minimize the ozone density in the air.

Installation

■The copier should not be installed in areas with the

followingconditions:

CExtremely high or low temperature and humidity.

Proper ambient conditions

Temperature: 50°F – 86°F

Relativehumidity: 30% – 80%

CWhere temperature and humidity can change

rapidly, causing condensation.

CDirect exposure to sunlight.

CDirectly in air conditioning flow.

CIn areas of high dust concentration.

CIn areas of poor ventilation.

CIn areas with chemical fume concentration.

CIn areas with extreme vibration.

CWith unstable or uneven conditions (floors, etc.).

■The power consumption is 1.0 kW.

A properly wired (with ground), dedicated, 15A, 120V AC outlet is required.Do not use an

extension cord.

The main plug on this equipment must be used to disconnect main power.Please ensure that the

socket outlet is installed near the equipment and shall be easily accessible.

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment.This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications.Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to correct the interference

at his/her own expense.

Any unauthorized changes or modifications to this equipment would void the users authority to

operate this device.

Precautions

Components

Using the Sheet Bypass

Control Panel Platen

■■

■External

External/Internal

Button

PaperTray

(See page 13, 18, 19)

ExitTray

Front Panel

Right Cover

Sheet Bypass

Off

Power Switch

Precautions

Components

Please push here when

closing Right Cover.

■■

■Internal

Knob

(See page 23)

Drum Surface

CDo not touch it!

Drum Unit

(See page 21)

Toner Cartridge

(See page 12, 20)

Fuser Cover

(See page 22)

Transfer Roller

CDo not touch it!

2SIDED


AUTO

DARK

LIGHT

LEGAL

79%

INVOICE

LETTER

129%

LETTER

65%

INVOICE

LEGAL

61%

INVOICE

100%

Components

Control Panel

Auto/Photo Mode Indicator

(See page 2) Auto/Photo Select Key

(See page 2)

Exposure Indicator

(L:Normal position)

(See page 2)

Exposure Control

Key

(See page 2) % Select Key

(See page 15)

PaperTray Key

Press to select

paper tray or

sheet bypass

By pressing Exposure Control key, the Exposure Indicator will be indicated as

follows.

DARK

LIGHT

Normal

Position Dark Darker Lighter Light

10 1

ZOOM

(50~200%)

START

CLEAR/STOP

SAVER

ENERGY

Components

Copy Count Display

Indicates number of

copies and error code

etc. (See page 24)

Energy Saver Key (See page 14)

Clear/Stop Key

Press to stop copy run or clear

copy count in display.

Zoom Keys

(See page 16)

Quantity Keys

Start Key

Symbol Marks

#Change Drum Unit (See page 21)

$ChangeToner Cartridge (See page 20)

%Add Paper (See page 18)

&Paper Misfeed (See page 22, 23)

Copier Operating Instructions

(1 piece)

Toner Cartridge

(1 piece)

ATTENTION

■■

■Unpack and install on a stable flat surface.

Note: Do not plug the copier until directed to do so.

Setup Procedure

Before Setting Up

CUse only the setup units/parts designated by Panasonic.If the copier should be

damaged by using other setup units/parts, Panasonic will not bear any responsibility.

CDrum unit already comes installed in copier.

■■

■Set up the main unit with following procedure

#Remove all shipping tape and styrofoam.

$Release the scanner/Remove shipping materials (See page 11)

%Installation of theToner Cartridge (See page 12)

&Loading paper (See page 13)

(Install the copier in an area that means or exceeds the minimum space requirement

(see diagram below).

Copier Sheet BypassExitTray

30 cm 70 cm

10 cm
