Panasonic KX-TU329FXME Manual de usuario

Operating Instructions

Easy Use Mobile Phone

Model No. KX-TU329 FX

Thank you for purchasing a Panasonic product.

Please read these operating instructions before using the unit and

save them for future reference.

Before initial use, see “Important Information” on page 12.

Supplied accessories

– AC adaptor (Part No. PNLV230CE): 1 pc

– Rechargeable battery (Part No. BJ-LT100010): 1 pc

– Charger: 1 pc

TU329FX(en)_1011_ver210.pdf 1 2016/10/11 14:54:15

Getting Started
Setting up ...............................3
Controls ..................................6
Display ....................................7
Turning the power on/off ......10
Initial settings ........................10
Important Information
For your safety .....................12
Important safety
instructions ...........................14
For best performance ...........15
Other information ..................15
SAR ......................................16
Specifications .......................17
Basic Operations
Making calls ..........................18
Answering calls ....................19
Call log .................................20
Voicemail service .................20
Text input ..............................21
Messages .............................21
Phonebook ...........................25
Alarm ....................................27
Night mode ...........................28
Calendar/Schedule ...............29
Voice recording ....................30
Priority call ............................31
Network service call
features ................................33
Security settings ...................34
Camera .................................35
Image viewer ........................37
File manager ........................38
Customising Your Phone
Menu list ...............................41
Connecting to Other Devices
Using the FM radio ...............49
Using a Bluetooth® wireless
connection ............................51
Using a USB connection ......54
Useful Information
Troubleshooting ....................55
General information ..............58
Sales department .................59
Declaration of conformity
form ......................................60
Index
Index......................................62
2
Table of Contents
TU329FX(en)_1011_ver210.pdf 2 2016/10/11 14:54:15

Setting up

Inserting a SIM card, microSD card, and the battery

A SIM card (not supplied) allows the phone to connect to a mobile

phone service. Contact your network operator/service provider for

more information.

A microSD card (not supplied) allows you to expand the phone’s

storage capabilities.

Important:

RWhen removing the battery, make sure you turn off the phone first.

RTo avoid loss of data or malfunction, do not damage, carelessly handle, or short-circuit the

gold-coloured contacts of the SIM card or microSD card.

1Remove the phone’s cover.

2Open the SIM card cover by

sliding it toward the nearest

side of the phone (A) and

then lifting up (B).

3Put the SIM card with the

gold-coloured contacts

facing down.

Getting Started

TU329FX(en)_1011_ver210.pdf 3 2016/10/11 14:54:15

4Close the SIM card cover

(A), and then gently slide

the cover toward the

opposite side of the phone

(B).

5Open the microSD card

cover by sliding it toward the

nearest side of the phone

(A) and then lifting up (B).

6Put the microSD card with

the gold-coloured contacts

facing down, close the

microSD card cover (A),

and then gently slide the

cover toward the opposite

side of the phone (B).

7Insert the battery (A) and

lower it into the phone (B),

then attach the cover (C).

Note:

RUse only the battery specified.

RWipe the battery ends ( , ), SIM card, and microSD card with a dry cloth.

RAvoid touching the battery ends ( , ) or the unit contacts.

RAfter installing the SIM card, microSD card, and battery, press MN for about 2 seconds to

turn the power on (page 10).

Getting Started

TU329FX(en)_1011_ver210.pdf 4 2016/10/11 14:54:15

Battery charging

You can charge the battery by connecting the phone to a power

outlet using the supplied AC adaptor, either directly or by using the

charger, or by connecting it to a computer using a USB cable (not

supplied).

RCharge for about 3 hours.

RCharging time and battery life might differ depending on the condition of the network.

RWhen using an AC adaptor, use only the supplied AC adaptor.

RWhen charging begins, the phone sounds and the battery indicator lights. When the battery is

fully charged, the battery indicator turns off.

AC adaptor or USB

connection

Using the charger

Battery indicator

To power outlet

Note:

RThe battery might swell when its life is close to an end. This is dependent on the usage

conditions and is not a problem.

RIt is normal for the phone and AC adaptor to feel warm during charging.

Getting Started

TU329FX(en)_1011_ver210.pdf 5 2016/10/11 14:54:16

Controls

A B

ALED light

BCamera lens

CLED status indicator;

page 9

DVolume up/down

Change font display size;

page 10

EDisplay; page 7

FMake calls/Answer calls/

Select the function shown

above (page 9).

GNavigation key

MDN ( ): Open the main menu.

MCN ( ): View the contacts

list.

HOne touch dial key; page 18

Getting Started

TU329FX(en)_1011_ver210.pdf 6 2016/10/11 14:54:16

ICall voicemail; page 21

JInternational call; page 18

KReceiver

LPower/End calls/Select the

function shown above

(page 9).

MCamera key; page 35

NPress and hold for 2 seconds

to turn the silent mode on/off.

OMicrophone

PCharge contacts

QPriority call; page 31

RSpeaker

SPress to turn the light on/off

(page 36).

THeadset jack

UUSB connector (Micro-B

type); page 5, 54

Display

Symbols

Signal strength

R: Roaming network

E: The phone is connected

to an EDGE network.

G: The phone is connected

to a GPRS network.

Battery level

– : High

– : Medium

– : Low

–: Needs charging.

The phone is connected to

a computer via USB.

The call is not encrypted.*1

Silent mode is on. (page 7,

47)

Vibration is on. (page 47)

Handsfree is on. (page 19)

Ringer volume off.

Incoming call

Outgoing call

Missed call

Mute is on. (page 19)

Frequency control equalizer

is set. (page 19)

A 2nd call is on hold.

RContact is saved to the

phone.

RRoot directory of phone

RMobile phone is

discovered in Bluetooth

search menu.

Contact is saved to the SIM

card.

Contact name

Getting Started

TU329FX(en)_1011_ver210.pdf 7 2016/10/11 14:54:16

Mobile phone number

Office phone number

Home phone number

Fax number

Selected ringer tone.

RNew SMS message is

received.

RSMS message (unread/

unsent) is saved to the

phone.

SMS message (sent) is

saved to the phone.

SMS message (opened) is

saved to the phone.

SMS message (unread/

unsent) is saved to the SIM

card.

SMS message (sent) is

saved to the SIM card.

SMS message (opened) is

saved to the SIM card.

MMS is running for sending

or receiving data.

RNew MMS message is

received.

– Flashing: Message

memory is full.

RMMS message is unread

or unsent.

MMS message is read.

MMS message is

unreceived.

MMS message is sent.

– Image file

–Image file is attached to

the MMS message.

– Image file is selected for

caller picture.

Root directory of memory

card

– Sound file

–Sound file is attached to

the MMS message.

vcf

VCF (vCard) file

Other format file

Other format file is attached

to the MMS message.

Folder

MMS recipient is set to To.

MMS recipient is set to Cc.

Bcc

MMS recipient is set to Bcc.

New voicemail message

received.*2 (page 21)

Alarm is on. (page 27,

29)

Night mode is on.

(page 28)

Headset (optional) is

connected.

– Bluetooth feature is on.

(page 51)

– Another Bluetooth device

is connected.

Bluetooth compatible

computer is discovered in

Bluetooth search menu.

Getting Started

TU329FX(en)_1011_ver210.pdf 8 2016/10/11 14:54:16

Bluetooth headset is

discovered in Bluetooth

search menu.

Bluetooth headset is

connected to the phone.

Bluetooth hands-free car kit

is discovered in Bluetooth

search menu.

*1 Contact your network operator/service provider for more information.

*2 Voicemail subscribers only

Function keys

Calls emergency number.

Returns to previous screen.

Accepts current selection.

Erases a number/character.

Opens recent call log.

Makes/answers a call.

Ends the call.

Sets handsfree.

Opens option menu.

Answers a 2nd call.

Allows editing.

Selects multiple items.

Stops alarm.

Activates snooze function.

Turns the power off.

Pauses playback.

Resumes playback.

Stops recording or

playback.

LED status indicator

Message indicator

Flashes when a new

message is received.*1

Incoming call indicator

Flashes when there is an

incoming call, when you

have a missed call*1, or

while talking.

Battery indicator

Turns on when charging.

– Flashing: The battery is

low.

*1 Message indicator and incoming call indicator stop flashing after about 12 hours have

passed.

Getting Started

TU329FX(en)_1011_ver210.pdf 9 2016/10/11 14:54:16

Turning the power on/off

Press MN for about 2 seconds.

RThe phone vibrates when you turn the power on.

Note:

REnter the PIN1 code and press MN or M N when the PIN1 code request is displayed

(page 34).

RThe display becomes dark when you do not operate the phone for about 1 minute. Press any

key to turn the display back on.

Initial settings

The phone may prompt you to set display language, time zone, and

date and time each time a new SIM card is installed.

1MbN: Select the desired language. a MN

2MbN: Select the desired time zone. a M N

3Enter the current date, month, and year. a MN

4Enter the current time. a MN

Note:

RIf you select a language you cannot read:

Press MDN. a MbN: Select . a M N 2 times a MCN 2 times a MN a MbN: Select the

desired language. a MN

RIf you want to change the date and/or time format, see page 46.

RTo adjust the hour for summer time, see page 46.

Display font size

Press MN or MN to adjust the font size of displayed menus.

Note:

RYou cannot adjust the display font size while you are on a call or the phone is ringing for an

incoming call.

Changing the ringer tone

You can change the ringer tone by selecting one of the preset

tones (“Using a preset ringer tone”, page 11) or by selecting one

of your own sound files (including sounds recorded using the phone’

Getting Started

TU329FX(en)_1011_ver210.pdf 10 2016/10/11 14:54:16

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Teléfono móvil de Panasonic

Panasonic

Panasonic KX-TU150 Manual de usuario

Panasonic

Panasonic EB-X700 Manual de usuario

Panasonic

Panasonic GS-12 Manual de usuario

Panasonic

Panasonic EBG51U - CELL PHONE Manual de usuario

Panasonic

Panasonic GSM900 Manual de usuario

Panasonic

Panasonic EB-GD75 Manual de usuario

Panasonic

Panasonic EB-GD67 Manual de usuario

Panasonic

Panasonic EBTX320 - Cell Phone ATLAS Manual de usuario

Panasonic

Panasonic EB-GD75 Manual de usuario

Panasonic

Panasonic EB-GD30 Guía de inicio rápido

Panasonic

Panasonic EB-X100 Manual de usuario

Panasonic

Panasonic EB-GD70 Manual de usuario

Panasonic

Panasonic KX-TU456 EX Manual de usuario

Panasonic

Panasonic EB-VS2 Manual de usuario

Panasonic

Panasonic EB-G450 Manual de usuario

Panasonic

Panasonic X300 Manual de usuario

Panasonic

Panasonic EB-MX7 Manual de usuario

Panasonic

Panasonic G600 Manual de usuario

Panasonic

Panasonic EB-GD52 Manual de usuario

Panasonic

Panasonic X400 Manual de usuario

Panasonic

Panasonic EBX70 - CELL PHONE Manual

Panasonic

Panasonic KX-PRS120AZ Manual de usuario

Panasonic

Panasonic ELUGA RAY 800 Manual de usuario

Panasonic

Panasonic EB-X200 Manual de usuario

Manuales populares de Teléfono móvil de otras marcas

Zte

Zte BLADE A520 Manual de usuario

Nokia

Nokia Lumia 620 Manual de usuario

Blackbe;rry

Blackbe;rry KEYone Manual de usuario

Bea-fon

Bea-fon X5 Premium Manual de usuario

Blackbe;rry

Blackbe;rry 8707 Series Manual de usuario

Blackbe;rry

Blackbe;rry Storm Instrucciones de funcionamiento

LG LM-X420QN Manual de usuario

LifeWatch

LifeWatch V Manual de usuario

Bea-fon

Bea-fon SILVER LINE SL860 Manual de usuario

IKI Mobile

IKI Mobile KF4.5i Manual de usuario

Hitech

Hitech HT-850 Manual de usuario

Yezz

Yezz Fashion F10 Manual de usuario

Point Mobile

Point Mobile PM60 Manual de usuario

Blackbe;rry

Blackbe;rry Q10 Manual de usuario

Blackbe;rry

Blackbe;rry Bold 9900 Manual de usuario

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manual de usuario

LG LM-K420EMW Manual de usuario

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manual de usuario
