Panasonic SL-VP48 Manual de usuario

ORDERNo. AD0009166C3

PortableVideoCD Player

SL-VP48 / SL-VP43 / SL-VP33

Traverse Deck:RAE0145ZMechanismSeries

Colours

(S)............SilverType

(N)............GoldType

Areas

GK..............China.

GH..............Hong Kong.

GCS...........Asia, LatinAmerica, MiddleNearEast, Africa and Oceania.

SPECIFICATIONS

Audio Section(Anti shock Off)

No. ofchannels: 2(left and right, stereo)

Frequencyresponse: 20-20,000Hz

(+0.5dB, -1.5dB)

Outputvoltage: 1.2V(10k )

S/N: morethan 96 dB

Wowand flutter: Belowmeasurable

limit

DA converter: 1bit, MASH

Headphoneoutputlevel: max. 9mW+9mW/16

(adjustable)

Pick up Section

Lightsouce: Semiconductorlaser

Wavelength: 780nm

Video Section

Outputformat: NTSC/PAL

Outputvoltage: 1.0Vp-p(75 )

General

Powersupply: DC4.5V

Powerconsumption:

SL-VP33

Using ACadaptor: 4.8W

SL-VP48/SL-VP43

ACadaptotr;

Audio CDs(Anti-shock OFF/ON): 4.8W/5.0W

Video CDs: 4.8W

When rechargeing: 5.6W

Playtime

(When used in hold mode, at25°Ctemperatureand on flatand

stablesurface.)

SL-VP33

2Alkalinebatteries;

Audio CDs: About18 hours

Video CD: About3hours

Rechargeablebatteries(P-3GAVT);

Audio CDs: About9hours

Video CDs: About2hours

SL-VP48

2Alkalinebatteries;

Audio CDs(Anti-shock OFF/ON): About18/20 hours

Video CDs: About3hours

Rechargeablebatteries(P-3GAVT);

Audio CDs(Anti-shock OFF/ON): About9/10 hours

Video CDs: About2hours

SL-VP43

2Alkalinebatteries;

Audio CDs(Anti-shock OFF/ON): About18/19 hours

Video CDs: About3hours

Rechargeablebatteries(P-3GAVT);

Audio CDs(Anti-shock OFF/ON): About9/9.5hours

Video CDs: About2hours

Theplaytime maybeless depending on theoperating

condetions.

Recharging time: About3hours

Dimensions(WxHxD): 128x29.3x135mm

Mass: 271g(with batteries)

228g(withoutbatteries)

Operational temperaturerange: 0°C-40°C

Recharging temperaturerange: 5°C-40°C

Note:

Specificationsaresubjecttochangewithoutnotice.

/ Mass and dimensionsareapproximate. / These

specificationsweremeasuredusing theACadaptor.

1. Accessories

-Stereoearphones......................................................1pc.

(RFEV334P-KS)

-Remote control transmitter........................................1pc.

(RAK-SL974WK)

-Connection cable........................................................1pc.

(RJL3X001X15)

-Batteries forremote control transmitter....................1pc.

(R6/LR6, AA, UM-3)

Note:Thereareavailableon sales route.

For GKarea

-ACadaptor...................................................................1pc.

(RFEA413T-1W)

For GCS area

-ACadaptor...................................................................1pc.

(RFEA413Z-W)

For GHarea

-ACadaptor...................................................................1pc.

(RFEA413H-W)

2. Precaution of LaserDiode

Caution:

Thisproductutilizes alaserdiodewiththeunitturned“on”, invisiblelaserrediation isemitted

from thepickup lens. / Wave length:780nm / Maximum outputradiation powerfrom pickup:100

W/VDE / Laserradiation from thepickup lensissafetylevel, butbesurethefollowings:

1. Donotdisassembletheoptical pickup unit, since radiation from

exposedlaserdiodeisdangerous.

2. Donotadjust thevariableresistoron thepickup unit. Itwas

alreadyadjusted.

3. Donotlookat thefocuslensusing optical instruments.

4. Recommend nottolookat pickup lensforalong time.

3. Handling Precautions forTraverse Deck

Thelaserdiodeinthetraverse deck (optical pickup)may break downduetopotential difference

causedbystaticelectricityofclothes or humanbody.

So, becareful ofelectrostaticbreakdownduring repairofthetraverse deck (optical pickup).

3.1. Handling thetraverse deck (optical pickup)

1. Thetraverse deck (optical pickup)isanextremelyhigh-precision

construction and must notbesubjectedtoimpact, excessive

vibration, orothertypes ofrough handling.

2. Inordertopreventstaticelectricitydamagetothelaserdiode, use

ashortpinorsimilartool toshorttheoptical pickup’sflexible

circuitboardsaftertheyhavebeendisconnectedfromthemain

circuitboard. (as shownin Fig. 1 )

3. Handletheflexiblecircuitboardswithcare;excessiveforce could

cause themtobebroken.

4. Donotturnthepre-set variableresistor(foradjustmentofthe

laserpower);ithas beenadjustedat thefactory.

(as shownin Fig. 2 )

Fig. 1

Fig. 2

3.2. Grounding forelectrostaticbreakdownprevention

1. Humanbodygrounding

Use theanti-staticwrist straptodischargethestaticelectricity

fromyourbody. (as shownin Fig. 3 )

2. Worktablegrounding

Putaconductivematerial (sheet) orsteel sheet on thearea where

thetraverse deck (optical pickup)isplaced, and ground thesheet.

(as shownin Fig. 4 )

Caution

Thestaticelectricityofyourclothes will notbegroundedthrough

thewrist strap.

So, take carenottolet yourclothes touchthetraverse deck (optical

pickup).

Fig. 3

Fig. 4

4. Operating Instructions

5. Operation Checks and Component Replacement

Procedures

-Thissection describes procedures forchecking theoperation of

themajorprintedcircuitboardsand replacing themain

components.

-Forreassemblyafteroperation checks orreplacement, reverse the

respectiveprocedures. Special reassemblyprocedures are

describedonlywhenrequired.

5.1. Checking forthevideoP.C.B.

5.1.1. Checking for thevideoP.C.B. / (A side)

-Check thevideoP.C.B. (Aside) as shownbelow.

5.1.2. Checking for thevideoP.C.B. / (B side)

5.2. Checking forthemainP.C.B.

5.2.1. Checking for themainP.C.B. / (A side)

-Follow the(Step1) -(Step7) ofitem5.1.1.
