This product is eligible for the P2HD

5 Year Warranty Repair Program. For

details, see page 7.



E-2

Read this rst! indicates safety information.

Caution for AC Mains Lead

For battery charger

FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.

This product is equipped with 2 types of AC mains cable. One is for continental Europe, etc.

and the other one is only for U.K.

Appropriate mains cable must be used in each local area, since the other type of mains cable is not

suitable.

FOR CONTINENTAL EUROPE, ETC.

Not to be used in the U.K.

FOR U.K. ONLY

This appliance is supplied with a moulded

three pin mains plug for your safety and

convenience.

A 5 amp fuse is tted in this plug.

Should the fuse need to be replaced please

ensure that the replacement fuse has a rating

of 5 amps and that it is approved by ASTA or

BSI to BS1362.

Check for the ASTA mark or the BSI mark

on the body of the fuse.

If the plug contains a removable fuse cover

you must ensure that it is retted when the

fuse is replaced.

If you lose the fuse cover the plug must

not be used until a replacement cover is

obtained.

A replacement fuse cover can be purchased

from your local Panasonic Dealer.

How to replace the fuse

1. Open the fuse compartment with a

screwdriver.

2. Replace the fuse

Fuse

EEE Yönetmeliğine Uygundur.

EEE Complies with Directive of Turkey.

ENGLISH

E-3

indicates safety information.

Caution for AC Mains Lead

For AC adaptor

FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.

This product is equipped with 2 types of AC mains cable. One is for continental Europe, etc.

and the other one is only for U.K.

Appropriate mains cable must be used in each local area, since the other type of mains cable is not

suitable.

FOR CONTINENTAL EUROPE, ETC.

Not to be used in the U.K.

FOR U.K. ONLY

This appliance is supplied with a moulded

three pin mains plug for your safety and

convenience.

A 13 amp fuse is tted in this plug.

Should the fuse need to be replaced please

ensure that the replacement fuse has a rating

of 13 amps and that it is approved by ASTA

or BSI to BS1362.

Check for the ASTA mark or the BSI mark

on the body of the fuse.

If the plug contains a removable fuse cover

you must ensure that it is retted when the

fuse is replaced.

If you lose the fuse cover the plug must

not be used until a replacement cover is

obtained.

A replacement fuse cover can be purchased

from your local Panasonic Dealer.

How to replace the fuse

1. Open the fuse compartment with a

screwdriver.

2. Replace the fuse

Fuse

E-4

WARNING:

This equipment must be earthed.

To ensure safe operation, the three-pin plug must

be inserted only into a standard three-pin power

point which is effectively earthed through normal

house-hold wiring.

Extension cords used with the equipment must

have three cores and be correctly wired to provide

connection to the earth. Wrongly wired extension

cords are a major cause of fatalities. The fact that

the equipment operates satisfactorily does not

imply that the power point is earthed or that the

installation is completely safe. For your safety, if

you are in any doubt about the effective earthing

of the power point, please consult a qualied

electrician.

WARNING:

• TO REDUCE THE RISK OF FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS EQUIPMENT

TO RAIN OR MOISTURE.

• TO REDUCE THE RISK OF FIRE OR SHOCK

HAZARD, KEEP THIS EQUIPMENT AWAY

FROM ALL LIQUIDS. USE AND STORE ONLY

IN LOCATIONS WHICH ARE NOT EXPOSED

TO THE RISK OF DRIPPING OR SPLASHING

LIQUIDS, AND DO NOT PLACE ANY LIQUID

CONTAINERS ON TOP OF THE EQUIPMENT.

WARNING:

Always keep memory cards or accessories (coin

battery, microphone holder screws, microphone

holder adapter, ferrite cores, INPUT terminal cover)

out of the reach of babies and small children.

CAUTION:

To reduce the risk of electric shock, do not

remove cover. No user serviceable parts inside.

Refer servicing to qualied service personnel.

CAUTION:

TO REDUCE THE RISK OF FIRE OR SHOCK

HAZARD AND ANNOYING INTERFERENCE, USE

THE RECOMMENDED ACCESSORIES ONLY.

CAUTION:

In order to maintain adequate ventilation, do

not install or place this unit in a bookcase,

built-in cabinet or any other conned space. To

prevent risk of electric shock or re hazard due

to overheating, ensure that curtains and any

other materials do not obstruct the ventilation.

CAUTION:

Do not lift the unit by its handle while the

tripod is attached. When the tripod is attached,

its weight will also affect the unit’s handle,

possibly causing the handle to break and

hurting the user. To carry the unit while the

tripod is attached, take hold of the tripod.

CAUTION:

Danger of explosion or re if battery is mistreated.

For Battery Pack

• Replace only with same or specied type.

• Do not disassemble or dispose of in re.

•

Do not store in temperatures over 60°C.

• Do not leave the battery in an automobile

exposed to direct sunlight for a long period of

time with doors and windows closed.

• Use specied charger.

For Battery of Remote Controller

• Replace battery with part No. CR2025 only.

• Do not recharge the battery.

• Do not disassemble or dispose of in re.

•

Do not store in temperatures over 60°C.

Camera-Recorder

The rating plate is on the underside of the

viewnder.

Battery Charger / AC Adaptor

The rating plate is on the underside of the

Battery Charger and AC Adaptor.

Disconnect the AC mains plug from the AC

mains socket when not in use.

CAUTION:

THE MAINS PLUG OF THE POWER SUPPLY

CORD SHALL REMAIN READILY OPERABLE.

THE AC RECEPTACLE (MAINS SOCKET

OUTLET) SHALL BE INSTALLED NEAR

THE EQUIPMENT AND SHALL BE EASILY

ACCESSIBLE.

TO COMPLETELY DISCONNECT THIS

EQUIPMENT FROM THE AC MAINS,

DISCONNECT THE POWER CORD PLUG

FROM THE AC RECEPTACLE.

CAUTION:

Do not jar, swing, or shake the unit by its

handle while the conversion lens or another

accessory is attached.

Due to the added weight of the conversion

lens, any strong jolt to the handle may damage

the unit or result in personal injury.

indicates safety information.

ENGLISH

E-5

CAUTION:

EXCESSIVE SOUND PRESSURE FROM

EARPHONES AND HEADPHONES CAN

CAUSE HEARING LOSS.

CAUTION:

Do not leave the unit in direct contact with the

skin for long periods of time when in use.

Low temperature burn injuries may be suffered

if the high temperature parts of this unit are

in direct contact with the skin for long periods

of time.

When using the equipment for long periods of

time, make use of the tripod.

indicates safety information.

EMC NOTICE FOR THE PURCHASER/USER OF THE APPARATUS

1. Applicable standards and operating environment

The apparatus is compliant with:

standards EN55103-1 and EN55103-2 2009, and

electromagnetic environments E1, E2, E3 and E4.

2. Pre-requisite conditions to achieving compliance with the above standards

<1> Peripheral equipment to be connected to the apparatus and special connecting cables

The purchaser/user is urged to use only equipment which has been recommended by us as

peripheral equipment to be connected to the apparatus.

The purchaser/user is urged to use only the connecting cables described below.

<2>

For the connecting cables, use shielded cables which suit the intended purpose of the apparatus.

Video signal connecting cables

Use double shielded coaxial cables, which are designed for 75-ohm type high-frequency

applications, for SDI (Serial Digital Interface).

Coaxial cables, which are designed for 75-ohm type high-frequency applications, are

recommended for analog video signals.

Audio signal connecting cables

If your apparatus supports AES/EBU serial digital audio signals, use cables designed for AES/EBU.

Use shielded cables, which provide quality performance for high-frequency transmission

applications, for analog audio signals.

Other connecting cables (IEEE1394, USB)

Use double shielded cables, which provide quality performance for high-frequency applications,

as connecting cables.

When connecting to the DVI signal terminal, use a cable with a ferrite core.

If your apparatus is supplied with ferrite core(s), they must be attached on cable(s) following

instructions in this manual.

3. Performance level

The performance level of the apparatus is equivalent to or better than the performance level required

by these standards.

However, the apparatus may be adversely affected by interference if it is being used in an EMC

environment, such as an area where strong electromagnetic fields are generated (by the presence

of signal transmission towers, cellular phones, etc.). In order to minimize the adverse effects of the

interference on the apparatus in cases like this, it is recommended that the following steps be taken

with the apparatus being affected and with its operating environment:

1. Place the apparatus at a distance from the source of the interference.

2. Change the direction of the apparatus.

3. Change the connection method used for the apparatus.

Connect the apparatus to another power outlet where the power is not shared by any other appliances.

�

E-6

Operating precaution

Operation near any appliance which generates strong magnetic elds may give rise to noise in the video

and audio signals. If this should be the case, deal with the situation by, for instance, moving the source of

the magnetic elds away from the unit before operation.

IMPORTANT

“Unauthorized recording of copyrighted television programs, video tapes and other materials may infringe

the right of copyright owners and be contrary to copyright laws.”

Recommendation for Use of Genuine Panasonic Battery (Rechargeable Battery)

Thank you for using a Panasonic product.

It has been found that counterfeit battery packs which look very similar to the genuine product are

made available to purchase in some markets. Some of these battery packs are not adequately

protected with internal protection to meet the requirements of appropriate safety standards. There is

a possibility that these battery packs may lead to re or explosion. Please be advised that we are not

liable for any accident or failure occurring as a result of use of a counterfeit battery pack. To ensure that

safe products are used we would recommend that a genuine Panasonic battery pack is used.

Be aware that many batteries sold at extremely cheap prices or in situations where it is difcult to

verify the actual products before purchase have proven to be counterfeit.

•

Software information for this product

1. Customer advisory: This product includes software licensed under the GNU General Public License

(GPL) and GNU Lesser General Public License (LGPL); customers have the right to download, modify,

and redistribute source code for this software.

Descriptions of the GPL and LGPL are stored on the installation CD included with this camera-recorder.

See the folder named \LDOC. (The description is the original (written in English).) To download the

relevant source code, visit http://pro-av.panasonic.net/

Please note that we cannot answer any questions you may have about the content, etc. of any source

code you may obtain from the above Web site.

2. This product includes software licensed under the MIT License. A description of the MIT is stored on

the installation CD included with this camera-recorder. See the folder named \LDOC. (The description is

the original (written in English).)

• LEICA is a trademark of Leica Microsystems IRGmbH.

• DICOMAR is a trademark of Leica Camera AG.

• SD logo is a trademark.

All other explanations, company names, and product names are the registered trademarks of the

respective companies.

ENGLISH

E-7

To remove the battery

Main Power Battery

(Refer to page 18 for the detail.)

Press the battery removal button.

Battery removal button

Remote Control Battery

AWhile pressing the stopper , pull out the

battery holder.

BRemove the button-type battery from the battery

holder.

P2HD 5 Year Warranty Repair Program

Thank you for purchasing this Panasonic P2HD device.

repairs.

Customers who register as users on the website will receive a extended warranty repair

valid for up to ve years.

1st year 2nd year 3rd year 4th year 5th year*5

P2HD device*2 Basic warranty*3 Extended warranty repair*4

*1: Please note that this extended warranty is not available in some countries/regions see web

site below for details. *2: Not all models eligible for extended warranty coverage. *3:The basic

warranty period may vary depending on the country/region see enclosed warranty for warranty

coverage. *4: Not all repair work is covered by this extended warranty see enclosed warranty

card for warranty coverage. *5:The maximum warranty period may be adjusted depending on

the number of hours the device has been used.

Purchase

P2 product

within 1 month

“Registration Notice”

e-mail sent

Free 5 years of Warranty Repairs

Make sure to save the “Registration Notice”

e-mail during the warranty period.

Details about user registration and the extended warranty:

http://panasonic.biz/sav/pass_e

ENGLISH

GERMAN

FRENCH

ITALIAN

SPANISH

Pursuant to at the directive 2004/108/EC, article 9(2)

Panasonic Testing Centre

Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, F.R. Germany

Entsprechend der Richtlinie 2004/108/EG, Artikel 9(2)

Panasonic Testing Centre

Panasonic Service Europe, eine Abteilung der Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Deutschland

En accord avec la directive 2004/108/EC, article 9(2)

Panasonic Testing Centre

Panasonic Service Europe, une division de Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, F.R. Allemagne

In conformità con la direttiva 2004/108/CE, articolo 9(2)

Panasonic Testing Centre

Panasonic Service Europe, un reparto di Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, F.R. Germania

Conforme a la directiva 2004/108/EC, artículo 9(2)

Panasonic Testing Centre

Panasonic Service Europe, una división de Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, F.R. Alemania

E-8

Contents

Read this rst! ..................................................... 2

Operating precaution .......................................... 6

IMPORTANT.......................................................... 6

Recommendation for Use of Genuine

Panasonic Battery (Rechargeable Battery)... 6

Software information for this product ............... 6

To remove the battery ......................................... 7

Main Power Battery ........................................... 7

Remote Control Battery..................................... 7

Before use

Outline of operations ........................................ 10

Precaution for use............................................. 11

Accessories ....................................................... 12

Optional units .................................................... 12

About this manual ............................................. 12

Description of parts

Description of parts .......................................... 13

Right side and rear side .................................. 13

Left side........................................................... 14

Terminals and mounting parts ......................... 15

Remote control ................................................ 16

Preparation

The battery ......................................................... 17

Charging.......................................................... 17

Installing and removing the power supply...... 18

Installing and removing the battery ................. 18

Connecting and disconnecting the power cord .. 18

Adjusting the hand strap .................................. 19

Attaching the shoulder strap............................ 19

Detaching and attaching the lens hood .......... 19

The remote control............................................ 20

Insert the battery ............................................. 20

Remote control setup ...................................... 20

Turn on/off the camera...................................... 21

Tally lamp ........................................................... 21

Viewnder .......................................................... 22

Using the viewnder ........................................ 22

Using the LCD ................................................. 23

Emphasizing outlines ...................................... 23

Adjusting the screen display............................ 24

Adjusting the backlight..................................... 25

Flipping images vertically and horizontally ...... 25

Switching between overscan and underscan .. 25

Setting the calendar .......................................... 26

Shooting

Basic shooting operations ............................... 27

Preparing to shoot ........................................... 27

Shooting in auto mode .................................... 27

Checking photos taken (REC CHECK) ........... 28

P2 card access lamps ..................................... 28

Protecting against a possible erasure ............. 28

Formatting P2 cards ........................................ 28

Recording times .............................................. 29

Remove the P2 card........................................ 30

Using SD/SDHC memory cards........................ 31

Installing and removing the SD memory card .. 31

Formatting SD memory card ........................... 31

Cautions in using SD memory cards ............... 31

Using the zoom function................................... 32

Digital zoom function ....................................... 32

Variable frame rates (VFR)................................ 33

Native recording .............................................. 35

Standard recording.......................................... 35

Using variable frame rates (VFR) .................... 36

Shooting in 1080i/576i (480i) progressive

mode............................................................... 37

Shooting in 1080i/576i progressive mode ....... 37

Shooting in 1080i/480i progressive mode ....... 37

Shooting in manual mode................................. 38

Switching to manual mode .............................. 38

Manual focusing .............................................. 38

Using focus assist............................................ 39

Iris adjustments ............................................... 39

Adjusting the gain............................................ 40

Light intensity adjustments .............................. 40

Adjusting the white balance............................. 41

Black balance adjustments.............................. 42

Auto Tracking White (ATW) .............................. 42

Shooting techniques for different targets....... 43

Low-angle shooting ......................................... 43

Self-portrait shooting ....................................... 43

Zebra pattern................................................... 43

Marker ............................................................. 43

Checking and displaying shooting status ........ 44

Changing the image size................................. 44

Optical Image Stabilizer................................... 45

Adding effects to images ................................. 45

Using the USER buttons.................................. 45

Backlight compensation................................... 45

Color bars........................................................ 45

Waveform monitor function.............................. 46

Adjusting the volume while shooting ............... 46

Backup recording............................................. 46

2-slot continuous recording ............................. 47

Shot mark function .......................................... 47

Text memo recording ....................................... 47

Time stamp function ........................................ 47

LAST CLIP DELETE function.......................... 48

Using the special recording functions ............ 49

Pre-recording (PRE REC) ............................... 49

Interval recording (INTERVAL REC)................ 49

One-shot recording (ONE-SHOT REC)........... 50

Loop recording (LOOP REC) .......................... 50

ENGLISH

E-9

Adjusting the shutter speed............................. 52

Synchro scan................................................... 53

Switching Audio Input....................................... 54

Using the built-in microphone.......................... 54

Using another microphone and audio

equipment.................................................... 54

Adjusting the recording level ........................... 55

Using scene les ............................................... 56

Changing scene le settings ........................... 56

Saving scene les and other settings on SD

memory cards................................................ 58

Clip metadata ..................................................... 60

Using the Counter ............................................. 61

Counter display................................................ 61

1394TC preset mode....................................... 61

Charging the built-in battery/Setting the time

data ................................................................. 62

Recharging the built-in battery ........................ 62

Setting the time code....................................... 62

Specifying the time code (TC PRESET).......... 62

Setting user information................................... 64

Playback

Basic playback operations ............................... 66

Thumbnail screen.............................................. 67

Basic thumbnail screen operations.................. 67

Adding shot marks to clips .............................. 69

Clearing the thumbnail screen......................... 69

Direct shooting functions ................................. 69

Thumbnail operations ....................................... 70

Selecting the thumbnail display method

(THUMBNAIL) ............................................. 70

Deleting clips and formatting cards

(OPERATION) ............................................. 71

Checking the clip or card information

(PROPERTY) .............................................. 72

Editing the recorded clip metadata.................. 74

Uploading the metadata (META DATA)............ 75

Useful playback functions ................................ 77

Variable speed search ..................................... 77

Slow playback.................................................. 77

Fast forward/rewind playback .......................... 77

Frame-by-frame playback ................................ 77

Clip skip........................................................... 78

Adjusting the volume ....................................... 78

Viewing images on a monitor .......................... 78

Checking the date and time............................. 78

Editing

Connecting external units ................................ 79

Headphones .................................................... 79

External microphone ....................................... 79

Computer (non-linear editing/le transfer) ....... 80

Hard disk drive (data copying)......................... 81

Digital video equipment (Dubbing) .................. 82

Video deck (Dubbing)...................................... 83

TV/Monitor (playback/dubbing)........................ 83

Nonlinear editing with P2 card (PC mode)...... 84

Copying from P2 cards to the hard disk drive

(1394 HOST mode) ........................................86

Warnings ......................................................... 88

Dubbing.............................................................. 89

Digital input/output........................................... 89

Analog output .................................................. 89

Displays

Screen displays ................................................. 90

Regular displays .............................................. 90

Main warning displays ..................................... 94

Setting the DISPLAY items.............................. 96

Using the setup menus..................................... 97

Using the menus.............................................. 97

Initializing the menu settings ........................... 98

Setup menu structure ....................................... 99

CAM (camera) mode menu ............................. 99

MCR (playback) mode menu......................... 100

Setup menu list................................................ 101

SCENE FILE screen...................................... 101

CAMERA SETUP screen .............................. 103

SW MODE screen ......................................... 104

AUTO SW screen .......................................... 106

RECORDING SETUP screen........................ 107

PLAYBACK FUNCTIONS screen .................. 110

AV IN/OUT SETUP screen ............................ 110

DISPLAY SETUP screen............................... 111

CARD FUNCTIONS screen........................... 113

OTHER FUNCTIONS screen ........................ 113

OPTION MENU screen ................................. 116

Reference

Before calling for service................................ 117

Operating precautions .................................... 120

Updating the driver in the camera ................. 122

Cleaning ........................................................... 123

Storage Precautions........................................ 124

How to handle data recorded on P2 cards.... 125

Checkpoints for using memory cards ........... 126

Recording format list....................................... 127

Appendix .......................................................... 128

Specications .................................................. 129

E-10

Outline of operations

This unit is compatible with P2 (Professional Plug-in) cards.

The P2 card has a large capacity with a high transfer rate, and allows you sophisticated movie-making on

this handy camera, including HD (High Denition) recording and smooth editing/dubbing.

BNC cable

(HD-SDI)

Video

equipment/

Monitor

The setting values

such as the user le

are saved to and read

from the SD memory

card.

P2 card

You can use the following features:

HD (High Denition) recording

Multi format recording

Variable frame rates

Slow & quick motion recording

Maximum 4 channel uncompressed

digital audio recording

DV recording (576i (480i))

For details on how to handle recorded

data, see Page 125.

•

P2 mode shooting and

playback (Pages 27 and 66)

Computer

The data (le) is transferred for nonlinear

editing on your computer or other unit.

2PC mode (Page 84)

External hard disk

The unit directly controls the external hard disk

drive, and transfers the data (le) to it.

31394 host mode (Page 86)

Video equipment/

Television

Computer/

Memory card recorder

The contents can be transferred

as a data stream (digital

dubbing).

AV cable Component

video cable

IEEE1394 (SBP-2*)

USB2.0

(Windows)

IEEE1394

(Macintosh)

P2 card

*Serial Bus Protocol-2

IEEE1394

(Windows/

Macintosh)

Before use

Tabla de contenidos

Otros manuales de Grabadora de cámara de Panasonic

Panasonic

Panasonic AJ-PX270EJ Manual de usuario
