TQBS0165

Thank you for purchasing this product.

Please read these instructions carefully before using this

product, and save this manual for future use.

Operating Instructions

HDD Recorder

Model No. DMR-HST270

Software (Firmware) Update

To support the latest features, it’s very

important you install the latest updates

to maintain proper operation of your unit.

For details, refer to “Software

(Firmware) Update” (>50) or

http://panasonic.jp/support/global/cs/

(This site is in English only.)

until

2018/01/26

DMR-HST270GZ_eng.book 1 ページ２０１７年１２月２６日　火曜日　午後５時４７分

TQBS0165

Unit

• To reduce the risk of fire, electric shock or

product damage,

- Do not expose this unit to rain, moisture,

dripping or splashing.

- Do not place objects filled with liquids, such as

vases, on this unit.

- Use the recommended accessories.

- Do not remove covers.

- Do not repair this unit by yourself. Refer

servicing to qualified service personnel.

- Do not let metal objects fall inside this unit.

- Do not place heavy items on this unit.

AC mains lead

• To reduce the risk of fire, electric shock or

product damage,

- Ensure that the power supply voltage

corresponds to the voltage printed on this unit.

- Insert the mains plug fully into the socket

outlet.

- Do not pull, bend, or place heavy items on the

lead.

- Do not handle the plug with wet hands.

- Hold onto the mains plug body when

disconnecting the plug.

- Do not use a damaged mains plug or socket

outlet.

• The mains plug is the disconnecting device.

Install this unit so that the mains plug can be

unplugged from the socket outlet immediately.

Unit

• Do not place sources of naked flames, such as

lighted candles, on this unit.

• This unit may receive radio interference caused

by mobile telephones during use. If such

interference occurs, please increase separation

between this unit and the mobile telephone.

• This unit is intended for use in moderate

climates.

Placement

• Place this unit on an even surface.

• To reduce the risk of fire, electric shock or

product damage,

- Do not install or place this unit in a bookcase,

built-in cabinet or in another confined space.

Ensure this unit is well ventilated.

- Do not obstruct this unit’s ventilation openings

with newspapers, tablecloths, curtains, and

similar items.

- Do not expose this unit to direct sunlight, high

temperatures, high humidity, and excessive

vibration.

Safety precautions

WARNING CAUTION

DMR-HST270GZ_eng.book 2 ページ２０１７年１２月２６日　火曜日　午後５時４７分

TQBS0165 3

Batteries

• Danger of explosion if battery is incorrectly

replaced. Replace only with the type

recommended by the manufacturer.

• Mishandling of batteries can cause electrolyte

leakage and may cause a fire.

- Do not mix old and new batteries or different

types at the same time.

- Do not heat or expose to flame.

- Do not leave the battery(ies) in a car exposed

to direct sunlight for a long period of time with

doors and windows closed.

- Do not take apart or short circuit.

- Do not recharge alkaline or manganese

batteries.

- Do not use batteries if the covering has been

peeled off.

- Remove batteries if you do not intend to use

the remote control for a long period of time.

Store in a cool, dark place.

• When disposing of the batteries, please contact

your local authorities or dealer and ask for the

correct method of disposal.

Please check and identify the supplied

accessories.

(Product numbers are correct as of December

2017. These may be subject to change.)

• Do not use AC mains lead with other equipment.

Insert batteries

Insert so the poles (i and j) match those in the

remote control.

Supplied accessories

Remote control (N2QAYB001077):1pc.

Batteries for remote control: 2 pcs.

AC mains lead: 1pc.

HDMI cable: 1pc.





R6/LR6, AA

(Alkaline or manganese batteries)

DMR-HST270GZ_eng.book 3 ページ２０１７年１２月２６日　火曜日　午後５時４７分

TQBS0165

Table of contents

Safety precautions . . . . . . . . . . . . . . . . . . . . 2

Supplied accessories. . . . . . . . . . . . . . . . . . 3

Getting started

Unit care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Main unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote Control. . . . . . . . . . . . . . . . . . . . . . . 8

Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Watching broadcasts

Watching broadcasts . . . . . . . . . . . . . . . . . 14

Recording

Recording TV programmes. . . . . . . . . . . . 17

Timer recording. . . . . . . . . . . . . . . . . . . . . . 19

FUNCTION MENU screen . . . . . . . . . . . . 23

Keyword Recording . . . . . . . . . . . . . . . . . . 24

Using the external HDD (USB HDD). . . . 26

Playing back video

Playing contents on the HDD . . . . . . . . . . 27

Playing contents on the media . . . . . . . . . 30

Operation during play. . . . . . . . . . . . . . . . . 31

4K Networking. . . . . . . . . . . . . . . . . . . . . . . 32

Playback menu . . . . . . . . . . . . . . . . . . . . . . 33

Editing video

Deleting/Editing programmes . . . . . . . . . . 35

Copying video

Copying programmes. . . . . . . . . . . . . . . . . 38

Photo and Music

Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Network

Network Service . . . . . . . . . . . . . . . . . . . . . 45

TV Anytime . . . . . . . . . . . . . . . . . . . . . . . . . 45

Home Networking (DLNA) . . . . . . . . . . . . 46

With Other Equipment

Copying the HD Video (AVCHD) . . . . . . . 49

Other functions

VIERA Link . . . . . . . . . . . . . . . . . . . . . . . . . 50

Software (Firmware) Update . . . . . . . . . . 50

Other operations. . . . . . . . . . . . . . . . . . . . . 51

Setup

Basic Settings . . . . . . . . . . . . . . . . . . . . . . . 52

Reference

Troubleshooting guide . . . . . . . . . . . . . . . . 60

HDD and media information . . . . . . . . . . . 64

Specifications . . . . . . . . . . . . . . . . . . . . . . . 67

Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

About descriptions in these operating

instructions

• Pages to be referred to are indicated as “>±±”.

• Images are for illustration purpose, contents may change

without notice.

DMR-HST270GZ_eng.book 4 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Getting started

TQBS0165 5

Unit care

• The HDD is a high precision recording

instrument and is easily susceptible to damage.

Therefore, be careful of the following points

while the unit is turned on, especially during

operation, otherwise the HDD and the recorded

content may be damaged:

- Do not subject the unit to any vibration and

shock.

- Do not remove the AC mains lead from the

household mains socket.

• If the HDD or USB HDD is damaged, the

recorded content cannot be recovered.

• Do not place on anything that generates heat

like a Set Top Box, etc.

When condensation occurs, without turning

the unit on, let the unit adjust to the room

temperature and wait 2–3 hours until

condensation is gone.

1Switch the unit to standby mode. (Wait until

“BYE” disappears from the display.)

2Remove the AC mains lead from the

household mains socket.

3Move only after the unit has come to a

complete stop (approx. 3 minutes) in order to

avoid subjecting to vibration and shock. (Even

after the unit is switched to standby mode, the

HDD continues operating for a short time.)

The registration of the USB HDD may be

cancelled in the process of repairing this unit.

You can use the USB HDD again by

re-registering, but all recorded content already on

the USB HDD will be lost. In such cases, the

recorded content (data) cannot be recovered.

This unit may contain private information. Before

disposing of or transferring this unit, perform the

following to delete the data:

- Format HDD (>54)

- Perform “Shipping Condition” (>59)

HDD/USB HDD handling care

• The HDD is a temporary storage device

This unit cannot save (backup) the HDD

programmes to media. You have to be very

careful when handling the unit and editing the

programme.

Setup precautions

Getting started

When moving the unit

Cleaning

• Wipe with a soft, dry cloth.

• Never use alcohol, paint thinner or benzine to

clean this unit.

• Before using chemically treated cloth, carefully

read the instructions that came with the cloth.

When requesting this unit for repair

To dispose or transfer this unit

DMR-HST270GZ_eng.book 5 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Getting started

TQBS0165

Main unit

• When inserting the media, ensure that it is facing the right

way up.

• While writing to/reading from the media, do not switch the

unit to standby mode or remove the media. Such action

may result in loss of the media contents.

• The USB port on the front side does not support

USB HDDs. Connect a USB HDD to the USB port on the

rear side. (>26, Connecting the USB HDD)

Front

    

Pull to flip down

the front panel.

1Display (>7)

2Remote control signal sensor

• Angle: Approx. 20° up and down, 30° left and

right

• Distance: Within approx. 7 m in front of the

unit

3Play

4Standby/on switch (Í/I)

Press to switch the unit from on to standby

mode or vice versa. In standby mode, the unit

is still consuming a small amount of power.

5USB port ( DC 5 V 500 mA)

Inserting or removing media

∫USB device

DMR-HST270GZ_eng.book 6 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Getting started

TQBS0165 7

The symbols on this product represent the following.

Display



  

 

1Drive (HDD) indicator

2Main display section indicator

• Messages and other information are

displayed. (>63)

3Timer recording indicator

• This indicator lights up when the timer

recording standby or Keyword Recording

standby is activated.

4Copying indicator

5USB port indicator

6Playback indicator

7Remote control signal indicator

8Recording indicator

• “REC” lights up while recording is in

progress.

• “1” flashes when the first timer recording

standby is activated or recording is paused,

and lights up while recording is in progress.

(In the same way as “1”, “2” lights up or

flashes for the second recording.)

Rear

 

 

1AC IN ( ) terminal (>9)

2Cooling fan

3LNB IN terminal (>9)

• Connect the satellite dish.

4USB port ( DC 5 V 500 mA)

• Connect a USB HDD to this USB port.

5HDMI terminal (>9, 10)

6LAN port

7COAXIAL terminal (>10)

• Connect a receiver etc.

AC Class II equipment (The construction of

the product is double-insulated.)

DMR-HST270GZ_eng.book 7 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Getting started

TQBS0165

Remote Control

Instructions for operations are generally described using the remote control.

PAGE

INPUT

VOL

RETURN

OPTION

DELETE

AUDIO

REC

TEXT

STTL

-10s

+60s

INTERNET

REWIND LIVE TV

abc

jkl

tuv

ghi

qrs

def

mno

xyz

STATUS

EXIT

SLOW

DRIVE

SELECT

x1.3

PAUSE LIVE TV

PROG

CHECK

LAST VIEW





















































1Transmit the remote control signal

• Point it at remote control signal sensor on

this unit. (>6)

2Switch the unit from on to standby mode or

vice versa

3Select channels numbers, etc./Enter numbers

or characters

4Switch to the previously watched channel

(>14)

Manual skip when playing back Video (MP4 etc.)

(

31)

-10s: Skip approx. 10 seconds backward

+60s: Skip approx. 1 minute forward

6Basic operations for recording and play,

REWIND LIVE TV/PAUSE LIVE TV (>16)

7Show Information (>14, 28, 31)

8Selection/OK,

Frame-by-frame (>31)

9Show Video Menu (>27)

:Show OPTION menu (>33, 35, 42)

;Colour buttons (red, green, yellow, blue)

(Use in accordance with instruction on the

screen.)

<Select audio (>15, 31)

=To delete unwanted recorded programmes,

timer programmes, video, photo or music

(>35)

>TV operation buttons (>13)

?Start recording (>17)

@Channel select (>14)/Change pages in the

Video Menu screen etc.

ASelect drive (HDD or USB)

BShow the Timer Recording screen (>20)

CShow NETFLIX screen (>45)

DShow the Network Service screen (>45)

EExit the menu screen

FShow the TV Guide screen (>15)

GShow the FUNCTION MENU screen (>23)

HReturn to previous screen

IShow subtitles (>14, 31)

JShow Teletext (>14)

DMR-HST270GZ_eng.book 8 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Getting started

TQBS0165 9

Connection

∫When connecting the antenna to the unit and TV with a splitter

Be sure to use an all ports power pass splitter.

• With a one port power pass splitter, the TV may not display picture or the unit may not be able to perform recording while only

either the TV or the unit is turned on.

• Before making any connections, please disconnect all the units from AC power.

(Connect the AC mains lead after making all connections.)

• When the unit is not to be used for a long time

To save power, unplug it from the household mains socket. This unit consumes a small amount of

power, even when the unit is in standby mode. (>67)

Basic connections

HDMI

This unit’s rear panel

Household mains socket

(AC 220 to 240 V, 50 Hz)

AC mains lead

(supplied)

• Connect only after all other

connections are complete.

HDMI cable

(supplied)

Satellite dish

LNB IN

OUT OUT

Splitter

Satellite dish

DMR-HST270GZ_eng.book 9 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Getting started

TQBS0165

• When using a TV or an amplifier/receiver that does not

display “ARC” on the HDMI terminal, it is necessary to

connect the TV and the amplifier/receiver with a digital

audio cable to enjoy the TV audio on the amplifier/receiver.

• To listen to only the sound from the amplifier/receiver/sound

bar, set “Audio Output” to “Off” to turn the TV sound off.

(>56)

When this unit is connected to the network, you

can enjoy network functions (DLNA function,

Network Service, TV Anytime, etc.).

For details about connection method, refer to the

instructions supplied with the connected

equipment.

• Use category 5 or above straight LAN cables (STP) when

connecting to peripheral devices.

About wireless LAN connection (>11, Easy

Network Setting)

• The unit is not compatible with public wireless LAN

services.

Amplifier/receiver connections

HDMI terminal

DIGITAL AUDIO OUT terminal

HDMI cable

Amplifier/receiver/

sound bar

HDMI cable

COAXIAL IN

Amplifier/receiver/

sound bar

Coaxial cable

Network connection

After you make the LAN cable/Wireless LAN

connection, the network setting is needed.

(>11, Easy Network Setting)

LAN cable connection

Wireless LAN connection

Broadband

router, etc.

Internet

LAN (ethernet)

cable

DMR-HST270GZ_eng.book 10 ページ２０１７年１２月２６日　火曜日　午後５時４７分

Tabla de contenidos

Otros manuales de Reproductor de Blu-ray de Panasonic

Panasonic

Panasonic DMP-BDT270 Instrucciones de instalación y servicio

Panasonic

Panasonic DMP-BDT110 Manual de usuario

Panasonic

Panasonic Diga DMR-PWT520 Manual de usuario

Panasonic

Panasonic DMP-BD75P Manual de usuario

Panasonic

Panasonic UltraHD DP-UB391 Manual de usuario

Panasonic

Panasonic DP-UB820 Manual de usuario

Panasonic

Panasonic DMPB100 - PORTABLE BLU-RAY DISC PLAYER Manual de usuario

Panasonic

Panasonic DMP-BD84 Especificaciones técnicas

Panasonic

Panasonic DMP-BD55; DMP-BD35 Manual de usuario

Panasonic

Panasonic dmp-bdt280 Instrucciones de instalación y servicio

Panasonic

Panasonic DP-UB9000P1K Manual de usuario

Panasonic

Panasonic DMP-B15 - Portable Blu-ray Player Manual de usuario

Panasonic

Panasonic DMP-BD60GN Manual de usuario

Panasonic

Panasonic DMP-BDT700 Manual de usuario

Panasonic

Panasonic DMP-BD60GN Manual de usuario

Panasonic

Panasonic DP-UB420 Manual de usuario

Panasonic

Panasonic DMP-BDT383 Especificaciones técnicas

Panasonic

Panasonic UltraHD DP-UB824 Manual de usuario

Panasonic

Panasonic DMP-BDT270 Manual de usuario

Panasonic

Panasonic DMP-BD871 Manual de usuario

Panasonic

Panasonic DMPBDT100 - 3D BLU-RAY DISC PLAYER Manual de usuario

Panasonic

Panasonic DMP-BD30 Manual de usuario

Panasonic

Panasonic DMP-UB400 Especificaciones técnicas

Panasonic

Panasonic Diga DMR-BWT735 Manual de usuario

Manuales populares de Reproductor de Blu-ray de otras marcas

Samsung

Samsung BD-F5900 Manual de usuario

Philips

Philips BDP3380K Manual de usuario

Samsung

Samsung BD-P4600 Manual de usuario

Sharp

Sharp BD-HP17U - AQUOS 1080p Blu-ray DiscTM Player Manual de usuario

Pioneer

Pioneer BDP-140 Manual de instalación y operación

Samsung

Samsung BD-D8200A Manual de usuario

LG HLX50W Manual de usuario

Sony

Sony BDP-S300 - Blu-Ray Disc Player Manual de usuario

Marantz

Marantz UD9004 Manual de usuario

LG BD611 Manual de usuario

Marantz

Marantz BD7004 Guía de inicio rápido

Kogan

Kogan KABRP3DWFIA Manual de usuario

Toshiba

Toshiba BDX2700 Manual de usuario

Samsung

Samsung BD-E5400 Manual de usuario

Samsung

Samsung BD-F5100 Manual de usuario

Philips

Philips BDP7100 Manual de usuario

LG UBK80.DUSALLK Manual de usuario
