CS/CU-PA7DKD

CS/CU-PC7DKD

CS/CU-PA9DKD

CS/CU-PC9DKD

Room Air Conditioners

WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It does not contain warnings or cautions to advise non-techical individuals of potential dangers in attempting to service a product.

Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service

or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

1 Features 2

2 Functions 3

3 Product Specifications 6

4 Dimensions 14

5 Refrigeration Cycle Diagram 16

6 Block Diagram 17

7 Wiring Diagram 19

8 Operation Details 21

9Installation 35

10 2-way,3-way Valve

11 Disassembly of The Parts

12 Troubleshooting Guide

13 Technical Data

14 Exploded View

15 Replacement Parts List

16 Exploded View

17 Replacement Parts List

18 Electronic Circuit Diagram

CONTENTS

Page Page

Order No. GMAC0504036C3

Guangzhou Matsushita Air Conditioner Co., Ltd.

and distribution is violation of law.

------------------------------------------------------

--------------------------------------------------------

------------------------------------------

-----------------------------------------------------

-----------------------------------

--------------------------------------------------

-------------------------------------------------

-----------------------------------------------

---------------------------------------------------

-----------------------------------------------------

--------------------------------------

----------------------------------------

--------------------------------------------------

-----------------------------------------

--------------------------------------------------

-----------------------------------------

--------------------------------------

OFF

MODE TEMP

OFF/ON

CANCEL SET

STD

TIMER

FAN SPEED AIR SWING

1 Features

High Efficiency

Air Quality Indicator

Comfort Environment

Air filter with function to reduce dust and smoke

Auto Restart Control

Automatically restart after power failure

12-hour Timer Setting

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

Operation START/STOP

Operation Mode Selection

Automatic Operation

Heating Mode Operation

(For PA7DKD,PA9DKD)

Cooling Mode Operation

Soft Dry Mode Operation

Air Circulation Mode Operation

(For PC7DKD,PC9DKD)

Mode

Indoor Fan Speed Selection

Low Speed

Medium Speed

High Speed

Automatic Speed

Airflow Direction Control

Horizontal Airflow Direction Control

-Auto Control

-Manual Control

Vertical Airflow Direction Manual Control

Room Temperature Setting

Temperature Setting(16 to 30 )

Auto Operation

Timer Operation Selection

Stop/Start Operation Control

(set the ON/OFF Timer hourly later)

Set /Cancel Timer Operation

Set timer/Cancel the set timer

2 Functions

Remote Control

OFF/ON

MODE

FAN

SPEED

Air

SWING

TEMP

TIMER

OFF/ON

TIMER

SET/

CANCEL

OFF

MODE TEMP

OFF/ON

CANCEL SET

STD

TIMER

FAN SPEED AIR SWING

Turn on/off the air conditionor

When stop the operation by pressing

OFF/ON button,the cursor key points

to OFF.

By pressing SET button for 5seconds

continuously to switch to set the sensor

sensitivity.

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

Indoor Unit

Demonstration Mode

When the remote control cannot be used or

for repairing and testing ,please use this

button.

Power Switch ON/OFF

Signal Receiving Sound Control

Keep pressing this button for 10seconds to turn

on or turn off the signal receiving sound.

Operation Indication Lamps

Power (green)

Timer(orange)

Lights up in operation;

Blinks during Test

Run operation and

determining Auto

Operation mode

Timer in operation

Operation Mode

Cooling/Heating/Soft Dry /Auto Operation

/ Air circulation

Time Delay Safety Control

The unit will restart operation in 3-4

minutes after each pause.

7-Minutes Time Save Control

7-minutes automatic restarting at Cooling

Operation

National

Keep pressing this button for 15seconds to start

or end the Demonstration Mode.

Auto Switch

Button

Air quality

Green

Orange

Red

Anti-freezing Control for the Evaporator

Cooling or Soft Dry Operation

Warm Booting Control

Indoor fan starts running when temperature

of evaporator reaches 30 or above.

When temperature of evaporator is between

30 and 34 ,indoor fan will run at Super Low

or Low speed.

When temperature of evaporator reaches 34 ,

Warm Booting Operation ends.

High,Med,Low

Auto Fan Speed

Indoor Fan Speed Control

Automatic Airflow Direction Control

The louver automatically swings up and down

Airflow Direction Manual Control

Airflow Direction Control

Delayed On-timer Control

For cooling or soft dry mode, the unit

starts 15 minutes before the set time with

the remote control, but for heating mode

30 minutes before the set time.

(For PA7DKD, PA9DKD only)

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

Outdoor Unit

Panasonic

Anti-reverse Protection

To protect the compressor from reverse

rotation when power off suddenly.

Overload Protector

The 2-step Overload Protector is to protect

the compressor when

1)Temperature of compressor reaches 150

(PA7DKD,PC7DKD,PA9DKD) or

2)High temperature or current enters into the

compressor

145

(PC9DKD)

60-seconds Test Operation Control

Once the compressor is activated, it does not

stop for 60 seconds. It stops immediately with

remote control ON/OFF button.

Anti-freezing operation for outdoor unit(during

Heating Mode Operation only)

Temperature of the condenser is tested by TRS.

(For PA7DKD,PA9DKD only)

Deicing Control

Overload Protection Control

When the temperature of evaporator

reaches 51 ,outdoor fan stops,and will

restart when the temperature of evaporator

declines to 49 .

When the temperature of evaporator

reaches 65 ,compressor will stop.

4-way Valve Control

If the unit is stopped during Heating

Operation,the 4-way valve will remain in

heating mode operation for 5 minutes.

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

(For PA7DKD,PA9DKD only)

(Only for PA7DKD,PA9DKD)

3 Product Specifications

Cooling Capacity

Heating Capacity

Moisture Removal

Power Source

Airflow Method

Air Circulation Indoor Air (low)

Indoor Air (medium)

Indoor Air (high)

Outdoor Air

Noise Level

Electrical

Data

Piping Connection Port(Flare piping)

Piping Size(Flare piping)

Drain Hose

Power Supply Cord Length

(Number of core-wire)

Dimensions

Net Weight

Compressor

Air Circulation

Unit

L/h

Phase

Cycle

OUTLET

INTAKE

m /min

dB(A)

W/W

Input

Running Current

EER/COP

Starting Current

Inner Diameter

Length

Height

Width

Depth

Type

Motor Type

Rated output

type

Motor type

Fan

Speed

Low

Med

High

Rated Output

Input

Inch

rpm

CS-PA7DKD CU-PA7DKD

2.10

2.30

1.2

Single

220

SIDE VIEW TOP VIEW

7.40

8.66

9.50

Cooling:high47

Heating:high48

Cooling:high37,Low29

Heating:high37,Low29

Cooling:695

Heating:620

Cooling:3.40

Heating:3.00

Cooling:3.02

Heating:3.71

G:half union3/8"

L:half union1/4"

G:gas side3/8"

L:liquid side1/4"

G:3-way valve3/8"

L:2-way valve1/4"

G:gas side3/8"

L:liquid side1/4"

0.5

1.3

3 core-wire/1.0mm2

250

770

205

7.5

530

650

230

Cross-flow fan

Induction(4 pole)

Rotary(1 cylinder)

Rolling piston type

Induction(2 pole)

600

Propeller fan

Induction(6 pole)

880 60

1030 60

1130 50

800 60

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

Heat

Exchanger

Description

Tube Material

Fin Type

FPI

Refrigerant Control Device

Refrigeration Oil

Refrigerant (R-22)

Thermostat

Protection Device

Capillary

Air Filter

Refrigerant Circulation Control Device

Compressor Capacitor

Fan Motor Capacitor

Unit CS-PA7DKD CU-PA7DKD

Length

Circulation

Inner Diameter

(c.c)

L/min

F,V

Evaporator

Copper

Slot type

(Plate fin configuration,forced draft)

2x12 1X24

Condenser

Copper

Corrugation type

610x252x25.4

Electronic Control

P.P. Honeycomb

Capillary Tube

530(*)

O.L.P.(230V,30A)

655 20

9.5 0.2

1.4

F,2.0 400V

Specifications are subject to change without notice for further improvement.

F , 400V

Dimensions

Rows/Stage

Capillary

20 370V

1.5

269.1x504x18.19

SUNISO 4GDID or ATMOS

M60 or ATMOS 56M

* 60g for air purging is not included.

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

Cooling Capacity

Heating Capacity

Moisture Removal

Power Source

Airflow Method

Air Circulation Indoor Air (low)

Indoor Air (medium)

Indoor Air (high)

Outdoor Air

Noise Level

Electrical

Data

Piping Connection Port(Flare piping)

Piping Size(Flare piping)

Drain Hose

Power Supply Cord Length

(Number of core-wire)

Dimensions

Net Weight

Compressor

Air Circulation

Unit

L/h

Phase

Cycle

OUTLET

INTAKE

m /min

dB(A)

W/W

Input

Running Current

EER/COP

Starting Current

Inner Diameter

Length

Height

Width

Depth

Type

Motor Type

Rated output

type

Motor type

Fan

Speed

Low

Med

High

Rated Output

Input

Inch

rpm

CS-PA9DKD CU-PA9DKD

2.60-2.65

3.00-3.05

1.40

Single

220/230

SIDE VIEW TOP VIEW

7.72

8.54

10.10

Cooling:high47

Heating:high48

Cooling:high38,Low29

Heating:high38,Low29

Cooling:830-850

Heating:790-820

Cooling:3.90-3.80

Heating:3.65-3.65

Cooling:3.13-3.12

Heating:3.80-3.72

G:half union3/8"

L:half union1/4"

G:gas side3/8"

L:liquid side1/4"

G:3-way valve3/8"

L:2-way valve1/4"

G:gas side3/8"

L:liquid side1/4"

m3 core-wire/1.0mm2

250

770

205

7.5

530

650

230

Cross-flow fan

Induction(4 pole)

Rotary(1 cylinder)

Rolling piston type

Induction(2 pole)

700

Propeller fan

Induction(6 pole)

940 60

1090 60

1230 60

800 60

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

0.5

1.3

Heat

Exchanger

Description

Tube Material

Fin Type

FPI

Refrigerant Control Device

Refrigeration Oil

Refrigerant (R-22)

Thermostat

Protection Device

Capillary

Air Filter

Refrigerant Circulation Control Device

Compressor Capacitor

Fan Motor Capacitor

Unit CS-PA9DKD CU-PA9DKD

Length

Circulation

Inner Diameter

(c.c)

L/min

F,V

Evaporator

Copper

Slot type

(Plate fin configuration,forced draft)

2x12 2X24

Condenser

Copper

Corrugation type

610x252x25.4

Electronic Control

P.P. Honeycomb

Capillary Tube

860(*)

O.L.P.(230V,37A)

609 10

10.0 0.2

1.4

F,2.0 400V

Specifications are subject to change without notice for further improvement.

F , 400V

Dimensions

Rows/Stage

Capillary

F,30 370V

1.5

X504x36.38

SUNISO 4GDID or ATMOS

M60 or ATMOS 56M

569.1

540.5

* 60g for air purging is not included.

495 20

9.0 0.2

1.3

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

Cooling Capacity

Moisture Removal

Power Source

Airflow Method

Air Circulation Indoor Air (low)

Indoor Air (medium)

Indoor Air (high)

Outdoor Air

Noise Level

Electrical

Data

Piping Connection Port(Flare piping)

Piping Size(Flare piping)

Drain Hose

Power Supply Cord Length

(Number of core-wire)

Dimensions

Net Weight

Compressor

Air Circulation

Unit

L/h

Phase

Cycle

OUTLET

INTAKE

m /min

dB(A)

W/W

Input

Running Current

EER

Starting Current

Inner Diameter

Length

Height

Width

Depth

Type

Motor Type

Rated Output

Type

Motor Type

Fan

Speed

Low

Med

High

Rated Output

Input

Inch

inch

Inch

inch

rpm

CS-PC7DKD CU-PC7DKD

2.10

1.20

Single

220

SIDE VIEW TOP VIEW

4.9

5.7

6.8

High47

High36,Low28

680

3.20

3.09

G:half union3/8"

L:half union1/4"

G:gas side3/8"

L:liquid side1/4"

G:3-way valve3/8"

L:2-way valve1/4"

G:gas side3/8"

L:liquid side1/4"

3 core-wire/1.0mm2

250

770

205

7.5

530

650

230

Cross-flow fan

Induction(4 pole)

810 60

940 60

1130 60

Rotary(1 cylinder)

Rolling piston type

Induction(2 pole)

660

Propeller fan

Induction(6pole)

800 60

rpm

CS-PA7DKD / CU-PA7DKD / CS-PC7DKD / CU-PC7DKD

0.5

1.3

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de Panasonic

Panasonic

Panasonic CU-RE9HKE Manual de usuario

Panasonic

Panasonic CS-V7PWA-2 Manual de usuario

Panasonic

Panasonic PZ2 Series Manual de usuario

Panasonic

Panasonic CS-E15NKE3 Manual de usuario

Panasonic

Panasonic CS-A281KR Manual de usuario

Panasonic

Panasonic CS-MKS7NKU Manual del propietario

Panasonic

Panasonic CS-PC9QKH Manual de usuario

Panasonic

Panasonic CS-XE7NKEW Manual de usuario

Panasonic

Panasonic CS-A181KE Manual de usuario

Panasonic

Panasonic U-5MX3XPQ Manual de usuario

Panasonic

Panasonic CS-NZ9SKE Manual de usuario

Panasonic

Panasonic WH-MXC09J3E8 Manual de usuario

Panasonic

Panasonic CS-MKE18NKU Manual de usuario

Panasonic

Panasonic CS-YS18UKA Manual de usuario

Panasonic

Panasonic CS-ME9SB4U Manual

Panasonic

Panasonic CSA18CKPG - SPLIT A/C IN DOOR Manual de usuario

Panasonic

Panasonic CS-TZ20ZKE Series Manual de usuario

Panasonic

Panasonic CS-PA7KKD Manual de usuario

Panasonic

Panasonic U-36PE1U6 Manual

Panasonic

Panasonic CS-E24EKRS Manual de usuario

Panasonic

Panasonic CS-C125KR Manual de usuario

Panasonic

Panasonic CW-C241SE Manual de usuario

Panasonic

Panasonic U-72MF2U94 Manual de usuario

Panasonic

Panasonic CSC18DKU - AIR CONDITIONER - SPLIT Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario

Webasto

Webasto Frigo Top 25 DS Manual de usuario

Panasonic cs-pa7dkd Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas
