Panasonic CS-E9CKP Manual de usuario

1 Features 2

2 Functions 3

3 Product Specifications 6

4 Dimensions 10

5 Refrigeration Cycle Diagram 12

6 Block Diagram 13

7 Wiring Diagram 14

8 Operation Details 16

9 Operating Instructions 41

and distribution is a violation of law.

CS-E9CKP CU-E9CKP5

CS-E12CKP CU-E12CKP5

10 Installation And Servicing Air Conditioner Using R410A 46

11 Installation Instructions 57

12 Servicing Information 66

13 Technical Data 75

14 Exploded View 78

15 Replacement Parts List 79

16 Exploded View 80

17 Replacement Parts List 81

18 Electronic Circuit Diagram 82

Room Air Conditioner

CONTENTS

Page Page

Order No: MAC0210055C8

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

• Product

− Microcomputer-controlled compressor operating

frequency

− Vertical and Horizontal Airflow Directions

− Five modes of operation selection

− Power Mode operation

− Delay ON Timer and OFF Timer

− Standby operation

− Remote Controller with illuminable buttons

− Power Monitor Display LED

− Catechin Air Purifying Filter

− Triple Deodorizing Filter

− Ionizer Mode Operation

− Quiet Mode Operation

• Serviceability

− Washable Front Panel

− Breakdown Self Diagnosis function

• Environmental Protection

− Non-ozone depletion substances refrigerant (R410A)

• Quality Improvement

− Gas leakage detection

− Deice operation

− Auto restart control

1 Features

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

2 Functions

Remote Control

Operation OFF / ON

OFF/ON

Room Temperature Setting

TEMP

Operation Mode Selection

•aAutomatic Operation

•HEAT Heating Operation

•COOL Cooling Operation

•DRY Soft Dry Operation

•FAN Fan Operation

Time / Timer Setting

• Hours and minutes setting.

Clock Setting

• Current time setting.

Quiet Mode Operation OFF / ON

QUIET

Airflow Direction Control

• 24-hour, OFF / ON Real Timer Setting.

Timer Operation Selection

Timer Operation Set / Cancel

• ON Timer and OFF Timer setting and

cancellation.

CLOCK

Powerful Mode Operation

POWERFUL

• Temperature Setting (16°C to 30°C)

Illuminable

buttons

•Vertical Automatic Airflow

Direction Control and Manual

Airflow Direction Control (5

stages of adjustment).

•Horizontal Automatic Airflow

Direction Control and Manual

Airflow Direction Control (5

stages of adjustment).

Indoor Fan Speed Selection

FAN SPEED

•Low

•Medium-

•Medium

•Medium+

•High

•AUTO Automatic Fan Speed

FAN

Check Point

Reset Point

RESET

TIMER

OFF

∧

∨

SET

CANCEL

CHECK

MODE

AIR SWING

• Breakdown self diagnosis function.

• Clear memory data.

Ion Mode Operation OFF / ON

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

Indoor Unit

Automatic Operation Switch

•Press for < 5s to run Automatic Operation.

(Used when the remote control cannot be used.)

•Press continuously for 5s and < 8s to run

Forced Cooling Operation.

•Press continuously for 8s and < 11s to

run Forced Heating Operation.

•Press continuously for 11s and < 16s to

change different remote controlling

setting (A↔B Mode).

•Press continuously for 16s or < 21s to

switch OFF / ON Remote Control

Receiving Sound or H14 Abnormality

Detection Mode.

Operation Indication Lamps (LED)

Quiet Mode

Five Operation Modes

•Automatic, Heating, Cooling, Soft Dry

and Fan Operation.

Delay ON Timer and OFF Timer

Powerful Mode

•For quick cooling or heating.

•POWER (Green) ......

Lights up during

MONITOR

compressor operation.

•(Green) ............ Lights up in Ionizer

Mode Operation.

•POWER (Green) ...... Lights up in

operation, blinks in

Automatic Operation

Mode judging and Hot

Start operation.

•TIMER (Orange) .... Lights up in Timer

Setting.

Blinks in Self

Diagnosis Control.

•QUIET (Orange) .... Lights up in Quiet

Mode Operation.

•POWERFUL (Orange) ... Lights up when

Powerful Mode is

selected.

Automatic and 5 Manual Indoor

Fan Speeds

Automatic and 5 Manual Vertical

Airflow Directions

Automatic and 5 Manual Horizontal

Airflow Directions

Automatic Restart Control

•Operation is restarted after power failure

at previous setting mode.

Microcomputer-controlled Room

Temperature Control

•To provide extra quiet operation.

Ionizer Control

•Ionizer control for generate negative ion

in discharge air.

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

Deodorizing Control

Indoor Power Relay Control

Anti-Fog Discharge Control

Anti Freezing Control

Low Pressure Control

(Gas Leakeage Detection)

Breakdown Self Diagnosis

Function

Automatic Restart Control

Anti-Cold Draft Control

High Pressure Control

Hot Start

Intake Air Temperature Control

Standby Control

Deice Operation

Outdoor Unit

30 seconds Forced Operation

Time Delay Safety Control

High Pressure Control

Deice Operation

Standby Control

Compressor Overheating

Prevention Control

IPM (Power Transistor)

Overheating Protection Control

Total Running Current Control

Mininum Operation Frequency

Protection Control

*Details can be refered to OPERATION

DETAILS in this manual.

Low Operation Frequency

Protection Control

Outdoor Air Temperature

Control

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

3 Product Specifications

Unit CS-E9CKP CU-E9CKP5

Cooling Capacity kW

kcal/h

BTU/h

2.6 (0.60 - 3.00)

2,240 (520 - 2,580)

8,870 (2,050 - 10,200)

Heating Capacity kW

kcal/h

BTU/h

3.6 (0.60 - 5.00)

3,100 (520 - 4,300)

12,300 (2,050 - 17,100)

Moisture Removal l/h

Pint/h

1.6

(3.4)

Power Source Phase

Cycle

Single

230

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 6.5 (231) —

Heating; 7.1 (249)

Indoor Air (Me) m3/min (cfm) Cooling; 8.1 (286) —

Heating; 8.8 (312)

Indoor Air (Hi) m3/min (cfm) Cooling; 9.9 (350) Cooling; 30.0 (1,060)

Heating; 10.6 (370)

dB (A) Cooling; High 39, Low 26 Cooling; 46

Heating; High 40, Low 27 Heating; 47

Noise Level

Power level dB Cooling; High 50 Cooling; High 59

Heating; High 51 Heating; High 60

Electrical Data Input WCooling; 700 (115 - 880)

Heating; 900 (110 - 1,400)

Running Current ACooling; 3.3

Heating; 4.0

EER W/W (kcal/hw), BTU/hw Cooling; 3.71(3.20), 12.7

COP W/W (kcal/hw), BTU/hw Heating; 4.00 (3.44), 13.7

Starting Current A4.00

Piping Connection Port

(Flare piping)

inch

G ; Half Union 3/8”

L ; Half Union 1/4”

G ; 3-way valve 3/8”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping)

inch

G (gas side) ; 3/8”

L (liquid side) ; 1/4”

G (gas side) ; 3/8”

L (liquid side) ; 1/4”

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

Unit CS-E9CKP CU-E9CKP5

Drain

Hose

Inner diameter mm 12 —

Length m0.65 —

Power Cord Length

Number of core-wire

2.1 m

3 core wires × 1.0 mm2—

—

Dimensions Height inch (mm) 10 - 26/32 (275) 21 - 9/32 (540)

Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)

Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)

Net Weight lb (kg) 20 (9.0) 77 (35)

Compressor Type —Involute scroll

Motor Type —Brushless (4-pole)

Rated Output W — 700

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 20% P.P

Motor Type Transistor (8-poles) Induction (6-poles)

Input W — 61.3

Rate Output W30 25

Fan Speed Lo (Cool/Heat) rpm 800 / 840 —

Me (Cool/Heat) rpm 1,000 / 1,040 —

Hi (Cool/Heat) rpm 1,200 / 1,270 770

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Blue Coated)

Fin Type Slit Fin Corrugated Fin

Row / Stage (Plate fin configuration, forced draft)

2/15 1/20

FPI 21 19

Size (W × H × L) mm 610 × 315 × 25.4 732.1 × 508 × 22

Refrigerant Control Device —Capillary Tube

Refrigeration Oil (c.c) —RB68A (360)

Refrigerant (R410A) g (oz) —840 (29.7)

Thermostat Electronic Control —

Protection Device Electronic Control Electronic Control

Length mm —C1, C2 ; 1,100, C3 ; 440

Capillary Tube Flow Rate l/min —C1, C2 ; 5.0, C3 ; 18.6

Inner Diameter mm —C1, C2 ; 1.2, C3 ; 1.7

Air Filter Material

Style

P.P.

Honeycomb

—

Fan Motor Capacitor µF, VAC —1.8 µF, 400 VAC

• Specifications are subject to change without notice for further improvement.

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

Unit CS-E12CKP CU-E12CKP5

Cooling Capacity kW

kcal/h

BTU/h

3.45 (0.60 - 4.00)

2,970 (520 - 3,440)

11,800 (2,050 - 13,600)

Heating Capacity kW

kcal/h

BTU/h

4.80 (0.60 - 6.50)

4,130 (520 - 5,590)

16,400 (2,050 - 22,200)

Moisture Removal l/h

Pint/h

2.0

(4.2)

Power Source Phase

Cycle

Single

230

Airflow Method OUTLET

INTAKE

SIDE VIEW TOP VIEW

Air Volume Indoor Air (Lo) m3/min (cfm) Cooling; 7.3 (258) —

Heating; 9.2 (325)

Indoor Air (Me) m3/min (cfm) Cooling; 9.2 (323) —

Heating; 10.3 (360)

Indoor Air (Hi) m3/min (cfm) Cooling; 10.9 (380) Cooling; 31.0 (1,090)

Heating; 11.8 (420)

dB (A) Cooling; High 42, Low 29 Cooling; 48

Heating; High 42, Low 33 Heating; 50

Noise Level

Power level dB Cooling; High 53 Cooling; High 61

Heating; High 53 Heating; High 63

Electrical Data Input WCooling; 950 (120 - 1,280)

Heating; 1,260 (115 - 1,890)

Running Current ACooling; 4.4

Heating; 5.6

EER W/W (kcal/hw), BTU/hw Cooling; 3.63 (3.13), 12.4

COP W/W (kcal/hw), BTU/hw Heating; 3.81 (3.28), 13.0

Starting Current A5.60

Piping Connection Port

(Flare piping)

inch

G ; Half Union 1/2”

L ; Half Union 1/4”

G ; 3-way valve 1/2”

L ; 2-way valve 1/4”

Pipe Size

(Flare piping)

inch

G (gas side) ; 1/2”

L (liquid side) ; 1/4”

G (gas side) ; 1/2”

L (liquid side) ; 1/4”

Drain

Hose

Inner diameter mm 12 —

Length m0.65 —

Power Cord Length

Number of core-wire

2.1 m

3 core wires ×1.5 mm2—

—

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

Unit CS-E12CKP CU-E12CKP5

Dimensions Height inch (mm) 10 - 26/32 (275) 21 - 9/32 (540)

Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)

Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)

Net Weight lb (kg) 20 (9.0) 82 (37)

Compressor Type —Involute scroll

Motor Type —Brushless (4-pole)

Rated Output W—700

Air Circulation Type Cross-flow Fan Propeller Fan

Material AS + Glass Fiber 20% P.P

Motor Type Transistor (8-poles) Induction (6-poles)

Input W—65.9

Rate Output W30 29

Fan Speed Lo (Cool/Heat) rpm 880 / 1,100 —

Me (Cool/Heat) rpm 1,100 / 1,230 —

Hi (Cool/Heat) rpm 1,310 / 1,410 830

Heat Exchanger Description Evaporator Condenser

Tube material Copper Copper

Fin material Aluminium (Pre Coat) Aluminium (Blue Coated)

Fin Type Slit Fin Corrugated Fin

Row / Stage (Plate fin configuration, forced draft)

2/15 2/24

FPI 21 17

Size (W ×H×L) mm 610 ×315 ×25.4 703.8

735.0

×504 ×36.4

Refrigerant Control Device —Capillary Tube

Refrigeration Oil (c.c) —RB68A (360)

Refrigerant (R410A) g (oz) —1,020 (36.0)

Thermostat Electronic Control —

Protection Device Electronic Control Electronic Control

Length mm —C1, C2 ; 1,100, C3 ; 750

Capillary Tube Flow Rate l/min —C1, C2 ; 5.0, C3 ; 15.4

Inner Diameter mm —C1, C2 ; 1.2, C3 ; 1.7

Air Filter Material

Style

P.P.

Honeycomb

—

Fan Motor Capacitor µF, VAC —2.0 µF, 400 VAC

• Specifications are subject to change without notice for further improvement.

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

4 Dimensions

CS-E9CKP CU-E9CKP5 / CS-E12CKP CU-E12CKP5

Panasonic ilmalämpöpumput korjaa ja huoltaa pääkaupunkiseudulla: Jäähdytinpalvelu RefGroup Oy

www.ilmalämpöpumput.com

Otros manuales para CS-E9CKP

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de Panasonic

Panasonic

Panasonic CS-E18GKR Manual de usuario

Panasonic

Panasonic CU-PW9DKE Manual de usuario

Panasonic

Panasonic CS-PS9UKA Manual de usuario

Panasonic

Panasonic CS-RE9JKX-1 Manual de usuario

Panasonic

Panasonic CS-WU12VKYF Series Manual de usuario

Panasonic

Panasonic CS-C12HKF Manual de usuario

Panasonic

Panasonic CS-VE9NKE Manual de usuario

Panasonic

Panasonic CS-D28DTH5 Manual de usuario

Panasonic

Panasonic CS-F50MD1E5 Manual de usuario

Panasonic

Panasonic CS-Z7RKR Manual de usuario

Panasonic

Panasonic CW-C200NU Manual de usuario

Panasonic

Panasonic CS-Z25UFRAW Manual de usuario

Panasonic

Panasonic CS-S9KKQ Manual de usuario

Panasonic

Panasonic CS-1270TR Manual de usuario

Panasonic

Panasonic CS/CU-HU12AKY Series Guía del producto

Panasonic

Panasonic OCU-CR400VF8 Instrucciones de funcionamiento

Panasonic

Panasonic PAPAMY1702034CE Manual de usuario

Panasonic

Panasonic CS-FZ25UKE Manual de usuario

Panasonic

Panasonic CS-PE9CKE Manual de usuario

Panasonic

Panasonic CW-1805SU Manual de usuario

Panasonic

Panasonic CS-W28BKP5 Manual de usuario

Panasonic

Panasonic CS-TZ20ZKEW Manual de usuario

Panasonic

Panasonic CU-E9SKE Manual de usuario

Panasonic

Panasonic CS-RZ25XKRW Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario

Webasto

Webasto Frigo Top 25 DS Manual de usuario
