Panasonic CS-C73KE Manual de usuario

ServiceManual

Room Air Conditioners

Contents

●Features ..........................................................1

●Functions ...................................................2 – 4

●Product Specifications .............................5 – 10

●Dimensions............................................11 – 12

●Refrigeration Cycle Diagram .........................13

●Block Diagram ...............................................14

●Wiring Diagram..............................................15

●Operation Details...................................16 – 23

●Installation Information ..........................24 – 25

●2-way, 3-way Valves..............................26 – 32

●Servicing Information.............................33 – 36

●Troubleshooting Guide ..........................37 – 38

●Technical Data.......................................39 – 40

●Exploded View...................................41, 43, 45

●Replacement Parts List .....................42, 44, 46

●Electronic Parts List.......................................47

CS-C73KE / CU-C73KE

CS-C93KE / CU-C93KE

CS-C123KE / CU-C123KE

ORDER NO. MAC9810034C2

 1998 Matsushita Air-Conditioning Corp. Sdn. Bhd.

(183914D)

tion is a violation of law.

Untitled-2 6/28/00, 5:22 PM1

– 1 –

MAC9512086C2

CS-C73KE

• High Efficiency

• Compact Design

• Comfort Enviroment

– 8 hours of sleep mode operation

– Air purifying filter with deodorizing function

to reduce dust, smoke and odours.

• Auto Restart

– Autorestartatrandomoperationafterpower

failure

• Removable and Washable

Front Panel

• Quality Improvement

– Gas leakage protection

– Prevent compressor reverse cycle

– 2-stage OLP to protect compressor

• Service Improvement

– Easy fan motor replacement procedure

• Operation Improvement

– Economy mode to reduce electrical power

consumption.

– Powerful mode to reaches the desired room

temperature quickly.

• Long Installation Piping

– CS/CU–C73KE,CS/CU–C93KE,long pipingupto10

meter.

– CS/CU–C123KE, long piping up to 15 meter.

Features

PRECAUTION OF LOW TEMPERATURE

In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigeration circuit.

WARNING

Thisserviceinformationisdesignedfor experienced repairtechnicians onlyand isnot designedfor useby thegeneral public.Itdoesnotcontain

warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity

should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the product or products dealt with

in this service information by anyone else could result in serious injury or death.

Untitled-1 6/29/00, 7:37 AM1

– 2 –

MAC9512086C2

CS-C73KE

Remote Control

Functions

Operation OFF / ON

OFF / ON IRoom Temperature Setting

TEMP.

• Temperature Setting (16°C to 30°C)

• Automatic Operation

2°C higher than standard

Standard

2°C lower than standard

Operation Mode Selection

•AUTO Automatic Operation Mode

•COOL Cooling Operation Mode

•DRY Soft Dry Operation Mode

•FAN Air Circulation Mode

MODE

TIMER Time / Timer Setting

• Hours and minutes setting.

Clock Setting

• Current time setting.

Sleep Mode Operation OFF / ON

SLEEP

Indoor Fan Speed Selection

FAN SPEED

•h j k Low Speed

•h j k Medium Speed

lll

•h j k High Speed

lllll

•AUTOFAN Automatic Fan Speed

•AUTO Automatic Airflow Direction

Control

•MANUAL Airflow Direction Manual Control

Airflow Direction Control

• 24-hour, OFF / ON Real Timer Setting.

ON-TIMER

OFF-TIMER Timer Operation Selection

SET

CANCEL Timer Operation Set / Cancel

• ON Timer and OFF Timer setting and

cancellation.

AIR SWING

Powerful Mode Operation OFF/ON

POWERFUL

Economy Mode Operation OFF/ON

ECONOMY

8 HI

9 Lo

CLOCK

Untitled-1 6/29/00, 7:37 AM2

– 3 –

MAC9512086C2

CS-C73KE

Indoor Unit

Functions

Power Switch OFF / ON

POWER I

Auto Operation Button

• Used when the remote control cannot be

used.

Remote Control Signal Receiving

Sound

• It can be controlled by pressing Auto

Operation Button for 10 seconds.

AUTO

OFF / ON

Operation Test Running / Pump

Down Switch

TEST RUN

OFF / ON

Operation Indication Lamps (LED)

•POWER (Red)...... Lights up in operation,

blinks in Automatic

Operation Mode judging

•SLEEP (Orange)..... Lights up in Sleep

Mode Operation

•TIMER (Orange)..... Lights up in Timer

Setting

•POWERFUL

(Orange).....

Lights up in Powerful

Mode Operation

•ECONOMY

(Green).....

Lights up in Economy

Mode Operation

Random Auto Restart Control

• Operation is restarted randomly after power

failure at previous setting mode.

Anti-Freezing Control

• Anti-Freezing control for indoor heat

exchanger. (Cooling and Soft Dry)

• Used when test running or servicing.

Sleep Mode Auto Control

• Indoor Fan operates at low speed.

• Operation stops after 8 hours.

Indoor Fan Speed Control

• High, Medium and Low.

• Automatic Fan Speed Mode

– Cooling : Fan rotates at Hi and Me

speed. Deodorizing control is

available.

– Soft Dry : Fan rotates at SLo and Lo

speed. Deodorizing control is

available.

Airflow Direction Control

• Automatic air swing and manual adjusted

by remote control for vertical airflow.

• Manually adjusted by hand for horizontal

airflow.

Operation Mode

• Cooling, Soft Dry, Air Circulation and

Automatic Mode.

Time Delay Safety Control

• Restarting is inhibited for appro. 3 minutes.

7 Minutes Time Save Control

• Cooling Operation only.

Starting Current Control

Powerful Operation

• Reaches the desired room temperature

quickly.

Economy Operation

• To reduce electrical power consumption.

Untitled-1 6/29/00, 7:37 AM3

– 4 –

MAC9512086C2

CS-C73KE

Compressor Reverse Rotation

Protection Control

Outdoor Unit

Functions

• To protect compressor from reverse

rotation when there is a instantaneous

power failure.

Overload Protector

• 2-Stage OLP to protect the compressor.

Overload Protector will trip when

– Temperature of compressor increases to

120°C.

– High temperature or high current flows to

compressor.

(Refer circuit diagram for OLP

characteristic)

60 Secs. Forced Operation Control

• Once the compressor is activated, it does

not stop within the first 60 secs. However, it

stops immediately with remote control stop

signal.

Outdoor Fan Operation Control

•

Inner protector.

CU-C123KE

CU-C73KE, CU-C93KE

Untitled-1 6/29/00, 7:37 AM4

– 5 –

MAC9512086C2

CS-C73KE

Product Specifications

Inner diameter

Length

Input

Running Current

COP

Starting Current

Cooling Capacity

Moisture Removal

Power Source

Airflow Method

Air Volume

Noise Level

Electrical

Data

Piping Connection Port

(Flare piping)

Pipe Size

(Flare piping)

Drain

Hose

Power Cord Length

Number of core-wire

Dimensions

Net Weight

Compressor

Air Circulation

Height

Width

Depth

Type

Motor Type

Rated Output

Type

Material

Motor Type

Input

Rated Output

Fan Low

Speed Medium

High

Unit

Btu/h

s/h

Pint/h

Phase

Cycle

OUTLET

INTAKE

m3/min (cfm)

dB (A)

W/W

inch

inch (mm)

lb (kg)

rpm

Indoor Air (Lo)

Indoor Air (Me)

Indoor Air (Hi)

Outdoor Air

2.05 - 2.00

7,000 - 6,830

1.3

2.7

Single

230 - 220

600 - 550

2.8 - 2.7

3.42 - 3.64

CS-C73KE

SIDE VIEW

5.5 (190)

6.3 (220)

7.0 (250)

–

High 33 - 32, Low 28 - 26

G ; Half Union 3/8"

L ; Half Union 1/4"

G (gas side) ; 3/8"

L (liquid side) ; 1/4"

0.7

2.0

3 (1.0 mm2)

10-31/32 (279)

31-15/32 (799)

7-15/32 (190)

20 (9.0)

–

Cross-flow Fan

AS + Glass Fiber 30%

Induction (4-poles)

29.0 - 27.0

835

945

1,055

CU-C73KE

TOP VIEW

–

22.2 (780)

High 46 - 45

G ; 3-way valve 3/8"

L ; 2-way valve 1/4"

G (gas side) ; 3/8"

L (liquid side) ; 1/4"

–

18-29/32 (480)

30-23/32 (780)

9-21/32 (245)

57 (26)

Rotary (1 cylinder)

rolling piston type

Induction (2-poles)

500

Propeller Fan

AES + Glass Fiber 16%

Induction (6-poles)

54.7 - 47.9

–

685

Untitled-1 6/21/00, 10:59 AM5

– 6 –

MAC9512086C2

CS-C73KE

Product Specifications

Description

Tube material

Fin material

Fin Type

Row / Stage

FPI

Size (W ×H ×L)

µF, VAC

Length

Flow Rate

Inner Diameter

Material

Style

Heat

Exchanger

Refrigerant Control Device

Refrigeration Oil

Refrigerant (R-22)

Thermostat

Protection Device

Capillary Tube

Air Filter

Capacity Control

Compressor Capacitor

Fan Motor Capacitor

Unit

(c.c)

g (oz)

s/min

(Plate fin configuration, forced draft)

Capillary Tube

• Specifications are subject to change without notice for further improvement.

CS-C73KE

Evaporator

Copper

Aluminium

Slit Fin

2 ×14

614 ×294 ×25.4

–

Electronic Control

–

P.P.

Honeycomb

–

1.5 µF, 400VAC

CU-C73KE

Condenser

Copper

Aluminium

Louver Fin

1 ×18

856 ×457.2 ×22

Capillary Tube

SUNISO 4GDID or

ATMOS M60 (260)

645 (22.8)

–

2 Stage Overload Protector

450

7.9

1.2

–

20 µF, 370VAC

1.2 µF, 400VAC

Untitled-1 6/21/00, 10:59 AM6

– 7 –

MAC9512086C2

CS-C73KE

Unit

Btu/h

s/h

Pint/h

Phase

Cycle

OUTLET

INTAKE

m3/min (cfm)

dB (A)

W/W

inch

inch (mm)

lb (kg)

rpm

Product Specifications

Inner diameter

Length

Input

Running Current

COP

Starting Current

Cooling Capacity

Moisture Removal

Power Source

Airflow Method

Air Volume

Noise Level

Electrical

Data

Piping Connection Port

(Flare piping)

Pipe Size

(Flare piping)

Drain

Hose

Power Cord Length

Number of core-wire

Dimensions

Net Weight

Compressor

Air Circulation

Height

Width

Depth

Type

Motor Type

Rated Output

Type

Material

Motor Type

Input

Rated Output

Fan Low

Speed Medium

High

Indoor Air (Lo)

Indoor Air (Me)

Indoor Air (Hi)

Outdoor Air

2.75 - 2.65

9,390 - 9,050

1.6

3.4

Single

230 - 220

800 - 770

3.5 - 3.6

3.44 - 3.44

16.4

CS-C93KE

SIDE VIEW

6.8 (240)

7.3 (260)

8.7 (310)

–

High 37 - 36, Low 30 - 28

G ; Half Union 3/8"

L ; Half Union 1/4"

G (gas side) ; 3/8"

L (liquid side) ; 1/4"

0.7

2.0

3 (1.0 mm2)

10-31/32 (279)

31-15/32 (799)

7-15/32 (190)

20 (9.0)

–

Cross-flow Fan

AS + Glass Fiber 30%

Induction (4-poles)

35.5 - 33.0

925

995

1,185

CU-C93KE

TOP VIEW

–

22.2 (780)

High 47 - 46

G ; 3-way valve 3/8"

L ; 2-way valve 1/4"

G (gas side) ; 3/8"

L (liquid side) ; 1/4"

–

18-29/32 (480)

30-23/32 (780)

9-21/32 (245)

64 (29.0)

Rotary (1 cylinder)

rolling piston type

Induction (2-poles)

700

Propeller Fan

AES + Glass Fiber 16%

Induction (6-poles)

54.7 - 47.9

–

685

Untitled-1 6/21/00, 10:59 AM7

– 8 –

MAC9512086C2

CS-C73KE

Heat

Exchanger

Refrigerant Control Device

Refrigeration Oil

Refrigerant (R-22)

Thermostat

Protection Device

Capillary Tube

Air Filter

Capacity Control

Compressor Capacitor

Fan Motor Capacitor

Product Specifications

Description

Tube material

Fin material

Fin Type

Row / Stage

FPI

Size (W ×H ×L)

µF, VAC

Length

Flow Rate

Inner Diameter

Material

Style

Unit

(c.c)

g (oz)

s/min

(Plate fin configuration, forced draft)

Capillary Tube

• Specifications are subject to change without notice for further improvement.

CS-C93KE

Evaporator

Copper

Aluminium

Slit Fin

2 ×14

614 ×294 ×25.4

–

Electronic Control

–

P.P.

Honeycomb

–

1.5 µF, 400VAC

CU-C93KE

Condenser

Copper

Aluminium

Louver Fin

1 ×18

856 ×457.2 ×22

Capillary Tube

SUNISO 4GDID or

ATMOS M60 (320)

760 (26.8)

–

2-Stage Overload Protector

1,040

9.0

1.5

–

30 µF, 370VAC

1.2 µF, 400VAC

Untitled-1 6/21/00, 10:59 AM8

– 9 –

MAC9512086C2

CS-C73KE

Unit

Btu/h

s/h

Pint/h

Phase

Cycle

OUTLET

INTAKE

m3/min (cfm)

dB (A)

W/W

inch

inch (mm)

lb (kg)

rpm

Product Specifications

Inner diameter

Length

Input

Running Current

COP

Starting Current

Cooling Capacity

Moisture Removal

Power Source

Airflow Method

Air Volume

Noise Level

Electrical

Data

Piping Connection Port

(Flare piping)

Pipe Size

(Flare piping)

Drain

Hose

Power Cord Length

Number of core-wire

Dimensions

Net Weight

Compressor

Air Circulation

Height

Width

Depth

Type

Motor Type

Rated Output

Type

Material

Motor Type

Input

Rated Output

Fan Low

Speed Medium

High

Indoor Air (Lo)

Indoor Air (Me)

Indoor Air (Hi)

Outdoor Air

3.65 - 3.52

12,500 - 12,000

2.1

4.4

Single

230 - 220

1,190 - 1,150

5.3 - 5.4

3.07 - 3.06

CS-C123KE

SIDE VIEW

7.4 (260)

8.0 (280)

9.0 (290)

–

High 39 - 39, Low 34 - 33

G ; Half Union 1/2"

L ; Half Union 1/4"

G (gas side) ; 1/2"

L (liquid side) ; 1/4"

0.7

2.0

3 (1.0 mm2)

10-31/32 (279)

31-15/32 (799)

7-15/32 (190)

20 (9.0)

–

Cross-flow Fan

AS + Glass Fiber 30%

Induction (4-poles)

35.5 - 33.0

1,060

1,145

1,280

CU-C123KE

TOP VIEW

–

32.2 (1130)

High 49 - 48

G ; 3-way valve 1/2"

L ; 2-way valve 1/4"

G (gas side) ; 1/2"

L (liquid side) ; 1/4"

–

21-1/4 (540)

27-17/32 (699)

11-7/32 (285)

82 (37)

Rotary (1 cylinder)

rolling piston type

Induction (2-poles)

1,100

Propeller Fan

AES + Glass Fiber 16%

Induction (6-poles)

72.0 - 68.0

–

785

Untitled-1 6/21/00, 10:59 AM9

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de Panasonic

Panasonic

Panasonic CS-E15GKR Manual de usuario

Panasonic

Panasonic FV-1115VQL1 Manual de usuario

Panasonic

Panasonic CS-ME7QKUA Manual de usuario

Panasonic

Panasonic CS-HZ12RKE Manual de usuario

Panasonic

Panasonic CS-RE9NKR Manual de usuario

Panasonic

Panasonic CS-PW18MKD Manual de usuario

Panasonic

Panasonic CS-E9BKP Manual de usuario

Panasonic

Panasonic CS-PV12CKE Manual de usuario

Panasonic

Panasonic CS-XE9SKUA Manual de usuario

Panasonic

Panasonic CW-XN1221VA Manual de usuario

Panasonic

Panasonic S-36MU1E51 Manual de usuario

Panasonic

Panasonic CS-MPS9SKH Manual de usuario

Panasonic

Panasonic CS/CU-RE9GKE Manual de usuario

Panasonic

Panasonic CU-3E19RBU-5 Manual de usuario

Panasonic

Panasonic mini VRF U-4LE2R5 Manual de usuario

Panasonic

Panasonic CS-TZ20ZKEW Manual de usuario

Panasonic

Panasonic CS-RE9MKD-2 Manual de usuario

Panasonic

Panasonic CS-MKE12NB4U Guía de instalación y uso

Panasonic

Panasonic CU-BZ25XKE Manual de usuario

Panasonic

Panasonic CU-2TZ41TBE Manual de usuario

Panasonic

Panasonic CS-ME7NKE Manual de funcionamiento

Panasonic

Panasonic CW-C141NU Manual de usuario

Panasonic

Panasonic CU-E15JKE-3 Manual de usuario

Panasonic

Panasonic S56MM1E5A Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario

Webasto

Webasto Frigo Top 25 DS Manual de usuario
