PaloAlto Networks TECHDOCS ION 9000 Guía de aplicación

ION 9000 Hardware Reference

docs.paloaltonetworks.com

Contact Informaon

Corporate Headquarters:

Palo Alto Networks

3000 Tannery Way

Santa Clara, CA 95054

www.paloaltonetworks.com/company/contact-support.html

About the Documentaon

• For the most recent version of this guide or for access to related documentaon, visit the

Technical Documentaon portal docs.paloaltonetworks.com.

• To search for a speciﬁc topic, go to our search page docs.paloaltonetworks.com/search.html.

• Have feedback or quesons for us? Leave a comment on any page in the portal, or write to us

at documenta[email protected]om.

Palo Alto Networks, Inc.

www.paloaltonetworks.com

Alto Networks. A list of our trademarks can be found at www.paloaltonetworks.com/company/

trademarks.html. All other marks menoned herein may be trademarks of their respecve

companies.

Last Revised

September 3, 2021

Table of Contents

Before You Begin................................................................................................5

Tamper Proof Statement............................................................................................................ 6

Third-Party Component Support............................................................................................. 7

Product Safety Warnings........................................................................................................... 8

ION 9000 Overview........................................................................................11

ION 9000.................................................................................................................................... 12

ION 9000 Ports......................................................................................................................... 13

ION 9000 Front Panel with LEDs......................................................................................... 14

ION 9000 Speciﬁcaons......................................................................................................... 15

ION Device Compliance Statement......................................................................................17

ION 9000 Installaon Kit Components...............................................................................19

Power on the ION 9000......................................................................................................... 20

Shut down the ION 9000............................................................................................20

Reboot the ION 9000...................................................................................................20

Install the ION 9000....................................................................................... 21

Rack Mount the ION 9000.....................................................................................................22

Install the ION 9000 in Virtual In-Path Conﬁguraon..................................................... 27

Conﬁgure Controller Port............................................................................................ 27

Conﬁgure Peering Ports............................................................................................... 28

Conﬁgure Internet Ports.............................................................................................. 28

Install ION 9000 in High Availability....................................................................................30

Table of Contents

Before You Begin

Read the following topics before you install or service a Palo Alto Networks® next-

generaon ﬁrewall or appliance. The following topics apply to all Palo Alto Networks

ﬁrewalls and appliances except where noted.

>Tamper Proof Statement

>Third-Party Component Support

>Product Safety Warnings

Before You Begin

Tamper Proof Statement

To ensure that products purchased from Palo Alto Networks were not tampered with during

shipping, verify the following upon receipt of each product:

• The tracking number provided to you electronically when ordering the product matches the

tracking number that is physically labeled on the box or crate.

• The integrity of the tamper-proof tape used to seal the box or crate is not compromised.

• The integrity of the warranty label on the ﬁrewall or appliance is not compromised.

Before You Begin

Third-Party Component Support

Before you consider installing third-party hardware, read the Palo Alto Networks Third-Party

Component Support statement.

Before You Begin

Product Safety Warnings

To avoid personal injury or death for yourself and others and to avoid damage to your Palo Alto

Networks hardware, be sure you understand and prepare for the following warnings before you

install or service the hardware. You will also see warning messages throughout the hardware

reference where potenal hazards exist.

All Palo Alto Networks products with laser-based opcal interfaces comply with 21 CFR

1040.10 and 1040.11.

The following safety warnings apply to all Palo Alto Networks ﬁrewalls and appliances, unless a

speciﬁc hardware model is speciﬁed.

• When installing or servicing a Palo Alto Networks ﬁrewall or appliance hardware component

that has exposed circuits, ensure that you wear an electrostac discharge (ESD) strap. Before

handling the component, make sure the metal contact on the wrist strap is touching your skin

and that the other end of the strap is connected to earth ground.

French Translaon: Lorsque vous installez ou que vous intervenez sur un composant matériel

de pare-feu ou de disposif Palo Alto Networks qui présente des circuits exposés, veillez

à porter un bracelet anstaque. Avant de manipuler le composant, vériﬁez que le contact

métallique du bracelet anstaque est en contact avec votre peau et que l’autre extrémité du

bracelet est raccordée à la terre.

• Use grounded and shielded Ethernet cables to ensure agency compliance with electromagnec

compliance (EMC) regulaons.

French Translaon: Des câbles Ethernet blindés reliés à la terre doivent être ulisés pour

garanr la conformité de l'organisme aux émissions électromagnéques (CEM).

• (ION 7000 and ION 9000 only) At least two people are recommended for unpacking, handling,

and relocang the heavier ﬁrewalls.

• Do not connect a supply voltage that exceeds the input range of the ﬁrewall or appliance. For

details on the electrical range, refer to electrical speciﬁcaons in the hardware reference for

your ﬁrewall or appliance.

French Translaon: Veillez à ce que la tension d’alimentaon ne dépasse pas la plage d’entrée

du pare-feu ou du disposif. Pour plus d’informaons sur la mesure électrique, consulter la

rubrique des caractérisques électriques dans la documentaon de votre matériel de pare-feu

ou votre disposif.

• Do not replace a baery with an incorrect baery type; doing so can cause the replacement

baery to explode. Dispose of used baeries according to local regulaons.

French Translaon: Ne remplacez pas la baerie par une baerie de type non adapté, cee

dernière risquerait d’exploser. Meez au rebut les baeries usagées conformément aux

instrucons.

• I/O ports are intended for intra-building connecons only and not intended for OSP (Outside

Plant) connecons or any network connecons subject to external voltage surge events.

Before You Begin

•(All Palo Alto Networks appliances with two or more

power supplies)

Cauon: Shock hazard

Disconnect all power cords (AC or DC) from the power

inputs to fully de-energize the hardware.

French Translaon: (Tous les appareils Palo Alto

Networks avec au moins deux sources d’alimentaon)

Débranchez tous les cordons d’alimentaon (c.a. ou

c.c.) des entrées d’alimentaon et meez le matériel

hors tension.

Before You Begin
