Pacific Tsunami Guía de solución de problemas

Tsunami / High Flow Extractor

Operations & MaintenanceOperations & Maintenance

Operations & Maintenance

PFM/MEM/1102 Pacific Floor Machine Co.

Tsunami Carpet Extractor Setup and OperationsTsunami Carpet Extractor Setup and Operations

Tsunami Carpet Extractor Setup and Operations

Setting the Chemical Dilution Ratio on the MacSetting the Chemical Dilution Ratio on the Mac

Setting the Chemical Dilution Ratio on the Machinehine

hinehine

hine

Before using the machine, it should be set up to feed the proper dilution ratio

of your traffic lane extraction cleaner to the prespray wand. The machine is

preset to feed a water chemical mix at a rate of 33:1 or about 4 ounces of

cleaner to one gallon of water.

Tip ColorTip Color

Tip Color

Tan

Orange

Turquoise

Pink

Clear

Brown

Red

White

Green

Blue

Yellow

Black

Purple

Gray

None

RatioRatio

Ratio

102:1

75:1

60:1

43:1

33:1

28:1

22:1

18:1

16:1

13:1

9:1

6:1

5:1

4:1

3.6:1

Ounces / GallonOunces / Gallon

Ounces / Gallon

1.25

1.70

2.15

3.00

3.90

4.55

5.80

7.00

7.90

9.80

14.80

20.15

27.80

31.60

35.00

Remove the two cover mounting screws

on the top of the machine body.

The Dema tip is located in the plumbing

on the left side of the machine.

The black cowling can now be removed.

This exposes the electrical and plumb-

ing hardware in the machine.

The machine comes with a set of 14, color coded,

Dema injector tips. Each tip will offer a different

feed ratio. The injector tip is located in a plumbing

manifold under the machine top cover.

Pacific Floor Machine Co. Page 1

MacMac

Machine Operationshine Operations

hine Operationshine Operations

hine Operations

Read and understand the Operators Manual that came with the machine.

If this manual is not on hand it may be ordered from your local Pacific

dealer or by calling Pacific directly at 800-968-1332 and speaking with a

customer care representative.

The Tsunami is a wet extraction, direct hookup, carpet cleaning tool. It is

meant to be used in conjunction with other carpet maintenance machines.

The frequent use of a good two motor upright vacuum or a high perfor-

mance wide area vacuum in conjunction with a good extraction spotter is

essential for a complete carpet cleaning program. When the situation dic-

tates, this machine may be used in conjunction with a slow speed buffer

and carpet bonnets and or carpet brushes. Air blowers should be used

when ever possible to aid in the drying process.

Install the proper color coded tip and

replace the feed hose. Reinstall the

machine cover and tighten the mount-

ing screws.

Remove the feed hose and the Dema tip

will be exposed. Unscrew the tip from the

feed system by hand.

Pacific Floor Machine Co. Page 2

AssembAssemb

Assemble the Neededle the Needed

le the Neededle the Needed

le the Needed TT

Toolsools

oolsools

ools

Tsunami with Hoses and ChemicalsTsunami with Hoses and Chemicals

Tsunami with Hoses and Chemicals

Extra hoses as neededExtra hoses as needed

Extra hoses as needed

HD eHD e

HD extension cabxtension cab

xtension cabxtension cab

xtension cable & plierle & plier

le & plierle & plier

le & plierss

Faucet adapteraucet adapter

aucet adapteraucet adapter

aucet adapterss

Traffic Lane Extraction Cleaner goes

into this bottle and is metered into

the yellow pre-treat hose and wand.

Anti-foam liquid goes into this bottle

and is metered into the recovery

tank when the operator depresses a

feed switch.

Pacific Floor Machine Co. Page 3

Vacuum the Carpet Areaacuum the Carpet Area

acuum the Carpet Areaacuum the Carpet Area

acuum the Carpet Area

Genius 14, a good 2 motor upright vacuum

Remove theaeratorfrom thesink and installa

matching adaptor from the hardware kit sup-

plied with the machine.

Prepair the SinkPrepair the Sink

Prepair the Sink

Prepair the MacPrepair the Mac

Prepair the Machinehine

hinehine

hine

Unroll the hoses and attach to the machine. The

gray hose is for the clean water IN and the clear

hose is for dirty water OUT. Plug the electrical

cable into the pig tail on the machine.

Aerator

Adapters

Turn valves to

Open position Clear line

dirty water OUT

Electrical Plug

Gray line

water IN

Pacific Floor Machine Co. Page 4

AttacAttac

Attach the Hose Assembh the Hose Assemb

h the Hose Assembh the Hose Assemb

h the Hose Assembll

lyy

Attach the gray hose to the faucet

and check for leaks.

Secure clear drain hose in sink,

floor drain or commode.

Plug electrical cable into

grounded outlet.

These valves are truned to OFF.

Turn all valves ON to begin cleaning.

Do aDo a

Do a TT

Test Pull with the Macest Pull with the Mac

est Pull with the Macest Pull with the Mac

est Pull with the Machinehine

hinehine

hine

Test clean an area using no chemicals. If

thereis cleanerresidualin thecarpet from

previous cleaning no pretreating will be

necessary. However, defoam liquid may

be needed if too much residue cleaner is

inthecarpet. Watchthe seethroughcover

on the front of the machine and you will be

able to tell if over foaming is going to be a

problem. If you note excess foam or the

vacuum motor sounds like it is slowing

downyoushoulddepressthe Defoambut-

ton on the machine control panel. This al-

lows defoam liquid to be pulled into the re-

coverytank. Ifthecarpetseemstobeclear

of cleaner residual, you may pretreat the

area as needed.

Pacific Floor Machine Co. Page 5

Pretreat as Needed and Begin CleaningPretreat as Needed and Begin Cleaning

Pretreat as Needed and Begin Cleaning

Position the machine for the first

cleaning pass. Turn the vacuum

switch ON. Depress the Intermittent

Spray button and pull the unit back-

wards. Lift up on the handle just

enough to keep the vacuum shoe in

good contact with the carpet.

At the end of the clean-

ingpassletoffthespray

button and pull the ma-

chine a few inches

more so the vacuum

can pick up the remain-

ing water. Reposition

themachineforthesec-

ond pull being sure to

over lap the cleaning

stroke about 2 inches.

Continueinthismanner

until the entire room is cleaned. Always try to work away from the hoses.

Keep both hands on the machine and work the hoses with your feet as

needed. Extra hoses are available in 50’sections with valves on each end.

Themaximumworkablehose lengthis250 feet. Ifmore distanceisneeded,

an extra externally mounted discharge pump may be used.

Intermittent Spray

Vacuum

Defoam Button

Constant Spray (ON / Off)

Pacific Floor Machine Co. Page 6

MacMac

Machine Maintenancehine Maintenance

hine Maintenancehine Maintenance

hine Maintenance

Remove the see through cover on the

front of the machine to access the filters

and the float switch.

The vacuum filter screen should be

cleaned after each job. Wipe the screen

clean on a regular basis and periodically

remove to do thorough cleaning.

Use the spray wand to clean the

inside of the tank.

Remove the pump filter screens

for a complete cleaning.

Unscrew the brass thumb nut to

removethe floatfora more com-

plete cleaning.

Use the spray wand to clean the

floatmechanismandpumpfilters.

Pacific Floor Machine Co. Page 7

The pump filter screens can be removed from the

machineand disassembled for acomplete cleaning.

The pump float switch should be removed periodi-

cally and given a thorough cleaning and inspection.

The see through channel cover should be removed for cleaning on a regular

basis. Use a wet pick up vacuum to remove residual sand and water.

Pacific Floor Machine Co. Page 8

Remove theimpellerand wipecleanthe running surfacesinside thepumphous-

ing. Coat the new impeller and running surfaces with a bit of vegetable oil.

The rubber, paddle wheel, impeller is a wear item and will need to be replaced

periodically. This pump is located in the right rear of the machine.

Remove the cover plate and the gasket seal. It has been noted that the use of

2 gaskets instead of 1 gives longer and more trouble free impeller life.

Pacific Floor Machine Co. Page 9
