Oxgard Praktika T-05 Hoja de instrucciones
Installation
guidelines
www.oxgard.com
Tel.+7(812) 366-15-94
Praktika T-05(K) speedgate
Installation guidelines 3
Content
1. Basic specifications.................................................................................. 5
2. Product design.......................................................................................... 6
3. Safety requirements.................................................................................. 9
4. Installation of speedgate......................................................................... 10
4.1. Required equipment........................................................................ 10
4.2. Installation of speedgate.................................................................. 11
5. Connecting speedgate............................................................................. 14
5.1. Connecting power supply................................................................ 15
5.2. Connecting remote control panel.................................................... 16
5.3. Connecting side units...................................................................... 17
5.4. Connecting access control system (optional).................................. 19
6.1. Card collector description............................................................... 24
6.2. Connecting power supply................................................................ 26
6.3. Connecting operating device........................................................... 27
6.4. Connecting ACS controller............................................................. 28
6.5. Installation of proximity card reader............................................... 30
Appendix 1. Summary of the data bus CAN2.0 ........................................ 33
Appendix 2. Block diagram of ACS with using the card reader............... 35
Appendix 3. Location of mounting holes in relation to the overall
dimensions of the
speedgate…………………………………………………….....38
Appendix 4. Block diagram of minimal connections for synchronized
operation of wings with the use of one RC panel...................................... 40
Praktika T-05(K) speedgate 4
List of abbreviations
PS – power supply
FA – fire alarm
RC – remote control
ACS – access control system
OD – operating device (turnstile)
NC – normally connected
NO – normally opened
Speedgate firmware version FW v2.0-2.2
Card collector firmware version FW v1.52
Installation guidelines 5
1. Basic specifications
Table 1 Basic specifications
Description Speedgate RC panel
Dimension of side unit with open wings
(mm) (HхWхL) 1050х1500х200
107х107х25
Dimension of side unit depending on
passage lane (mm)
660
900
1050х1500х500
1050х1500х620
107х107х25
Weight of side unit
depending on passage
lane, kg 660
900
110,0
113,0
0,5
Temperature range,
0
C
operation
- transportation and storage
+1...+40
+1...+40
+1...+40
+1...+40
Atmosphere relative humidity, no more
than % 80 80
Throughput, persons per minute
30
Card collector capacity (pcs.)
**
More than 500
Max. number of connected RC panels, pcs 2
Lifetime, years 8 8
Praktika T-05(K) speedgate 6
Table 2 Electrical specifications
Description Speedgate Card collector** RC panel
Supply voltage, V:
- nominal
- working
12,0
10,8...15,0
12,0
8…18,0
12,0
7,5...15,0
Average current
in standby
mode * A 0,4 0,2
Average
current operational
mode * A 3,0
Maximal current of
1 side
unit*/***, A 5,0
Maximal current
of card
collector*, A 1,5
*- values mentioned at a nominal supply voltage
**-optional
***-
to form a passage area required 2 side units, i.e. 2 power supply 12V 5A
The producer reserves the right to change the packaging, specifications and appearance without
notice
2. Product design
Speedgate housing
Speedgate housing is made of brushed stainless steel, wings are made
of tempered glass. Additionally the card collector can be integrated in the
design of the speedgate. Base covers for access to PU, RC and ACS cables
holes (Fig. 1) are provided at the bottom of side units.
Installation guidelines 7
Speedgate may have only a single passage, however an unlimited
number of passages can be arranged with the use of side units and middle
units, depending on customer requirements.
Fig. 1 General view of speedgate
LED panel
Display panel of the speedgate is made of artificial stone with an
insertion made of acrylic glass. Speedgate operating modes are displayed
on the panel in the form of mnemonic signs depicting authorization and
non-authorization (Fig. 2).
Praktika T-05(K) speedgate 8
Fig. 2 General view of LED panel display
Remote Control Panel
The housing of RC panel is made of polished stainless steel. On the
front side there are control buttons and LED indicators of RC operational
modes (Fig. 3). The standard supplied cable is 5 m long.
Fig. 3 General view of remote control panel
Installation guidelines 9
3. Safety requirements
CAUTION! Failure to comply with the safety requirements specified in
this section may result in damage to human life and health, total or partial
loss of workability of products and (or) auxiliary equipment.
CAUTION! The producer disclaims any liability for damage to human life
and health, total or partial loss of workability of products and (or) auxiliary
equipment for non-compliance of the safety requirements specified in this
section, as well as terminates the product warranty.
IT IS NOT ALLOWED TO:
•Set the power supply unit inside the speedgate housing as this could
lead to electric shock to persons;
•Set the speedgate other than in dry and heated places;
•Impede or accelerate the speedgate wings;
•Apply chemically aggressive cleaning detergents as pastes and
liquids.
Praktika T-05(K) speedgate 10
4. Installation of speedgate
CAUTION: The speedgate should be installed securely to avoid swinging
and (or) overthrow during operation. In case of installation on the low
strength floors - take action to strengthen the floor at the installation site.
Before checking operability of the speedgate carefully read this section of
the Regulations.
4.1. Required equipment
Tools used for card reader mounting:
•Electric perforator;
•20mm diameter carbide drill for drilling holes in the floor for anchors
(recommended anchor - SORMAT PFG LB 12-50);
•wrench for hexagon socket head screws S10;
•slotted screwdriver;
•plumb line or level;
•steel underlayer for turnstile alignment
•round file
•side cutters
