Osram E:cue SYMPL input Node Guía del usuario

AB444200035

e:cue SYMPL input Node

Setup Manual / Installationsanleitung

Our Brand

www.osram.com/ecue

Light is OSRAM

AB444200035

e:cue SYMPL input Node Setup Manual (original issue)

e:cue SYMPL input Node Installationsanleitung (Originalversion)

Edition/Ausgabe: 23.08.19 [EN_DE_SYMPL_input_Node_Setup_v2p0]

Published by / Herausgegeben von:

OSRAM GmbH

Karl-Schurz-Strasse 38

33100 Paderborn, Germany

Read the Setup Manual

carefully before unpacking the

product. Subject to

modication without prior

notice. Typographical and other

errors do not justify any claim

for damages. All dimensions

should be veried using an

actual part.

Except for internal use,

relinquishment of the

instructions to a third party,

duplication in any type or form

- also extracts - as well as

exploitation and/or

communication of the contents

is not permitted.

Lesen Sie die

Installationsanleitung vor dem

Auspacken des Produktes

sorgfältig durch. Alle Änderungen

vorbehalten.

Rechtschreibfehler oder andere

Fehler rechtfertigen keinen

Anspruch bei Schäden. Alle

Maße sollten an einem realen

Gerät überprüft werden.

Außer für interne Verwendung ist

die Überlassung dieser Anleitung

an Dritte, die gesamte oder

auszugsweise Veröffentlichung,

Verwertung oder Mitteilung in

jeglicher Art und Form sind nicht

gestattet.

Table of Contents / Inhalt

English 06

1 Security instructions 07

1.1 Symbols 07

1.2 General security instructions 07

2 General device description 08

2.1 Delivery content 08

2.2 Connectors and interfaces 09

2.3 User interface: LEDs 09

2.4 Identify button: Identication & Reset 10

3 General remarks 11

3.1 Transport 11

3.2 Unpacking 11

3.3 Warranty regulations 12

3.4 Maintenance and Repair 12

3.5 Disposal 12

3.6 Support 13

4 Installation 13

4.1 Installation conditions 13

4.2 Mounting process 14

4.3 Ethernet connection 14

4.4 Input connection 15

4.5 Power supply 15

5 Network conﬁguration 16

5.1 Default network properties 16

5.2 Network conguration with SYMPHOLIGHT 16

5.3 Network conguration with the web interface 17

6 Firmware Update 19

7 Dismounting 19

Table of Contents / Inhalt

8 Product speciﬁcations 20

9 Certiﬁcations 21

Deutsch 22

10 Sicherheitshinweise 23

10.1 Symbole 23

10.2 Hinweise 23

11 Gerätebeschreibung 24

11.1 Lieferumfang 24

11.2 Anschlüsse und Schnittstellen 25

11.3 Benutzeroberäche: LEDs 26

11.4 Identify-Taster: Identikation & Reset 27

12 Allgemeine Hinweise 27

12.1 Transport 27

12.2 Entpacken 28

12.3 Garantiebestimmungen 28

12.4 Reparatur und Wartung 28

12.5 Entsorgung 28

12.6 Technischer Support 29

13 Installation 29

13.1 Installationsbedingungen 30

13.2 Montage 30

13.3 Ethernet-Verbindung 30

13.4 Eingangs-Verbindung 31

13.5 Stromversorgung 31

14 Netzwerk-Konﬁguration 32

14.1 Standardeinstellungen vom Netzwerk 32

14.2 Netzwerkeinstellung über SYMPHOLIGHT 33

14.3 Netzwerkeinstellung über die Webschnittstelle 33

15 Firmware-Update 35

16 Demontage 35

17 Produktdaten 36

Table of Contents / Inhalt

18 Zertiﬁzierung 37

Dimensions / Abmessungen 38

Application examples / Anwendungsbeispiele 39

English

Security instructions

1 Security instructions

Please read the safety instructions, provided in a separate manual, carefully.

Make sure that the environmental, mounting, and installation prerequisites

are met. This manual should be kept at a safe place and in reach of the

installation.

1.1 Symbols

The exclamation mark warns about possible damage of the

device itself or connected devices.

The information symbol gives general hints and informs

about handling and procedures for use of the device.

1.2 General security instructions

Connect cables and data only when the device is powered

down.

The device must be supplied by a separate certied SELV

Class 2 power supply.

The maximum length of each connected cable is 30 m.

If safety instructions are missing, please contact OSRAM to

receive a new copy.

General device description

2 General device description

e:cue SYMPL Nodes are a system of interfaces for e:cue SYMPHOLIGHT

only. They provide various connection types like DMX512, DALI, digital

inputs and outputs etc. SYMPL Nodes always operate in online mode, as a

device interface for SYMPHOLIGHT. All interactions are initiated and

controlled by SYMPHOLIGHT. Connections between servers, Cores and

Nodes are always made with e:net via Ethernet.

The e:cue SYMPL input Node is an eight-channel analog input interface for

use with e:cue’s lighting control solution SYMPHOLIGHT. It provides eight

independent analog 10 V inputs, four inputs also support 20 mA constant

current input, congurable with four slide switches. The e:cue

SYMPL input Node can be powered by an external power supply or via

Power-over-Ethernet. It is easily mounted on standard 35 mm DIN rails, or

with a key hole in the housing base on walls or on any stable vertical

surface. The e:cue SYMPL input Node is a simple, reliable and easy to use

interface solution for e:cue lighting control solutions with SYMPHOLIGHT.

2.1 Delivery content

Delivery content for the e:cue SYMPL input Node (AB444200035):

1. e:cue SYMPL input Node

2. Safety instructions

3. Installation guide (English only)

To operate SYMPL Nodes a SYMPHOLIGHT version 2.0 or

higher is mandatory. Earlier versions do not support the

SYMPL Nodes. SYMPL Nodes are not supported by the

e:cue Lighting Application Suite.

e:cue SYMPL input Node is not hot-pluggable.

General device description

2.2 Connectors and interfaces

View from top

1Common ground

2a Inputs 0 ... 10 V

(pins 1 ... 4, left to right)

2b Inputs 0 ... 10 V or 0/4 ... 20 mA

(pins 5 ... 8, left to right)

3Mode switches inputs 5 ... 8

(left: 0 ... 10 V, right: 0/4 ... 20 mA)

4Input status 1 ... 8 LEDs (left to

right)

5Error LED

6e:net LED (Ethernet, LAN activity)

7Status LED (Device status)

8Identify button

9Power supply

(Vcc+, Vcc– left to right)

10 e:net / Ethernet

2.3 User interface: LEDs

The SYMPL input Node has 11 LEDs. The 11 LEDs show the basic states

of the SYMPL Node.

LEDs

Status On: If constantly on, the device is online. Server

application is in operation.

Blinking: If blinking in one second intervals, the device is

ofine, no connection to a SYMPHOLIGHT server or

Core is available. If blinking more rapidly, the device is in

bootloader mode.

General device description

e:net Off: no link available.

On: link established.

Blinking: e:net trafc.

Error Off: no error detected.

On: If constantly lights in red, an error occurred. This

can be an internal error or malfunction of the device, or

an external error, e.g. a shortcut of interface

connections or alien power supply. Switch the device off

and on. If the error persists, check the wiring or contact

OSRAM Service.

Status +

Error

The Status and Error LED blink simultaneously to

identify the SYMPL Node (enabled “Identify Interface

Mode” in SYMPHOLIGHT).

Input status 1

to 8

Off: Input value is smaller than the Digital Threshold

Low.

On: Input value is bigger than the Digital Threshold

High.

(Change the Digital Thresholds in the properties of the

Node in the Setub Tab of SYMPHOLIGHT).

2.4 Identify button: Identiﬁcation & Reset

The Identify button has four functions: to send an Identify message (A) and

to reset the Node (B).

(A) A short press during operation in online mode sends an Identify

message to the server. This helps to assign the Node in the Layout in

SYMPHOLIGHT.

(B) The Identify button can also be used to reset the device to factory state

or to stay in bootloader mode:

• Keep the Identify button pressed while powering up, Status and

Error light up at rst. Bootloader mode is signaled by a fast blinking
