Matchbox Demo User Manual

Intelligent Proximity Sensing

Rolf Weber | August 2013

Matchbox Demo Manual

Page

1. Demo Kit Contents 03

2. Getting Started 04

3. Modes 05

4. Software Installation 06

5. Graphical User Interface 12

6. PCB 14

1. Demo Kit Contents

Sensor demo

with Micro USB

jack

3 x AAA

batteries

Battery pack with

Micro USB

connector

USB cable

2. Getting Started

Use the battery pack or USB cable to power the demo.

1a. Battery Pack

•Insert AAA batteries in the

battery pack

•Connect the battery pack to the

demo

•Switch on battery pack

2. Operating the demo

1b. USB Cable

•Connect the USB cable to

demo and a computer

•See 4. Software Installation

and 5. Graphical User Interface

Indicator LED

layouts and

respective

hand motions

3. Modes

Proximity sensing

(1”, 4” & 6”)

Place hand over

indicator LED at

respective distance for

on. Remove hand for

off.

Slide

Slide finger across the

two indicator LEDs for

on. Slide finger across

in the opposite

direction for off.

Rotary

Rotate finger counter

clockwise around the

three indicator LEDs to

increase brightness.

Rotate finger clockwise

to reduce brightness.

Touch

Tap indicator LED to

turn on/off. Hold finger

down to increase/

decrease brightness.

Wave

Wave hand left- right-

left once for on. Wave

a second time for off.

Ambient Light

Sensor

Ambient light will

increase brightness.

The reduction of

ambient light will

decrease brightness.

4. Software Installation

Go to: http://ledlight.osram-os.com/matchboxdemo

File name | ORG CODE | Initial

Title/Occasion | MM/DD/YYYY

5. Graphical User Interface

Proximity sensor parameters:

•Active LED indicator

•Display mode:

•shows all events

•shows events above threshold only

5. Graphical User Interface

Ambient light sensor parameters:

•ALS lower threshold

•ALS upper threshold

•ActualALS readings in counts

•Display mode:

•shows all events

•shows events above upper or below

lower threshold only

5. Graphical User Interface

•Counter of measurements

•Counter limit

•Save data:Active / non active

•Display data:Active / non active

•Data saved in shown excel files

•Data in new file or appended

•Display of measured prox and ALS values
