Operating Instructions

UHF2100 40 Channel UHF 2 Way

Citizen Band Radio

Table of contents

Safety Information and Warnings ................................... 4

Getting Started .............................................................. 6

Oricom UHF2100 instructions ...................................... 10

Operation..................................................................... 11

Specications .............................................................. 20

Warranty information (Australia)................................... 22

Customer support ........................................................ 23

Safety Information and Warnings

CAUTION

Damaged Antenna

Do not use any radio that has a damaged

antenna. If a damaged antenna comes in

contact with the skin, a minor burn may result.

Batteries

All batteries can cause property damage and/

or bodily injury such as burns if conductive

material such as jewelry, keys, or beaded

chains touches exposed terminals. The

material may complete an electrical circuit

(short circuit) and become quite hot. Exercise

care in handling any charged battery,

particularly when placing it inside a pocket,

purse, or other container with metal objects.

WARNING

For Vehicles with an Air Bag

Do not place your radio in the area over an

air bag or in the air bag deployment area.

Air bags inﬂate with great force. If a radio is

placed in the air bag deployment area and the

air bag inflates, the radio may be propelled

with great force and cause serious injury to

the occupants of the vehicle.

Potentially Explosive Atmospheres

Turn your radio OFF when in any area with a

potentially explosive atmosphere, unless it is

a type especially qualified for such use (for

example, Factory Mutual Approved). Sparks in

such areas could cause an explosion or fire

resulting in injury or even death.

Safety Information and Warnings

WARNING

Batteries

Do not replace or charge batteries in a

potentially explosive atmosphere. Contact

sparking may occur while installing or

removing batteries and cause an explosion.

Blasting Caps and Areas

To avoid possible interference with blasting

operations, turn your radio OFF near electrical

blasting caps or in a “blasting area” or in

areas posted: “Turn off the two way radio.”

Obey all signs and instructions.

NOTE: Areas with potentially explosive atmospheres are often,

but not always clearly marked. They include fueling areas

such as below deck on boats; fuel or chemical transfer or

storage facilities; areas where the air contains chemicals

or particles, such as grain, dust, or metal powders; and any

other area where you would normally be advised to turn off

your vehicle engine.

Cleaning and Care

To clean your radio, use a soft cloth dampened with water. Do not

use cleaners or solvent, which may cause damage that may not be

covered by guarantee.

Getting Started

Installation

Removing the Belt Clip

Pull the Belt Clip latch forward (away

from the unit)

While pulling the Belt Clip latch, push

up the Belt Clip as shown in Figure1.

Installing the Belt Clip

Slide the Belt clip into the slot as

shown in Figure2.

A “click” indicates the Belt clip is

locked into position.

Installing the Batteries

Figure 3 Figure 4

Caution: Observe the proper battery polarity orientation when installing batteries.

Incorrect positioning can damage both the batteries and the unit.

a. Slide down the Battery Compartment Cover.

b. Install the rechargeable batteries by following the orientation as shown in

Figure 3 (the arrow is showing and pointing upward.)

c. Replace the Battery Compartment Cover. See Figure 4.

Belt Clip latch

Figure 1 Figure 2

Getting Started

Charging the batteries

Insert the small plug on the end of the mains adaptor into the

Power-in connection jack at the back of the desktop charger.

Plug the mains adaptor into a 240V AC, 50Hz main socket with the

switch on the socket set to OFF.

a. Switch ON the main socket.

b. Place the radio in the charge cradle in an upright position

The Charge LED indicators will light up.

It takes about 10 hours to fully charge the batteries if they are

completely run down. New batteries take up to 14 hours to

fully charged.

Important

Read these Safety Warnings before you charge the

batteries.

When placing the radio in the charger, use only the power

supplies listed in the user instructions supplied with the unit.

Don’t try to recharge non-rechargeable batteries.

Make sure the battery compartment cover is securely

locked in place when you are charging the batteries.

Dispose of used batteries safely and in a way that will not

harm the environment- never try to burn them or put them

anywhere, they could get burnt or punctured.

Don’t leave dead batteries in your radio.

They might leak if you do.

Switched Mains Power Outlet

Getting Started

Battery meter

The battery meter is located in the left corner of the LCD screen.

It appears like a battery with three bars inside. These indicate

the amount of power available. When the battery level reaches it

minimum level, the unit will emit two beep tones and automatically

it will power off.

Your UHF2100 can detect the battery charge in 4 levels;

Battery charge at high level.

Battery charge at medium level.

Battery charge at low level. At this level, the radio will emit

a “beep” sound for every 10 seconds in standby mode.

TIP: At this stage, you need to recharge the unit at

once, otherwise the battery will run down totally.

Battery charge at very low level. When the battery level

reaches its minimum level, the unit will emit two beep tones

and automatically turn off the power.

Important: You need to charge the unit for 10-14 hours.

CAUTION: Risk of explosion if battery is replaced by

an incorrect type. Dispose of used batteries

according to the instructions.

Battery life

Your radio has a built in power saver to make the batteries last

longer. But when you are not using the units, turn them OFF to

conserve battery power.

Getting Started

Operation

Transmitting range

The talk range depends on the environment and terrain. It will reach

(up to about 10km) in wide open spaces, without obstructions

such as hills or buildings. Don’t try to use two radio units which

are less than 1.5m (5feet) apart. Otherwise, you may experience

interference.

Important safety warning:

To reduce radio frequency exposure when you are using your

units, hold the unit at least 5cm (2 inches) away from your face.

Never use your radio outdoors during a thunderstorm.

Don’t use the radio in the rain.

If your radio gets wet, turn it off and remove the battery. Dry the

battery compartment and leave the cover off for a few hours.

Don’t use the unit until it is completely dry.

Keep the radio out of reach of babies and young children.

The operation of this radio in Australia and New Zealand is

subject to conditions in the following licenses.

In Australia the ACMA Radio communications (Citizen Band Radio

Stations)

In New Zealand the General User Radio License for Citizen Band

Radio.

Oricom UHF2100 instructions

Antenna

Speaker MIC (Microphone)

LCD Screen

- Displays the current channel

selection and other radio

symbols.

PTT (PUSH to TALK)

button

- P r e s s a n d h o l d t o

transmit.

UP/DOWN Buttons

- Press to change

channels, volume, and

to select settings during

programming.

MENU Button

- Press to change

To switch between

Modes

CALL button

- Press to send Ringing

tone to other radio units.

PWR/VOL Switch

- Rotate clockwise/

counter clockwise to

turn the unit ON or OFF.

Ear/Mic/Charge

jack

LCD Screen

Channel Number. Changes from 1 to 40 as

selected by the user.

CTCSS Code. Changes from 1 to 38 as selected by the user.

Displays the Battery change level. When the bars are reduced, the

battery needs to recharge.

Displayed when transmitting a signal.

Displayed when receiving a signal.

Displayed when the Dual Watch function is turned ON.

Displayed when the Digital Code System is turned On.

Displayed when the VOX feature is enabled.

Displayed when the radio is doing scan.

RPT

Displayed when the repeater function is activated.

Displayed when the call signal is ON.

Displayed when the vibrator function is activated.

Displayed when the Key Lock feature is activated.
