User Guide
PIX2000
Keep this user guide for future reference.
PIX2000 User Guide.indd 3PIX2000 User Guide.indd 3 2009-6-30 17:33:292009-6-30 17:33:29

PIX2000 User Guide.indd 章节1:2PIX2000 User Guide.indd 章节1:2 2009-6-30 17:33:302009-6-30 17:33:30

1
Table of contents
Safety Information and Warnings ...........................................2
Getting Started ......................................................................5
Handset and Base Layouts.....................................................7
Photo frame and remote control Layouts................................9
Operation and setup of the cordless handset .......................13
Redial Function....................................................................17
Caller ID Service ..................................................................19
Phone Book .........................................................................22
Menu Operation...................................................................24
Operation and setup of the picture frame.............................32
Operation during an incoming call........................................53
Troubleshooting ...................................................................59
Warranty Information ...........................................................62
PIX2000 User Guide.indd 章节2:1PIX2000 User Guide.indd 章节2:1 2009-6-30 17:33:302009-6-30 17:33:30

2
Safety Information and Warnings
Safety Information and Warnings
IMPORTANT
• Avoid exposure of this telephone to moisture or liquid.
• To prevent electric shock, do not open the handset or base cabinet.
• Avoid metallic contact (e.g. metal clips, keys) between the battery
contacts and charging conductors.
• There is a slight chance that the telephone could be damaged by an
electrical storm. It is recommended that users unplug the phone from
the mains supply and telephone socket during a storm.
• Do not use the handset in an explosive hazard area such as where
there is gas leaking.
• Follow the local regulations regarding the disposal of your packing
materials, exhausted batteries and used phone. Wherever possible,
recycle those materials.
• We advise that this phone should not be used near intensive care
medical equipment or by persons with pacemakers.
• Clean with a dry, soft, lint-free cloth. Never use cleaning agents,
particularly aggressive solvents.
• Because the phone works by sending radio signals between base station
and handset, wearers of hearing aids may experience interference in the
form of a humming noise.
• Your phone can interfere with electrical equipment such as answering
machines, TV and radio sets, clock radios and computers if placed too
close. It is recommended that you position the base unit at least one
metre from such appliances.
• This telephone complies with applicable safety requirements for
exposure to radio waves (EMR). The mean power of this telephone
does not exceed 20mW limit at which point testing is required.
• The earpiece of the handset may attract small metal objects such as
staples and pins. Care should be taken when placing the handset near
these items.
PIX2000 User Guide.indd 章节2:2PIX2000 User Guide.indd 章节2:2 2009-6-30 17:33:302009-6-30 17:33:30

3
Safety Information and Warnings
• This telephone is not designed for making emergency telephone calls
when the mains power fails.
• Always have a corded phone available to be able to make and receive
calls to emergency services if the mains power fails.
• Do not use your telephone during an electrical storm thunderstorm as
it is possible to get an electric shock.
• Refer to information contained in White pages directory.
• This phone is designed for connection to a PSTN telephone line or an
analogue extension port of a PBX system. If you connect this device to
a digital extension of a PBX, damage may result to the PBX.
CAUTION
Only use the AC/DC adaptors provided with the photo
frame. Details of AC/DC Adaptor listed below:
For Photo Frame adaptor
Model no. KSS12_060_1500S
Input 100-240V~, 50/60Hz, 0.35A
Output: 6V 1500mA
For Base adaptor
Model No.: KG35-6-250D
Manufacturer: Kings
Input: 240V AC / 50 Hz
Output: 6 V DC, 250mA
PIX2000 User Guide.indd 章节2:3PIX2000 User Guide.indd 章节2:3 2009-6-30 17:33:302009-6-30 17:33:30

4
Safety Information and Warnings
WARNING
DO NOT USE STANDARD/ALKALINE BATTERIES IN THIS
PRODUCT, AS THERE IS A RISK OF EXPLOSION AND/OR
INJURY. USE ONLY NI-MH RECHARGEABLE BATTERIES
AS SPECIFIED IN THIS USER GUIDE. CONTACT ORICOM
FOR REPLACEMENT BATTERIES.
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE.
Never use non-rechargeable batteries. Use
recommended type supplied with this product.
• Never use alkaline or lithium batteries.
• Do not dispose of the batteries in a re, as they can
explode.
• Do not open or mutilate the battery. Released
electrolyte is corrosive and can cause damage to the
eyes or skin. It can be toxic if swallowed.
• Avoid contact with metal objects when handling the
battery. These objects could short out the batteries or
cause the conductor to overheat resulting in burns.
• Do not attempt to recharge the battery cell by heating
it. Sudden release of battery electrolyte can cause
burns or irritation to the eyes or skin.
• Observe the proper polarity, or direction, of any
battery. Reverse insertion of the battery cell can result
in leakage or explosion.
• Remove the batteries if you do not plan to use the
product for several months at a time.
• Follow the local regulations regarding the disposal of
your packing materials, exhausted batteries and used
phone. Wherever possible, recycle those materials.
PIX2000 User Guide.indd 章节2:4PIX2000 User Guide.indd 章节2:4 2009-6-30 17:33:302009-6-30 17:33:30

5
Getting Started
Getting Started
Pack Contents
The pack should contain the following items:
Cordless Phone Base Unit & AC adaptor
Cordless Phone Handset
Phone Line cord
Digital Picture Frame & AC adaptor
Handset Rechargeable Batteries
If any of these items are missing, please contact the retailer where you
purchased the product from.
Adding additional handsets
The PIX2000 is GAP compatible. Additional GAP compatible handsets
may be registered to the PIX2000 see registration.
Please note GAP compatibility only ensures the ability to answer and
make calls, not all PIX2000 features may be available to additional
handsets.
Important:
DO YOU HAVE BROADBAND/ADSL?
If you do, you must connect an in line lter (not supplied) between
the telephone socket and your PIX2000 base to ensure that your
broadband and PIX2000 will work properly. If you do not install
the lter you will experience interference on the PIX2000 and your
Broadband may suffer dropouts. Please refer to the user guide of the
in line lter for installation.
PIX2000 User Guide.indd 章节2:5PIX2000 User Guide.indd 章节2:5 2009-6-30 17:33:302009-6-30 17:33:30

6
Getting Started
Installation of the Telephone Base and handset
1. Connect the mains adaptor (supplied) to the socket on the back of the
base unit and to the wall mains supply.
2. Connect the telephone cord to the phone socket on the back of the
base unit and into the wall phone socket.
3. Insert 2 rechargeable Ni-MH AAA batteries (included), observing the
correct polarity, into the battery compartment on the handset. Slide the
battery door rmly into place.
4. Place the handset on the charging cradle and charge the batteries for
a full 14 hours before using it for the rst time.
Note:
It may take some time for the cordless handset to power up, and it
may get warm during initial charge. This is normal.
Tip!
It is good practice to put the cordless handset on the charging cradle
when it is not in use to ensure that the handset is always fully charged.
Installation of the Photo Frame
1. Insert the supplied power adaptor into the socket on the bottom of the
Photo Frame.
PIX2000 User Guide.indd 章节2:6PIX2000 User Guide.indd 章节2:6 2009-6-30 17:33:302009-6-30 17:33:30

7
Handset and Base Layouts
Handset and Base Layouts
Redial / Up / Increase volume key
Caller ID / Down / Decrease volume key
Menu / OK key
Mute / Cancel / Ring off key
Recall key
Phone book key
Talk on / Off key
Asterisk / Intercom key
Hash / Keypad lock key
Speaker Key
Paging key
PIX2000 User Guide.indd 章节2:7PIX2000 User Guide.indd 章节2:7 2009-6-30 17:33:312009-6-30 17:33:31

8
Handset and Base Layouts
LCD Display
Icon Description
Aerial icon
Phone icon
Key lock icon
No ring icon
Microphone mute icon
Intercom call indicator
Battery level indicator
Phonebook icon
Menu icon
Voice mail waiting indicator (VMWI icon)
Caller ID icon
Alarm icon
Speaker icon
PIX2000 User Guide.indd 章节2:8PIX2000 User Guide.indd 章节2:8 2009-6-30 17:33:312009-6-30 17:33:31
