Oregon Scientific RA313P Manual de usuario

PROJECTION CLOCK

Model : RA313P

User Manual

使用指南

PROJECTION CLOCK

MODEL : RA313P

INSTRUCTION MANUAL

INTRODUCTION

Congratulations on your purchase of the Projection Clock

(RA313P).

To facilitate night time reading, the unit comes with

projector that can cast large, clear clock-time ﬁgures onto

ﬂat surfaces in dark. It also has a back light for easy reading

of the display.

313p en.indd 1 2006.9.19 4:32:39 PM

MAIN FEATURES

A Two-line display

Displays the local time and alarm time in two selectable

modes

B [ ] Alarm icon

Appear when alarm is activated

C [ ] button

Enables or disables the snooze function when an alarm

goes off or activates the back light and projector for 8

seconds

D Up [ ] and Down [ ] buttons

Increases or decreases the value of a setting

E [ ] button

Sets the time for the alarm

F [ ON / OFF ] button

Enables or disables the alarm

G [ MODE ] button

Toggles the display modes and conﬁrms entry while

setting the values for display

H Projector

For projecting the current time on the wall or ceiling

I [ PROJECTION ON ] switch

Used with the power adapter to enable extended use of

the projector

J Battery compartment

Accommodates two (2) UM-3 or “AA” size batteries for

operation

K [ RESET ] button

Resets the unit by returning all settings to factory set

default values

Figure 1

313p en.indd 2 2006.9.19 4:32:42 PM

BATTERY INSTALLATION

The unit uses two (2) UM-3 or “AA” size 1.5V batteries.

To insert batteries:

1. Slide the battery door in the direction of the arrow.

2. Insert the batteries strictly according to the polarities

shown therein.

3. Replace the battery compartment door.

Figure 2

Note: Under normal circumstances, the batteries are good for

1 year. However, the battery life can be reduced vastly by

frequent use of the back light, projector or snooze function.

If not disposed of properly batteries can be harmful.

Protect the environment by taking exhausted batteries

to authorized disposal stations.

HOW TO USE THE PROJECTOR

Press [ ], the wall projection will be

activated for approximately 8 seconds.

HOW TO USE THE PROJECTOR POWER ADAPTER

Your unit comes with a power adapter so you can use the

projector

for extended period of time.

To install the adapter:

1. Insert adapter into jack on the bottom of the unit.

2. Plug the adapter into the adapter socket.

Figure 3

Note:The display backlight and projection function work

simultaneously. When [ ] is pressed both the

backlight and projection function will activate.

Note: Making sure the voltage is correct, plug the other

end of the power adapter into a free wall socket.

313p en.indd 3 2006.9.19 4:32:43 PM

Once the power adapter is in place, you can select to turn on

the projector for longer time, such as throughout the night, by

sliding down the [ PROJECTION ON ] switch on the side of

the unit. To turn off the projector, slide the switch back.

DISPLAY MODES

The unit supports two display modes in the sequence of:

Note that this switch can only be used with the power

adapter installed. For momentary projection, use the

[ ].

HOW TO SET THE CLOCK

1. To set the clock, hold for three seconds.

The display will return to MODE 1, with the hour digits

blinking.

2. Use[ ] or [ ] to select the hour. Keep pressing the

button to increase or decrease the value rapidly.

3. Press to conﬁrm. The minute digits will blink.

Repeat the same procedure to set the minutes,

then the day-of-month,month, display language and day-of-

week.

taSya

nerF

-f

If there is an item you do not wish to change, simply press

to bypass the item.

Press to exit. The display will return to the mode

last chosen.

Note that the time and date are displayed in 24-hour

clock and DAY-MONTH format, respectively. For display

language,you can choose among English, French, German

and Italianóin that order. Day-of-week is the usual sequence

of Monday through Sunday.

siD

[ e

i ya

lggo

]

evo

dno

ht f

.desse

p si

oH k

W-

tno

noM

yaD

noc

,ru

----

-----

---

----

---

------

-------

313p en.indd 4 2006.9.19 4:32:45 PM

[ ]

HOW TO SET THE ALARMS

To set an alarm:

1. Press once to enter alarm mode. The

last selected

displayed. If you

have never set

as 0:00.

2. Press for three seconds. The hour

digits will blink.

3. Enter the hour using [ ] and [ ].

4. Press . The minute digits will blink.

5. Enter the minutes using [ ] and [ ].

6. Press to exit. The alarm-on icon will

be displayed

arm is activated.

You can activate / disactivate the alarm by pressing the

[ ON / OFF ] button.

When the alarm sounds, the display will light up for 8-

seconds with the alarm icon ﬂashing.

The four-step crescendo function allows the alarm to start

off gently and step up its intensity for four times. Without

interruption, the alarm will go off for a total of two minutes.

To stop the alarm, you can use either of the three buttons:

[ ] , or [ ON / OFF ] .

• Pressing [ ] during an alarm will invoke the

snooze function, arm and let it sound

again after eight

• Pressing or [ ON / OFF ] will stop

the alarm,

it will go off at the set time the following day.

• If [ ON / OFF ] again, the alarm will be deactivated

all together.

HOW TO RESET THE UNIT

There is a RESET function near to the battery compartment.

It allows you to return all settings to its factory values.

To use the RESET:

1. Locate the RESET beside the door tab.

2. Use a blunt stylus to press the [ RESET ] once.

PRECAUTIONS

This unit is engineered to give you years of satisfactory

service if you handle it carefully. Here are a few precautions:

1. Do not immerse the unit in water. If you spill liquid over

it, dry it immediately with a soft, lint-free cloth.

Do not clean the unit with abrasive or corrosive materials.

They may scratch the plastic parts and corrode the

electronic circuit.

3. Do not subject the unit to excessive force, shock, dust,

temperature or humidity, which may result in malfunction,

shorter electronic life span,damaged battery and distorted

parts.

4. Do not tamper with the unitís internal components. Doing

so will invalidate the warranty on the unit and may cause

unnecessary damage.The unit contains no user-serviceable

parts.

5. Only use fresh batteries as speciﬁed in the userís instructions.

Do not mix new and old batteries as the old ones may leak.

6. Always read the userís instructions thoroughly before

operating the unit.

313p en.indd 5 2006.9.26 3:00:10 PM

time of the alarm will be

the alarm before, the time will be displayed

indicating the al

which will stop the al

minutes.

PRODUCT SPECIFICATIONS

Operating Temperature : -5°C to 50°C

Calendar :

Day of week in English / German / French

/ Italian Current date / month format

Clock Time : 24-hour format

Alarm Duration : 2-minute crescendo

Snooze : 8 minutes

Accuracy : +/- 0.5 second/day

Battery Type

: Two (2) UM-3 or “AA” size 1.5V batteries

Unit Dimension : 107mm x 115mm x 64mm

( H x W x D )

Unit Weight : 175 g (without battery)

CAUTION

— The content of this manual is subject to change without

further notice.

— Due to printing limitation, the displays shown in this

manual may differ from the actual display.

— The contents of this manual may not be reproduced

without the permission of the manufacturer.

ABOUT OREGON SCIENTIFIC:

Visit our website (www.oregonscientiﬁc.com) to learn more

about Oregon Scientiﬁc products such as digital cameras; MP3

players; children’s electronic learning products and games;

projection clocks; health and ﬁtness gear; weather stations;

and digital and conference phones. The website also includes

contact information for our customer care department in case

you need to reach us, as well as frequently asked questions

and customer downloads.

We hope you will ﬁnd all the information you need on our

website, however if you’re in the US and would like to contact

the Oregon Scientiﬁc Customer Care department directly,

please visit:

www2.oregonscientiﬁc.com/service/default.asp

Call 1-800-853-8883.

For international enquiries, please visit:

www2.oregonscientiﬁc.com/about/international.asp

313p en.indd 6 2006.9.26 3:00:11 PM

()
