POLERMO Projection Clock
with Motion Alert
Model: RMR939PA / MSR939A
USER MANUAL
RMR939PA English Cover R5 9/21/04, 2:40 PM1
EN
1
CONTENTS
Introduction .............................................................. 2
Product Overview .................................................... 3
Front View .............................................................. 3
Back View .............................................................. 5
LCD Display ........................................................... 6
Remote Motion ensor (M R939A) - Front View .. 8
Remote Motion ensor (M R939A) - Back View .. 9
Safety and Care ...................................................... 10
afety Precautions ............................................... 10
Caring for this Product ......................................... 10
Getting Started ....................................................... 10
Package Contents ............................................... 10
Batteries ............................................................... 11
AC Adaptor .......................................................... 12
A out Atomic Clock Reception ............................ 12
Turning the Atomic Clock ignal ON / OFF ......... 13
Clock / Calendar ..................................................... 13
Clock / Calendar Display ..................................... 13
etting the Clock / Calendar ................................ 14
Backlight ................................................................. 14
Temperature ............................................................ 14
Alarm ....................................................................... 15
Alarm Display ...................................................... 15
etting the Alarm(s) ............................................. 15
Activating / Deactivating the Alarm(s) .................. 15
Alarm ound ........................................................ 15
nooze / Turning the Alarm OFF ......................... 15
Motion Alarm .......................................................... 16
Motion Alarm etting Display ............................... 16
etting the Motion Alarm ...................................... 16
Turning the Motion Alarm OFF ............................ 17
Sleep Timer ............................................................. 17
Projection Unit ....................................................... 18
Motion Sensor (MSR939A) .................................... 18
etup ensor ....................................................... 18
Wake-Up Vi ration Alarm - VR101A (Optional) .... 19
Resetting the Clock ............................................... 19
Warnings ................................................................. 20
Trou leshooting ..................................................... 20
Technical Specifications ....................................... 21
POLERMO Projection Clock
with Motion Alert
Model: RMR939PA / MSR939A
USER MANUAL
RMR939PA English R5 9/21/04, 2:40 PM1
EN
2
INTRODUCTION
Thank you for selecting the Oregon cientificTM
POLERMO Projection Clock with Motion Alert. This
device is designed to give you many years of reliable
service, including the following conveniences:
• U Atomic Calendar Clock
• Optional Wireless Vibration Alarm with 8-Minute
nooze Function (Wake-Up Vibrating Alarm
VR101A can be purchased separately)
• leep Function with 6 oothing ounds
• 5 Alarm Melodies with 2 Volume Levels
• 2-Minute Dual Alarm with 8-Minute nooze Function
• Time / Alarm tatus Projection Unit
• ecurity Alarm / Motion ensor Unit
• Indoor Temperature Display
• Day of the Week in 1 of 5 Languages
• Time Zone Hour Offset Function
• Backlight for Clock
Keep this manual handy as you use your new product.
It contains practical step-by-step instructions, as well
as technical specifications and warnings you should
know.
Notices .................................................................... 23
tatement of Responsibility ................................. 23
A out Oregon Scientific ........................................ 23
FCC Statement ....................................................... 24
Declaration of Conformity .................................... 24
RMR939PA English R5 9/21/04, 2:40 PM2
EN
3
1
2
3
5
4
8
7
6
1. SOUND / SLEEP utton
• Press to turn the soothing sound ON.
• Press to wrap around the sleep timer setting as
follows: 0 120 90 60 30 15
0 minutes.
• Press and hold for 2 seconds to choose 1 of
6 soothing sounds.
2. SNOOZE / LIGHT utton
• Press to activate the 8-minute snooze function.
• Press and hold for 2 seconds to turn snooze OFF
and reset the alarm for the next day.
• Press to activate the backlight and projection for
5 seconds.
3. LCD display
4. CLOCK ALARM utton
• Press to toggle between alarm 1 and alarm 2 -
ON / OFF.
• Press and hold for 2 seconds to enter the Alarm
Time etting Mode.
5. MOTION ALARM utton
• Press to enter the Motion Alarm Mode; press
again to toggle between motion alarm ON / OFF.
PRODUCT OVERVIEW
FRONT VIEW
RMR939PA English R5 9/21/04, 2:40 PM3
EN
4
• Press and hold for 2 seconds to enter:
- Motion ensor Code.
- Motion Alarm etting Mode for motion alarm
period and alarm type.
6. Projector
Projects time and alarm status.
7. CLOCK utton
• Press to toggle between the following display
modes:
- Clock with seconds and calendar.
- Clock with weekday and calendar.
- Clock with time zone hour offset and calendar.
• Press and hold for 2 seconds to enter the
Clock etting Mode - U time zone hour offset,
12- / 24-hour format, hour, minute, year, MM / DD
or DD / MM format, month, day and day of the
week language.
8. UP / DOWN utton
• Press to increase or decrease a setting.
• Press and hold for 2 seconds to activate or
deactivate atomic clock.
• Press to increase or decrease the soothing sound
volume.
RMR939PA English R5 9/21/04, 2:40 PM4
EN
5
1
2
3
4
5
6
7
8
1. Projector FOCUS kno
• Twist to focus the projected image.
2. Projector IMAGE ROTATION kno
• Twist to get the best viewing angle of the projected
image.
3. PROJECTION ON switch
• lide to ON for continuous image projection when
the AC power is connected.
4. Projector 180° ROTATION utton
• Press to rotate the image upside down.
5. 6V AC / DC Power Socket
6. Battery Compartment (cover on)
• Uses 4 x UM-3 / AA 1.5V batteries.
7. RESET hole
• Insert a thin blunt instrument to return all values
to the default settings.
8. °C / °F switch
• Press to select between °C / °F display format.
BACK VIEW
RMR939PA English R5 9/21/04, 2:40 PM5
EN
6
LCD DISPLAY
1. SOUND
• Appears when the sleep function is activated.
2. Battery Low icon
• Appears when the clock batteries are low or, no
batteries are installed and only the AC adaptor is
connected.
3. Time
• HH / MM, 12- / 24-Hour, AM / PM.
4. ZONE
• Appears when you are in the Time and Zone Hour
Offset display.
5. Channel 1 / 2
• Ch.1 or Ch.2 will appear when the related motion
sensor is activated.
6. Motion Alarm ON icon
7. Calendar
• DD / MM / YY or MM / DD / YY.
8. Temperature
•°C / °F.
9. Atomic Clock Signal Reception icon
• hows the strength of the reception signal.
2
3
5
6
7
8
9
11
10
12
13
14
15
16
17
18
19
4
1
RMR939PA English R5 9/21/04, 2:40 PM6
EN
7
10. MIN
• Appears when the sleep function is activated.
11. Time Zone Hour Offset / Day of the Week
• Offsets the atomic clock time setting when you
are in a different time zone (+ / -23 hours).
• Name of day available in 1 of 5 languages.
12. START
• tart time for the motion sensor to be activated.
13. Alarm 1
• Indicator to show this is alarm 1.
14. Alarm 1 / 2 Time
• hows alarm times / AM or PM.
15. Melody Alarm icon
• hows when the clock alarm is set.
16. Vi ration Alarm icon (Wake-Up Vibration Alarm -
optional item)
• Appears on the display when the vibrating alarm
has been set.
17. Alarm 2
• Indicator to show this is alarm 2.
18. STOP
• top time for the motion sensor.
19. Motion Alarm Settings icon
RMR939PA English R5 9/21/04, 2:40 PM7
EN
8
REMOTE MOTION SENSOR (MSR939A) - FRONT VIEW
1. Rotary Motion Sensor
• Detects motion and activates both alarms on the
remote motion sensor and main clock units in
accordance with the settings used.
• Twist the knob to direct the sensor to the position
you want.
2. ALARM SOUND ON / OFF switch
• lide switch to ON - the sensor will sound the
alarm if it detects movement.
• lide switch to OFF - the alarm sound function
will be turned off.
3. POWER ON / OFF
• lide to turn the motion sensor ON or OFF.
4. 4.5V Adaptor Socket (adaptor not included)
5. Motion Alarm Speaker
6. LED Indicator
1
2
3
5
6
4
RMR939PA English R5 9/21/04, 2:40 PM8
EN
9
REMOTE MOTION SENSOR (MSR939A) - BACK VIEW
1. Wall Mount
2. Battery Compartment (cover on)
• Uses 3 x UM-3 / AA 1.5V batteries.
3. CHANNEL 1 / 2
• lide to select either Channel 1 or Channel 2.
4. CODE switch
• lide to change the Code.
5. RESET hole
• Insert a thin blunt instrument to return all values
to the default settings.
1
2
3
4
5
RMR939PA English R5 9/21/04, 2:40 PM9
