Mini electric oven with grill
EC-322
Instruction manual EN
EC-322
Dear Customer
Thank you for purchasing our product. In order to use it safely and effi ciently, please read
these instructions carefully.
2EN
The intended use of the device
The device is designed exclusively for the cooking of food - baking, grilling
and cooking, to the extent that it is determined by the technical and
operating parameters and functions, the safety and user instructions and
the external infl uences of the operating environment.
ORAVA electrical appliances are manufactured according to the state of
the art and recognized safety-technical rules. Nevertheless, the use or use
contrary to designation may result in the risk of injury or endanger the life of
the user or third person, damage to the device and other material values.
1. GENERAL SAFETY INSTRUCTIONS AND WARNINGS
• This document contains important safety instructions and warnings for
safe, correct and economical operation of the electrical equipment. Its
compliance helps the user avoid risks, increase reliability and product life.
• In this document, the generic term product is used in text parts such as:
electrical equipment - any device used for the production, conversion,
transmission, distribution or use of electricity.
• From the point of view of the purpose of using electricity, the concept of
electrical equipment in the strict sense of the word will include the following
categories:
- household electric appliances,
- information and communication equipment,
- consumer electronics,
- lighting equipment,
- electrical and electronic tools,
- toys and equipment for sporting and recreational
1.1 General safety instructions
• Before commissioning the unit, we recommend that you carefully read
the operating instructions and operate the equipment in accordance with
the instructions!
• The safety instructions and warnings in this manual do not cover all the
possible conditions and situations that may arise when using the device.
The user must understand that a factor that can not be incorporated
into any of the products is responsibility and caution. These factors must
therefore be ensured by users / users who use and operate this device.
• Failure to follow the safety instructions and warnings is forbidden by the
manufacturer for any damage to health or property!
• Make sure that the appliance is complete and shows no signs of damage
before using the appliance for the fi rst time. If the product is defective or if it
has any visible damage, do not use the product.
• Keep the operating instructions as close to the device as possible
throughout its service life. Always keep the operating instructions together
with the appliance for future use and use by new users.
• Use the appliance only for the purpose for which it is intended and in the
manner specifi ed by the manufacturer.
3EN
• The appliance is intended for home and similar indoor use, with no special
focus.
• It is not a professional device for commercial use.
• Do not change the technical parameters and features of the device by
unauthorized modifi cation or modifi cation of any part of the device.
• The manufacturer is not responsible for damages caused during
transportation, misuse, damage or destruction of the equipment due to
adverse weather conditions.
1.2 Safety of the operating environment
• Do not use the device in an industrial environment or outside environment.
• Always keep the operating environment clean and well lit.
• Do not place the device on an unstable surface. Overriding or dropping the
device may result in personal injury or damage to the device.
• Do not expose the unit to direct sunlight or excessive heat sources.
• Do not use an electric appliance in areas with fl ammable liquids, gases or
dust. The appliance may be the source of scaling, which can result in the
ignition of dust or vapors.
Features of the operating environment
1. Ambient temperature: +5 ÷ +40 ° C
2. Humidity: 5 ÷ 85%
3. Altitude: ≤ 2 000 m
4. Occurrence of water: intermittent condensation of water or occurrence of
water vapor
5. Occurrence of foreign bodies: amount and type of dust are not signifi cant
Protection class: IP20
• Other characteristics of the operating environment (mechanical stress
- shocks and vibrations, occurrence of plant, animals, weather effects)
are negligible in terms of effect on the correct and safe use of electrical
equipment.
1.3 Electrical safety
• Before connecting the appliance to the power supply for the fi rst time, make
sure that the voltage on the appliance label corresponds to that of the
household electrical outlet.
• The electrical appliance is designed for mains supply 230 V ~.
The electrical safety of the appliance is guaranteed only if it is properly
connected to the electricity grid.
• Only use a power cord with a plug (mains lead) that came with the device
and compatible with a wall outlet. Using another cable may result in fi re or
electric shock.
• Always connect an electrical appliance to an easily accessible power outlet.
In the event of an operating fault, the appliance must be switched off as
soon as possible and disconnected from mains supply.
• Do not pull the power cord / power cord by pulling on the cord / cord.
Disconnect the power cord by pulling the plug behind the power cord /
power cord plug.
4EN
• If you use an extension cord, check that the total rated (ampere) power of
all devices connected to the extension cord does not exceed the maximum
current rating of the extension cable.
• If you need to use an extension cord or power supply block, make sure that
the extension cord or power pack is plugged into a power outlet, and not
to another extension cord or power supply. Extension power cord or power
supply block must be designed for grounded plugs and plugged into a
grounded outlet.
• The power plug of the appliance must be compatible with the mains socket.
Never use any adapters or modify the socket in any other way. Do not use
inappropriate or damaged soclets.
• To avoid electrical shock, plug the power cables into properly grounded
electrical outlets. If the device is equipped with a 3-pin power supply cord,
do not use adapters that do not have a grounding element or remove the
grounding element from the plug or adapter.
• Do not bend, crush or otherwise expose the power cord / power cord of the
appliance to mechanical stress or external heat sources. Damage to the
power cord may result in electric shock.
• If the power cord is damaged, disconnect the appliance from the mains and
do not use it again. If the power cord / power cord is damaged, it must be
replaced by the manufacturer, its service department, or a qualifi ed person
to avoid the risk of electric shock.
• Regularly check and maintain the electrical appliance as well as the
power cable. Disconnect the power plug regularly and clean it if necessary.
Pollution by dust or other substances may cause disruption of the insulating
state and consequently fi re.
• Do not expose the appliance to water or moisture. The ingress of water into
the appliance increases the risk of electric shock. If the power cord is wet
or the appliance gets water, disconnect it immediately from the mains. If the
appliance is plugged into a mains socket and if possible, turn off the power
supply before attempting to disconnect the power supply. If you are pulling
wet wires from a live power source, be very careful.
• If the electrical equipment is installed (connecting) the protective covers are
dismantled, the electrical parts must not be accessible to the user when the
installation is fi nished.
1.4 Safety of persons
• This appliance is intended for use by persons without an electrotechnical
qualifi cation (layperson) according to the instructions specifi ed by the
manufacturer.
• Device operation includes activities such as switching on and off, user
manipulation and setting of operating parameters, visual or auditory
inspection of the equipment, and user cleaning and maintenance.
5EN
• This appliance can be used by children 8 years of age and older and
persons with reduced physical, sensory or mental abilities or lack of
experience and knowledge only when under the supervision or guidance of
the responsible person have been instructed to use the appliance in a safe
way and understand the potential hazards .
• Cleaning and user maintenance can be carried out by children 8 years of
age and older only under the supervision of the responsible person.
• Children may not play with the appliance.
• Always keep the appliance out of reach of children during use and
operation. Be sure to download the appliance even for a freely accessible
power cord.
• Always be careful when operating the electric appliance. Do not use an
electric appliance if you are overly tired, under the infl uence of medication
or narcotic drugs that reduce attention and focus. Inattention during
operation may result in serious injury.
1.5 Cleaning, maintenance and repairs
• Observe the normal user cleaning and maintenance of the appliance in
the recommended way. Do not use solvents or harsh cleaners for cleaning.
Pollution and visible stains from fi nger contact, respectively. The hands
can be cleaned using detergent detergents specially designed to clean
household appliances.
• If you do not use the appliance, clean it or disconnect the appliance from
the power supply when the appliance is faulty.
• Do not disassemble the appliance. The appliance works with a dangerous
voltage. For this reason, always switch off the appliance and disconnect
it from the power supply. In the event of a fault, please have the repair
serviced by an authorized service center.
• Only guarantee qualifi ed and qualifi ed personnel to repair and repair the
electrical appliance.
(*) Appropriate qualifi ed professional: the sales department of the manufacturer or importer or the
person qualifi ed and authorized to carry out this type of activity with the ability to avoid all risks.
6EN
2. SPECIAL SAFETY INSTRUCTIONS.
READ CAREFULLY
• Electrical equipment is designed and manufactured in such a way as
to allow for safe operation and use by persons without a professional
qualifi cation. Despite all the measures that have been
to the manufacturer for safe use, handling and use carries with it
certain residual risks and the associated potential hazards.
• To warn of possible hazards, the following symbols and their
meanings have been used on the device and in the accompanying
documentation:
This symbol alerts users that the device is operating a
dangerous electrical voltage. Do not remove protective covers
on the device.
Failure to observe the safety instructions during use and
operation of the device may result in:
Danger of electric shock! Danger of serious injury or life
threatening!
This symbol alerts users that the following precautions can
be avoided if the following precautions are observed when
operating and operating the device:
Danger of serious injury or life threatening! Danger of damage
to equipment or other damage to property!
This symbol alerts users that the following precautions can
be avoided if the following precautions are observed when
operating the device:
Danger of burning from hot surfaces!
Transport / Carriage
• For shipping and use, of the transport cart, be careful when moving, to
avoid overturning the device.
• Do not transport / transmit the device until the space has been
thoroughly inspected and routes that must be unobstructed.
• Never carry the device while in operation.
Do not carry the appliance while it is connected to the power outlet.
7EN
WARNING!
• Some surfaces are hot during operation. Do not touch hot surfaces!
• Never transfer the appliance until it has cooled down to ambient
temperature.
• Transfer the device fi rmly by both hands to the bottom edge of the
base or fi xed parts of the body.
• Make sure that your hands and equipment are not damp or slippery
when carrying.
• For increased safety (in terms of size and weight), transfer the device
using two capable and physically fi t persons.
There is a risk of serious injury or life threatening injury!
There is a risk of damage to the device!
Unpacking / Packaging
• Unpack and remove all parts and accessories of packaging materials
and labels before putting the device into operation. Keep all packaging
materials in a safe place or keep them out of the reach of children and
inappropriate persons.
There is a risk of serious injury!
Risk of suffocation!
Check / Startup
• Clean the machine before commissioning as described in the „Startup“
section. „Cleaning“.
• Never clean the appliance (body with electrical parts and control
panel) and the power cord with the plug - under running water, which
could cause the liquid to fl ow into the device.
• Clean these parts with a slightly moistened cloth and wipe dry or let it
dr y.
• Only clean the appliance if it is switched off and disconnected from the
mains.
• We recommend performing both initial and subsequent regular
machine inspections. It is very important that the glass door is
well closed and not damaged. No curtains may be damaged. Do
not attempt to interfere with the construction or adjustment of the
component parts in any way.
• Never use the appliance if it is incomplete, damaged, or any part of
it has been damaged during use. Have the appliance repaired by a
specialist workshop.
There is a risk of serious injury!
8EN
Location / Installation
• Only place the appliance on straight, strong and stable pads - kitchen
work desks and furniture parts, suitable for the location of kitchen
utensils.
Always make sure that the place you want to place the device has
enough space, mechanical strength and appropriate lighting.
If you do not use the appliance, do not place any objects or liquid
containers on the cooker.
Warning!
• Do not expose the device to:
- direct sunlight, sources and equipment producing heat,
- vibration and mechanical stress,
- excessive dust,
- water and excess moisture,
- insect,
- aggressive effects of the external environment.
• Do not place the appliance:
- unstable tables or inappropriate parts of furniture,
- on an uneven and dirty surface,
- on the sealing edge of tables or parts of furniture,
- in the vicinity of containers with water or other liquids.
• Do not cover the appliance in part. Do not add anything to the device
Do not insert or allow the foreign bodies to enter the holes of the
device covers.
• Do not cover the openings of the airfl ow covers. Air ventilation ensures
reliable and safe operation of the device.
• From a fi re protection and safety point of view, the device can also be
placed on a work table or similar surface if a safe distance from the
fl ammable surfaces is maintained. materials:
- at least 500 mm in the direction of the main heat sink, and
- at least 100 mm in other directions.
There is a risk of electric shock! There is a danger of fi re!
9EN
Warning!
• Place the device in a place where children can not reach freely. Work
desks and furniture for placing should not be less than 85 cm.
• Prevent children from handling the device. The device may overwrite
and cause serious injury. Mechanical damage (breakage or breakage
of parts and covers) of the device can cause serious injury.
There is a risk of serious injury!
There is a risk of damage to equipment or other property damage!
• Do not place the appliance and do not use the proximity of containers
containing water. If the appliance falls into the water, do not remove
it! First, pull the power cord plug out of the mains socket and then
select the appliance from the water. In such cases, take the device
for inspection to a specialist service to check if it is safe and works
properly.
There is a risk of electric shock!
There is a risk of electrical short circuit!
Operation / Supervision
• Always keep your device under control during use and
operation!
• This device is not intended to be operated via a
programmer, external time switch or remote control
because there is a risk of fi re if the device is covered or
incorrectly positioned.
• Do not leave the appliance unattended during operation,
especially if there are children, inappropriate persons or
animals nearby.
• Do not use the appliance near easily fl ammable materials
and objects, curtains, curtains, decorative fabrics,
Warning!
• Do not use the appliance for space heating, drying textiles,
clothing, footwear or any other items!
There is a danger of fi re!
• Make sure that the controller is set to „OFF“ in the „0“
position before each connection to the power supply.
• Do not switch the device on or off by plugging in or pulling
out the plug of the power cord from the wall socket.
• Always connect the appliance to main power supply for
normal use, then switch on the main switch - the controller.
• When you have fi nished using the appliance, turn off the
main switch - the controller, and then pull the power cord
plug out of the mains socket.
10EN
• Do not use the device if the main power switch does not
work.
• The device is under dangerous voltage when the power
supply is connected.
There is a risk of electric shock!
• The device contains parts and surfaces that are very hot
during operation - device covers, surface areas of the work
area and cooking plate.
Warning!
• Do not touch heated covers, surfaces or parts! Use
handles!
• Use kitchen towels or gloves to open the door of the
appliance and handle the cookware.
• Open the doorglass door slowly and carefully while it is
operating. When the door is suddenly opened, there is a
risk of a hot spill from the working area of the appliance.
There is a risk of burning from the hot surface! There is a
risk of burns from hot air!
WARNING!
• After switching off the appliance, the surfaces and
hotplates remain warm for a certain amount of time. Before
any further handling of the storage and storage device,
always wait for the hot surfaces to cool completely.
• The electrical socket and power cord must remain easily
accessible for safe disconnection of the device from the
power supply.
• It is recommended to connect the device to a separate
electrical circuit with a 16A circuit breaker.
• Never leave the appliance unattended and freely
accessible with a free-hanging power cord. Children,
inappropriate persons or animals could fl ip the device for
the power cord.
Tabla de contenidos
Otros manuales de Horno de Orava
