optris PI NetBox Manual de usuario
Operator‘s Manual
optris®PI NetBox
Mini-PC for optris PI series
Optris GmbH
Ferdinand-Buisson-Str. 14
13127 Berlin
Germany
Tel.: +49 30 500 197-0
Fax: +49 30 500 197-10
E-mail: info@optris.global
Internet: www.optris.global
Table of Contents 3-
Table of Contents
Table of Contents .............................................................................................................................................3
1General Information.................................................................................................................................6
1.1 Description ....................................................................................................................................... 6
1.2 Warranty........................................................................................................................................... 7
1.3 Scope of Supply............................................................................................................................... 7
1.4 Maintenance..................................................................................................................................... 8
1.5 Cautions ........................................................................................................................................... 8
2Technical Data..........................................................................................................................................9
2.1 General Specifications ..................................................................................................................... 9
2.2 Electrical Specifications.................................................................................................................. 10
3Installation ..............................................................................................................................................11
3.1 Mounting......................................................................................................................................... 11
3.2 Controls and Connections.............................................................................................................. 12
-4 -
3.3 Protective Housing ......................................................................................................................... 13
3.4 SD Card.......................................................................................................................................... 15
3.5 Mini-USB Socket............................................................................................................................ 15
3.6 Power Supply ................................................................................................................................. 15
4Operation ................................................................................................................................................16
4.1 Operation Modes............................................................................................................................ 16
4.2 Status LEDs ................................................................................................................................... 16
4.3 Stand-Alone Operation................................................................................................................... 17
4.4 Network Settings ............................................................................................................................ 18
4.5 Remote Access to the NetBox (NetBox Utility).............................................................................. 23
4.6 File transfer between NetBox and PC............................................................................................ 26
4.7 NetBox Control Center................................................................................................................... 27
4.8 Converter mode USB –Ethernet ................................................................................................... 32
4.9 Write Protection Filter..................................................................................................................... 36
Table of Contents 5-
5System Information ...............................................................................................................................38
5.1 Watchdog ....................................................................................................................................... 38
5.2 Startup............................................................................................................................................ 39
5.3 System Time .................................................................................................................................. 40
5.4 System Recovery........................................................................................................................... 41
Appendix A –Declaration of Conformity .....................................................................................................47
-6 -
1 General Information
1.1 Description
Thank you for choosing the optris®PI NetBox.
The optris PI NetBox is a miniaturized PC which expands the optris PI series to a stand-alone solution or
which works as a USB to Ethernet converter. This mode generates larger possible distances between
process (IR camera) and process control (PC).
The NetBox works with a Windows 7 operating system that allows the user to install additional software.
The housing of the NetBox is made of anodized aluminum –the optional NetBox protection housing supports
the usage in industrial environments (IP65/ NEMA-4 rating).
Read the manual carefully before the initial start-up. The producer reserves the right to change
the herein described specifications in case of technical advance of the product.
General Information 7-
1.2 Warranty
Each single product passes through a quality process. Nevertheless, if failures occur please contact the
customer service at once. The warranty period covers 24 months starting on the delivery date. After the
warranty is expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted
product components. Warranty does not apply to damages, which result from misuse or neglect. The
warranty also expires if you open the product. The manufacturer is not liable for consequential damage or in
case of a non-intended use of the product.
If a failure occurs during the warranty period the product will be replaced, calibrated or repaired without
further charges. The freight costs will be paid by the sender. The manufacturer reserves the right to
exchange components of the product instead of repairing it. If the failure results from misuse or neglect the
user has to pay for the repair. In that case you may ask for a cost estimate beforehand.
1.3 Scope of Supply
NetBox incl. Micro SDHC card (32 GB)
Power supply (100-240 VAC / 24 VDC)
HDMI cable (Micro HDMI to HDMI/ 1,5 m)
Ethernet cable, 1 m
System recovery stick (USB/ 8 GB)
Rail mount adapter
Operators manual
-8 -
1.4 Maintenance
The housing of the NetBox can be cleaned with a soft, humid tissue moistened with water or a water based
cleaner.
Never use cleaning compounds which contain solvents. Take care that no moisture infiltrates
into the housing.
1.5 Cautions
Take care that no foreign substances penetrate into the venting slots of the NetBox.
In case of problems or questions which may arise when you use the NetBox, please contact our service
department.
Please use only the threads in the housing or the supplied rail mount adapter for mechanical
installation of the NetBox.
Avoid mechanical violence –this may destroy the system (expiry of warranty).
Technical Data 9-
2 Technical Data
2.1 General Specifications
Operating temperature
0...50 °C
Storage temperature
-20...75 °C
Relative humidity
10...95 %, non condensing
Material (housing)
Anodized aluminum
Dimensions
113 mm x 57 mm x 47 mm (L x W x H)
Weight
385 g
Vibration
IEC 60068-2-6 (sinus shaped)
IEC 60068-2-64 (broadband noise)
Shock
IEC 68-2-27 (25 G and 50 G)
Operating system
Windows 7 Professional
-10 -
2.2 Electrical Specifications
Power supply
8...48 VDC or Power over Ethernet (PoE/ 1000BASE-T)
Power consumption
7,5 W (+ additional 2,5 W for IR camera)
Cooling
active via two integrated fans
Board
COM Express mini embedded board
Processor
Intel®AtomTM E3845, Quad Core, 1,91 GHz
Hard disc
16 GB SSD
RAM
2 GB (DDR2, 533 MHz)
Ports
2x USB 2.0/ 1x USB 3.0/ 1x Mini-USB 2.0
Micro-HDMI
Ethernet (Gigabit Ethernet)
Extensions
Micro-SDHC- or SDXC-card
Additional functions
4x Status-LEDs (L1-L4)
