Opticon CS1504 Manual de usuario

Version REV-00

Barcode scanner CS1504 / OPN2001

Installation and handling

PopScan® is a technology of Sensational AG.

Index

Install driver . . . . . . . . . . . . . . . . . . . 2

Connect scanner . . . . . . . . . . . . . . . . . 3

CS1504 serial cable . . . . . . . . . . . . . 3

CS1504 USB connection . . . . . . . . . . . . 3

OPN2001 USB connection . . . . . . . . . . . 3

Read scanner . . . . . . . . . . . . . . . . . . 4

Scanner CS1504 . . . . . . . . . . . . . . . . . 5

Handling . . . . . . . . . . . . . . . . . 5

Functions . . . . . . . . . . . . . . . . . 6

Change batteries . . . . . . . . . . . . . . 7

Disposal of device . . . . . . . . . . . . . . 7

Problem solving . . . . . . . . . . . . . . . 8

Technical Data . . . . . . . . . . . . . . . 8

Scanner OPN2001 . . . . . . . . . . . . . . . . 9

Handling . . . . . . . . . . . . . . . . . 9

Functions . . . . . . . . . . . . . . . . .10

Problem solving . . . . . . . . . . . . . . .11

Meaning of LCD-Display . . . . . . . . . . . .11

Quantity chart . . . . . . . . . . . . . . . . . . 12

Version REV-00

Install driver

To allow communication between the scanner an

your PC respectively the PopScan web applicati-

on, please run the installation program.

This installation program is availabe on the web

application (see "help").

Download installation program from the web application.1.

Click "allow", if eventual warnings occur.

(To start the installation you have to be logged in as admi-

nistrator on your PC)

The installation program starts..2.

Proceed with "continue".

Click "Install" to start with the installation.3.

Click "complete" to nish the installation.4.

Version REV-00

Connect scanner

Connect your scanner to the PC. You can choose

between USB connection and serial connection.

CS1504 serial connection

Connect serial cable with PC.1.

CS1504 USB connection

Connect USB Adapter with PC1.

Advice: Keep the USB Adapter plugged in to avooid

problems reading the scanner.

Connect serial cable with USB Adapter.2.

OPN2001 USB connection

connect USB cable with PC.1.

Version REV-00

Read scanner

Your scanner is ready. Test now, if the scanner is

working properly and if you can log in to the web

application.

Ensure that the scanner is connected to the PC1.

Load the starting page of your web application in the2.

browser (Internet Explorer, Firefox, ...) an click on the

scanner-icon to rad the scanner.

The reading window loads. For the rst time, this process3.

can take several minutes.

After a successful search, the scanner connection appears4.

automatically, e.g. COM4

Click "read" , to log into the web application via scanner.5.

Please note: problems due to ﬁrewalls

and other restrictions

If you are using a rewall, please consider the following

settings::

Make sure you have java applets and pop-ups allowed

The java applet sends data via HTTP-POST to the web-

site (in most cases the browser communication already

allows this).

If you are working with a professionally hosted network,

please contact your administrator to make these modi-

cations..

Version REV-00

Scanner CS1504

Handling

The compact scanner offers the practical possi-

bility to scan articles via barcode and saves more

than 300 items.

plus buttona)

minus buttonb)

LED displayc)

USB connectiond)

Hint

Point the scanner at the code and ensure the red beam

covers the whole barcode and is in square with the bars.

Warning! Laser Class 1

Don’t aim a laser pointer towards a person’s head. This

is to prevent the beam from getting in their eyes, possib-

ly causing eye damage.

Version REV-00

Functions

Your scanner maintains an article list in its sto-

rage and remembers each product and amount

(amount by default = 1)

Add product

Scan article with plus button.

(another scan increases the amount by one)

Add product with amount

Scan article with plus button,

then scan amount from the quantity chart.

(nd quantity chart in the appendix of this documentation)

Reduce amount by one

Scan article with minus button.

Delete single article

Scan article with minus button for six seconds.

Delete all articles

Push minus button for ten seconds without scanning anything.

Sound on / off

Push plus button for ten seconds without scanning anything.

(We recommend leave Sound on)

10s

Version REV-00

Change batteries

If LED is red during scanning, the batteries are

dead soon. Please change batteries.

Recommended manufacturers and types:

- Energizer EPX 76

- Energizer 357

- Maxwell SR 44W

- Rayovac 357

Undo screw on bottom.1.

Open battery compartment.2.

Remove old batteries.3.

Insert 4 new batteries. Please pay attention to polarity4.

(+/-).

Close5. battery compartment and tighten screw.

Disposal of device

The scanner has to be returned to Motorola.

Please nd information and return adress under:

www.symbol.com/environmental_compliance

Version REV-00

problem solving

technical data

problem possible cause suggested solution

scanner doesn't work batteries is inserted

the wrong way

insert batteries again.

pay attention if plus and minus is correct

(instruction placed in lid)

batteries are dead replace batteries

scanner is broken send in scanner to your supplier

scanner can't scan or

delete barcode

barcode is defective test scanner on other barcode

distance or ankle

doesn't t

place beam vertically on barcode and modify the

distance

scanner is connected

to PC

if the scanner is connected to PC, no codes can be

scanned. Unplug scanner to gather data.

memory is full if more than 150 articles are scanned, data has to be

transferred to the PC or deleted

PC doesn't recognize

scanner

cable unplugged check if cable and adaptor is connected properly to

PopScan-driver not

properly installed

install the driver again

LED ashes red batteries are dead replace batteries

LED ashes red, green

and orange

scanner is broken send in scanner to your supplier

speiﬁcation information

supported barcode formats UPC/EAN, Code 3 von 9, Code 128, D 2 von 5,

Coupon-Code

memory capacity 150 barcodes (30 characters per code)

compatible battery types Energizer EPX 76*

Energizer 357*

Maxell SR 44 W

Rayovac 357

* recommended by Symbol

battery capacity approx. 5000 scans with fresh batteries

working temperature 5°C to 40°C

max. humidity 95%

weight 80 g (with batteries)

storage temperature -20°C to 60°C

Version REV-00

Scanner OPN2001

Handling

This device enables storage and removal of

barcode scans. The collected barcodes can be

transmitted by a USB cable. The integrated batte-

ry recharges automatically when you connect the

scanner to a computer. It has memory space for

5’000 barcodes. Using the OPN2001 is very easy:

users only need to press a trigger key to operate

and a reset key to control mistakes.

plus buttona)

minus buttonb)

LED displayc)

USB connectiond)

Hint

Point the scanner at the code and ensure the red beam

covers the whole barcode and is in square with the bars.

Warning! Laser Class 1

Don’t aim a laser pointer towards a person’s head. This

is to prevent the beam from getting in their eyes, possib-

ly causing eye damage.

Version REV-00

Functions

Your scanner maintains an article list in its sto-

rage and remembers each product and amount

(amount by default = 1)

Add product

Scan article with plus button.

(another scan increases the amount by one)

Add product with amount

Scan article with plus button,

then scan amount from the quantity chart.

(nd quantity chart in the appendix of this documentation)

Reduce amount by one

Scan article with minus button.

Delete single article

Scan article with minus button for six seconds.

Delete all articles

Push minus button for ten seconds without scanning anything.

Sound on / off

Push plus button for ten seconds without scanning anything.

(We recommend leave Sound on)

10s
